I TEXAS INSTRUMENTS 1v 5v

ERROR AMP

& ISOLATION

ERROR AMP

& ISOLATION

CS1

CS2

OUT1

OUT2

AC1

AC2

COMP1

COMP2

VIN

SS1

SS2

VCC2

DCL

OVLP

VCC1

RES

UVLO

LM5034

VCC

3.3V

2.5V

Sync

36V to 75V

Input

GND1 GND2

VPWR

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

LM5034 High Voltage Dual Interleaved Current Mode Controller with Active Clamp

Check for Samples: LM5034

1FEATURES APPLICATIONS

2• Two Independent PWM Current Mode • Telecommunication Power Converters

Controllers • Industrial Power Converters

• Integrated High Voltage Startup Regulator • +42V Automotive Systems

• Compound 2.5A Main Output Gate Drivers DESCRIPTION

• Single Resistor Oscillator Setting to 2 MHz The LM5034 dual current mode PWM controller

• Synchronizable Oscillator contains all the features needed to control either two

• Active Clamp Gate Driver for P-Channel independent forward/active clamp dc/dc converters or

MOSFETs a single high current converter comprised of two

interleaved power stages. The two controller

• Adjustable Gate Drive Overlap Time channels operate 180° out of phase thereby reducing

• Programmable Maximum Duty Cycle input ripple current. The LM5034 includes a startup

• Maximum Duty Cycle Fold-Back at High Line regulator that operates over a wide input range up to

Voltage 100V and compound (bipolar + CMOS) gate drivers

that provide a robust 2.5A peak sink current. The

• Adjustable Timer for Hiccup Mode Current adjustable dead-time of the active clamp gate drivers

Limiting and adjustable maximum PWM duty cycle reduce

• Integrated Slope Compensation stress on the primary side MOSFET switches.

• Adjustable Line Under-Voltage Lockout Additional features include programmable line under-

voltage lockout, cycle-by-cycle current limit, hiccup

• Independently Adjustable Soft-Start (Each mode fault operation with adjustable restart delay,

Regulator) PWM slope compensation, soft-start, and a 2 MHz

• Direct Interface with Opto-Coupler Transistor capable oscillator with synchronization capability.

• Thermal Shutdown PACKAGE

• TSSOP-20

Typical Application Circuit

Figure 1. Dual Interleaved Regulators with Independent Outputs

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2All trademarks are the property of their respective owners.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.

l TEXAS INSTRUMENTS

OVLP

VIN

COMP1

CS1

SS1

UVLO

VCC1

OUT1

AC1

GND1 GND2

AC2

OUT2

VCC2

RES

SS2

CS2

COMP2

DCL

RT/SYNC

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Connection Diagram

Figure 2. 20-Lead TSSOP Package – Top View

See Package Number PW

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

PIN DESCRIPTIONS

PIN NAME DESCRIPTION APPLICATIONS INFORMATION

1 OVLP Active Clamp Overlap Adjust An external resistor (10 kΩto 100 kΩ) sets the overlap time of the active clamp

outputs relative to the main outputs for both Controller 1 and Controller 2. The

overlap time results in deadtime between each main switch and its active clamp

switch.

2 VIN Input Supply Input to the startup regulator. The operating input range is 13V to 100V with

transient capability to 105V.

3 COMP1 PWM Control, Controller 1 The COMP1 input provides voltage feedback to the PWM comparator inverting

input of Controller 1 through a 3:1 divider. The OUT1 duty cycle increases as

the COMP1 voltage increases. An internal 5KΩpull-up resistor to +5.0V

provides bias current to an opto-coupler transistor.

4 CS1 Current Sense Input, Controller 1 Input for current mode control and the current limit sensing. If the CS1 pin

exceeds 0.5V the OUT1 pulse is terminated producing cycle-by-cycle current

limiting. External resistance connected to CS1 will adjust (increase) PWM slope

compensation. This pin's voltage must not exceed 1.25V.

5 SS1 Soft-start, Controller 1 An internal 50 µA current source charges an external capacitor to set the soft-

start rate. During a current limit restart sequence, the internal current source is

reduced to 1 µA to increase the delay before retry. Forcing SS1 below 0.5V

shuts off Controller 1.

6 UVLO VIN Under-Voltage Lockout An external resistor divider sets the input voltage threshold to enable the

LM5034. The UVLO comparator reference voltage is 1.25V. A switched 20 µA

current source provides adjustable UVLO hysteresis. The UVLO pin voltage

also controls the maximum duty cycle as described in the Functional

Description section.

7 VCC1 Start-up regulator output, Controller 1 Output of the 7.7V high voltage start-up regulator for Controller 1. The sum of

the currents drawn from VCC1 and VCC2 should not exceed 19 mA.

8 OUT1 Main Gate Driver, Controller 1 Gate driver output to the primary side switch for Controller 1. OUT1 swings

between VCC1 and GND1 at a frequency equal to half the oscillator frequency.

9 AC1 Active Clamp Driver, Controller 1 Gate driver output to the active clamp P-channel MOSFET for Controller 1. The

AC1 pulse overlaps the leading and trailing edges of the OUT1 pulse by an

interval set by the OVLP pin resistor. The overlap produces deadtime between

the main switch transistor and the P-channel active clamp transistor.

10 GND1 Ground, Controller 1 Ground connection for Controller 1 including gate drivers, PWM controller, soft-

start and support functions.

11 GND2 Ground, Controller 2 Ground connection for Controller 2 including gate drivers, PWM controller and

soft-start.

12 AC2 Active Clamp Driver, Controller 2 Gate driver output to the active clamp P-channel MOSFET for Controller 2. The

AC2 pulse overlaps the leading and trailing edges of the OUT2 pulse by an

interval set by the OVLP pin resistor. The overlap produces deadtime between

the main switch transistor and the P-channel active clamp transistor.

13 OUT2 Main Gate Driver, Controller 2 Gate driver output to the primary side switch for Controller 2. OUT2 swings

between VCC2 and GND2 at a frequency equal to half the oscillator frequency.

14 VCC2 Start-up regulator output, Controller 2 Output of the 7.7V high voltage start-up regulator for Controller 2. The sum of

the currents drawn from VCC1 and VCC2 should not exceed 19 mA.

15 RES Hiccup mode restart adjust An external capacitor sets the time delay before forced restart during a

sustained period of cycle-by-cycle current limiting. The hiccup mode

comparator threshold is 2.55V.

16 SS2 Soft-start, Controller 2 An internal 50 µA current source charges an external capacitor to set the soft-

start rate. During a current limit restart sequence, the internal current source is

reduced to 1µA to increase the delay before retry. Forcing SS2 below 0.5V

shuts off Controller 2.

17 CS2 Current Sense Input, Controller 2 Input for current mode control and the current limit sensing. If the CS2 pin

exceeds 0.5V the OUT2 pulse is terminated producing cycle-by-cycle current

limiting. External resistance connected to CS2 will adjust (increase) PWM slope

compensation. This pin's voltage must not exceed 1.25V.

18 COMP2 PWM Control, Controller 2 The COMP2 input provides voltage feedback to the PWM comparator inverting

input of Controller 2 through a 3:1 divider. The OUT2 duty cycle increases as

the COMP2 voltage increases. An internal 5kΩpull-up resistor to +5.0V

provides bias current to the opto-coupler transistor.

19 DCL Duty Cycle Limit An external resistor sets the maximum allowed duty cycle at OUT1 and OUT2.

20 RT/SYNC Oscillator Adjust and Synchronizing An external resistor sets the oscillator frequency. This pin also accepts ac-

input coupled synchronization pulses from an external source.

Product Folder Links: LM5034

‘5‘ TEXAS INSTRUMENTS ...-.-.......'.-....-z-.... ..-..1.-..-.-....-.-....-.I I I I I I l I I I I l l I I I I I I I I I I ': I I I I I I I I I I

7.7V SERIES

REGULATOR

VCC UVT

VCC1

VCC2

UVLO

1.25V

20 PA

THERMAL

SHUTDOWN

VCC Disable

Drivers Off

Ramp1

Ramp2

MaxDC1

PWM

Comp 1

5.0V

10k

COMP1

SS1

45 PA

SLOPE1

CS1

0.5V

Current

Limit

CLK1

5.0V

10k

COMP2

SS2

45 PA

SLOPE2

CS2

0.5V

Current

Limit

CLK2

OUT1

GND1

AC1

OUT2

GND2

AC2

OVLP

Drivers Off

SS1

1PA

5.0V

49 PA

5.0V

Logic SS2

SS2

1PA

5.0V

49 PA

5.0V

Logic

Driver

Logic

5.0V

VCC

Controller 2

Controller 1

Restart

Drivers Off

UVLO

MaxDC2

MaxDC1

MaxDC2

PWM

Latch

PWM

Latch

PWM

Comp 2

ILim1

ILim2

DC2

DC1

Soft-start

42k

Support Functions

VCC UVT

Soft-start

BIAS VOLTAGE

GENERATOR

RT/

SYNC

DCL

OSCILLATOR

& RAMP

GENERATOR

CLK1, 2

UserMaxDC1, 2

SLOPE1, 2

RAMP1, 2

20 PA

10 PA

2.55V

LOGIC

Restart

Latch

ILim1,2

Clk1,2

5.0V

RES

Driver

Logic

Overlap

Generator

Restart

PWM1

DC1,2 Vref

Driver Enable

Drivers Off

Restart

Driver Enable

Driver Enable Restart

Latch

UserMaxDC1

UserMaxDC2

Restart

Latch

PWM2

VCC2

VCC1

VCC2

-VUVLO

CLK1

OUT1 + 50 ns

OUT2 + 50 ns

CLK2

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Block Diagram

Figure 3. Detailed Block Diagram

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam

during storage or handling to prevent electrostatic damage to the MOS gates.

Absolute Maximum Ratings(1)(2)

VIN to GND -0.3V to 105V

VCC to GND -0.3V to 16V

RT/SYNC, RES and DCL to GND -0.3V to 5.5V

CS Pins to GND -0.3V to 1.25V

All other inputs to GND -0.3V to 7V

ESD Rating(3) Human Body Model 2kV

Storage Temperature Range -55°C to 150°C

Junction Temperature 150°C

Lead Temperature (Soldering 4 sec),(4) 260°C

(1) Absolute Maximum Ratings are limits beyond which damage to the device may occur. Operating Ratings are conditions under which

operation of the device is intended to be functional. For specifications and test conditions, see the Electrical Characteristics.

(2) If Military/Aerospace specified devices are required, please contact the Texas Instruments Sales Office/Distributors for availability and

specifications.

(3) The human body model is a 100 pF capacitor discharged through a 1.5 kΩresistor into each pin.

(4) For detailed information on soldering plastic TSSOP packages, refer to the Packaging Data Book available from Texas Instruments.

Operating Ratings(1)

VIN Voltage 13.0V to 100V

External Voltage Applied to VCC1, VCC2 8V to 15V

Operating Junction Temperature -40°C to +125°C

(1) Absolute Maximum Ratings are limits beyond which damage to the device may occur. Operating Ratings are conditions under which

operation of the device is intended to be functional. For specifications and test conditions, see the Electrical Characteristics.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Electrical Characteristics

Specifications with standard typeface are for TJ= 25°C, and those with boldface type apply over full Operating Junction

Temperature range. VIN = 48V, VCC1 = VCC2 = 10V externally applied, RT= RDCL = 42.2kΩ, ROVLP =70kΩ, UVLO = 1.5V,

unless otherwise stated. See(1) and (2).

Symbol Parameter Conditions Min Typ Max Units

Startup Regulator (VIN, VCC1, VCC2 Pins)

VCCReg VCC voltage VCC1 connected to VCC2, ext. supply 7.4 7.7 8V

disconnected.

ICC(Lim) VCC current limit Sum of currents out of VCC1 and VCC2 19 22 mA

with VCC1 = VCC2 = 0V.

VCC UVT VCC Under-voltage threshold VCC1 connected to VCC2, ext. supply VCC - 300 VCC - V

(VCC increasing) disconnected, VIN =11V. mV 100 mV

VCC decreasing 5.5 6.2 6.9 V

IIN Startup regulator current VIN = 90V, UVLO = 0V 500 600 µA

ICCIn Supply current into VCC from Output loads = open, VCC = 10V 4.3 7mA

external source

UVLO

UVLO Under-voltage threshold 1.22 1.25 1.28 V

IHYST Hysteresis current 16 20 24 µA

Current Sense Input (CS1, CS2 Pins)

CS Current Limit Threshold 0.45 0.5 0.55 V

CS delay to output CS1 (CS2) taken from zero to 1.0V. Time 40 ns

for OUT1 (OUT2) to fall to 90% of VCC1

(VCC2). Output load = 0 pF.

Leading edge blanking time at 50 ns

CS1 (CS2)

CS1 (CS2) sink impedance Internal pull-down FET on. 30 55 Ω

(clocked)

RCS Equivalent input resistance at CS taken from 0.2V to 0.5V, internal FET 42 kΩ

CS off.

Current Limit Restart (RES Pin)

ResTh Threshold 2.4 2.55 2.7 V

Charge source current 15 20 25 µA

Discharge sink current 7.5 10 12.5 µA

Soft-start (SS1, SS2 Pins)

ISS Current source (normal 35 50 65 µA

operation)

Current source during a current 0.7 11.3 µA

limit restart

VSS Open circuit voltage 5 V

Oscillator (RT/SYNC Pin)

FS1 Frequency 1 (at OUT1, OUT2) RT= 42.2 kΩ183 200 217 kHz

FS2 Frequency 2 (at OUT1, OUT2) RT= 13.7 kΩ530 600 670 kHz

DC voltage 2 V

Input Sync threshold 2.6 3.3 3.7 V

PWM Controller (COMP1, COMP2, Duty Cycle Limit Pins)

Delay to output COMP1 (COMP2) set to 2V. CS1 (CS2) 50 ns

stepped from 0 to 0.4V. Time for OUT1

(OUT2) to fall to 90% of VCC1 (VCC2).

Output load = 0 pF.

VCOMP COMP1 (COMP2) open circuit 5 V

voltage

(1) All electrical characteristics having room temperature limits are tested during production with TA= 25°C. All hot and cold limits are

specified by correlating the electrical characteristics to process and temperature variations and applying statistical process control.

(2) Typical specifications represent the most likely parametric norm at 25°C operation

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

Electrical Characteristics (continued)

Specifications with standard typeface are for TJ= 25°C, and those with boldface type apply over full Operating Junction

Temperature range. VIN = 48V, VCC1 = VCC2 = 10V externally applied, RT= RDCL = 42.2kΩ, ROVLP =70kΩ, UVLO = 1.5V,

unless otherwise stated. See(1) and (2).

Symbol Parameter Conditions Min Typ Max Units

ICOMP COMP1 (COMP2) short circuit COMP1 (COMP2) = 0V 0.6 11.4 mA

current

COMP1 (COMP2) to PWM1 0.33 V/V

(PWM2) gain

Minimum duty cycle SS1 (SS2) = 0V 0%

Maximum duty cycle 1 UVLO pin = 1.30V, RDCL = RT, COMP1 76 %

(COMP2) = open

Maximum duty cycle 2 UVLO pin = 3.75V, RDCL = RT, COMP1 20 %

(COMP2) = open

Maximum duty cycle 3 UVLO pin = 1.30V, RDCL = RT/4, COMP1 20 %

(COMP2) = open

Maximum duty cycle 4 UVLO pin = 2.50V, RDCL = RT, COMP1 50 %

(COMP2) = open

Maximum duty cycle 5 UVLO pin = 1.30V, RDCL = RT/2, COMP1 40 %

(COMP2) = open

Slope compensation Delta increase at PWM comparator to CS1 90 mV

(CS2)

Channel mismatch CS1 (CS2) = 0.25V 7%

Soft-start to COMP offset SS1 (SS2) = 0.8V 0 V

Main Output Drivers (OUT1, OUT2)

Output high voltage IOUT = 50mA (source) VCC-1 VCC-0.2 V

Output low voltage IOUT = 100 mA (sink) 0.3 1V

Rise time CLOAD = 1 nF 12 ns

Fall time CLOAD = 1 nF 10 ns

Peak source current 1.5 A

Peak sink current 2.5 A

Active Clamp Output Drivers (AC1, AC2)

Output high voltage IOUT = 10mA (source) VCC-0.5 VCC-0.2 V

Output low voltage IOUT = 20 mA (sink) 0.1 0.5 V

Rise time CLOAD = 1.0 nF 44 ns

Fall time CLOAD = 1.0 nF 22 ns

Peak source current 0.1 A

Peak sink current 0.25 A

Overlap time ROVLP = 70 kΩ75 100 125 ns

Thermal Shutdown

TSD Shutdown temperature 165 °C

Hysteresis 20 °C

Thermal Resistance

θJA Junction to ambient, 0 LFPM Air TSSOP-20 package 120 °C/W

Flow

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

INTERNAL

CLOCK

CLK1

CLK2

1/OSC. FREQ.

RAMP1

RAMP2

40% 60%

VDCL

UserMaxDC1

UserMaxDC2

MaxDC1

MaxDC2

PWM

Comp1

PWM

Comp2

PWM1

PWM2

OUT1

OUT2

CLK2

CLK1

VDCL

-VUVLO

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

TEST CIRCUIT DIAGRAMS

Timing Diagram

Figure 4. Internal Timing Diagram

Product Folder Links: LM5034

N gm 1 L

UVLO

UVT

OUT1

SS1

1.5V

COMP1

OUT2

SS2

1.5V

COMP2

1.5V

VCC

VIN

tVCC

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

Figure 5. Startup Sequence

Product Folder Links: LM5034

l TEXAS INSTRUMENTS w; «Emmy z 200 kHz

0 5 10 15 20 25

VCC (V)

ICC (mA)

ICC = sum of currents

out of VCC1 and VCC2

110 100 1000

RT (k:)

0.01

0.1

1.0

OSCILLATOR FREQUENCY (MHz)

89 10 11 12 13 14

APPLIED VCC VOLTAGE (V)

100

ICC (mA)

VCC1 and VCC2 connected together

Output Drivers = Open

OUT1, 2 load = 2200 pF, AC1, 2 load = 150 pF

50 kHz

500 kHz

1 MHz

200 kHz

Output Drivers @ 1 MHz

02 4 6 8 10 12 14

VOLTAGE AT VIN (V)

VCC (V)

UVLO > 1.25V

VCC Pins Unloaded

0 20 40 60 80 100

100

200

300

400

500

600

INPUT CURRENT IIN (PA)

VOLTAGE AT VIN (V)

UVLO = 0V

VCC Pins = Open

VCC Pins = 10V

0 20 40 60 80 100

INPUT CURRENT IIN (mA)

VOLTAGE AT VIN (V)

VCC pins = open,

OUT1 & OUT2 load = 2200 pF

AC1 & AC2 load = 150 pF

VCC pins = open, Driver Outputs

Open

UVLO > 1.25V

Outputs frequency = 200 kHz

VCC pins = 10V, Driver Outputs

open or loaded

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Typical Performance Characteristics

IIN vs VIN IIN vs VIN

Figure 6. Figure 7.

ICC vs Externally Applied VCC VCC vs VIN

Figure 8. Figure 9.

VCC vs ICC (Externally Loaded) Oscillator Frequency vs RTResistor

Figure 10. Figure 11.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS an ow: 11

190

192

194

196

198

200

202

204

206

208

210

FREQUENCY @ OUT1, OUT2 (kHz)

-50 0 50 100 150

RT = 42.2k

TEMPERATURE (oC)

-50 0 50 100 150

TEMPERATURE (oC)

OVERLAP TIME (ns)

100

105

110

115

ROVLP = 70k

0 20 40 60 80

100

MAXIMUM DUTY CYCLE (%)

VOLTAGE AT VIN (V)

R1 = 150 k:

R2 = 10 k:

Figure 27

0 20 40 60 80 100

120

150

OVERLAP TIME (ns)

ROVLP (k:)

0 0.2 0.4 0.6 0.8 1.0

100

MAXIMUM DUTY CYCLE (%)

RDCL/RT

UVLO Pin = 1.26V

0 1.0 2.0 3.0 4.0 5.0

100

MAXIMUM DUTY CYCLE (%)

VOLTAGE AT UVLO PIN (V)

1.25V

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

Typical Performance Characteristics (continued)

User Defined Maximum Duty Cycle vs. RDCL Resistor Maximum Duty Cycle vs. UVLO Voltage

Figure 12. Figure 13.

Maximum Duty Cycle vs. VIN (Figure 31) Active Clamp Overlap Time vs. ROVLP

Figure 14. Figure 15.

Frequency vs. Temperature Overlap Time vs. Temperature

Figure 16. Figure 17.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

0.9

1.0

1.10

SOFT-START CURRENT (PA)

TEMPERATURE (oC)

-50 0 50 100 150

490

492

494

496

498

500

502

504

506

508

510

CURRENT LIMIT THRESHOLD

@ CS1, CS2 (mV)

-50 0 50 100 150

TEMPERATURE (oC)

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Typical Performance Characteristics (continued)

Soft-start Pin Current vs. Temperature Current Limit Threshold at CS1, CS2 vs. Temperature

Figure 18. Figure 19.

FUNCTIONAL DESCRIPTION

The LM5034 contains all the features necessary to implement two independently regulated current mode dc/dc

converters, or a single high current converter comprised of two parallel interleaved channels using the Forward/

Active Clamp topology. The two controllers operate 180° out of phase from a common oscillator, thereby

reducing input ripple current. Each regulator channel contains a complete PWM controller, current sense input,

soft-start circuit, main gate driver output, and active clamp driver output. Common to both channels are the

startup and VCC regulators, line under-voltage lockout, 2 MHz capable oscillator, maximum duty cycle control,

overlap time setting, and the hiccup mode fault protection circuit.

The main gate driver outputs (OUT1, OUT2) are designed to drive N-channel MOSFETs. Their compound

configuration reduces the turn-off-time, thereby reducing switching losses. The active clamp outputs (AC1, AC2)

are designed to drive P-channel MOSFETs. The adjustable overlap time of the active clamp outputs relative to

the main outputs produces a deadtime between the main switch and the P-channel active clamp switch.

Additional features include thermal shutdown, slope compensation, and the oscillator synchronization capability.

Line Under-Voltage Lock Out, UVLO, Shutdown

The LM5034 contains a line under-voltage lockout circuit (UVLO) designed to enable the VCC regulator and

output drivers when the system voltage (VPWR) exceeds the desired level (see Figure 20). VPWR is the voltage

normally applied to the transformer primary, and usually connected to the VIN pin (see the schematic on Page

1). The threshold at the UVLO comparator is 1.25V. An external resistor divider connected from VPWR to ground

provides 1.25V at the UVLO pin when VPWR is increased to the desired turn-on threshold. When VPWR is below

the threshold the VCC regulator and output drivers are disabled, and the internal 20 µA current source is off.

When VPWR reaches the threshold, the comparator output switches low to enable the internal circuits and the 20

µA current source. The 20 µA flows into the external divider’s junction, raising the voltage at UVLO, thereby

providing hysteresis. Internally the voltage at UVLO also drives the Maximum Duty Cycle Limiter circuit

(described below), which may influence the values chosen for the UVLO pin resistors. At maximum VPWR, the

voltage at UVLO should not exceed 6V. Refer to Applications Information for a procedure to calculate the

resistors values.

The LM5034 controllers can be shutdown by forcing the UVLO pin below 1.25V with an external switch. When

the UVLO pin is low, the outputs and the VCC regulator are disabled, and the LM5034 enters a low power mode.

If the VCC pins are not powered from an external source, the current into VIN drops to a nominal 500 µA. If the

VCC pins are powered from an external source, the current into VIN is nominally 50 µA, and the current into the

VCC pins is approximately 4.3 mA. To disable one regulator without affecting the other, see the description of the

Soft-start section.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

Drivers Off

UVLO

Disable

UVLO

7.6V/6.2V THERMAL

SHUTDOWN

Max . Duty

Cycle Limiter

20PA

LM5034

VPWR

VCC

1.25V

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

Figure 20. Drivers Off and VCC Disable

Startup Regulator, VIN, VCC1, VCC2

The high voltage startup regulator is integral to the LM5034. The input pin VIN can be connected directly to a

voltage between 13V and 100V, with transient capability to 105V. The startup regulator provides bias voltages to

the series pass VCC regulator and the UVLO circuit. The VCC regulator is disabled until the voltage at the UVLO

pin (described above) exceeds 1.25V. For applications where VPWR exceeds 100V the internal startup regulator

can be powered from an external startup regulator or other available low voltage source. See Applications

Information for details.

The VCC under-voltage threshold circuit (UVT) monitors the VCC regulator output. When the series pass

regulator is enabled and the internal VCC voltage increases to > 7.6V, the UVT comparator activates the PWM

controller and output drivers via the Drivers Off signal. The UVT comparator has built-in hysteresis, with the lower

threshold nominally set to 6.2V. See Figure 5 and Figure 20.

When enabled, the VCC regulated output is 7.7V ±4% with current limited to a minimum of 19 mA (typically 22

mA). The regulator’s output is split by a resistor divider to provide separate VCC1 and VCC2 rails for the two

controller channels. VCC1 powers Controller 1, drivers OUT1 and AC1, Soft-start1, and all the support functions.

VCC2 powers Controller 2, drivers OUT2 and AC2, and Soft-start2. If VCC1 and/or VCC2 are used to power

external circuitry, the current limit specification applies to the sum of the load currents at the two pins.

Splitting the VCC regulator output through two 5Ωresistors allows separate external VCC bypass capacitors to

reduce cross-talk between channels. Each VCC output pin requires a capacitor to its corresponding ground for

stability, as well as to provide the surge currents to the external MOSFETs via the gate driver outputs. The

capacitors should be the same value, and be physically close to their respective pins.

In most applications it is necessary to power VCC from an external source as the average current required at the

output drivers may exceed the current capability of the internal regulator and/or the thermal capability of the

LM5034 package (see Figure 8). Normally the external source is derived from the converter’s power stage once

the LM5034 outputs are active. See Applications Information for more information.

Drivers Off, VCC Disable

Referring to Figure 20, Drivers Off and VCC Disable are internal signals which, when active disable portions of the

LM5034. If the UVLO pin is below 1.25V, or if the thermal shutdown activates, the VCC Disable line switches high

to disable the VCC regulator. UVLO also activates the Drivers Off signal to disable the output drivers, connect the

SS1, SS2, COMP1, COMP2 and RES pins to ground, and enable the 50 µA Soft-start current sources.

If the VCC voltage falls below the under-voltage threshold of 6.2V , the UVT comparator activates only the Drivers

Off signal. The output drivers are disabled but the VCC regulator is not disabled. Additionally, the CS1, CS2, SS1,

SS2, COMP1, COMP2 and RES pins are internally grounded, and the 50 µA Soft-start current sources are

enabled.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS IIH II

Load

Power

Transformer

LM5034

5.0V

PWM

Comparator

COMP1

Slope Comp.

42k

Error

Amplifier

Current

Sense

10k

CS1 RCS

LEB

VPWR

45 PA

VREF

VOUT

RT = 17100

- 0.001(FS - 400)

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Oscillator

The oscillator frequency is set with an external resistor RTconnected between the RT/SYNC and GND1 pins.

The resistor value is calculated from:

(1)

where FSis the desired oscillator frequency in kHz (maximum of 2 MHz), and RTis in kΩ. See Figure 11. The

two gate driver outputs (OUT1 and OUT2) switch at half the oscillator frequency and 180° out of phase with each

other. The voltage at the RT/SYNC pin is internally regulated at 2.0V. The RTresistor should be located as close

as possible to the LM5034 with short direct connections to the pins.

The LM5034 can be synchronized to an external clock by applying a narrow clock pulse to the RT/SYNC pin. See

Applications Information for details on this procedure. The RTresistor is always required, whether the oscillator is

free running or externally synchronized.

PWM Comparator/Slope Compensation

The PWM comparator of each controller compares a slope compensated current ramp signal with the loop error

voltage derived from the COMP pin. The COMP voltage is typically controlled by an external error

amplifier/optocoupler feedback circuit to regulate the converter output voltage. Internally, the voltage at the

COMP pin passes through two level shifting diodes and a gain reducing 3:1 resistor divider (see Figure 21). The

compensated current ramp signal is a combination of the current waveform at the CS pin, and an internally

generated ramp derived from the internal clock. At duty cycles greater than 50% current mode control circuits are

prone to subharmonic oscillation. By adding a small fixed ramp to the external current sense signal oscillations

can be avoided. The internal ramp has an amplitude of 45 µA and is sourced into an internal 2kΩresistor, and a

42 kΩresistor in parallel with the external impedance at the CS pin. The ramp current also flows through the

external impedance connected to the CS pin and thus, the amount of slope compensation can be adjusted by

varying the external circuit at the CS pin.

The output of the PWM comparator provides the pulse width information to the output drivers. This comparator is

optimized for speed in order to achieve minimum controllable duty cycles. The comparator’s output duty cycle is

0% for VCOMP ≤1.5V, and increases as VCOMP increases.

If either Soft-start pin is pulled low (internally or externally) the corresponding COMP pin is pulled down with it,

forcing the output duty cycle to zero. When the Soft-start pin voltage increases, the COMP pin is allowed to

increase. An internal 5 kΩresistor connected from COMP to an internal 5.0V supply provides a pull-up for the

COMP pin and bias current to the collector of the opto-coupler transistor.

Figure 21. Typical Feedback Network

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

Cycle-by-Cycle Current Limit

Each CS pin is designed to accept a signal representative of its transformer primary current. If the voltage at CS

exceeds 0.5V the current sense comparator terminates the present main output driver (OUT pin) pulse. If the

high current fault persists, the controller operates with constant peak switch current in a cycle-by-cycle current

limit mode, and a Hiccup Mode Current Limit Restart cycle begins (see below).

Each CS pin is internally connect to ground through a 30Ωresistor during the main output off time to discharge

external filter capacitance. The discharge device remains on for an additional 50 ns after the main output driver

switches high to blank leading edge transients in the current sensing circuit. Discharging the CS pin filter each

cycle and blanking leading edge spikes reduces the filter requirement which improves the current sense

response time.

The current sense comparators are fast and respond to short duration noise pulses. The external circuitry at

each CS pin should include an R-C filter to suppress noise. Layout considerations are critical for the current

sense filter and the sense resistor. See Applications Information for PC board layout guidelines.

Hiccup Mode Current Limit Restart

If cycle-by-cycle current limiting continues in either or both controllers for a sufficient period of time, the Current

Limit Restart circuit disables both regulators and initiates a soft-start sequence after a programmable delay. The

duration of cycle-by-cycle current limiting before turn-off occurs is programmed by the value of the external

capacitor at the RES pin. The dwell time before output switching resumes is programmed by the value of the

Soft-start capacitor(s). The circuit is detailed in Figure 22 and the timing is shown in Figure 23. A description of

this circuit’s operation is as follows:

a) No current limit detected:

The 10 µA discharge current source at RES is enabled pulling the RES pin to ground.

b) Current limit repeatedly detected at both CS inputs:

The 20 µA current source at RES is enabled continuously to charge the RES pin capacitor as shown in

Figure 23. The current limit comparators also terminate the PWM output pulses to provide a cycle-by-cycle

current limiting. When the voltage on the RES capacitor reaches the 2.55V restart comparator threshold, the

comparator sets the Restart Latch which produces the following restart sequence:

• The SS1 and SS2 pin charging currents are reduced from 50µA to 1 µA,

• An internal MOSFET is turned on to discharge the RES pin capacitor.

• The internal MOSFETs at SS1 and SS2 are turned on to discharge the Soft-start capacitors.

• COMP1 and COMP2 follow SS1 and SS2 respectively and reduce the PWM duty cycles to zero

• When the voltages at the SS pins fall below 200mV, the internal MOSFETs at the SS pins are turned off

allowing the SS pins to be charged by the 1µA current sources.

• When either SS pin reaches ≊1.5V its PWM controller produces the first pulse of a soft-start sequence which

resets the Restart Latch. The SS charging currents are increased to 50 µA and the soft-start sequence

continues at the normal rate.

If the overload condition still exists, the voltage at RES begins to increase again and repeat the restart cycle as

shown in Figure 23. If the overload condition has been cleared, the RES pin is held at ground by the 10 µA

current source.

c) Current limit repeatedly detected at one of the two CS inputs:

In this condition the RES pin capacitor is charged by the 20 µA current source once each clock cycle of the

current limited regulator (CLK1 or CLK2), and discharged by the 10 µA current source once each clock cycle of

the unaffected regulator. The voltage at the RES pin increases one fourth as fast as in case b) described above.

The current limited regulator operates in a cycle-by-cycle current limit mode until the voltage at RES reaches the

2.55V threshold. When the Restart Comparator output switches high the Restart Latch is set, both SS pin

capacitors are discharged to disable the regulator channels, and a restart sequence begins as described in case

b) above.

To determine the value of the RES pin capacitor, see Applications Information.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

RES

SS1

and

SS2

OUT1

2.55V

5.0V

t1 t2 t3

Current Limit Detected at

CS1 and/or CS2

OUT2

50PA

1PA

#1.5V

DC1

0.5V

Clk1, Clk2

0.5V

5.0V

2.55V

Restart

Comparator

Drivers Off Restart

Latch

DC2

SS1

SS2

To Output

Drivers

PWM #1

PWM #2

COMP2

COMP1

CS2

CS1

Current

Sense Circuit

RES

Soft-start #1

Soft-start #2

Voltage

Feedback

Voltage

Feedback

LM5034

SS2

SS1

49 PA

Restart

Current

Source

Logic

Drivers Off

SS1

200 mV

Logic

SS2

200 mV

Logic

Current

Limit

Current

Sense Circuit

20PA

CSS1

CSS2

Current

Limit

49PA1PA

1PA

CRES

10 PA

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Figure 22. Current Limit Restart Circuit

Figure 23. Current Limit Restart Timing

Soft-Start

Each soft-start circuit allows the corresponding regulator to gradually reach a steady state operating point,

thereby reducing startup current surges and output overshoot. Upon turn-on, both SS pins are internally held at

ground. When VCC increases past its under-voltage threshold (UVT), the SS pins are released and internal 50

µA current sources charge the external capacitors. The voltage at each COMP pin follows the SS pin, and when

COMP reaches ≊1.5V, the output pulses commence at a low duty cycle. The voltage at the SS pins continues to

increase and saturates at ≊5.0V, The voltage at each COMP pin increases to the value required for regulation

where it is controlled by its voltage feedback loop (see Figure 5).

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

If the internal Drivers Off line is activated (see Drivers Off, VCC Disable), both SS pins are internally grounded.

The SS pins pull the COMP pins to ground while the Driver Off signal disables the output drivers. When the

event which activated the Drivers Off line is cleared and Vcc exceeds its under-voltage threshold, the SS pins

are released. The internal 50 µA current sources then charge the external soft-start capacitors allowing each

regulator’s output duty cycle to increase.

If the Current Limit Restart threshold is reached due to repeated over-current detections, both SS pins (and the

COMP pins) are pulled to ground. The output drivers are disabled, and the 50 µA SS pin current sources are

reduced to 1 µA. After a short propagation delay the SS pins and the COMP pins are released, and the external

capacitors are charged up at a slow rate. When the COMP voltage reaches ≊1.5V, the output drivers are

enabled, and the current sources at the SS pins are increased to 50 µA. The output duty cycle then increases to

the value required for regulation.

To shutdown one regulator without affecting the other, ground the appropriate SS pin. This forces the COMP pin

to ground, reducing the output duty cycle to zero for that regulator. Releasing the SS pin allows normal operation

to resume.

Output Duty Cycle

The output driver’s duty cycle for each controller is normally controlled by comparing the voltage provided to the

COMP input by the external voltage feedback circuit with the current information at the CS pin. However, the

maximum duty cycle during transient or fault conditions may be intentionally limited by two other circuits, both of

which are common to the two controller channels.

User Defined Maximum Duty Cycle. The maximum allowed duty cycle can be set with the RDCL resistor

connected from the DCL pin to GND1, according to the following equation:

Maximum User Duty Cycle = 80% x RDCL/RT(2)

RTis the oscillator frequency programming resistor connected to the RT/SYNC pin. The value of the RDCL resistor

must be calculated after the RTresistor is selected. See Figure 12. Referring to the block diagrams of Figure 3,

and Figure 4, the voltage at the DCL pin (VDCL) is compared to the Ramp1 and Ramp2 signals, creating the

UserMaxDC1 and UserMaxDC2 timing signals. These signal are provided to the two 4-input AND gates to limit

the PWM duty cycle of both channels.

Line Voltage Maximum Duty Cycle. The voltage at the UVLO pin, normally proportional to the voltage at VPWR,

further limits the maximum duty cycle at high input voltages. Referring to Figure 13, when the UVLO pin is below

1.25V, the outputs are disabled. At UVLO = 1.25V the maximum allowed duty cycle is 80% (or less if limited by

the DCL resistor). As the UVLO pin voltage increases with VPWR, the maximum duty cycle decreases, reaching a

minimum of 10% at ≊4.5V. Referring to Figure 3 and Figure 4, the UVLO voltage, after passing through an

inverting gain stage, is compared to the Ramp1 and Ramp2 signals generated by the oscillator. The output of

these comparators are the MaxDC1 and MaxDC2 timing signals. These signals are provided to the two 4-input

AND gates which limit the PWM pulses delivered to the output drivers.

Resulting Output Duty Cycle. The controller duty cycle is determined by the four signals into the 4-input AND

gates in Figure 3 (UserMaxDC, MaxDC, PWM and CLK). The output driver pulsewidth is equal to the least of

these four pulses. Whichever input of the AND gate transitions high-to-low first terminates the output driver’s on-

time. For example, in Figure 4, the OUT1 driver’s on-time is set by PWM Comparator #1. The on-time for OUT2

is limited by the UVLO pin voltage (determined by VPWR) even though the PWM Comparator #2 is seeking a

higher duty cycle.

Driver Outputs

OUT1, the primary switch driver for Controller 1 is designed to drive the gate of an N-channel MOSFET with 1.5A

sourcing current and 2.5A sinking current. The corresponding active clamp driver, AC1, is designed to drive a P-

channel MOSFET and is capable of sourcing 100 mA and sinking 250 mA. The peak output levels at OUT1 and

AC1 are VCC1 and GND1. The ground return path for Controller 1 is GND1. The corresponding driver pins for

Controller 2 are OUT2, AC2, VCC2 and GND2.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS ¢ |

OUT1

OUT2

AC2

AC1

1/Fs

Main Switch On

Active Clamp Switch On

tOVLP tOVLP

tOVLP

PWM OUT

GND

LM503

4VCC

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

OUT1 and OUT2 are compound gate drivers with CMOS and Bipolar output transistors as shown in Figure 24.

The parallel MOS and Bipolar devices provide a faster turn-off of the primary switch thereby reducing switching

losses. The outputs switch at one-half the oscillator frequency with the rising edges at OUT1 and OUT2 180° out

of phase with each other. The on-time of OUT1 and OUT2 is determined by their respective duty cycle control.

The active clamp outputs are in phase with their respective main outputs, with their edge timing altered by the

overlap control circuit as shown in Figure 25. The overlap time provides deadtime between the operation of the

primary switch and the active clamp switch at both the rising and falling edges. The overlap times are the same

at the rising and falling edges, independent of frequency and duty cycle. The overlap time is programmed by the

resistor at the OVLP pin (ROVLP) according to the following equation (see Figure 15 and Figure 17):

tOVLP = (1.25 x ROVLP) + 5 (3)

where ROVLP is in kΩ, and tOVLP is in ns. The range for ROVLP is 10 kΩto 100 kΩ. If the application requires zero

overlap time, the OVLP pin should be left open.

Figure 24. Compound Gate Driver

Figure 25. Output Overlap Timing

Thermal Shutdown

The LM5034 should be operated so the junction temperature does not exceed 125°C. If a junction temperature

transient reaches 165°C (typical), the Thermal Shutdown circuit activates the VCC Disable and Drivers Off lines

(see Figure 20). The VCC regulator and the four output drivers are disabled, the SS1, SS2, and RES pins are

grounded, and the soft-start current is set to 50 µA. This puts the LM5034 in a low power state helping to prevent

catastrophic failures from accidental device overheating. When the junction temperature reduces below 145°C

(typical hysteresis = 20°C), the VCC regulator is enabled and a startup sequence is initiated (Figure 5).

Product Folder Links: LM5034

l TEXAS INSTRUMENTS HF 49% .n- -n—)I« 4+

VCC1

VCC2

8V - 15V

LM5034

VIN

8V-15V

Start-up

Voltage

VPWR

VIN VCC1

VCC2

8V - 15V (from

power stage)

LM5034

9V 0.1

0.1 PF

LM503

VIN

VPWR

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

APPLICATIONS INFORMATION

VIN

The voltage applied to the VIN pin, normally the same as the system voltage applied to the power transformer’s

primary (VPWR), can vary in the range of 13 to 100V with transient capability to 105V. The current into VIN

depends primarily on the output driver capacitive loads, the switching frequency, and any external loads on the

VCC pins. If the power dissipation associated with the VIN current exceeds the package capability, an external

voltage should be applied to the VCC pins (see Figure 6 &Figure 7) to reduce power in the internal start-up

regulator. It is recommended the circuit of Figure 26 be used to suppress transients which may occur at the input

supply, in particular where VIN is operated close to the maximum operating rating of the LM5034.

When all internal bias currents for the LM5034 and output driver currents are supplied through VIN and the

internal VCC regulator, the required input current (IIN) is shown in Figure 6 &Figure 7. In most applications, upon

turn-on, IIN increases with VIN as shown in Figure 6 until the UVLO threshold is reached. After the outputs are

enabled and the external VCC supply voltage is active, the current into VIN then drops to a nominal 120 µA.

Figure 26. Input Transient Production

FOR APPLICATIONS >100V

For applications where the system input voltage (VPWR) exceeds 100V, VIN can be powered from an external

start-up regulator as shown in Figure 27, or from any other low voltage source as shown in Figure 28.

Connecting VIN and the VCC together allows the LM5034 to be operated with VIN below 13V. The voltage at the

VCC pins must not exceed 15V. The voltage source at the right side of Figure 27 is typically derived from the

power stage, and becomes active once the LM5034’s outputs are active.

Figure 27. Start-up Regulator for VPWR >100V

Figure 28. Bypassing the Internal Start-up Regulator

Product Folder Links: LM5034

l TEXAS INSTRUMENTS uwo uvm

tVCC = (C1 + C2) x 7.6V

ICC(Lim)

UVLO

LM5034

1.25V

20 PA

Max. Duty

Cycle Limiter

VPWR

Shutdown

Control

UVLO

LM5034

1.25V

20 PA

Max. Duty

Cycle Limiter

VPWR

Enable VCC Regulator

and Output Drivers

R2 = 1.25 x R1

VPWR - 1.25

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

UVLO

The under-voltage lockout threshold (UVLO) is internally set at 1.25V at the UVLO pin. With two external

resistors as shown in Figure 29, the LM5034 is enabled when VPWR exceeds the programmed threshold voltage.

When VPWR is above the threshold, the internal 20 µA current source is enabled to raise the voltage at the UVLO

pin, providing hysteresis. R1 and R2 are determined from the following equations:

R1 = VHYS/20 µA (4)

(5)

where VHYS is the desired UVLO hysteresis at VPWR, and VPWR in the second equation is the turn-on voltage. For

example, if the LM5034 is to be enabled when VPWR reaches 20V, and disabled when VPWR is decreased to 17V,

R1 calculates to 150 kΩ, and R2 calculates to 10 kΩ. The voltage at UVLO should not exceed 6V at any time.

Figure 29. UVLO Circuit

The LM5034 can be remotely shutdown by taking the UVLO pin below 1.25V with an external open collector or

open drain device, as shown in Figure 30. The outputs, and the VCC regulator, are disabled, and the LM5034

enters a low power mode. To shut down one regulator without affecting the other, see Soft-Start.

Figure 30. Shutdown Control

VCC1, VCC2

The capacitors at each VCC pin provide not only regulator noise filtering and stability, but also prevents VCC

from dropping to the lower under-voltage threshold level (UVT = 6.2V) when the output drivers source current

surges to the external MOSFET gates. Additionally, the capacitors provide a necessary time delay during startup.

The time delay allows the internal circuitry of the LM5034 and associated external circuitry to stabilize before VCC

reaches the upper UVT threshold level (7.6V), at which time the outputs are enabled and the soft-start sequence

begins. VCC is nominally regulated at 7.7V. The delay to the UVT level (Figure 5) is calculated from the following:

(6)

where C1 and C2 are the capacitors at VCC1 and VCC2, and ICC(Lim) is the VCC regulator’s current limit. If the

capacitors are 0.1 µF each, the nominal ICC(Lim) of 22 mA provides a delay of approximately 69 µs. The VCC

capacitor values should range between 0.1 µF and 25 µF, and they should be the same value. Experimentation

with the final design may be necessary to determine the optimum value for the VCC capacitors.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS .u— HP 4*

VCC1

VCC2

8V - 15V (from

external source)

LM5034

GND1

GND2 C2

VIN

VPWR

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

The average VCC regulator current required to drive the external MOSFETs is a function of the MOSFET gate

capacitance and the switching frequency (see Figure 8). To ensure VCC does not droop below the lower UVT

threshold, an external supply should be diode connected to both VCC pins to provide the required current, as

shown in Figure 31. The applied VCC voltage must be between 8V and 15V. Providing the VCC voltage higher

than the 7.7V regulation level with an external supply shuts off the internal regulator, reducing power dissipation

within the IC. Internally there is a diode from the VCC regulator output to VIN. Typically the applied voltage is

derived from an auxiliary winding on the power transformer, or on the output inductor.

Figure 31. External Power to VCC

OSCILLATOR, SYNC INPUT

The oscillator frequency is generally selected in conjunction with the system magnetic components, and any

other aspects of the system which may be affected by the frequency. The RTresistor at the RT/SYNC pin sets

the frequency according to Equation 1. Each output (OUT1 and OUT2) switches at one-half the oscillator

frequency. If the required frequency tolerance is critical in a particular application, the tolerance of the external

resistor and the frequency tolerance specified in the Electrical Characteristics table must be considered when

selecting the RTresistor.

If the LM5034 is to be synchronized to an external clock, that signal must be coupled into the RT/SYNC pin

through a 100 pF capacitor. The external synchronizing frequency must be at least 4% higher than the free

running frequency set by the RTresistor and no higher than twice the free running frequency. The RT/SYNC pin

voltage is nominally regulated at 2.0V and the external pulse amplitude should lift the pin to between 3.8V and

5.0V on the low-to-high transition. The synchronization pulse width should be between 15 and 150 ns. The RT

resistor is always required, whether the oscillator is free running or externally synchronized.

VOLTAGE FEEDBACK, COMP1, COMP2

Each COMP pin is designed to accept a voltage feedback signal from the respective regulated output via an

error amplifier and (typically) an opto-coupler. A typical configuration is shown in Figure 21. VOUT is compared to

a reference by the error amplifier which has an appropriate frequency compensation network. The amplifier’s

output drives the opto-coupler, which in turn drives the COMP pin.

When the LM5034’s two controller channels are configured to provide a single high current output, COMP1 and

COMP2 are typically connected together, and to the feedback signal from the optocoupler.

CURRENT SENSE, CS1, CS2

Each CS pin receives an input signal representative of its transformer’s primary current, either from a current

sense transformer or from a resistor in series with the source of the primary switch, as shown in Figure 32 and

Figure 33. In both cases the sensed current creates a ramping voltage across R1, and the RF/CFfilter

suppresses noise and transients. R1, RFand CFshould be as physically close to the LM5034 as possible, and

the ground connection from the current sense transformer, or R1, should be a dedicated track to the appropriate

GND pin. The current sense components must provide >0.5V at the CS pin when an over-current condition

exists.

Product Folder Links: LM5034

t3 = CSS x 3.5V

50 PA= 7 x 104 x CSS

t2 = CSS x 1.5V

1 PA= 1.5 x 106 x CSS

t1 =CRES x 2.55V

20 PA= 1.275 x 105 x CRES

LM5034

CS1

OUT1

GND1

VIN

AC1

Q1 Q2

Power

Transformer

CAC

VPWR

LM5034

CS1

OUT1

GND1

VIN

AC1

Power

Transformer

Current

Sense

Q1 Q2

VPWR

CAC

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Figure 32. Current Sense Using a Current Sense Transformer

Figure 33. Current Sense Using a Source Sense Resistor (R1)

HICCUP MODE CURRENT LIMIT RESTART

This circuit’s operation is described in the Functional Description. Also see Figure 22 and Figure 23. In the case

of continuous current limit detection at both CS pins, the time required to reach the 2.55V RES pin threshold is:

(7)

For example, if CRES = 0.1 µF the time t1 in Figure 23 is approximately 12.75 ms.

In the case of continuous current limit detection at one CS pin only, the time to reach the 2.55V threshold is

increased by a factor of four, or:

t1 = 5.1 x 105x CRES (8)

The time t2 in Figure 23 is set by the capacitor at each SS pin and the internal 1 µA current source, and is equal

to:

(9)

If CSS = 0.1 µF t2 is ≊150 ms. Time t3 is set by the internal 50 µA current source, and is equal to:

(10)

The time t2 provides a periodic dwell time for the converter in the event of a sustained overload or short circuit.

This results in lower average input current and lower power dissipated within the circuit components. It is

recommended that the ratio of t2/(t1 + t3) be in the range of 5 to 10 to make good use of this feature.

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

CSS1

PWM

Controller #1

Softstart

COMP1

SS1

Shutdown

Control

PWM

Controller #2 COMP2

To Output

Drivers

Softstart

#2 CSS2

SS2

LM5034

Coupler

Opto-

Coupler

Opto-

t2 = CSS x 1.5V

1 PA= 1.5 x 106 x CSS

t1 = CSS x 1.5V

50 PA= 3 x 104 x CSS

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

If the application requires no delay from the first detection of a current limit condition, so that t1 is effectively

zero, the RES pin can be left open (no external capacitor). If it is desired to disable the hiccup mode current limit

operation then the RES pin should be connected to ground.

SOFT-START

The capacitors at SS1 and SS2 determine the time required for each regulator’s output duty cycle to increase

from zero to its final value for regulation. The minimum acceptable time is dependent on the output capacitance

and the response of each feedback loop to the COMP pin. If the Soft-start time is too quick, the output could

significantly overshoot its intended voltage before the feedback loop has a chance to regulate the PWM

controller.

After power is applied and VCC has passed its upper UVT threshold (≊7.6V), the voltage at each SS pin ramps up

as its external capacitor is charged up by an internal 50 µA current source (see Figure 5). The voltage at the

COMP pins follow the SS pins. When both have reached ≊1.5V, PWM pulses appear at the driver outputs with

very low duty cycle. The voltage at each SS pin continues to increase to ≊5.0V. The voltage at each COMP pin,

and the PWM duty cycle, increase to the value required for regulation as determined by its feedback loop. The

time t1 in Figure 5 is calculated from:

(11)

With a 0.1 µF capacitor at SS, t1 is ≊3 ms.

If the Hiccup Mode Current Limit Restart circuit activates due to repeated current limit detections at CS1 and/or

CS2, both SS1 and SS2 are internally grounded (see HICCUP MODE CURRENT LIMIT RESTART). After a

short propagation delay, the SS pins are released and the external SS pin capacitors are charged by internal 1

µA current sources. The slow charge rate provides a rest or dwell time for the converter power stage (t2 in

Figure 23), reducing the average input current and component temperature rise while in an overload condition.

When the voltage at the SS and COMP pins reach ≊1.5V, the first pulse out of either PWM comparator switches

the internal SS pin current sources to 50 µA. The voltages at the SS and COMP pins then increase more quickly,

increasing the duty cycle at the output drivers. The rest time t2 is the time required for SS to reach 1.5V:

(12)

With a 0.1 µF capacitor at SS, t2 is ≊150 ms.

Experimentation with the startup sequence and over-current restart condition is usually necessary to determine

the appropriate value for the SS capacitors.

To shutdown one regulator without affecting the other, ground the appropriate SS pin with an open collector or

open drain device as shown in Figure 34. The SS pin forces the COMP pin to ground which reduces the PWM

duty cycle to zero for that regulator. Releasing the SS pin allows normal operation to resume.

When the LM5034’s two controller channels are configured to provide a single high current output, SS1 and SS2

are typically connected together, requiring a single capacitor for the two pins.

Figure 34. Shutting Down One Regulator Channel

Product Folder Links: LM5034

l TEXAS INSTRUMENTS uwo

UVLO

LM5034

1.25V

20 PA

Max. Duty

Cycle Limiter

R1A

R1B

VPWR

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

LINE VOLTAGE DEPENDENT MAXIMUM DUTY CYCLE

As VPWR increases and the voltage at UVLO follows, the maximum allowed duty cycle decreases according to

the graph of Figure 13. Using values from the example above (R1 = 150 kΩ,R2=10kΩin Figure 29), the

maximum duty cycle varies as shown in Figure 14. If it is desired to increase the slope of the ramp in Figure 14,

Figure 35 shows a suggested configuration. After the LM5034 is enabled, Z1 clamps the voltage across R1B,

and UVLO increases with VPWR at a rate determined by the ratio R2/(R1A + R2).

Figure 35. Altering the Slope of Duty Cycle vs. VPWR

USER DEFINED MAX DUTY CYCLE

The maximum allowed duty cycle at OUT1 and OUT2 can be set with a resistor from DCL to GND1. See

Figure 12 and Equation 2. The default maximum duty cycle (80%) determined by the internal clock signals can

be selected by setting RDCL = RT. The oscillator frequency setting resistor (RT) must be determined before RDCL is

selected. The DCL pin should not be left open.

PRINTED CIRCUIT (PC) BOARD LAYOUT

The LM5034 Current Sense and PWM comparators are very fast, and respond to short duration noise pulses.

The components at the CS, COMP, SS, DCL, UVLO, OVLP and the RT/SYNC pins should be as physically close

as possible to the IC, thereby minimizing noise pickup in the PC board tracks.

Layout considerations are critical for the current sense filter. If current sense transformers are used, both leads of

each transformer secondary should be routed to the sense filter components and to the IC pins. The ground side

of each transformer should be connected via a dedicated PC board track to its appropriate GND pin, rather than

through the ground plane.

If the current sense circuits employ sense resistors in the drive transistor sources, low inductance resistors

should be used. In this case, all the noise sensitive low current ground tracks should be connected in common

near the IC, and then a single connection made to the power ground (sense resistor ground point). The outputs

of the LM5034 should have short direct paths to the power MOSFETs in order to minimize inductance in the PC

board traces.

The two ground pins (GND1, GND2) must be connected together with a short direct connection to avoid jitter due

to relative ground bounce in the operation of the two regulators.

If the internal dissipation of the LM5034 produces high junction temperatures during normal operation, the use of

wide PC board traces can help conduct heat away from the IC. Judicious positioning of the PC board within the

end product, along with use of any available air flow (forced or natural convection) can help reduce the junction

temperatures.

Product Folder Links: LM5034

R33/C34/C35

2.5V

Ref.

From U5

From U6

COMP2

COMP1

LM5034

R31

R34

R43

D E

U4 B C

R48

R47

F G

3.3V

OUT

VPWR

R33/C34/C35

2.5V

Ref.

From U5

From U6

COMP2

COMP1

LM5034

R31

R34

R43

D E

U4 B A

R48

R47

F G

3.3V

VPWR

|2.5V

Ref.

2.5V

R46/C37/C38

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

APPLICATION CIRCUIT EXAMPLE

Figure 40 shows an example of an LM5034 controlled 200W dual interleaved regulator which provides two

independent regulated outputs or a single high current output. The input voltage range (VPWR) is 36V to 78V, and

the output voltages are 3.3V and 2.5V in the dual output mode, or 3.3V in the single output mode. The output

current capability is 30A from each output or 60A in the single output mode. Current sense transformers T1 and

T2 provide information to the CS2 and CS1 pins for the current mode control, and error amplifiers U3 and U4

provide voltage feedback to COMP2 and COMP1 via optocoupler U2. Synchronous rectifiers Q5-Q12 minimize

rectification losses in the secondaries. An auxiliary winding on inductor L2 provides power to the LM5034 VCC

pins when the outputs are enabled. The UVLO levels are ≊34.3V for increasing VPWR, and ≊32.3V for decreasing

VPWR. The circuit can be shut down by forcing the ON/OFF input (J2) below 1.25V. An external synchronizing

frequency can be applied to the SYNC input (J3). Each regulator output is current limited at ≊31.5A.

To configure the circuit for two independent outputs, jumper A-B is installed, and the other jumpers connections

(C through G) are left open. U5 and U6 are the references for the two error amplifiers which control the

LM5034’s COMP pins via the optocouplers. See Figure 36.

To configure the circuit for a single high current output, jumpers B-C, D-E, and F-G are installed and A-B is

removed. Output terminals J8 and J6 are connected together at the load, as well as the ground terminals J5 and

J7. In this mode U4 is a follower to error amplifier U3, and the optocoupler outputs are connected together to

provide the same voltage to COMP1 and COMP2. See Figure 37. Efficiency measurements for this circuit are

shown in Figure 38 and Figure 39.

Figure 36. Circuit Configuration for Independent Outputs

Figure 37. Circuit Configuration for Single High Current Output

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

010 20 30 40 50 60

LOAD CURRENT (A)

100

EFFICIENCY (%)

VIN = 78V

VIN = 36V

VIN = 48V

VOUT = 3.3V

05 10 15 20 25 30

LOAD CURRENT (A)

100

EFFICIENCY (%)

3.3V and 2.5V outputs loaded equally,

simultaneously

VIN = 48V

VIN = 78V

VIN = 36V

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Figure 38. Total Board Efficiency, Independent Outputs

Figure 39. Efficiency, Single Output

Product Folder Links: LM5034

l TEXAS INSTRUMENTS 16 n In UM , L2 2 11 3 c w i im im la; Luz 3.31m: L1 ' :13 am I L5, L5, Lain. 122.3 .3" I r , 5: I, .7 , 2:2 I, 3. E’2 T1 “T3 Jim: mm mm )9 sin a sxnssw sum» m WM . :wagw T m swam» J as A w as 5., am: am an: m — F r = I m ‘" 1|» 4 ’7' ’ cnmvam Law as :3; . . . . v :22 .mm H . W W ‘11 '11 "1’1 :3 I Wag, ”5 1:. ES. 53; rm ,Iczu ”1 \l' “-54 “7 :21 H2: :24 - n27 mm SIWU , , 7 mm 5.52 an EN:- Mu; m .53 am "75“.? m s u n In uﬁ 127k 7m 15:75:17 as u m :25 mm __ m cnvmsﬂs mnuzm 13.522 W J5 I ma W 5" 2m umwm “‘ um w m m JR n2 u E 45.5 mm in“ in“ in, im lm 25““ F“ “"2 cza “2 333 up 339 I; 47 I: 4: “F1475 It 2‘? m‘ “m ”7 MI" PM“ swa v sw Q5 9 sw s v swamp . $4 45 W m as an m w an: awn iGU ' VB pf M uN ‘ = __ am an Ensure“ um = E E 4 4W on I144 :12 H! “r 'ﬁ , ﬂ: . H: m AH-Icmnzlaa ﬂ Gr mm m 4' 191 T1 at T1 j: 4N1 am m :37le gr m 2m “5 II .52 .53 m “:33 m FT ,—.3 .r a: 4m 1m um mu (an 5.52 5.52 w I“ “Jr” I nu II" :3 u, as '25: m5 _; 5:2”: mm. cmnzeas c. m ,, m . we: ”5% I, I4 I; 5 a ,7 w W has . 7 ‘ E?’ 5:: , 5 w W W. W 439 :EL m an i 551 mm mm must m M :3 I35: 552 m I; mm M i _ 40:14 me . 1 53°" rm ' ‘64: u? . us ' - - - um [4)“ 2.11:»: “‘35 C15 3 ' an am I u. ur I w ”a I mfaaa ”he: ur R11 )1“ , m I w m m MSW—IF . __ W w m u m V mcnzem ,3: 1-2“ SW mu m

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

Evaluation Board Schematic

Figure 40. Dual Interleaved Regulator

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

Table 1. Bill of Materials (Circuit of Figure 40)

Item Description Package Value

C1-4 Capacitor 1812 2.2 µF, 100V

C5, 50 Capacitor 1812 0.01 µF, 1000V

C6, 17, 19 Capacitor 1206 0.1 µF, 250V

C7, 10, 11, 35, 38 Capacitor 0805 0.01 µF, 50V

C8, 16, 18, 24, 26, 27, 39, 40, 42 Capacitor 0805 0.1 µF, 50V

C9 Capacitor 0805 100 pF

C12, 13 Capacitor 1210 10 µF, 16V

C14, 15 Capacitor 0805 0.33 µF

C20, 21 Capacitor 0805 1000 pF

C22, 23, 34, 37, 43, 44 Capacitor 0805 470 pF

C25, 41 Capacitor 0805 0.022 µF

C28, 29, 45, 46 Capacitor 3018 330 µF, 6.3V Tantalum

C30-32, 47-49 Capacitor 1812 47 µF

C33, 36, 51, 52 Capacitor 0805 1500 pF

D1-D11 Dual Diode SOT-23 75V, 200 mA

D12, 13 Dual Diode SOT-23 100V, 200 mA

D14, 15 Schottky diode SOD-323 30V, 100 mA

L1 Inductor, TDK SLF12575 12.5 x 12.5 5.6 µH, 6A

L2, 3 Inductor w/ aux out, Coilcraft 0.92 x 0.81 2 µH, 30A

B0358-C

Q1, 3 N-MOSFET, Vishay Si7846DP SO8 150V, 4A

Q2, 4 P-MOSFET, IRF6217 SO8 150V, 0.7A

Q5-12 N-MOSFET, Vishay Si7866DP SO8 20V, 25A

R1 Resistor 1206 10Ω, 1/8W

R2 Resistor 1206 49.9Ω

R3, 8 Resistor 0805 43.2kΩ

R4 Resistor 0805 100kΩ

R5 Resistor 0805 3.74kΩ

R6, 10, 11, 25, 26, 32, 37, 38, 44 Resistor 0805 1.0kΩ

R7 Resistor 0805 32.4kΩ

R9, 45 Resistor 0805 Open

R12, 13 Resistor 0805 10kΩ

R14, 17 Resistor 0805 1.5kΩ

R15, 18 Resistor 0805 8.2Ω

R16, 19 Resistor 0805 301Ω

R20, 22, 49, 51 Resistor 2512 10Ω, 1W

R21, 23, 24, 50, 52, 53 Resistor 0805 5.62Ω

R27, 39 Resistor 0805 49.9Ω

R28, 40 Resistor 0805 12.7kΩ

R29, 41 Resistor 0805 20kΩ

R30, 35, 36, 42 Resistor 0805 10Ω

R31, 43 Resistor 0805 24.9kΩ

R33, 46 Resistor 0805 30.1kΩ

R34 Resistor 0805 76.8kΩ

R47, 48 Resistor 0805 1.21kΩ

T1, 2 Transformer, Pulse Eng. P8208T 0.33 x 0.28 100:1, 6A

T3, 4 Transformer, Coilcraft B0357-B 0.92 x 0.81 12:2, 30A

U1 PWM dual controller TSSOP-20 LM5034PW

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

www.ti.com

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

Table 1. Bill of Materials (Circuit of Figure 40) (continued)

Item Description Package Value

U2 Dual Optocoupler SO8 MOCD207M

U3, 4 Op Amp SOT23-5 LM8261

U5, 6 Reference SOT23 LM4040-4.1V

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

LM5034

SNVS347A –FEBRUARY 2005–REVISED APRIL 2013

www.ti.com

REVISION HISTORY

Changes from Original (April 2013) to Revision A Page

• Changed layout of National Data Sheet to TI format .......................................................................................................... 28

Product Folder Links: LM5034

l TEXAS INSTRUMENTS

PACKAGE OPTION ADDENDUM

www.ti.com 25-Jun-2022

PACKAGING INFORMATION

Orderable Device Status

(1)

Package Type Package

Drawing Pins Package

Qty Eco Plan

(2)

Lead finish/

Ball material

(6)

MSL Peak Temp

(3)

Op Temp (°C) Device Marking

(4/5)

Samples

LM5034MTC NRND TSSOP PW 20 73 Non-RoHS

& Green Call TI Level-1-260C-UNLIM -40 to 125 LM5034

LM5034MTC/NOPB ACTIVE TSSOP PW 20 73 RoHS & Green SN Level-1-260C-UNLIM -40 to 125 LM5034

MT Samples

LM5034MTCX/NOPB ACTIVE TSSOP PW 20 2500 RoHS & Green SN Level-1-260C-UNLIM -40 to 125 LM5034

MT Samples

(1) The marketing status values are defined as follows:

ACTIVE: Product device recommended for new designs.

LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.

NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design.

PREVIEW: Device has been announced but is not in production. Samples may or may not be available.

OBSOLETE: TI has discontinued the production of the device.

(2) RoHS: TI defines "RoHS" to mean semiconductor products that are compliant with the current EU RoHS requirements for all 10 RoHS substances, including the requirement that RoHS substance

do not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, "RoHS" products are suitable for use in specified lead-free processes. TI may

reference these types of products as "Pb-Free".

RoHS Exempt: TI defines "RoHS Exempt" to mean products that contain lead but are compliant with EU RoHS pursuant to a specific EU RoHS exemption.

Green: TI defines "Green" to mean the content of Chlorine (Cl) and Bromine (Br) based flame retardants meet JS709B low halogen requirements of <=1000ppm threshold. Antimony trioxide based

flame retardants must also meet the <=1000ppm threshold requirement.

(3) MSL, Peak Temp. - The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications, and peak solder temperature.

(4) There may be additional marking, which relates to the logo, the lot trace code information, or the environmental category on the device.

(5) Multiple Device Markings will be inside parentheses. Only one Device Marking contained in parentheses and separated by a "~" will appear on a device. If a line is indented then it is a continuation

of the previous line and the two combined represent the entire Device Marking for that device.

(6) Lead finish/Ball material - Orderable Devices may have multiple material finish options. Finish options are separated by a vertical ruled line. Lead finish/Ball material values may wrap to two

lines if the finish value exceeds the maximum column width.

Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is provided. TI bases its knowledge and belief on information

provided by third parties, and makes no representation or warranty as to the accuracy of such information. Efforts are underway to better integrate information from third parties. TI has taken and

continues to take reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on incoming materials and chemicals.

TI and TI suppliers consider certain information to be proprietary, and thus CAS numbers and other limited information may not be available for release.

Addendum-Page 1

TEXAS INSTRUMENTS

PACKAGE OPTION ADDENDUM

www.ti.com 25-Jun-2022

In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI to Customer on an annual basis.

Addendum-Page 2

l TEXAS INSTRUMENTS REEL DIMENSIONS TAPE DIMENSIONS ’ I+K0 '«PI» Reel Diame|er AD Dimension deSIgned Io accommodate me componem wIdIh E0 Dimension desIgned Io eeeemmodaIe me component Iengm K0 Dlmenslun desIgned to accommodate me componem Ihlckness 7 w Overall with loe earner cape i p1 Pitch between successwe cavIIy cemers f T Reel Width (W1) QUADRANT ASSIGNMENTS FOR PIN 1 ORIENTATION IN TAPE O O O D O O D O SprockeIHoles ,,,,,,,,,,, ‘ User Direcllon 0' Feed Pocket Quadrams

TAPE AND REEL INFORMATION

*All dimensions are nominal

Device Package

Type Package

Drawing Pins SPQ Reel

Diameter

(mm)

Reel

Width

W1 (mm)

(mm) B0

(mm) K0

(mm) P1

(mm) W

(mm) Pin1

Quadrant

LM5034MTCX/NOPB TSSOP PW 20 2500 330.0 16.4 6.95 7.1 1.6 8.0 16.0 Q1

PACKAGE MATERIALS INFORMATION

www.ti.com 5-Jan-2022

Pack Materials-Page 1

l TEXAS INSTRUMENTS TAPE AND REEL BOX DIMENSIONS

*All dimensions are nominal

Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)

LM5034MTCX/NOPB TSSOP PW 20 2500 367.0 367.0 35.0

PACKAGE MATERIALS INFORMATION

www.ti.com 5-Jan-2022

Pack Materials-Page 2

l TEXAS INSTRUMENTS T - Tube height| L - Tube length l ,g + w-Tuhe _______________ _ ______________ width 47 — B - Alignment groove width

TUBE

*All dimensions are nominal

Device Package Name Package Type Pins SPQ L (mm) W (mm) T (µm) B (mm)

LM5034MTC PW TSSOP 20 73 495 8 2514.6 4.06

LM5034MTC/NOPB PW TSSOP 20 73 495 8 2514.6 4.06

PACKAGE MATERIALS INFORMATION

www.ti.com 5-Jan-2022

Pack Materials-Page 3

--I L J f T , g T Q f ﬂ g

www.ti.com

PACKAGE OUTLINE

18X 0.65

5.85

20X 0.30

0.19

TYP

6.6

6.2

1.2 MAX

0.15

0.05

0.25

GAGE PLANE

-80

NOTE 4

4.5

4.3

NOTE 3

6.6

6.4

0.75

0.50

(0.15) TYP

TSSOP - 1.2 mm max heightPW0020A

SMALL OUTLINE PACKAGE

4220206/A 02/2017

10 11

0.1 C A B

PIN 1 INDEX AREA

SEE DETAIL A

0.1 C

NOTES:

1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing

per ASME Y14.5M.

2. This drawing is subject to change without notice.

3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions, or gate burrs shall not

exceed 0.15 mm per side.

4. This dimension does not include interlead flash. Interlead flash shall not exceed 0.25 mm per side.

5. Reference JEDEC registration MO-153.

SEATING

PLANE

A 20

DETAIL A

TYPICAL

SCALE 2.500

““‘w‘+‘w““‘

www.ti.com

EXAMPLE BOARD LAYOUT

0.05 MAX

ALL AROUND 0.05 MIN

ALL AROUND

20X (1.5)

20X (0.45)

18X (0.65)

(5.8)

(R0.05) TYP

TSSOP - 1.2 mm max heightPW0020A

SMALL OUTLINE PACKAGE

4220206/A 02/2017

NOTES: (continued)

6. Publication IPC-7351 may have alternate designs.

7. Solder mask tolerances between and around signal pads can vary based on board fabrication site.

LAND PATTERN EXAMPLE

EXPOSED METAL SHOWN

SCALE: 10X

SYMM

10 11

15.000

METAL

SOLDER MASK

OPENING METAL UNDER

SOLDER MASK SOLDER MASK

OPENING

EXPOSED METAL

SOLDER MASK DETAILS

NON-SOLDER MASK

DEFINED

(PREFERRED)

SOLDER MASK

DEFINED

gmgmmj r Egg;

www.ti.com

EXAMPLE STENCIL DESIGN

20X (1.5)

20X (0.45)

18X (0.65)

(5.8)

(R0.05) TYP

TSSOP - 1.2 mm max heightPW0020A

SMALL OUTLINE PACKAGE

4220206/A 02/2017

NOTES: (continued)

8. Laser cutting apertures with trapezoidal walls and rounded corners may offer better paste release. IPC-7525 may have alternate

design recommendations.

9. Board assembly site may have different recommendations for stencil design.

SOLDER PASTE EXAMPLE

BASED ON 0.125 mm THICK STENCIL

SCALE: 10X

SYMM

10 11

IMPORTANT NOTICE AND DISCLAIMER

TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATA SHEETS), DESIGN RESOURCES (INCLUDING REFERENCE

DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”

AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY

IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD

PARTY INTELLECTUAL PROPERTY RIGHTS.

These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate

TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable

standards, and any other safety, security, regulatory or other requirements.

These resources are subject to change without notice. TI grants you permission to use these resources only for development of an

application that uses the TI products described in the resource. Other reproduction and display of these resources is prohibited. No license

is granted to any other TI intellectual property right or to any third party intellectual property right. TI disclaims responsibility for, and you

will fully indemnify TI and its representatives against, any claims, damages, costs, losses, and liabilities arising out of your use of these

resources.

TI’s products are provided subject to TI’s Terms of Sale or other applicable terms available either on ti.com or provided in conjunction with

such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for

TI products.

TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

LM5034 Datasheet by Texas Instruments

INFORMATION

HELP

CONTACT US

FOLLOW US
