The TS488/9 is an enhancement of TS486/487 that eliminates pop & click noise. It is a dual audio power amplifier capable of driving, in single-ended mode, either a 16Ω or a 32Ω stereo headset.
It delivers up to 31mW per channel (into 16Ω loads) of continuous average power with 0.1% THD+N in the audio bandwidth from a 2.5V power supply. An externally-controlled standby mode reduces the supply current to 10nA (typical). The TS488/9 is unity gain stable and is configured by external gain-setting resistors.
| Manufacturer | STMicroelectronics |
|---|---|
| Category | Audio Amplifiers |
| Eval Board |
Normally In Stock
|
| Amplifier Type |
Class AB
|
| Number of Outputs |
Stereo
|
| Output Power (RMS) @ Load |
120 mW x 2 @ 16 Ω (5V)
|
| Voltage In |
2.2 ~ 5.5 V
|
| THD+N (1kHz) @ Conditions |
< 0.1% @ 120 mW (16 Ω, 5V)
< 0.1% @ 31 mW (16 Ω, 2.5V) < 0.1% @ 55 mW (16 Ω, 3.3V) |
| Features |
Short Circuit Protection
Shutdown, Enable, Standby Turn On/Off Depop |
| Efficiency @ Conditions |
- Not Given
|
| Standby Current [Typical] |
10 nA
|
| Quiescent Current [Typical] |
1.8 mA
|
| Component Count + Extras |
8 + 5
|
| Application / Target Market |
Audio: MP3 Players
Cell Phones Computers Digital Cameras Portable Devices RF: BlueTooth Headsets |
| Design Author |
STMicroelectronics
|
| Main I.C. Base Part |
TS489
|
| Quiescent Current [Maximum] |
2.7 mA
|
| Standby Current [Maximum] |
1 µA
|
