8MS8 Series Multi-Channel I/O Twin Axial Cable Assemblies
The 8MS8 series uses 3M™ twin axial cable technology, making it highly routable, foldable, and flexible
High-speed cable assemblies are essential for the efficient operation of systems that process large volumes of data. 3M's cabling solutions are ideal for connecting devices with the latest industry-standard physical interfaces for high-performance computing, routers, storage, and switches. The 8MS8 series uses 3M twin axial cable technology, making it highly routable, foldable, and flexible. The thin, low-profile, twin-ax ribbon cable allows more routing options within a case and enables many packaging configurations. Foldable ribbon construction allows for extremely tight bend radii with minimal performance impact.
3M's multi-channel I/O twin axial cable assembly is a family of cable assemblies including x4 (38p) and x8 (74p) connectors utilizing 3M low loss twin axial cable 85 ohm, 31 AWG, which is ideal for PCIe® applications.
3M multi-channel I/O twin axial cable assemblies are designed to support high-density PCIe applications and meet SFF-TA-1016 specifications. Signal integrity (SI) performance metrics are not degraded, even with multiple folds.
- 8M series, x8 configuration
- PCIe (85 ohm) applications
- Signal wire size 31 AWG
- Thinner than other similar AWG twin axial cables
- Thin ribbon cable construction allows easy routing in dense servers
- Extremely tight bend radius facilitates custom foldable ribbon construction enabling unique packaging configurations
- Standard lengths of 0.5 m, 0.75 m, and 1.0 m
- Custom lengths and folding available
- See 3M.com/SDS for regulatory information
Multi-Channel I/O Twin Axial Cable Assembly 8MS8 Series
| Image | Manufacturer Part Number | Description | Number of Positions | Connector Type | Gender | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|---|---|---|
 |  | 8MS8-1DG11-0.50 | ASSY/MULTI-CHANNEL IO 0.50M | 74 | Card Edge to Card Edge | Male to Male | 14 - Immediate | $38.83 | View Details |
| | 8MS8-1DG11-0.75 | ASSY/MULTI-CHANNEL IO 0.75M | 74 | Card Edge to Card Edge | Male to Male | 47 - Immediate | $43.55 | View Details |
| | 8MS8-1DG11-1.0 | ASSY/MULTI-CHANNEL IO 1.0M | 74 | Card Edge to Card Edge | Male to Male | 87 - Immediate | $48.12 | View Details |
