RPL-20 Series High Power Density Buck Converter

RECOM’s RPL-20 15 A buck converter (with 20 A peak capability) with integrated inductor is offered in a compact 7 mm x 7 mm x 4.4 mm thermally enhanced LGA package. The input range is from 4.0 V_DC to 16 V_DC, allowing both 5 V and 12 V supply rails to be used. The output voltage can be set with two resistors ranging from 0.6 V up to 5.5 V. The output is fully protected against continuous short-circuit, overload, undervoltage, or overtemperature faults. A PG output and EN input allow easy power sequencing. Its high output current capability, small size, light load pulse skipping, and fast transient regulation make the RPL-20 ideal for FPGAs, imaging systems, distributed power architectures, portable telecom equipment and industrial applications.
