a MICROCHIP

2005 Product Selector Guide

October - December 2005

Update

PlCmicroa crocontrollers Baseline 8»bit architecture Mid»Range 8»bit architecture High Performance PIC18 8»bit architecture 16-bit PlCmicrog Microcontrollers 16-bit rlsPlCg Digital Signal Controllers Stand-Alone Analog & Interface Products Linear and Mixed-Signal. Power Management. Thermal Management. Interface. Secure Data Products Memog Products Development Systems

Product Proﬁ le

8-bit PICmicro® Microcontrollers

Microchip’s PICmicro® family of microcontrollers combine high performance, low cost and small package size to offer the best price/

performance ratio in the industry. Based on a powerful RISC core, these 8-bit PIC® microcontrollers fall into three product architecture

categories, providing a variety of options for any application requirement:

• Baseline 8-bit architecture: 12-bit instruction set, 6-44 pin count, 384-3.5K bytes program memory, up to 5 MIPS

• Mid-Range 8-bit architecture: 14-bit instruction set, 8-68 pin count, 896-14K bytes program memory, up to 5 MIPS

• High Performance (PIC18) 8-bit architecture: 16-bit instruction set, 18-100 pin count, 8K-128K bytes program memory,

up to 16 MIPS

The common architecture provides users with an easy migration path from 6 to 100 pins among all families with little or no code

change required. Advanced features available are:

• Sophisticated timing peripherals

• Embedded analog peripherals including A/D and D/A converters, comparators, PBOR, PLVD, DAC, VREF, Op Amps and PSMC

• Communications peripherals (I2C™/SPI™/USB/CAN and USARTs)

• Low-power, single-chip RF solutions targeting RF connectivity for high-volume embedded control applications

• Battery management solutions

• Flexible programming options including In-Circuit Serial Programming™ (ICSP™) technology, self-programming (Enhanced

Flash), One-Time-Programmable (OTP), QTP, SQTP and ROM

16-bit PICmicro® Microcontrollers

The PIC24 microcontrollers build upon the high performance, wide selection of peripherals, Flash memory sizes and packaging choices

found in the 8-bit PIC18 family. The PIC24 architecture, paired with the optimized MPLAB C30 C Compiler, provides the high throughput

and C code density needed to achieve system performance goals and product launch schedules.

• Leadership 16-bit microcontroller performance and C code efﬁ ciency

• Extension of the 8-bit PIC18 microcontroller performance, memory and peripherals

• Easy migration path to dsPIC® digital signal controllers with over 40 MIPS and DSP capability, MPLAB® compatibility

16-bit dsPIC® Digital Signal Controllers

Microchip’s 16-bit High Performance Digital Signal Controllers (DSC) combine the best features of microcontrollers with the best

features of DSPs in a single core. These dsPIC DSC devices reach speeds of up to 30 MIPS.

• C compiler efﬁ ciency programming, Flash, data EEPROM, and powerful peripherals

• Extensive software libraries for effortless design

• Familiar microcontroller architecture and design environment

Stand-Alone Analog & Interface Products

Microchip offers a broad portfolio of analog and related products:

• Linear and Mixed-Signal. ADCs/DACs, digital potentiometers, op amps and comparators.

• Power Management. LDO and switching regulators, charge pumps, voltage references, CPU/system supervisors and volt age

detectors, battery chargers and power MOSFET drivers.

• Thermal Management. Temperature sensors (logic output, voltage output, and serial output), brushless DC fan controllers, and

fan fault detectors.

• Interface. Peripheral products supporting industry-standard networking protocols like CAN, LIN and infrared (including IrDA®

Standard infrared), as well as products that provide embedded system input/output expansion capability.

Secure Data Products

Microchip’s KEELOQ® code hopping algorithm combines high security, a small package outline and a very low cost to make this an

ideal solution for unidirectional RKE systems. The KEELOQ code hopping technology creates a high degree of security using a long

code word length together with encryption and synchronization techniques.

Memory Products

Microchip offers one of the broadest selections of serial EEPROMs in densities from 128 bits to 512 Kbits, with operating voltages

down to 1.8V, in all popular bus protocols (I2C™, Microwire and SPI™ compatible). They are available in all standard temperature

ranges from -40°C to +125°C and packaged in the world’s smallest standard packaging; up to 16 Kbits in 5-lead SOT-23 and up to

256 Kbits in 8-lead MSOP.

Development Systems

Microchip offers a full range of microcontroller development systems, including the MPLAB® ICE 2000 and ICE 9000 in-circuit

emulators; MPLAB Integrated Development Environment; MPLAB C18 and C30 Compiler; the MPLAB ICD In-Circuit Debugger,

MPLAB PM3 full-featured device programmer; PICSTART® low-cost development system; the PICkit™ 1 Flash Starter Kit, SEEVAL®

Serial EEPROM Evaluation Kit and various demonstration boards. Microchip has shipped more than 300,000+ development systems

worldwide.

PAGE i

TABLE OF CONTENTS

CURRENT dsPIC® DIGITAL SIGNAL CONTROLLER FAMILY PRODUCTS. . . . . . . . 5

dsPIC30F Motor Control and Power Conversion Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

dsPIC30F General Purpose Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

dsPIC30F Sensor Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

FUTURE dsPIC® DIGITAL SIGNAL CONTROLLER FAMILY PRODUCTS . . . . . . . . . 7

dsPIC30F Motor Control and Power Conversion Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

dsPIC33F Motor Control and Power Conversion Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

dsPIC33F General Purpose Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

CURRENT ANALOG/INTERFACE PRODUCTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

THERMAL MANAGEMENT PRODUCTS – Temperature Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Logic Output Temperature Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Voltage Output Temperature Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Serial Output Temperature Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

THERMAL MANAGEMENT PRODUCTS – Brushless DC Fan Controllers and

Fan Fault Detectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

POWER MANAGEMENT – Voltage References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

POWER MANAGEMENT – Linear Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

50 mA to 250 mA Low Dropout Linear Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

300 mA Low Dropout Linear Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

500 mA to 800 mA Low Dropout Linear Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

1A and Above Low Dropout Linear Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Application Specific Low Dropout Linear Regulators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Power Management Combination Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

POWER MANAGEMENT – Switching Regulators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

POWER MANAGEMENT – PWM Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

POWER MANAGEMENT – Charge Pump DC-to-DC Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Inverting or Doubling Charge Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Multi-Function Charge Pumps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Inverting and Doubling Charge Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Regulated Charge Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

POWER MANAGEMENT – CPU/System Supervisors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

POWER MANAGEMENT – Voltage Detectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

POWER MANAGEMENT – Power MOSFET Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Low-Side Drivers, 0.5A to 1.2A Peak Output Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Low-Side Drivers, 1.5A Peak Output Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Low-Side Drivers, 2.0A to 9.0A Peak Output Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

High-Side/Low-Side Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

POWER MANAGEMENT – Battery Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

POWER MANAGEMENT – Hot Swap Controllers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

PAGE ii

LINEAR – Op Amps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

LINEAR – High Precision Operational Amplifiers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Chopper Stabilized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Auto-Zero. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

LINEAR – Programmable Gain Amplifiers (PGA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

LINEAR – Integrated Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

LINEAR – Comparators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

MIXED SIGNAL – Successive Approximation Register (SAR) A/D Converters. . . . . . . . . . . . . . . . . .23

MIXED SIGNAL – Delta-Sigma A/D Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

MIXED SIGNAL – Energy Measurement ICs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

MIXED SIGNAL – Dual Slope A/D Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

MIXED SIGNAL – Binary and BCD A/D Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

MIXED SIGNAL – Display A/D Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

MIXED SIGNAL – Digital Potentiometers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

MIXED SIGNAL – Frequency-to-Voltage/Voltage-to-Frequency Converters. . . . . . . . . . . . . . . . . . . .26

MIXED SIGNAL – D/A Converters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

INTERFACE – Controller Area Network (CAN) Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

INTERFACE – Infrared Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

INTERFACE – Ethernet Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

INTERFACE – LIN Transceiver Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

INTERFACE – Serial Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

FUTURE ANALOG/INTERFACE PRODUCTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Power Management – Low-Side Power MOSFET Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Power Management – Battery Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Power Management – Charge Pump DC/DC Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Power Management – Linear Regulators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Power Management – Switching Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Power Management – CPU/System Supervisors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Linear – Linear Gain Blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Mixed Signal – Successive Approximation Register (SAR) A/D Converters . . . . . . . . . . . . . . . . . . . .30

Interface – Passive Access Products. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

CURRENT PICmicro® MICROCONTROLLER FAMILY PRODUCTS . . . . . . . . . . . . . 31

Baseline 8-Bit PICmicro® Microcontroller Family (12-bit Instruction Set) . . . . . . . . . . . . . . . . . . . . . .31

PIC10FXXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

PIC12FXXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

PIC16F5XX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

PIC16C5X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Mid-Range 8-Bit PICmicro® Microcontroller Family (14-bit Instruction Set) . . . . . . . . . . . . . . . . . . . .32

PIC12FXXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

PIC16FXXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

PIC16CXXX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

PAGE iii

High-Performance 8-Bit PICmicro® Microcontroller Family (16-bit Instruction Set) . . . . . . . . . . . . . .35

PIC18 Flash MCUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

PIC18FXXJXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

FUTURE PICmicro® MICROCONTROLLER FAMILY PRODUCTS. . . . . . . . . . . . . . . 40

Mid-Range 8-Bit PICmicro® Microcontroller Family (14-bit Instruction Set) . . . . . . . . . . . . . . . . . . . .40

PIC12FXXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

PIC16FXXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

PIC16CRXX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

High-Performance 8-Bit PICmicro® Microcontroller Family (16-bit Instruction Set) . . . . . . . . . . . . . .40

PIC18FXXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

PIC18FXXJXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

PIC18FXXKXX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

PIC24 16-Bit Microcontroller (MCU) Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

PIC24FJ128GA Family 16-bit Flash MCUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

PIC24HJ256GP Family 16-bit Flash MCUs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

MATURE – PICmicro® MICROCONTROLLER FAMILY PRODUCTS . . . . . . . . . . . . . 45

FOCUSED SOLUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

CAN Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

CAN Peripherals/Transceivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Ethernet Solutions – Integrated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Ethernet Solutions – Stand-Alone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

USB Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

USB Battery Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Switching Battery Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Battery Fuel Gauge ICs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Radio Frequency Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

rfPIC® Microcontrollers with UHF RF Transmitter, ICSP™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

rfHCS KEELOQ® Encoders with UHF RF Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

UHF RF Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

microID® RFID Tagging Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

LCD Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Display Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Motor Control Solutions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Motor Control Solutions – MOSFET Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Motor Control Solutions – LINEAR – Comparators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Motor Control Solutions – LINEAR – Op Amps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Motor Control Solutions – LINEAR – High Precision Operational Amplifiers. . . . . . . . . . . . . . . . . . . .58

High-Speed Sensor Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

Power-Managed Solutions Featuring nanoWatt Technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

PAGE iv

CURRENT SECURE DATA PRODUCTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

KEELOQ® Encoder Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

KEELOQ® Decoder Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

KEELOQ® Programmable Encoder/Decoder Flash Devices (x14), ICSP™ . . . . . . . . . . . . . . . . . . . . .61

CURRENT SERIAL ELECTRICALLY ERASABLE PROMS (EEPROM) . . . . . . . . . . 62

Microwire Compatible Serial EEPROM Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

2-Wire I2C™ Compatible Serial EEPROM Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

SPI™ Compatible Serial EEPROM Family. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

ISO Smart Card Family.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

Identification Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

FUTURE SERIAL ELECTRICALLY ERASABLE PROMS (EEPROM) . . . . . . . . . . . . 66

SPI™ Compatible Serial EEPROM Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

I2C™ Compatible Serial EEPROM Family. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

DEVELOPMENT SYSTEMS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

MPLAB® ICE 2000 and MPLAB® ICE 4000 Emulator Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

How Do I Order MPLAB® ICE? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

A Complete MPLAB® ICE System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

MPLAB® PM3 Programmers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

In-Circuit Debuggers: MPLAB® ICD 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

MPLAB® ICE 2000 and MPLAB® ICE 4000 Emulator Systems, PRO MATE® II Programmer Socket

Modules, MPLAB® In-Circuit Debugger, Software Tools, Programmers & Demonstration Boards. . .68

Analog Interface Development Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

PICmicro® Microcontroller Development Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

rfPIC® Microcontroller Development Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98

dsPIC® DSC Development Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Demonstration Boards and Evaluation Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103

PICmicro® Demonstration Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103

Connectivity Demonstration Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103

Mixed Signal Control Demonstration Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

dsPIC® Digital Signal Controller Demonstration Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

dsPIC® 16-bit DSC Software Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

PowerSmart® Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

Memory Evaluation/Developer’s Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

KeeLoq® Evaluation Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

RFID Evaluation/Developer’s Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

Analog/Interface Demo/Eval/Developer’s Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

PIN AND CODE COMPATIBILITY CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

PART NUMBER SUFFIX DESIGNATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

ABBREVIATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

PAGE 5

dsPIC® DSC FAMILY

CURRENT dsPIC® DIGITAL SIGNAL CONTROLLER FAMILY PRODUCTS

dsPIC® Digital Signal Controller (DSC) Family

Product Program

(Flash)

KBytes

Memory

(Flash)

KWords

Bytes SRAM

Bytes I/O Pins

(max.) Packages A/D 12-bit

200 ksps A/D 10-bit

1000 ksps Timer

16-bit Input

Cap

Output

Comp/Std

PWM

Motor

Control

PWM

Quad

Enc. UART SPI™ I2C™ CAN Codec

Interface

dsPIC30F Motor Control and Power Conversion Family

dsPIC30F2010 12 4 1024 512 20 28SO, 28SP,

28MM (6x6) —6 ch3426✓111——

dsPIC30F3010 24 81024 1024 20 28SO, 28SP,

44ML (8x8) —6 ch 5 4 2 6 ✓1 1 1 — —

dsPIC30F4012 48 16 1024 2048 20 28SO, 28SP,

44ML (8x8) —6 ch5426✓1111—

dsPIC30F3011 24 81024 1024 30 40P, 44PT, 44ML

(8x8) —9 ch 5 4 4 6 ✓2 1 1 — —

dsPIC30F4011 48 16 1024 2048 30 40P, 44PT, 44ML

(8x8) —9 ch544 6✓2111—

dsPIC30F5015 66 22 1024 2048 52 64PT —16 ch 5 4 4 8 ✓1 2 1 1 —

dsPIC30F6015 144 48 4096 8192 52 64PT — 16 ch 5 8 8 8 ✓2212—

dsPIC30F5016 66 22 1024 2048 68 80PT —16 ch 5 4 4 8 ✓1 2 1 1 —

dsPIC30F6010 144 48 4096 8192 68 80PF — 16 ch 5 8 8 8 ✓2212—

dsPIC30F6010A 144 48 4096 8192 68 80PF, 80PT —16 ch 5 8 8 8 ✓2 2 1 2 —

dsPIC30F General Purpose Family

dsPIC30F3014 24 8 1024 2048 30 40P, 44PT, 44ML

(8x8) 13 ch — 3 2 2 — — 2 1 1 — —

dsPIC30F4013 48 16 1024 2048 30 40P, 44PT, 44ML

(8x8) 13 ch — 5 4 4 — — 2 1 1 1 AC97, I2S

dsPIC30F5011 66 22 1024 4096 52 64PT 16 ch — 5 8 8 — — 2 2 1 2 AC97, I2S

dsPIC30F6011 132 44 2048 6144 52 64PF 16 ch — 5 8 8 — — 2 2 1 2 —

dsPIC30F6011A 132 44 2048 6144 52 64PF, 64PT 16 ch — 5 8 8 — — 2 2 1 2 —

dsPIC30F6012 144 48 4096 8192 52 64PF 16 ch — 5 8 8 — — 2 2 1 2 AC97, I2S

dsPIC30F6012A 144 48 4096 8192 52 64PF, 64PT 16 ch — 5 8 8 — — 2 2 1 2 AC97, I2S

dsPIC30F5013 66 22 1024 4096 68 80PT 16 ch — 5 8 8 — — 2 2 1 2 AC97, I2S

dsPIC30F6013 132 44 2048 6144 68 80PF 16 ch — 5 8 8 — — 2 2 1 2 —

dsPIC30F6013A 132 44 2048 6144 68 80PF, 80PT 16 ch — 5 8 8 — — 2 2 1 2 —

Abbreviations are found on the last page of the Selector Guide.

PAGE 6

dsPIC® DSC FAMILY

dsPIC30F General Purpose Family (continued)

dsPIC30F6014 144 48 4096 8192 68 80PF 16 ch — 5 8 8 — — 2 2 1 2 AC97, I2S

dsPIC30F6014A 144 48 4096 8192 68 80PF, 80PT 16 ch — 5 8 8 — — 2 2 1 2 AC97, I2S

dsPIC30F Sensor Family

dsPIC30F2011 12 4 0 1024 12 18SO, 18P, 28ML

(6x6) 8 ch — 3 2 2 — — 1 1 1 — —

dsPIC30F3012 24 81024 2048 12 18SO, 18P, 28ML

(6x6) 8 ch — 3 2 2 — — 1 1 1 — —

dsPIC30F2012 12 4 0 1024 20 28SO, 28SP,

28ML (6x6) 10 ch — 3 2 2 — — 1 1 1 — —

dsPIC30F3013 24 81024 2048 20 28SO, 28SP,

28ML (6x6) 10 ch — 3 2 2 — — 2 1 1 — —

dsPIC® Digital Signal Controller (DSC) Family (continued)

Product Program

(Flash)

KBytes

Memory

(Flash)

KWords

Bytes SRAM

Bytes I/O Pins

(max.) Packages A/D 12-bit

200 ksps A/D 10-bit

1000 ksps Timer

16-bit Input

Cap

Output

Comp/Std

PWM

Motor

Control

PWM

Quad

Enc. UART SPI™ I2C™ CAN Codec

Interface

Abbreviations are found on the last page of the Selector Guide.

PAGE 7

dsPIC® DSC FAMILY

FUTURE dsPIC® DIGITAL SIGNAL CONTROLLER FAMILY PRODUCTS

dsPIC® Digital Signal Controller (DSC) Family

Product Program

(Flash)

Kbytes

SRAM

KBytes DMA I/O Pins

(max.) Packages A/D 12-bit

500ksps A/D 10-bit

1,000ksps Timer

16-bit Input

Cap

Output

Comp/

Std PWM

Motor

Control

PWM

Quad Enc.

Interface UART SPI™ I2C™ CAN Codec

Interface

dsPIC30F Motor Control and Power Conversion Family

dsPIC30F2005 8 300 — 20 28SO,

28SP,

28MM —1 A/D, 6 ch

4 S/H 33 1 6 ✓1000 —

dsPIC30F2015 12 500 —20 28SO,

28SP,

28MM —1 A/D, 6 ch

4 S/H 3 4 2 6 ✓1 1 1 0 —

dsPIC33F Motor Control and Power Conversion Family

dsPIC33FJ64MC506 64 8 6 ch 53 64PT — 1 A/D, 16 ch

4 S/H 98 8 8 ✓2221 —

dsPIC33FJ64MC508 64 86 ch 69 80PT —1 A/D, 18 ch

4 S/H 9 8 8 8 ✓2 2 2 1 —

dsPIC33FJ64MC510 64 8 6 ch 85 100PT — 1 A/D, 24 ch

4 S/H 98 8 8 ✓2221 —

dsPIC33FJ64MC706 64 16 6 ch 53 64PT —2 A/D, 16 ch

8 S/H 9 8 8 8 ✓2 2 2 1 —

dsPIC33FJ64MC710 64 16 6 ch 85 100PT — 2 A/D, 24 ch

8 S/H 98 8 8 ✓2222 —

dsPIC33FJ128MC506 128 86 ch 53 64PT —1 A/D, 16 ch

4 S/H 9 8 8 8 ✓2 2 2 1 —

dsPIC33FJ128MC510 128 8 6 ch 85 100PT — 1 A/D, 24 ch

4 S/H 98 8 8 ✓2221 —

dsPIC33FJ128MC706 128 16 6 ch 53 64PT —2 A/D, 16 ch

8 S/H 9 8 8 8 ✓2 2 2 1 —

dsPIC33FJ128MC708 128 16 6 ch 69 80PT — 2 A.D, 18 ch

8 S/H 98 8 8 ✓2222 —

dsPIC33FJ128MC710 128 16 6 ch 85 100PT —2 A/D, 24 ch

8 S/H 9 8 8 8 ✓2 2 2 2 —

dsPIC33FJ256MC510 256 16 6 ch 85 100PT — 1 A/D, 16 ch

4 S/H 98 8 8 ✓2221 —

dsPIC33FJ256MC710 256 30 6 ch 85 100PT —2 A/D, 24 ch

8 S/H 9 8 8 8 ✓2 2 2 2 —

PAGE 8

dsPIC® DSC FAMILY

dsPIC33F General Purpose Family

dsPIC33FJ64GP206 64 8 6 ch 53 64PT 1 ADC, 18 ch — 9 8 8 — — 2 2 1 0 1

dsPIC33FJ64GP306 64 16 6 ch 53 64PT 1 ADC, 18 ch — 9 8 8——2 2 2 0 1

dsPIC33FJ64GP310 64 16 6 ch 85 100PT 1 ADC, 32 ch — 9 8 8 — — 2 2 2 0 1

dsPIC33FJ64GP706 64 16 6 ch 53 64PT 2 ADC, 18 ch

2 S/H — 9 8 8 — — 2 2 2 2 1

dsPIC33FJ64GP708 64 16 6 ch 69 80PT 2 ADC, 24 ch

2 S/H —988——22221

dsPIC33FJ64GP710 64 16 6 ch 85 100PT 2 ADC, 32 ch

2 S/H — 9 8 8 — — 2 2 2 2 1

dsPIC33FJ128GP206 128 8 6 ch 53 64PT 1 ADC, 18 ch — 9 8 8 — — 2 2 1 0 1

dsPIC33FJ128GP306 128 16 6 ch 53 64PT 1 ADC, 18 ch — 9 8 8 — — 2 2 2 0 1

dsPIC33FJ128GP310 128 16 6 ch 85 100PT 1 ADC, 32 ch — 9 8 8 — — 2 2 2 0 1

dsPIC33FJ128GP706 128 16 6 ch 53 64PT 2 ADC, 18 ch

2 S/H — 9 8 8 — — 2 2 2 2 1

dsPIC33FJ128GP708 128 16 6 ch 69 80PT 2 ADC, 24 ch

2 S/H —988——22221

dsPIC33FJ128GP710 128 16 6 ch 85 100PT 2 ADC, 32 ch

2 S/H — 9 8 8 — — 2 2 2 2 1

dsPIC33FJ256GP506 256 16 6 ch 53 64PT 1 ADC, 18 ch — 9 8 8 — — 2 2 2 1 1

dsPIC33FJ256GP510 256 16 6 ch 85 100PT 1 ADC, 32 ch — 9 8 8 — — 2 2 2 1 1

dsPIC33FJ256GP710 256 30 6 ch 85 100PT 2 ADC, 32 ch

2 S/H —988——22221

Abbreviations are found on the last page of the Selector Guide.

dsPIC® Digital Signal Controller (DSC) Family (continued)

Product Program

(Flash)

Kbytes

SRAM

KBytes DMA I/O Pins

(max.) Packages A/D 12-bit

500ksps A/D 10-bit

1,000ksps Timer

16-bit Input

Cap

Output

Comp/

Std PWM

Motor

Control

PWM

Quad Enc.

Interface UART SPI™ I2C™ CAN Codec

Interface

PAGE 9

Analog/Interface

Family Products

CURRENT ANALOG/INTERFACE PRODUCTS

Lead-free versions of many devices are currently offered. Check Microchip’s web site for availability.

THERMAL MANAGEMENT PRODUCTS – Temperature Sensors

Part # Typical Accuracy

(°C) Maximum Accuracy

@ 25°C (°C)

Maximum

Temperature Range

(°C) VCC Range (V) Maximum Supply

Current (μA) Features Packages

Logic Output Temperature Sensors

TC6501 ±0.5 ±3 -55 to +125 +2.7 to +5.5 40 Cross to MAX6501, Open-drain 5-Pin SOT-23A

TC6502 ±0.5 ±3 -55 to +125 +2.7 to +5.5 40 Cross to MAX6502, Push-pull 5-Pin SOT-23A

TC6503 ±0.5 ±3 -55 to +125 +2.7 to +5.5 40 Cross to MAX6503, Open-drain 5-Pin SOT-23A

TC6504 ±0.5 ±3 -55 to +125 +2.7 to +5.5 40 Cross to MAX6504, Push-pull 5-Pin SOT-23A

TC620 ±1 ±3 -40 to +125 +4.5 to +18 400 Two resistor-programmable trip points 8-Pin PDIP, 8-Pin SOIC

TC621 Note 1 Note 1 -40 to +85 +4.5 to +18 400 Requires external thermistor, resistor-

programmable trip points 8-Pin PDIP, 8-Pin SOIC

TC622 ±1 ±5 -40 to +125 +4.5 to +18 600 Dual output, TO-220 for heat sink mounting,

resistor-programmable trip points 8-Pin PDIP, 8-Pin SOIC, 5-Pin TO-220

TC623 ±1 ±3 -40 to +125 +2.7 to +4.5 250 Two resistor-programmable trip points 8-Pin PDIP, 8-Pin SOIC

TC624 ±1 ±5 -40 to +125 +2.7 to +4.5 300 Dual output, resistor-programmable trip

points 8-Pin PDIP, 8-Pin SOIC

Voltage Output Temperature Sensors

MCP9700 +1 +4 -40 to +125 +2.3 to +5.5 12 Linear Active Thermistor™ IC, Temperature

slope: 10 mV/°C 5-pin SC-70

MCP9701 +1+4 -10 to +125 +3.1 to +5.5 12 Linear Active Thermistor™ IC, Temperature

slope: 19.53 mV/°C, cross to MAX6612 5-pin SC-70

TC1046 ±0.5 ±2 -40 to +125 +2.7 to +4.4 60 High precision temperature-to-voltage

converter, 6.25 mV/°C 3-Pin SOT-23B

TC1047 ±0.5 ±2 -40 to +125 +2.7 to +4.4 60 High precision temperature-to-voltage

converter, 10 mV/°C 3-Pin SOT-23B

TC1047A ±0.5 ±2 -40 to +125 +2.5 to +5.5 60 High precision temperature-to-voltage

converter, 10 mV/°C 3-Pin SOT-23B

Serial Output Temperature Sensors

MCP9800 ±0.5 ±1 -55 to +125 +2.7 to +5.5 400 SMBus/I2C™ compatible interface,

0.0625°C to 0.5°C adj. resolution, power-

saving one-shot temperature measurement

5-Pin SOT-23

MCP9801 ±0.5 ±1 -55 to +125 +2.7 to +5.5 400

SMBus/I2C™ compatible interface,

0.0625°C to 0.5°C adj. resolution, power-

saving one-shot temperature measurement,

multi-drop capability

8-Pin MSOP, 8-pin SOIC

MCP9802 ±0.5 ±1 -55 to +125 +2.7 to +5.5 400

SMBus/I2C™ compatible interface with time

out, 0.0625°C to 0.5°C adj. resolution,

power-saving one-shot temperature

measurement

5-Pin SOT-23

NOTE 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor.

2: TCN75 idle current is 250 μA. This device also has a Software Shutdown mode that reduces supply current to <1 μA.

3: MCP9805 max. accuracy measured at 85°C.

PAGE 10

Analog/Interface

Family Products

Serial Output Temperature Sensors (continued)

MCP9803 ±0.5 ±1 -55 to +125 +2.7 to +5.5 400

SMBus/I2C™ compatible interface with time

out, 0.0625°C to 0.5°C adj. resolution,

power-saving one-shot temperature

measurement, multi-drop capability

8-Pin MSOP, 8-Pin SOIC

MCP9805 +0.5 +1(3) -20 to +125 +3.0 to +3.6 400 JEDEC compatible register set, SMBus/

I2C™ compatible interface, programmable,

shut-down modes and EVENT output 8-Pin TSSOP, 8-Pin 2x3 DFN

TC77 ±0.5 ±1 -55 to +125 +2.7 to +5.5 400 SPI™ compatible interface, 0.0625°C

temperature resolution 5-Pin SOT-23A, 8-Pin SOIC

TC72 ±0.5 ±1 -55 to +125 +2.65 to +5.5 400 SPI™ compatible interface, power saving

one-shot temperature measurement, 0.25°C

temperature resolution 8-Pin MSOP, 8-Pin 3x3 DFN

TC74 ±0.5 ±2 -40 to +125 +2.7 to +5.5 350 SMBus/I2C™ compatible interface, 1°C

temperature resolution 5-Pin SOT-23A, 5-Pin TO-220

TCN75A ±0.5 ±2 -40 to +125 +2.7 to +5.5 500

SMBus/I2C™ compatible interface, power-

saving one-shot temperature measurement,

multi-drop capability, 0.0625°C to 0.5°C

adjustable temperature resolution

8-Pin SOIC, 8-Pin MSOP

TCN75 ±0.5 ±2 -55 to +125 +2.7 to +5.5 1,000(2) SMBus/I2C™ compatible interface, multi-

drop capability, interrupt output, 0.5°C

temperature resolution 8-Pin MSOP, 8-Pin SOIC

THERMAL MANAGEMENT PRODUCTS – Brushless DC Fan Controllers and Fan Fault Detectors

Part # Description Typical Accuracy

(°C) Maximum Accuracy

@ 25°C (°C)

Maximum

Temperature Range

(°C) Vcc Range (V) Maximum Supply

Current (μA) Features Packages

TC642 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 FanSense™ Fan Monitor,

minimum fan speed control 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC642B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400 FanSense™ Fan Monitor,

minimum fan speed control, fan

auto-restart

8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC646 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 FanSense™ Fan Monitor,

auto-shutdown 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC646B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400 FanSense™ Fan Monitor,

auto-shutdown, fan auto-restart 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC647 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 FanSense™ Fan Monitor,

minimum fan speed control 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC647B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400 FanSense™ Fan Monitor,

minimum fan speed control, fan

auto-restart

8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

NOTE 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor.

THERMAL MANAGEMENT PRODUCTS – Temperature Sensors (continued)

Part # Typical Accuracy

(°C) Maximum Accuracy

@ 25°C (°C)

Maximum

Temperature Range

(°C) VCC Range (V) Maximum Supply

Current (μA) Features Packages

NOTE 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor.

2: TCN75 idle current is 250 μA. This device also has a Software Shutdown mode that reduces supply current to <1 μA.

3: MCP9805 max. accuracy measured at 85°C.

PAGE 11

Analog/Interface

Family Products

TC648 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 Over-temperature alert,

auto-shutdown 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC648B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400 Over-temperature alert,

auto-shutdown, fan auto-restart 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC649 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 FanSense™ Fan Monitor,

auto-shutdown 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC649B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400 FanSense™ Fan Monitor,

auto-shutdown, fan auto-restart 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

TC650 Fan Manager ±1 ±3 -40 to +125 +2.8 to +5.5 90 Over-temperature alert 8-Pin MSOP

TC651 Fan Manager ±1 ±3 -40 to +125 +2.8 to +5.5 90 Over-temperature alert,

auto-shutdown 8-Pin MSOP

TC652 Fan Manager ±1 ±3 -40 to +125 +2.8 to +5.5 90 FanSense™ Fan Monitor,

over-temperature alert 8-Pin MSOP

TC653 Fan Manager ±1 ±3 -40 to +125 +2.8 to +5.5 90 FanSense™ Fan Monitor,

over-temperature alert,

auto-shutdown 8-Pin MSOP

TC654 Dual SMBus Fan

Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 320 FanSense™ Fan Monitor,

RPM data 10-Pin MSOP

TC655 Dual SMBus Fan

Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 320 FanSense™ Fan Monitor, RPM

data, over-temperature alert 10-Pin MSOP

TC664 Single SMBus Fan

Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 320 FanSense™ Fan Monitor,

RPM data 10-Pin MSOP

TC665 Single SMBus Fan

Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 320 FanSense™ Fan Monitor, RPM

data, over-temperature alert 10-Pin MSOP

TC670 Predictive Fan Fault

Detector N/A N/A -40 to +85 +3.0 to +5.5 150 FanSense™ Fan Monitor,

programmable threshold 6-Pin SOT-23

POWER MANAGEMENT – Voltage References

Part # Vcc Range (V) Output Voltage (V) Max. Load Current (mA) Initial Accuracy

(max.%) Temperature

Coefficient (ppm/°C) Max. Supply Current

(μA @ 25°C) Packages

MCP1525 2.7 to 5.5 2.5 ±2 ±1 50 100 3-Pin TO-92, 3-Pin SOT-23B

MCP1541 4.3 to 5.5 4.096 ±2 ±1 50 100 3-Pin TO-92, 3-Pin SOT-23B

THERMAL MANAGEMENT PRODUCTS – Brushless DC Fan Controllers and Fan Fault Detectors (continued)

Part # Description Typical Accuracy

(°C) Maximum Accuracy

@ 25°C (°C)

Maximum

Temperature Range

(°C) Vcc Range (V) Maximum Supply

Current (μA) Features Packages

NOTE 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor.

PAGE 12

Analog/Interface

Family Products

POWER MANAGEMENT – Linear Regulators

Part # Max. Input

Voltage (V) Output Voltage (V) Output

Current (mA)

Junction

Temperature

Range (°C)

Typical

Active

Current (μA)

Typical Dropout

Voltage @ Max.

IOUT (mV)

Typical Output

Voltage

Accuracy (%) Features Packages

50 mA to 250 mA Low Dropout Linear Regulators

TC2014 6.0 1.8, 2.7, 2.8, 3.0, 3.3 50 -40 to +125 55 45 ±0.4 Shutdown, Reference bypass input 5-Pin SOT-23A

TC1014 6.0 1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0 50 -40 to +125 50 85 ±0.5 Shutdown, Reference bypass input 5-Pin SOT-23A

TC2054 6.0 1.8, 2.7, 2.8, 3.0, 3.3 50 -40 to +125 55 45 ±0.4 Shutdown, Error output 5-Pin SOT-23A

TC1054 6.0 1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0 50 -40 to +125 50 85 ±0.5 Shutdown, Error output 5-Pin SOT-23A

TC1070 6.0 1.23 → VIN 50 -40 to +125 50 85 — Shutdown, Adjustable 5-Pin SOT-23A

TC1072 6.0 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0 50 -40 to +125 50 85 ±0.5 Shutdown, Reference bypass

input, Error output 6-Pin SOT-23A

TC1223 6.0 2.5, 2.7, 2.8, 3.0, 3.3, 3.6, 4.0, 5.0 50 -40 to +125 50 85 ±0.5 Shutdown 5-Pin SOT-23A

TC1016 6.0 1.8, 2.7, 2.8, 3.0 80 -40 to +125 50 150 ±0.5 Shutdown 5-Pin SC-70

TC2015 6.0 1.8, 2.7, 2.8, 3.0, 3.3 100 -40 to +125 55 90 ±0.4 Shutdown, Reference bypass input 5-Pin SOT-23A

TC1015 6.0 1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0 100 -40 to +125 50 180 ±0.5 Shutdown, Reference bypass input 5-Pin SOT-23A

TC2055 6.0 1.8, 2.7, 2.8, 3.0, 3.3 100 -40 to +125 55 90 ±0.4 Shutdown, Error output 5-Pin SOT-23A

TC1055 6.0 1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0 100 -40 to +125 50 180 ±0.5 Shutdown, Error output 5-Pin SOT-23A

TC1071 6.0 1.23 → VIN 100 -40 to +125 50 180 — Shutdown, Adjustable 5-Pin SOT-23A

TC1073 6.0 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0 100 -40 to +125 50 180 ±0.5 Shutdown, Reference bypass

input, Error output 6-Pin SOT-23A

TC1224 6.0 2.5, 2.7, 2.8, 3.0, 3.3, 3.6, 4.0, 5.0 100 -40 to +125 50 180 ±0.5 Shutdown 5-Pin SOT-23A

TC1188 6.0 1.8, 2.8, 2.84, 3.15 120 -40 to +125 50 130 ±0.5 Shutdown 5-Pin SOT-23A

TC1189 6.0 1.8, 2.8, 2.84, 3.15 120 -40 to +125 50 130 ±0.5 Shutdown 5-Pin SOT-23A

TC2185 6.0 1.8, 2.7, 2.8, 3.0, 3.3 150 -40 to +125 55 140 ±0.4 Shutdown, Reference bypass input 5-Pin SOT-23A

TC1185 6.0 1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0 150 -40 to +125 50 270 ±0.5 Shutdown, Reference bypass input 5-Pin SOT-23A

TC2186 6.0 1.8, 2.7, 2.8, 3.0, 3.3 150 -40 to +125 55 140 ±0.4 Shutdown, Error output 5-Pin SOT-23A

TC1186 6.0 1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0 150 -40 to +125 50 270 ±0.5 Shutdown, Error output 5-Pin SOT-23A

TC1187 6.0 1.23 → VIN 150 -40 to +125 50 270 —Shutdown, Adjustable 5-Pin SOT-23A

TC1017 6.0 1.8, 2.6, 2.7, 2.8, 2.85, 2.9, 3.3, 3.4 150 -40 to +125 53 285 +0.5 Shutdown 5-Pin SOT-23A, 5-Pin SC-70

MCP1700 6.0 1.2, 1.8, 2.5, 3.0, 3.3, 5.0 250 -40 to +125 1.0 300 +0.4 1.0 μF ceramic cap stable,

Short-circuit protection 3-Pin TO-92, 3-Pin

SOT-23A, 3-Pin SOT-89

MCP1701 10 1.8, 2.5, 3.0, 3.3, 5.0 250 -40 to +85 1.1 380 +0.5 10V max. input voltage 3-Pin SOT-23A, 3-Pin

SOT-89, 3-Pin TO-92

NOTE 1: Depending on external transistor configuration.

2: Each channel (for Dual and Quad LDOs).

3: LDOs with shutdown (except Power-Management Combination Products as indicated) have typical shutdown currents of 0.05 μA.

PAGE 13

Analog/Interface

Family Products

300 mA Low Dropout Linear Regulators

TC1107 6.0 2.5, 2.7, 2.8, 3.0, 3.3, 5.0 300 -40 to +125 50 240 ±0.5 Shutdown, Reference bypass input 8-Pin MSOP, 8-Pin SOIC

TC1108 6.0 2.5, 2.7, 2.8, 3.0, 3.3, 5.0 300 -40 to +125 50 240 ±0.5 3-Pin SOT-223

TC1173 6.0 2.5, 2.7, 2.8, 3.0, 3.3, 5.0 300 -40 to +125 50 240 ±0.5 Shutdown, Reference bypass

input, Error output 8-Pin MSOP, 8-Pin SOIC

TC1174 6.0 1.23 → VIN 300 -40 to +125 50 240 —Shutdown, Reference bypass

input, Adjustable 8-Pin MSOP, 8-Pin SOIC

TC1269 6.0 2.5, 2.8, 3.0, 3.3, 5.0 300 -40 to +125 50 240 ±0.5 Shutdown, Reference bypass input 8-Pin MSOP

500 mA to 800 mA Low Dropout Linear Regulators

TC1262 6.0 2.5, 2.8, 3.0, 3.3, 5.0 500 -40 to +125 80 350 ±0.5 3-Pin TO-220, 3-Pin DDPAK,

3-Pin SOT-223

TC1263 6.0 2.5, 2.8, 3.0, 3.3, 5.0 500 -40 to +125 80 350 ±0.5 Shutdown, Reference bypass

input, Error output 8-Pin SOIC, 5-Pin

TO-220, 5-Pin DDPAK

TC1268 6.0 2.5 500 -40 to +125 80 350 ±0.5 Shutdown, Reference bypass

input, Error output 8-Pin SOIC

TC1264 6.0 1.8, 2.5, 3.0, 3.3 800 -40 to +125 80 450 ±0.5 3-Pin TO-220, 3-Pin DDPAK,

3-Pin SOT-223

TC1265 6.0 1.8, 2.5, 3.0, 3.3 800 -40 to +125 80 450 ±0.5 Shutdown, Reference bypass

input, Error output 8-Pin SOIC, 5-Pin

TO-220, 5-Pin DDPAK

TC2117 6.0 1.8, 2.5, 3.0, 3.3 800 -40 to +125 80 600 ±0.5 3-Pin SOT-223, 3-Pin DDPAK

1A and Above Low Dropout Linear Regulators

MCP1726 6.0 Fixed: 5, 3.3, 3, 2.5, 1.8, 1.2, 0.8

Adjustable: 0.8 to 5.0 1000 -40 to +125 140 300 ±0.4 Ceramic output capacitor stable,

Shutdown, Cdelay, Power-Good 8-Pin 3x3 DFN, 8-Pin SOIC

Application Specific Low Dropout Linear Regulators

TC1266 6.0 3.3 200 -5 to +70 230 200 ±1.0 PCI compliant 8-Pin SOIC, 8-Pin MSOP

TC1267 6.0 3.3 400 -5 to +70 230 300 ±1.0 PCI compliant 5-Pin DDPAK

TC57 82.5, 3.0, 3.3 4,000(1) -40 to +85 50 100(1) ±2.0 Shutdown, External transistor 5-Pin SOT-23A

TC59 -10 -3.0, -5.0 100 -40 to +85 3 380 ±0.5 Negative LDO 3-Pin SOT-23A

Power Management Combination Products

TC1300(3) 6.0 2.5, 2.7, 2.8, 2.85, 3.0, 3.3 300 -40 to +125 80 210 ±0.5 Shutdown, Reference bypass

input, LDO plus Reset output 8-Pin MSOP

TC1301A(3) 6.0 LDO1: 1.5-3.3

LDO2: 1.5-3.3 LDO1: 300

LDO2: 150 -40 to +125 103 LDO1: 104

LDO2: 150 ±0.5 Dual LDO plus Reset output,

Shutdown, Reference bypass,

Voltage detect 8-Pin MSOP, 8-Pin 3x3 DFN

TC1301B(3) 6.0 LDO1: 1.5-3.3

LDO2: 1.5-3.3 LDO1: 300

LDO2: 150 -40 to +125 114 LDO1: 104

LDO2: 150 ±0.5 Dual LDO plus Reset, per channel

output shutdown, Reference bypass 8-Pin MSOP, 8-Pin 3x3 DFN

TC1302A(3) 6.0 LDO1: 1.5-3.3

LDO2: 1.5-3.3 LDO1: 300

LDO2: 150 -40 to +125 103 LDO1: 104

LDO2: 150 ±0.5 Dual LDO, Output shutdown

reference bypass, Voltage detect 8-Pin MSOP, 8-Pin 3x3 DFN

POWER MANAGEMENT – Linear Regulators (continued)

Part # Max. Input

Voltage (V) Output Voltage (V) Output

Current (mA)

Junction

Temperature

Range (°C)

Typical

Active

Current (μA)

Typical Dropout

Voltage @ Max.

IOUT (mV)

Typical Output

Voltage

Accuracy (%) Features Packages

NOTE 1: Depending on external transistor configuration.

2: Each channel (for Dual and Quad LDOs).

3: LDOs with shutdown (except Power-Management Combination Products as indicated) have typical shutdown currents of 0.05 μA.

PAGE 14

Analog/Interface

Family Products

Power-Management Combination Products (continued)

TC1302B(3) 6.0 LDO1: 1.5-3.3

LDO2: 1.5-3.3 LDO1: 300

LDO2: 150 -40 to +125 114 LDO1: 104

LDO2: 150 ±0.5 Dual LDO, per channel output

shutdown, Reference bypass 8-Pin MSOP, 8-Pin 3x3 DFN

TC1305 6.0 2.5, 2.8, 3.0 150(2) -40 to +125 120 240 ±0.5

Dual LDO plus Reset output,

Reference bypass input, Shutdown,

Select Mode™ selectable output

voltages

10-Pin MSOP

TC1306 6.0 1.8, 2.8, 3.0 150(2) -40 to +125 120 240 ±0.5 Dual LDO plus Reset output,

Shutdown, Select Mode™

selectable output voltages 8-Pin MSOP

TC1307(3) 6.0 1.8, 2.5, 2.8, 3.0 150(2) -40 to +125 220 200 ±0.5 Quad LDO plus Reset output,

Shutdown, Select Mode™

selectable output voltage 16-Pin QSOP

POWER MANAGEMENT – Switching Regulators

Part # Description Input

Voltage

Range (V)

Output Voltage

(V)

Operating

Temperature

Range (°C) Control Scheme Switching

Frequency

(kHz)

Typical

Active

Current (μA)

Output Current

(mA) Features Packages

MCP1601 Synchronous Buck Regulator 2.7 to 5.5 0.9V to VIN -40 to +85 PFM/PWM/LDO 750 825 (PWM)

125 (PFM) 500 UVLO, Auto-switching, LDO 8-Pin MSOP

MCP1612 Synchronous Buck DC/DC

Regulator 2.7 to ViN0.8 to 5.5 -40 to +85 Constant frequency

PWM 1400 10,000 1000 Overall efficiency >94% soft start, over-

temperature and over-current protection 8-Pin MSOP,

8-Pin 3x3 DFN

MCP1650 Step-up DC/DC Controller 2.7 to 5.5 2.5 to ext. tx

limited -40 to +125 Constant frequency,

2 fixed DC 750 120 560/440 2 duty cycles for min. and max. loads, shutdown

control, UVLO, soft start 8-Pin MSOP

MCP1651 Step-up DC/DC Controller 2.7 to 5.5 2.5 to ext. tx

limited -40 to +125 Constant frequency,

2 fixed DC 750 120 560/440 2 duty cycles for min. and max. loads, shutdown

control, low battery detect, UVLO, soft start 8-Pin MSOP

MCP1652 Step-up DC/DC Controller 2.7 to 5.5 2.5 to ext. tx

limited -40 to +125 Constant frequency,

2 fixed DC 750 120 560/440 2 duty cycles for min. and max. loads, shutdown

control, power-good indicator, UVLO, soft start 8-Pin MSOP

MCP1653 Step-up DC/DC Controller 2.7 to 5.5 2.5 to ext. tx

limited -40 to +125 Constant frequency,

2 fixed DC 750 120 560/440 2 duty cycles for min. and max. loads, shutdown

control, low battery detect, power-good

indicator, UVLO, soft start 10-Pin MSOP

TC105 Step-down DC/DC Controller 2.2 to 10 3.0, 3.3, 5.0 -40 to +85 PFM/PWM 300 57 1,000 Low-Power Shutdown mode 5-Pin SOT-23A

TC120 Step-down Regulator/

Controller Combination 1.8 to 10 3.0, 3.3, 5.0 -40 to +85 PFM/PWM 300 52 2,000 Soft-start, Low-Power Shutdown mode 8-Pin SOP

TC125 Step-up DC/DC Regulator 0.9 to 10 3.0, 3.3, 5.0 -40 to +85 PFM 100 20 80 Low-Power Shutdown mode 5-Pin SOT-23A

TC126 Step-up DC/DC Regulator 0.9 to 10 3.0, 3.3, 5.0 -40 to +85 PFM 100 20 80 Feedback voltage sensing 5-Pin SOT-23A

TC115 Step-up DC/DC Regulator 0.9 to 10 3.0, 3.3, 5.0 -40 to +85 PFM/PWM 100 80 140 Feedback voltage sensing, Low-Power

Shutdown mode 5-Pin SOT-89

TC110 Step-up DC/DC Controller 2.0 to 10 3.0, 3.3, 5.0 -40 to +85 PFM/PWM 100/300 50/120 300 Soft-start, Low-Power Shutdown mode 5-Pin SOT-23A

TC1303 Synchronous Buck Regulator,

LDO w/Power Good 2.7 to 5.5 DC/DC: 0.8 to 4.5

LDO: 1.5 to 3.3 -40 to +85 PFM/PWM 2000 65/600 DC/DC: 500 mA

LDO: 300 mA PFM/PWM auto-switching, Power Good output 10-Pin MSOP

10-Pin 3x3 DFN

POWER MANAGEMENT – Linear Regulators (continued)

Part # Max. Input

Voltage (V) Output Voltage (V) Output

Current (mA)

Junction

Temperature

Range (°C)

Typical

Active

Current (μA)

Typical Dropout

Voltage @ Max.

IOUT (mV)

Typical Output

Voltage

Accuracy (%) Features Packages

NOTE 1: Depending on external transistor configuration.

2: Each channel (for Dual and Quad LDOs).

3: LDOs with shutdown (except Power-Management Combination Products as indicated) have typical shutdown currents of 0.05 μA.

PAGE 15

Analog/Interface

Family Products

TC1304 Synchronous Buck Regulator,

LDO 2.7 to 5.5 DC/DC: 0.8 to 4.5

LDO: 1.5 to 3.3 -40 to +85 PFM/PWM 2000 65/600 DC/DC: 500 mA

LDO: 300 mA PFM/PWM auto-switching, Power sequencing 10-Pin MSOP

10-Pin 3x3 DFN

TC1313 Synchronous Buck Regulator,

LDO 2.7 to 5.5 DC/DC: 0.8 to 4.5

LDO: 1.5 to 3.3 -40 to +85 PFM/PWM 2000 65/600 DC/DC: 500 mA

LDO: 300 mA PFM/PWM auto-switching 10-Pin MSOP

10-Pin 3x3 DFN

POWER MANAGEMENT – PWM Controllers

Part # Description Input Voltage

Range (V) Output

Voltage (V)

Operating

Temperature

Range (°C)

Control

Scheme

Switching

Frequency

(kHz)

Typical

Active

Supply (μA)

Output

Current (mA) Features Packages

MCP1630 High-speed PWM to use with

PIC® MCUs 2.7 to 5.5 VSS + 0.2V

VDD – 0.2V -40 to +125 Cycle-by-

Cycle DC

control 1000 2.5 +10 UVLO, current sense to VEXT, response <25 ns 8-Pin MSOP

MCP1630V High-speed PWM to use with

PIC® MCUs 2.7 to 5.5 VSS + 0.2V

VDD – 0.2V -40 to +125 Cycle-by-

Cycle DC

control 1000 2.5 +10 Voltage mode and Average Current mode 8-Pin MSOP

POWER MANAGEMENT – Charge Pump DC-to-DC Converters

Part # Input Voltage Range

(V) Output Voltage (V) Operating

Temperature

Range (°C)

Maximum Input

Current(1) (μA)

Typical Active

Output Current (mA) Features Packages

Inverting or Doubling Charge Pumps

TC1044S 1.5 to 12 VOUT = -VIN or VOUT = 2 VIN -40 to +85 160 20 85 kHz oscillator, Boost mode 8-Pin PDIP, 8-Pin SOIC

TC7660 1.5 to 10 VOUT = -VIN or VOUT = 2 VIN -40 to +85 180 20 10 kHz oscillator 8-Pin PDIP, 8-Pin SOIC

TC7660H 1.5 to 10 VOUT = -VIN or VOUT = 2 VIN -40 to +85 1,000 20 120 kHz oscillator 8-Pin PDIP, 8-Pin SOIC

TC7660S 1.5 to 12 VOUT = -VIN or VOUT = 2 VIN -40 to +85 160 20 45 kHz oscillator, Boost mode 8-Pin PDIP, 8-Pin SOIC

TC7662B 1.5 to 15 VOUT = -VIN or VOUT = 2 VIN -40 to +85 180 20 35 kHz oscillator, Boost mode 8-Pin PDIP, 8-Pin SOIC

TC1219 1.5 to 5.5 VOUT = -VIN or VOUT = 2 VIN -40 to +85 115 25 12 kHz oscillator, Low-Power Shutdown mode 6-Pin SOT-23A

TC1220 1.5 to 5.5 VOUT = -VIN or VOUT = 2 VIN -40 to +85 325 25 35 kHz oscillator, Low-Power Shutdown mode 6-Pin SOT-23A

TC1221 1.8 to 5.5 VOUT = -VIN or VOUT = 2 VIN -40 to +85 600 25 Shutdown, 125 kHz oscillator 6-Pin SOT-23A

TC1222 1.8 to 5.5 VOUT = -VIN or VOUT = 2 VIN -40 to +85 2,800 25 Shutdown, 750 kHz oscillator 6-Pin SOT-23A

TCM828 1.5 to 5.5 VOUT = -VIN or VOUT = 2 VIN -40 to +85 90 25 12 kHz oscillator 5-Pin SOT-23A

TCM829 1.5 to 5.5 VOUT = -VIN or VOUT = 2 VIN -40 to +85 260 25 35 kHz oscillator 5-Pin SOT-23A

TC1240 2.5 to 4.0 VOUT = 2 VIN -40 to +85 900 40 Shutdown, 160 kHz oscillator 6-Pin SOT-23A

TC1240A 2.5 to 5.5 VOUT = 2 VIN -40 to +85 900 40 Shutdown, 160 kHz oscillator 6-Pin SOT-23A

TC7662A 3 to 18 VOUT = -VIN or VOUT = 2 VIN -40 to +85 200 40 12 kHz oscillator 8-Pin PDIP

TC962 3 to 18 VOUT = -VIN or VOUT = 2 VIN -40 to +85 200 80 8-Pin PDIP, 16-Pin SOIC

TC1121 2.4 to 5.5 VOUT = -VIN or VOUT = 2 VIN -40 to +85 100 100 Low-Power Shutdown mode 8-Pin MSOP, 8-Pin PDIP,

8-Pin SOIC

NOTE 1: Measured at VDD = 5.0V at 25°C and no load.

POWER MANAGEMENT – Switching Regulators (continued)

Part # Description Input

Voltage

Range (V)

Output Voltage

(V)

Operating

Temperature

Range (°C) Control Scheme Switching

Frequency

(kHz)

Typical

Active

Current (μA)

Output Current

(mA) Features Packages

PAGE 16

Analog/Interface

Family Products

Multi-Function Charge Pumps

TCM680 2.0 to 5.5 VOUT = ±2 VIN -40 to +85 1,000 ±10 Generates ±6V from +3V or ±10V from +5V 8-Pin PDIP, 8-Pin SOIC

Inverting and Doubling Charge Pumps

TC682 2.4 to 5.5 VOUT = -2 VIN -40 to +85 400 10 12 kHz oscillator 8-Pin PDIP, 8-Pin SOIC

Regulated Charge Pumps

MCP1252 2.1/2.7 to 5.5

2.0 to 5.5 Selectable 3.3V or 5.0V or

Adjustable 1.5V to 5.5V -40 to +85 120 120 mA for VIN>3.0V Power-Good output, 650 kHz oscillator 8-Pin MSOP

MCP1253 2.1/2.7 to 5.5

2.0 to 5.5 Selectable 3.3V or 5.0V or

Adjustable 1.5V to 5.5V -40 to +85 120 120 mA for VIN>3.0V Power-Good output, 1 MHz oscillator 8-Pin MSOP

POWER MANAGEMENT – CPU/System Supervisors

Part # VCC Range

(V)

Operating

Temperature Range

(°C) Nominal Reset Voltage (V) Reset Type Output Typical

Reset Pulse

Width (ms)

Typical

Supply

Current

(μA)

Additional

Features Packages Bond

Options

MCP102 1.0 to 5.5 -40 to +125 4.63, 4.38, 3.08, 2.93, 2.63, 2.32, 1.9 Active Low CMOS Push-Pull 120 13-Pin SOT-23B, 3-Pin SC-70,

3-Pin TO-92 N/A

MCP103 1.0 to 5.5 -40 to +125 4.63, 4.38, 3.08, 2.93, 2.63, 2.32, 1.9 Active Low CMOS Push-Pull 120 1 Max. 809 Pinout 3-Pin SOT-23B, 3-Pin SC-70,

3-Pin TO-92 N/A

TC1272 1.2 to 5.5 -40 to +85 4.62, 4.37, 4.12 Active Low CMOS Push-Pull 200 17 3-Pin SOT-23B N/A

TC1275 1.2 to 5.5 -40 to +85 3.06, 2.88, 2.55 Active Low CMOS Push-Pull 200 20 3-Pin SOT-23B N/A

TCM809 1.2 to 5.5 -40 to +85 4.63, 4.38, 4.00, 3.08, 2.93, 2.63, 2.32 Active Low CMOS Push-Pull 240 12 3-Pin SOT-23B, 3-Pin SC-70 N/A

TC1270 1.2 to 5.5 -40 to +85 4.63, 4.38, 3.08, 2.93, 2.63, 1.75 Active Low CMOS Push-Pull 280 7 Manual Reset 4-Pin SOT-143 N/A

TCM811 1.0 to 5.5 -40 to +85 4.63, 4.38, 3.08, 2.93, 2.63, 1.75 Active Low CMOS Push-Pull 280 6Manual Reset 4-Pin SOT-143 N/A

MCP100 1.0 to 5.5 -40 to +85 4.72, 4.62, 4.47, 4.37, 3.075, 2.92, 2.62 Active Low CMOS Push-Pull 350 45 3-Pin TO-92, 3-Pin SOT-23B D, H

MCP809 1.0 to 5.5 -40 to +85 4.72, 4.62, 4.47, 4.37, 3.075, 2.92, 2.62 Active Low CMOS Push-Pull 350 45 3-Pin SOT-23B N/A

TC1274 1.8 to 5.5 -40 to +85 4.62, 4.37, 4.13 Active High CMOS Push-Pull 200 17 3-Pin SOT-23B N/A

TC1277 1.8 to 5.5 -40 to +85 3.06, 2.88, 2.55 Active High CMOS Push-Pull 200 20 3-Pin SOT-23B N/A

TCM810 1.2 to 5.5 -40 to +85 4.63, 4.38, 3.08, 2.93, 2.63, 2.32 Active High CMOS Push-Pull 240 12 3-Pin SOT-23B, 3-Pin SC-70 N/A

TC1271 1.2 to 5.5 -40 to +85 4.63, 4.38, 3.08, 2.93, 2.63, 1.75 Active High CMOS Push-Pull 280 7Manual Reset 4-Pin SOT-143 N/A

TCM812 1.1 to 5.5 -40 to +85 4.63, 4.38, 3.08, 2.93, 2.63, 1.75 Active High CMOS Push-Pull 280 6 Manual Reset 4-Pin SOT-143 N/A

MCP101 1.0 to 5.5 -40 to +85 4.72, 4.62, 4.47, 4.37, 3.075, 2.92, 2.62 Active High CMOS Push-Pull 350 45 3-Pin TO-92, 3-Pin SOT-23B D, H

MCP810 1.0 to 5.5 -40 to +85 4.72, 4.62, 4.47, 4.37, 3.075, 2.92, 2.62 Active High CMOS Push-Pull 350 45 3-Pin SOT-23B N/A

MCP121 1.0 to 5.5 -40 to +125 1.9, 2.32, 2, 63, 2.93, 3.08, 4.38, 4.63 Active Low Open-drain 120 13-Pin SOT-23B, 3-Pin SC-70,

3-Pin TO-92 N/A

TC1273 1.2 to 5.5 -40 to +85 4.62, 4.37, 4.12 Active Low Open-drain 200 17 3-Pin SOT-23B N/A

TC1276 1.2 to 5.5 -40 to +85 3.06, 2.88, 2.55 Active Low Open-drain 200 20 3-Pin SOT-23B N/A

POWER MANAGEMENT – Charge Pump DC-to-DC Converters (continued)

Part # Input Voltage Range

(V) Output Voltage (V) Operating

Temperature

Range (°C)

Maximum Input

Current(1) (μA)

Typical Active

Output Current (mA) Features Packages

NOTE 1: Measured at VDD = 5.0V at 25°C and no load.

PAGE 17

Analog/Interface

Family Products

MCP120 1.0 to 5.5 -40 to +85 4.72, 4.62, 4.47, 4.37, 3.075, 2.92, 2.62 Active Low Open-drain 350 45 3-Pin TO-92, 3-Pin SOT-23, 8-Pin SOIC D, G, H

TC1279 1.2 to 5.5 -40 to +85 4.62, 4.37, 4.125 Active Low Open-drain 350 900 3-Pin SOT-23B N/A

MCP131 1.0 to 5.5 -40 to +125 1.9, 2.32, 2, 63, 2.93, 3.08, 4.38, 4.63 Active Low Open-drain 120 1 100kΩ Internal

Pull-up Resistor 3-Pin SOT-23B, 3-Pin SC-70,

3-Pin TO-92 N/A

MCP130 1.0 to 5.5 -40 to +85 4.72, 4.62, 4.47, 4.37, 3.075, 2.92, 2.62 Active Low Open-drain w/

5 kOhm Pull-up 350 45 3-Pin TO-92, 3-Pin SOT-23, 8-Pin SOIC D, F, H

TC1278 1.2 to 5.5 -40 to +85 4.62, 4.37, 4.125 Active High Open-drain 350 900 3-Pin SOT-23B N/A

TC1232 4.5 to 5.5 -40 to +85 4.62, 4.37 Active Low/High Open-drain 610 50 Watchdog Timer 8-Pin PDIP, 8-Pin SOIC, 16-Pin SOIC N/A

TC32M 4.5 to 5.5 -40 to +85 4.5 Active Low Open-drain 700 50 Watchdog Timer 3-Pin TO-92, 3-Pin SOT-223 N/A

POWER MANAGEMENT – Voltage Detectors

Part # VCC Range

(V)

Operating

Temperature

Range (°C) Nominal Reset Voltage (V) Reset Type Output Minimum

Reset Pulse

Width (ms)

Typical Supply

Current (μA) Features Packages

MCP111 1.0 to 5.5 -40 to +125 4.63, 4.38, 3.08, 2.93, 2.63, 2.32, 1.90 Active Low Open-drain — 1 3-Pin SOT-23B, 3-Pin TO-92, 3-Pin SC-70,

3-Pin SOT-89

MCP112 1.0 to 5.5 -40 to +125 4.63, 4.38, 3.08, 2.93, 2.63, 2.32, 1.90 Active Low CMOS Push-Pull — 1 3-Pin SOT-23B, 3-Pin TO-92, 3-Pin SC-70,

3-Pin SOT-89

TC51 0.7 to 10 -40 to +85 3.0, 2.7, 2.2 Active Low Open-drain 50 1Reset delay 3-Pin SOT-23A

TC52 1.5 to 10 -40 to +85 4.5/2.7, 3.0/2.7 Active Low Open-drain — 2 Dual channel 5-Pin SOT-23A

TC53 1.5 to 10 -40 to +85 2.9, 2.7, 2.2 Active Low CMOS Push-Pull or

Open-drain — 1 5-Pin SOT-23A

TC54 0.7 to 10 -40 to +85 7.7, 4.3, 4.2, 3.0, 2.9, 2.7, 2.1, 1.4 Active Low CMOS Push-Pull or

Open-drain — 1 3-Pin SOT-23A, 3-Pin SOT-89, 3-Pin TO-92

POWER MANAGEMENT – Power MOSFET Drivers

Part # Configuration Operating

Temperature

Range (°C)

Peak Output

Current (A)

Output Resistance

(RH/RL)

(Max. Ω @ 25°C)

Max. Supply Voltage

(V) Input/Output Delay (td1, td2)(1)

(ns) Packages

Low-Side Drivers, 0.5A to 1.2A Peak Output Current

TC1410 Single, Inverting -40 to +85 0.5 22/22 16 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1410N Single, Non-inverting -40 to +85 0.5 22/22 16 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1411 Single, Inverting -40 to +85 111/11 16 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1411N Single, Non-inverting -40 to +85 1 11/11 16 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1426 Dual, Inverting 0 to +70 1.2 18/18 16 75/75 8-Pin PDIP, 8-Pin SOIC

NOTE 1: *tD1 = delay time from input low-to-high transition to output transition. tD2 = delay time from input high-to-low transition to output transition.

POWER MANAGEMENT – CPU/System Supervisors (continued)

Part # VCC Range

(V)

Operating

Temperature Range

(°C) Nominal Reset Voltage (V) Reset Type Output Typical

Reset Pulse

Width (ms)

Typical

Supply

Current

(μA)

Additional

Features Packages Bond

Options

PAGE 18

Analog/Interface

Family Products

Low-Side Drivers, 0.5A to 1.2A Peak Output Current (continued)

TC1427 Dual, Non-inverting 0 to +70 1.2 18/18 16 75/75 8-Pin PDIP, 8-Pin SOIC

TC1428 Dual, Inverting and Non-inverting 0 to +70 1.2 18/18 16 75/75 8-Pin PDIP, 8-Pin SOIC

TC4467 Quad, Inverting -40 to +85 1.2 15/15 18 40/40 14-Pin PDIP, 16-Pin SOIC (W)

TC4468 Quad, Non-inverting -40 to +85 1.2 15/15 18 40/40 14-Pin PDIP, 16-Pin SOIC (W)

TC4469 Quad, Non-inverting -40 to +85 1.2 15/15 18 40/40 14-Pin PDIP, 16-Pin SOIC (W)

Low-Side Drivers, 1.5A Peak Output Current

TC4403 Single, Non-inverting Floating Load

Driver -40 to +85 1.5 5/5 18 33/38 8-Pin PDIP

TC4426A Dual, Inverting -40 to +125 1.5 9/9 18 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin DFN

TC4427A Dual, Non-inverting -40 to +125 1.5 9/9 18 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin DFN

TC4428A Dual, Inverting and Non-inverting -40 to +125 1.5 9/9 18 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin DFN

TC4426 Dual, Inverting -40 to +125 1.5 10/10 18 20/40 8-Pin PDIP, 8-Pin SOIC, 8-Pin DFN, 8-Pin MSOP

TC4427 Dual, Non-inverting -40 to +125 1.5 10/10 18 20/40 8-Pin PDIP, 8-Pin SOIC, 8-Pin DFN, 8-Pin MSOP

TC4428 Dual, Inverting and Non-inverting -40 to +125 1.5 10/10 18 20/40 8-Pin PDIP, 8-Pin SOIC, 8-Pin DFN, 8-Pin MSOP

TC426 Dual, Inverting -40 to +85 1.5 15/10 18 50/75 8-Pin PDIP, 8-Pin SOIC

TC427 Dual, Non-inverting -40 to +85 1.5 15/10 18 50/75 8-Pin PDIP, 8-Pin SOIC

TC428 Dual, Inverting and Non-inverting -40 to +85 1.5 15/10 18 50/75 8-Pin PDIP, 8-Pin SOIC

TC4404 Dual, Inverting -40 to +85 1.5 10/10 18 15/32 8-Pin PDIP, 8-Pin SOIC

TC4405 Dual, Non-inverting -40 to +85 1.5 10/10 18 15/32 8-Pin PDIP, 8-Pin SOIC

Low-Side Drivers, 2.0A to 9.0A Peak Output Current

TC1412 Single, Inverting -40 to +85 26/6 16 35/35 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1412N Single, Non-inverting -40 to +85 2 6/6 16 35/35 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1413 Single, Inverting -40 to +85 34/4 16 35/35 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1413N Single, Non-inverting -40 to +85 3 4/4 16 35/35 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC4423 Dual, Inverting -40 to +125 35/5 18 33/38 8-Pin PDIP, 16-Pin SOIC (W), 8-Pin DFN

TC4424 Dual, Non-inverting -40 to +125 3 5/5 18 33/38 8-Pin PDIP, 16-Pin SOIC (W), 8-Pin DFN

TC4425 Dual, Inverting and Non-inverting -40 to +125 35/5 18 33/38 8-Pin PDIP, 16-Pin SOIC (W), 8-Pin DFN

TC429 Single, Inverting -40 to +85 6 2.5/2.5 18 53/60 8-Pin PDIP, 8-Pin DFN, 8-Pin SOIC

TC4420 Single, Non-inverting -40 to +125 62.8/2.5 18 55/55 8-Pin PDIP, 8-Pin SOIC, 5-Pin TO-220, 8-Pin DFN

TC4429 Single, Inverting -40 to +125 6 2.8/2.5 18 55/55 8-Pin PDIP, 8-Pin SOIC, 5-Pin TO-220, 8-Pin DFN

TC4421 Single, Inverting -40 to +125 91.4 (typ)/1.7 18 30/33 8-Pin PDIP, 5-Pin TO-220, 8-Pin DFN

TC4421A Single, Inverting -40 to +125 9 1.25 (typ)/1.5 18 38/42 8-Pin PDIP, 8-Pin SOIC, 5-Pin TO-220,

8-Pin 6x5 DFN

TC4422 Single, Non-inverting -40 to +125 91.4 (typ)/1.7 18 30/33 8-Pin PDIP, 5-Pin TO-220, 8-Pin DFN

POWER MANAGEMENT – Power MOSFET Drivers (continued)

Part # Configuration Operating

Temperature

Range (°C)

Peak Output

Current (A)

Output Resistance

(RH/RL)

(Max. Ω @ 25°C)

Max. Supply Voltage

(V) Input/Output Delay (td1, td2)(1)

(ns) Packages

NOTE 1: *tD1 = delay time from input low-to-high transition to output transition. tD2 = delay time from input high-to-low transition to output transition.

: : : + : : : :

PAGE 19

Analog/Interface

Family Products

Low-Side Drivers, 2.0A to 9.0A Peak Output Current (continued)

TC4422A Single, Non-inverting -40 to +125 9 1.25 (typ)/1.5 18 38/42 8-Pin PDIP, 8-Pin SOIC, 5-Pin TO-220,

8-Pin 6x5 DFN

High-Side/Low-Side Drivers

TC4626 Single, Inverting -40 to +85 1.5 15/10 635/45 8-Pin PDIP, 16-Pin SOIC (W)

TC4627 Single, Non-inverting -40 to +85 1.5 15/10 6 35/45 8-Pin PDIP, 16-Pin SOIC (W)

TC4431 Single, Inverting -40 to +85 1.5 10/10 30 62/78 8-Pin PDIP, 8-Pin SOIC

TC4432 Single, Non-inverting -40 to +85 1.5 10/10 30 62/78 8-Pin PDIP, 8-Pin SOIC

POWER MANAGEMENT – Battery Chargers

Part # Mode Cell Type # of Cells VCC Range (V) Max. Voltage

Regulation (%) Int/Ext FET Features Packages

MCP73826 Linear Li-Ion/Li-Polymer 14.5 to 5.5 +1.0 Ext Small size 6-Pin SOT-23

MCP73827 Linear Li-Ion/Li-Polymer 1 4.5 to 5.5 +1.0 Ext Mode indicator, Charge Current monitor 8-Pin MSOP

MCP73828 Linear Li-Ion/Li Polymer 14.5 to 5.5 +1.0 Ext Temperature monitor 8-Pin MSOP

MCP73831 Linear Li-Ion/Li-Polymer 1 3.7 to 6.0 +0.5 Int SOT-23 charger, UVLO, Thermal regulation, Programmable charge

current, 4.2, 4.35, 4.4 and 4.5V VREG options 5-Pin SOT-23,

8-Pin 2x3 DFN

MCP73841 Linear Li-Ion/Li-Polymer 14.5 to 12 +0.5 Ext Safety charge timers, Temperature monitor 10-Pin MSOP

MCP73842 Linear Li-Ion/Li-Polymer 2 8.7 to 12 +0.5 Ext Safety charge timers, Temperature monitor 10-Pin MSOP

MCP73843 Linear Li-Ion/Li-Polymer 14.5 to 12 +0.5 Ext Safety charge timers 8-Pin MSOP

MCP73844 Linear Li-Ion/Li-Polymer 2 8.7 to 12 +0.5 Ext Safety charge timers 8-Pin MSOP

MCP73853 Linear Li-Ion/Li-Polymer 14.5 to 5.5 +0.5 Int USB control, Safety charge timers, Temperature monitor, Thermal

regulation 16-Pin QFN (4x4)

MCP73855 Linear Li-Ion/Li-Polymer 1 4.5 to 5.5 +0.5 Int USB control, Safety charge timers, Thermal regulation 10-Pin DFN (3x3)

MCP73861 Linear Li-Ion/Li-Polymer 14.5 to 12 +0.5 Int Safety charge timers, Temperature monitor, Thermal regulation 16-Pin 4x4 QFN,

16-Pin SOIC

MCP73862 Linear Li-Ion/Li-Polymer 2 8.7 to 12 +0.5 Int Safety charge timers, Temperature monitor, Thermal regulation 16-pin 4x4 QFN,

16-Pin SOIC

POWER MANAGEMENT – Hot Swap Controllers

Part # Number of

Outputs

Vpos to Vneg

Differential

Voltage (V)

Junction

Temperature

Range (°C) OVLO UVLO Power Good Int/Ext FET Applications Packages

MCP18480 1-0.3 to +15.0 -40 to +85 Adjustable Adjustable Adjustable Ext -48V Telecom/Datacom, Bus/Backplane 20-Pin SSOP

POWER MANAGEMENT – Power MOSFET Drivers (continued)

Part # Configuration Operating

Temperature

Range (°C)

Peak Output

Current (A)

Output Resistance

(RH/RL)

(Max. Ω @ 25°C)

Max. Supply Voltage

(V) Input/Output Delay (td1, td2)(1)

(ns) Packages

NOTE 1: *tD1 = delay time from input low-to-high transition to output transition. tD2 = delay time from input high-to-low transition to output transition.

PAGE 20

Analog/Interface

Family Products

LINEAR – Op Amps

Part # # per Package GBWP IQ Typical

(μA) VOS Max

(mV)

Input Voltage

Noise Density

(nV/rtHz)

Operating Voltage

(V) Temp. Range

(°C) Features Packages

TC1034 190 kHz 61.5 125(1) 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output 5-Pin SOT-23A(R)

TC1035 1 90 kHz 6 1.5 125(1) 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output, Shutdown pin 6-Pin SOT-23A(R)

TC1029 290 kHz 12 1.5 125(1) 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin MSOP, 8-Pin SOIC

TC1030 4 90 kHz 5 1.5 125(1) 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output, Shutdown pins 16-Pin QSOP

MCP6041 114 kHz 0.6 3170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP,

5-Pin SOT-23(S)

MCP6042 2 14 kHz 0.6 3 170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6043 114 kHz 0.6 3170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6044 4 14 kHz 0.6 3 170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6141 1100 kHz 0.6 3170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, G>10 stable 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6142 2 100 kHz 0.6 3 170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, G>10 stable 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6143 1100 kHz 0.6 3170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, G>10 stable,

Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6144 4 100 kHz 0.6 3 170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, G>10 stable 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP606 1155 kHz 19 0.25 38(1) 2.5 to 5.5 -40 to +85 Rail-to-Rail Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP,

5-Pin SOT23(S)

MCP607 2 155 kHz 19 0.25 38(1) 2.5 to 5.5 -40 to +85 Rail-to-Rail Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP608 1155 kHz 19 0.25 38(1) 2.5 to 5.5 -40 to +85 Rail-to-Rail Output, Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP609 4 155 kHz 19 0.25 38(1) 2.5 to 5.5 -40 to +85 Rail-to-Rail Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP616 1190 kHz 19 0.15 32(1) 2.3 to 5.5 -40 to +85 Rail-to-Rail Output, PNP Input 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP617 2 190 kHz 19 0.15 32(1) 2.3 to 5.5 -40 to +85 Rail-to-Rail Output, PNP 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP618 1190 kHz 19 0.15 32(1) 2.3 to 5.5 -40 to +85 Rail-to-Rail Output, Chip Select, PNP Input 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP619 4 190 kHz 19 0.15 32(1) 2.3 to 5.5 -40 to +85 Rail-to-Rail Output, PNP Input 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6231 1300 kHz 20 552(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 5-Pin SC-70(U), 5-Pin SOT-23(S,R,U), 8-Pin PDIP,

8-Pin SOIC, 8-Pin MSOP

MCP6232 2 300 kHz 20 5 52(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6234 4300 kHz 20 552(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6241 1 550 kHz 50 5 45(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 5-Pin SC-70(U), 5-Pin SOT-23(S,R,U), 8-Pin PDIP,

8-Pin SOIC, 8-Pin MSOP

MCP6242 2550 kHz 50 545(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6244 4 550 kHz 50 5 45(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

Legend: S = Standard Pinout; R = Reverse Pinout; U = Alternative Pinout

NOTE 1: Values are typical at 1 kHz

2: Values are typical at 10 kHz

PAGE 21

Analog/Interface

Family Products

MCP6001 11 MHz 140 4.5 28(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 5-Pin SOT-23(U), 5-Pin SC-70(S,R,U)

MCP6002 2 1 MHz 140 4.5 28(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6004 41 MHz 140 4.5 28(1) 1.8 to 5.5 -40 to +125 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6271 1 2 MHz 170 3 20(1) 2.0 to 5.5 -40 to +125 Rail-to-Rail Input/Output 5-Pin SOT-23(S,R), 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

MCP6272 22 MHz 170 320(1) 2.0 to 5.5 -40 to +125 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6273 1 2 MHz 170 3 20(1) 2.0 to 5.5 -40 to +125 Rail-to-Rail Input/Output, Chip Select 5-Pin SOT-23(S), 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

MCP6274 42 MHz 170 320(1) 2.0 to 5.5 -40 to +125 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6275 2 2 MHz 150 3 20(1) 2.0 to 5.5 -40 to +125 Rail-to-Rail Input/Output, Dual connected,

Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP601 12.8 MHz 230 229(1) 2.7 to 5.5 -40 to +125 Rail-to-Rail Output 5-Pin SOT-23(S,R),8-Pin PDIP, 8-Pin SOIC,

8-Pin TSSOP,

MCP602 2 2.8 MHz 230 2 29(1) 2.7 to 5.5 -40 to +125 Rail-to-Rail Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP603 12.8 MHz 230 229(1) 2.7 to 5.5 -40 to +125 Rail-to-Rail Output, Chip Select 6-Pin SOT-23(S), 8-Pin PDIP, 8-Pin SOIC,

8-Pin TSSOP

MCP604 4 2.8 MHz 230 2 29(1) 2.7 to 5.5 -40 to +125 Rail-to-Rail Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6281 15 MHz 445 316(1) 2.2 to 5.5 -40 to +125 Rail-to-Rail Input/Output 5-Pin SOT-23(S,R), 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

MCP6282 2 5 MHz 445 3 16(1) 2.2 to 5.5 -40 to +125 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6283 15 MHz 445 316(1) 2.2 to 5.5 -40 to +125 Rail-to-Rail Input/Output, Chip Select 6-Pin SOT-23(S,R), 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

MCP6284 4 5 MHz 445 3 16(1) 2.2 to 5.5 -40 to +125 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6285 25 MHz 400 316(1) 2.2 to 5.5 -40 to +125 Rail-to-Rail Input/Output, Dual connected,

Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6291 1 10 MHz 1000 3 8.7(2) 2.4 to 5.5 -40 to +125 Rail-to-Rail Input/Output 5-Pin SOT-23(S,R), 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

MCP6292 210 MHz 1000 38.7(2) 2.4 to 5.5 -40 to +125 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6293 1 10 MHz 1000 3 8.7(2) 2.4 to 5.5 -40 to +125 Rail-to-Rail Input/Output, Chip Select 6-Pin SOT-23(S), 8-Pin PDIP, 8-Pin SOIC,

8-Pin MSOP

MCP6294 410 MHz 1000 38.7(2) 2.4 to 5.5 -40 to +125 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6295 2 10 MHz 1100 3 8.7(2) 2.4 to 5.5 -40 to +125 Rail-to-Rail Input/Output, Dual connected,

Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6021 110 MHz 1000 0.5 8.7(2) 2.5 to 5.5 -40 to +125 Rail-to-Rail Input/Output, 1/2 VCC VREF 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

LINEAR – Op Amps (continued)

Part # # per Package GBWP IQ Typical

(μA) VOS Max

(mV)

Input Voltage

Noise Density

(nV/rtHz)

Operating Voltage

(V) Temp. Range

(°C) Features Packages

Legend: S = Standard Pinout; R = Reverse Pinout; U = Alternative Pinout

NOTE 1: Values are typical at 1 kHz

2: Values are typical at 10 kHz

PAGE 22

Analog/Interface

Family Products

MCP6022 2 10 MHz 1000 0.5 8.7(2) 2.5 to 5.5 -40 to +125 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP6023 110 MHz 1000 0.5 8.7(2) 2.5 to 5.5 -40 to +125 Rail-to-Rail Input/Output, Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP6024 4 10 MHz 1000 0.5 8.7(2) 2.5 to 5.5 -40 to +125 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

LINEAR – High Precision Operational Amplifiers

Part # # per

Package GBWP IQ MAX (mA) Typical VOS

(μV) VOS Drift Max

(μV/°C) Operating Voltage

(V) Temp. Range (°C) Features Packages

Chopper Stabilized

TC7650 1 2.0 MHz 3.5 5 0.05 4.5 to 16 0 to 70 Single and Split Supply 8-Pin PDIP, 14-Pin PDIP

TC7652 10.4 MHz 3 5 0.05 5 to 16 0 to 70 Single and Split Supply, Low Noise 8-Pin PDIP, 14-Pin PDIP

Auto-Zero

TC913A/B 2 1.5 MHz 1.1 15 0.15/0.30 6.5 to 16 0 to 70 Single and Split Supply 8-Pin PDIP, 8-Pin SOIC

LINEAR – Programmable Gain Amplifiers (PGA)

Part # Channels -3dB BW (MHz) IQ Typ. VOS (μV) Operating Voltage (V) Temp. Range (°C) Features Packages

MCP6S21 12 to 12 1.1 mA 275 2.5 to 5.5 -40 to +85 SPI, 8 Gain Steps, Software Shutdown 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6S22 2 2 to 12 1.1 mA 275 2.5 to 5.5 -40 to +85 SPI, 8 Gain Steps, Software Shutdown 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6S26 62 to 12 1.1 mA 275 2.5 to 5.5 -40 to +85 SPI, 8 Gain Steps, Software Shutdown 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6S28 8 2 to 12 1.1 mA 275 2.5 to 5.5 -40 to +85 SPI, 8 Gain Steps, Software Shutdown 16-Pin PDIP, 16-Pin SOIC

MCP6S91 11 to 18 1.0 mA 4000 2.5 to 5.5 -40 to +125 SPI, 8 Gain Steps, Software Shutdown 8-Pin PDIP, 8-Pin SSOIC, 8-Pin MSOP

MCP6S92 2 1 to 18 1.0 mA 4000 2.5 to 5.5 -40 to +125 SPI, 8 Gain Steps, Software Shutdown 8-Pin PDIP, 8-Pin SSOIC, 8-Pin MSOP

MCP6S93 21 to 18 1.0 mA 4000 2.5 to 5.5 -40 to +125 SPI, 8 Gain Steps, Software Shutdown 10-Pin MSOP

LINEAR – Integrated Devices

Part # # of Op Amps per

Package # of Comparators per

Package IQ Typical (μA) VREF (V) Operating

Voltage (V) Temp. Range

(°C) Features Packages

TC1026C 1 1 12 1.2 1.8 to 5.5 -40 to +85 On-board VREF 8-Pin PDIP, 8-Pin MSOP, 8-Pin SOIC

TC1043C 2 2 16 1.2 1.8 to 5.5 -40 to +85 On-board VREF, Shutdown pin 16-Pin QSOP

LINEAR – Op Amps (continued)

Part # # per Package GBWP IQ Typical

(μA) VOS Max

(mV)

Input Voltage

Noise Density

(nV/rtHz)

Operating Voltage

(V) Temp. Range

(°C) Features Packages

Legend: S = Standard Pinout; R = Reverse Pinout; U = Alternative Pinout

NOTE 1: Values are typical at 1 kHz

2: Values are typical at 10 kHz

PAGE 23

Analog/Interface

Family Products

LINEAR – Comparators

Part # # per

Package VREF (V) Typical

Propagation

Delay (μs)

IQ Typical

(μA) VOS Max (mV) Operating

Voltage (V) Temp. Range

(°C) Features Packages

TC1027 41.2 418 51.8 to 5.5 -40 to +85 On-board VREF, Rail-to-Rail Input/Output 16-Pin PDIP, 16-Pin QSOP, 16-Pin SOIC

TC1037 1 — 4 4 5 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output 5-Pin SOT-23A(S)

TC1038 1 — 4 4 5 1.8 to 5.5 -40 to +85 Shutdown pin, Rail-to-Rail Input/Output 6-Pin SOT-23A(S)

TC1039 1 1.2 4 6 5 1.8 to 5.5 -40 to +85 On-board VREF, Rail-to-Rail Input/Output 6-Pin SOT-23A(S)

TC1041 21.2 410 51.8 to 5.5 -40 to +85 On-board VREF, Programmable hysteresis, Rail-to-Rail

Input/Output 8-Pin MSOP, 8-Pin SOIC

MCP6541 1 — 4 1 5 1.6 to 5.5 -40 to +85 Push-Pull, Rail-to-Rail Input/Output 5-Pin SOT-23(S,R), 5-Pin SC-70(S),

8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6542 2 — 4 1 5 1.6 to 5.5 -40 to +85 Push-Pull, Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6543 1 — 4 1 5 1.6 to 5.5 -40 to +85 Push-Pull, Rail-to-Rail Input/Output, Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6544 4 — 4 1 5 1.6 to 5.5 -40 to +85 Push-Pull, Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6546 1 — 4 1 5 1.6 to 5.5 -40 to +85 Open-drain, 9V, Rail-to-Rail Input/Output 5-Pin SOT-23(S,R), 5-Pin SC-70(S),

8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6547 2 — 4 1 5 1.6 to 5.5 -40 to +85 Open-drain, 9V, Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6548 1 — 4 1 5 1.6 to 5.5 -40 to +85 Open-drain, 9V, Rail-to-Rail Input/Output, Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6549 4 — 4 1 5 1.6 to 5.5 -40 to +85 Open-drain, 9V, Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

Legend: S = Standard Pinout; R = Reverse Pinout

MIXED SIGNAL – Successive Approximation Register (SAR) A/D Converters

Part # Resolution

(bits)

Maximum

Sampling Rate

(ksamples/sec)

# of Input

Channels Input Type Interface Input Voltage

Range

(V)

Max. Supply

Current

(μA) Max. INL Temp. Range

(°C) Packages

MCP3021 10 22 1Single-ended I2C2.7 to 5.5 250 +1 LSB -40 to +125 5-Pin SOT-23A

MCP3001 10 200 1 Single-ended SPI 2.7 to 5.5 500 ±1 LSB -40 to +85 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP3002 10 200 2Single-ended SPI 2.7 to 5.5 650 ±1 LSB -40 to +85 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP3004 10 200 4 Single-ended SPI 2.7 to 5.5 550 ±1 LSB -40 to +85 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP3008 10 200 8Single-ended SPI 2.7 to 5.5 550 ±1 LSB -40 to +85 16-Pin PDIP, 16-Pin SOIC

MCP3221 12 22 1 Single-ended I2C2.7 to 5.5 250 ±2 LSB -40 to +125 5-Pin SOT-23A

MCP3201 12 100 1Single-ended SPI 2.7 to 5.5 400 ±1 LSB -40 to +85 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP3202 12 100 2 Single-ended SPI 2.7 to 5.5 550 ±1 LSB -40 to +85 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP3204 12 100 4Single-ended SPI 2.7 to 5.5 400 ±1 LSB -40 to +85 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP3208 12 100 8 Single-ended SPI 2.7 to 5.5 400 ±1 LSB -40 to +85 16-Pin PDIP, 16-Pin SOIC

MCP3301 13 100 1Differential SPI 2.7 to 5.5 450 ±1 LSB -40 to +85 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP3302 13 100 2 Differential SPI 2.7 to 5.5 450 ±1 LSB -40 to +85 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP3304 13 100 4Differential SPI 2.7 to 5.5 450 ±1 LSB -40 to +85 16-Pin PDIP, 16-Pin SOIC

PAGE 24

Analog/Interface

Family Products

MIXED SIGNAL – Delta-Sigma A/D Converters

Part # Resolution

(bits)

Maximum

Sampling Rate

(samples/sec)

# of Input

Channels Interface Supply

Voltage Range

(V)

Typical Supply

Current

(μA)

Typical INL

(%FSR) Temp. Range

(°C) Features Packages

MCP3551 22 15 1 Diff SPI™ 2.7 to 5.5 120 0.0002 -40 to +125 Simultaneous 50/60 Hz rejection 8-Pin SOIC, 8-Pin MSOP

MCP3553 22 60 1 Diff SPI™ 2.7 to 5.5 120 0.0002 -40 to +125 8_pin SOIC, 8-Pin MSOP

TC3400(1) 10 to 16 >400 1 Diff 2-Wire 1.8 to 5.5 260 0.0038 0 to +85 8-Pin PDIP, 8-Pin SOIC

TC3401(1) 10 to 16 >400 2 Diff 2-Wire 1.8 to 5.5 300 0.0038 0 to +85 Enable mode, Reset monitor, Power-fail

monitor 16-Pin PDIP, 16-Pin QSOP

TC3402(1) 10 to 16 >400 4 Diff 2-Wire 1.8 to 5.5 250 0.0038 0 to +85 16-Pin PDIP, 16-Pin QSOP

TC3405(1) 10 to 16 >400 3 Single-ended,

1 Diff 2-Wire 1.8 to 5.5 250 0.0038 0 to +85 Enable mode, Reset monitor 16-Pin PDIP, 16-Pin QSOP

NOTE 1: All TC340X are not recommended for new designs.

MIXED SIGNAL – Energy Measurement ICs

Part # Dynamic

Measurement

Typical

Measurement

Accuracy Gain Typical Voltage

Reference Drift Typical Supply

Current Supply

Voltage Range (V) Temp. Range (°C) Features Packages

MCP3905 500:1 0.1% 1, 2, 8, 16 15 ppm 4 mA 4.5 to 5.5 -40 to +85 Active (real) power pulse output 24-Pin SSOP

MIXED SIGNAL – Dual Slope A/D Converters

Part # Supply

Voltage

(V)

Input Voltage Range

(V) Resolution Sampling Rate

(Conv/s) Input

Channels Data

Interface Temp.

Range (°C) Features Packages

TC500 ±4.5 to ±7.5 VSS + 1.5V to VDD – 1.5V Up to 16 bits 4 to 10 13-Wire 0 to +70 Differential input range, Programmable resolution/

conversion time 16-Pin PDIP, 16-Pin SOIC, 16-Pin CerDIP

TC500A ±4.5 to ±7.5 VSS + 1.5V to VDD – 1.5V Up to 17 bits 4 to 10 1 3-Wire 0 to +70 Differential input range, Programmable resolution/

conversion time 16-Pin PDIP, 16-Pin SOIC, 16-Pin CerDIP

TC510 +4.5 to +5.5 VSS + 1.5V to VDD – 1.5V Up to 17 bits 4 to 10 13-Wire 0 to +70 Differential input range, Programmable resolution/

conversion time, Charge pump (-V) output pin 24-Pin PDIP, 24-Pin SOIC

TC514 +4.5 to +5.5 VSS + 1.5V to VDD – 1.5V Up to 17 bits 4 to 10 4 3-Wire 0 to +70 Differential input range, Programmable resolution/

conversion time, Charge pump (-V) output pin 28-Pin PDIP, 28-Pin SOIC

TC520A +4.5 to +5.5 — — — — Serial port 0 to +70 Optional serial interface adapter for

TC500/500A/510/514 14-Pin PDIP, 16-Pin SOIC

TC530 +4.5 to +5.5 VSS + 1.5V to VDD – 1.5V Up to 17 bits 3 to 10 1 Serial port 0 to +70 Differential input range, Programmable resolution/

conversion time, Charge pump (-V) output pin 28-Pin PDIP, 28-Pin SOIC

TC534 +4.5 to +5.5 VSS + 1.5V to VDD – 1.5V Up to 17 bits 3 to 10 4Serial port 0 to +70 Differential input range, Programmable resolution/

conversion time, Charge pump (-V) output pin 40-Pin PDIP, 44-Pin MQFP

TC7109 ±4.5 to ±5.5 VSS + 1.5V to VDD – 1.0V 12 bits plus sign bit 2 to 10 1 Parallel or

Serial port -25 to +85 Differential input range 40-Pin PDIP, 40-Pin CerDip, 44-Pin PLCC,

44-Pin MQFP

TC7109A ±4.5 to ±5.5 VSS + 1.5V to VDD – 1.0V 12 bits plus sign bit 2 to 10 1Parallel or

Serial port -25 to +85 Differential input range 40-Pin PDIP, 40-Pin CerDip, 44-Pin PLCC,

44-Pin MQFP

PAGE 25

Analog/Interface

Family Products

MIXED SIGNAL – Binary and BCD A/D Converters

Part # Description Supply

Voltage (V) Input Voltage

Range (V) Resolution

(Digits) Resolution

(Counts) Max Power

(mW) Data

Interface Temp. Range

(°C) Features Packages

TC835 BCD A/D ±5 VSS + 1.0V to VDD – 0.5V 4½ ±20,000 30 MUXed BCD 0 to +70 Upgrade to TC7135 64-Pin MQFP, 44-Pin MQFP, 28-Pin PDIP

TC850 Binary A/D ±5 VSS + 1.5V to VDD – 1.5V 15-bit ±32,768 35 8-bit

parallel -25 to +70 Highest conversion speed (40 conv/sec) 44-Pin PLCC, 40-Pin PDIP, 40-Pin CerDIP

TC7135 BCD A/D ±5 VSS + 1.0V to VDD – 1.0V 4½ ±20,000 30 MUXed BCD 0 to +70 For DMM, DPM, Data loggers 28-Pin PLCC, 28-Pin PDIP, 64-Pin MQFP

TC14433 BCD A/D ±4.5 to ±8 ±199.9 mV to 1.999V 3½ ±2,000 20 MUXed BCD -40 to +85 For DMM, DPM, Data loggers 24-Pin SOIC, 24-Pin PDIP, 28-Pin PLCC,

24-Pin CerDIP

TC14433A BCD A/D ±4.5 to ±8 ±199.9 mV to 1.999V 3½ ±2,000 20 MUXed BCD -40 to +85 For DMM, DPM, Data loggers 24-Pin PDIP, 28-Pin PLCC, 24-Pin CerDIP

MIXED SIGNAL – Display A/D Converters

Part # Display Type Supply Voltage (V) Resolution

(Digits) Resolution

(Counts) Power (mW) Temp. Range

(°C) Features Packages

TC820 LCD 9 3¾ ±4,000 10 0 to +70 DMM plus frequency counter and logic probe 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP

TC7106 LCD 93½ ±2,000 10 -25 to +85 For DMM, DPM, Data logger applications 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7106A LCD 9 3½ ±2,000 10 -25 to +85 For DMM, DPM, Data logger applications 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7107 LED ±5 3½ ±2,000 10 -25 to +85 For DMM, DPM, Data logger applications 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7107A LED ±5 3½ ±2,000 10 -25 to +85 For DMM, DPM, Data logger applications 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7116 LCD 93½ ±2,000 10 -25 to +85 Hold function 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7116A LCD 9 3½ ±2,000 10 -25 to +85 Hold function 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7117 LED ±5 3½ ±2,000 10 -25 to +85 Hold function 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7117A LED ±5 3½ ±2,000 10 -25 to +85 Hold function 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7126 LCD 93½ ±2,000 0.5 -25 to +85 Low-power TC7106 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7126A LCD 9 3½ ±2,000 0.5 -25 to +85 Low-power TC7106 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7129 LCD 94½ ±20,000 4.5 0 to +70 Lowest noise ±3 mV sensitivity 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP

MIXED SIGNAL – Digital Potentiometers

Part # Number of

Taps Memory Number per

Package Interface Resistance

(kOhms) INL (max) DNL (max) Temp. Range (°C) Comments Packages

MCP4011 64 Volatile 1 Up/Down 2, 5, 10, 50 0.5 0.5 -40 to +125 Potentiometer mode 6-Pin SOT-23, 8-Pin

SOIC, 8-Pin MSOP,

8-Pin 2x3 DFN

MCP4012 64 Volatile 1Up/Down 2, 5, 10, 50 0.5 0.5 -40 to +125 Rheostat mode 6-Pin SOT-23

MCP4013 64 Volatile 1 Up/Down 2, 5, 10, 50 0.5 0.5 -40 to +125 Potentiometer to VSS 6-Pin SOT-23

PAGE 26

Analog/Interface

Family Products

MCP4014 64 Volatile 1 Up/Down 2, 5, 10, 50 0.5 0.5 -40 to +125 Rheostat to VSS 5-Pin SOT-23

MCP4021 64 Non-volatile 1Up/Down 2, 5, 10, 50 0.5 0.5 -40 to +125 Potentiometer mode, Shutdown,

WiperLock™ Technology

6-Pin SOT-23, 8-Pin

SOIC, 8-Pin MSOP,

8-Pin 2x3 DFN

MCP4022 64 Non-volatile 1 Up/Down 2, 5, 10, 50 0.5 0.5 -40 to +125 Rheostat mode, Shutdown,

WiperLock™ Technology 6-Pin SOT-23

MCP4023 64 Non-volatile 1Up/Down 2, 5, 10, 50 0.5 0.5 -40 to +125 Potentiometer to VSS, WiperLock™

Technology 6-Pin SOT-23

MCP4024 64 Non-volatile 1 Up/Down 2, 5, 10, 50 0.5 0.5 -40 to +125 Rheostat to VSS, Shutdown,

WiperLock™ Technology 5-Pin SOT-23

MCP41010 256 Volatile 1SPI™ 10 1 1 -40 to +85 Potentiometer mode, Shutdown 8-Pin PDIP, 8-Pin SOIC

MCP41050 256 Volatile 1 SPI™ 50 1 1 -40 to +85 Potentiometer mode, Shutdown 8-Pin PDIP, 8-Pin SOIC

MCP41100 256 Volatile 1SPI™ 100 1 1 -40 to +85 Potentiometer mode, Shutdown 8-Pin PDIP, 8-Pin SOIC

MCP42010 256 Volatile 2 SPI™ 10 1 1 -40 to +85 Potentiometer mode, Shutdown 14-Pin PDIP, 14-Pin

SOIC, 14-Pin TSSOP

MCP42050 256 Volatile 2SPI™ 50 1 1 -40 to +85 Potentiometer mode, Shutdown 14-Pin PDIP, 14-Pin

SOIC, 14-Pin TSSOP

MCP42100 256 Volatile 2 SPI™ 100 1 1 -40 to +85 Potentiometer mode, Shutdown 14-Pin PDIP, 14-Pin

SOIC, 14-Pin TSSOP

MIXED SIGNAL – Frequency-to-Voltage/Voltage-to-Frequency Converters

Part # Frequency Range (kHz) Full Scale (ppm FS/°C) Non-linearity (%FS) Temp. Range (°C) Packages

TC9400 100 ±40 ±0.05 -40 to +85 14-Pin PDIP, 14-Pin SOIC

TC9401 100 ±40 ±0.02 -40 to +85 14-Pin PDIP, 14-Pin SOIC

TC9402 100 ±100 ±0.25 -40 to +85 14-Pin PDIP, 14-Pin SOIC

MIXED SIGNAL – D/A Converters

Part # Resolution

(Bits) DACs per

Package Interface VREF

Output Settling Time

(μs) DNL

(LSB) Typical Standby

Current (μA) Typical Operating

Current (μA) Temp. Range (°C) Packages

TC1320 8 1 SMBus Ext 10 ±0.8 0.1 350 -40 to +85 8-Pin MSOP, 8-Pin SOIC

TC1321 10 1 SMBus Ext 10 ±2 0.1 350 -40 to +85 8-Pin MSOP, 8-Pin SOIC

MCP4821 12 1SPI Y4.5 10.3 330 -40 to +125 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP4822 12 2 SPI Y 4.5 1 0.3 415 -40 to +125 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP4921 12 1SPI Ext 4.5 0.75 1175 -40 to +125 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP4922 12 2 SPI Ext 4.5 0.75 1 350 -40 to +125 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

NOTE: The analog output is voltage.

MIXED SIGNAL – Digital Potentiometers (continued)

Part # Number of

Taps Memory Number per

Package Interface Resistance

(kOhms) INL (max) DNL (max) Temp. Range (°C) Comments Packages

PAGE 27

Analog/Interface

Family Products

INTERFACE – Controller Area Network (CAN) Products

Part # Operating

Voltage (V) Temperature

Range (°C) Tx Buffers Rx Buffers Filters Masks Interrupt

Output Unique Features Packages

MCP2510(1) 2.7 to 5.5 -40 to +125 3 2 6 2 Yes CAN 2.0B Active controller with SPI interface to

MCU, 3 transmit buffers, 2 receive buffers, HW and

SW message triggers 18-Pin PDIP, 18-Pin SOIC, 20-Pin TSSOP

MCP25152.7 to 5.5-40 to +1253262Yes

MCP2510 pin compatible upgrade with enhanced

features including higher throughput and data byte

filtering 18-Pin PDIP, 18-Pin SOIC, 20-Pin TSSOP

MCP25020 2.7 to 5.5 -40 to +125 3 2 2 1 N/A CAN 2.0B Active I/O Expander, Configurable I/O,

2 PWM outputs 14-Pin PDIP, 14-Pin SOIC

MCP250252.7 to 5.5-40 to +853221N/A

CAN 2.0B Active I/O Expander, Configurable I/O,

2 PWM outputs, One-wire CAN option 14-Pin PDIP, 14-Pin SOIC

MCP25050 2.7 to 5.5 -40 to +125 3 2 2 1 N/A Mixed-Signal CAN 2.0B Active I/O Expander,

Configurable I/O, 4 10-bit ADCs, 2 PWM outputs 14-Pin PDIP, 14-Pin SOIC

MCP250552.7 to 5.5-40 to +853221N/A

Mixed-Signal CAN 2.0B Active I/O Expander,

Configurable I/O, 4 10-bit ADCs, 2 PWM outputs,

One-wire CAN option 14-Pin PDIP, 14-Pin SOIC

MCP2551 4.5 to 5.5 -40 to +125 n/a n/a n/a n/a N/A High-speed CAN Transceiver (1 Mbps max. CAN bus

speed), ISO11898 compatible, Industry standard

pinout 8-Pin PDIP, 8-Pin SOIC

NOTE 1: Not recommended for new designs.

INTERFACE – Infrared Products

Part # Operating Voltage (V) Operating Temperature Range

(°C) Max. Baud Rate (Kbaud) Unique Features Packages

MCP2120 2.5 to 5.5 -40 to +85 325 UART to IR encoder/decoder with both

hardware and software baud rate selection 14-Pin PDIP, 14-Pin SOIC

MCP2122 1.8 to 5.5 -40 to +85 16x less than clock input UART to IR encoder/decoder 8-Pin PDIP, 8-Pin SOIC

MCP2140 2.7 to 5.5 -40 to +85 9.6 IrDA® Standard protocol handler plus bit

encoder/decoder, Fixed baud rate, Low-cost 18-Pin PDIP, 18-Pin SOIC, 20-Pin SSOP

MCP2150 3.0 to 5.5 -40 to +85 115.2 IrDA® Standard protocol handler plus bit

encoder/decoder on one chip for DTE

applications, Programmable ID 18-Pin PDIP, 18-Pin SOIC, 20-Pin SSOP

MCP2155 3.0 to 5.5 -40 to +85 115.2 IrDA® Standard protocol handler plus bit

encoder/decoder on one chip for DCE

applications, Programmable ID 18-Pin PDIP, 18-Pin SOIC, 20-Pin SSOP

NOTE: IrDA® is a registered trademark of Infrared Data Association.

INTERFACE – Ethernet Products

Part # Operating Voltage (V) Operating

Temperature Range

(°C) MAC PHY TX/RX Dual

Port RAM Bus

Type

Max Bus

Speed

(MHz) Features Packages

ENC28J60 3.14 to 3.45 -40 to +85 yes 10-Base-T 8 KB SPI 25 Ethernet controller, IEEE 802.3 compatible,

Loopback Test modes, Auto-polarity detection 28-Pin SOIC, 28-Pin SSOP, 28-Pin 6x6 QFN

PAGE 28

Analog/Interface

Family Products

INTERFACE – LIN Transceiver Products

Part # Description Vreg Output Voltage

(V)

Operating

Temperature Range

(°C)

Vreg Output Current

(mA) VCC Range (V) Max Baud Rate LIN Specification

Supported Packages

MCP201 LIN Transceiver with integrated VREG 4.75 to 5.25 -40 to +125 50 7.4 to 18(1) 20 Kbaud Revision 1.2 8-pin PDIP, 8-pin SOIC, 8-Pin DFN

NOTE 1: Can withstand 40V load dump.

INTERFACE – Serial Peripherals

Part # Description Operating Voltage

(V)

Operating

Temperature Range

(°C) Bus Type Max. Bus Frequency

(kHz) Features Packages

MCP23008 8-bit I/O Port Expander 1.8 to 5.5 -40 to +85 I2C™ 1700 3 HW address pins, HW interrupt,

25 mA source/sink capability per I/O 18-Pin PDIP, 18-Pin SOIC, 20-Pin SSOP

MCP23S08 8-bit I/O Port Expander 1.8 to 5.5 -40 to +85 SPI™ 10000 2 HW address pins, HW interrupt,

25 mA source/sink capability per I/O 18-Pin PDIP, 18-Pin SOIC, 20-Pin SSOP

MCP23016 16-bit I/O Port Expander 2.0 to 5.5 -40 to +85 I2C™ 400 3 H/W address inputs, HW interrupt,

25 mA source/sink capability per I/O 28-Pin PDIP, 28-Pin SOIC, 28-Pin SSOP,

28-Pin 6x6 QFN

MCP23017 16-bit I/O expander 1.8 to 5.5 -40 to +125 I2C™ 1,700

3 HW address pins, 25 mA sink/

source per I/O, 100 kHz,

400 kHz and 3-4 MHz I2C™

supported, Interrupt output

28-Pin PDIP, 28-Pin SOIC, 28-Pin SSOP,

28-Pin QFN

MCP23S17 16-bit I/O expander 1.8 to 5.5 -40 to +125 SPI™ 10,000 3 HW address pins, 25 mZ sink/

source per I/O, Interrupt output 28-Pin PDIP, 28-Pin SOIC, 28-Pin SSOP,

28-Pin QFN

PAGE 29

Analog/Interface

Family Products

FUTURE ANALOG/INTERFACE PRODUCTS

Lead-free versions of many devices are currently offered. Check Microchip’s web site for availability.

Power Management – Low-Side Power MOSFET Drivers

Part # Configuration Operating Temperature

(°C) Peak Output

Current (A) Output Resistance

(Ω)Max. Supply Voltage Input/Output

Delay (td1, td2) Packages

TC4451 Single, Inverting -40 to +125 12 0.6 (typ)/1.5 18 15/15 8-Pin SOIC, 8-Pin PDIP, 8-Pin 6x5 DFN, 5-Pin TO-220, 5-Pin DDPAK

TC4452 Single, Non-inverting -40 to +125 12 0.6 (typ)/1.5 18 15/15 8-Pin SOIC, 8-Pin PDIP, 8-Pin 6x5 DFN, 5-Pin TO-220, 5-Pin DDPAK

Power Management – Battery Chargers

Part # Mode Cell Type # of Cells VCC Range (V) Max. Voltage

Regulation (%) Int/Ext FET Features Packages

MCP73831 Linear Li-Ion/Li-Polymer 14.5 to 5.5 +0.5 Int Small size, Status output 5-Pin SOT-23,

8-Pin 2x3 DFN

Power Management – Charge Pump DC/DC Converters

Part # Input Voltage

(V) Output

Voltage (V)

Operating

Temperature

Range (°C) Maximum Input

Current (mA)

Typical Active

Output Current

(mA) Features Packages

MCP1256/7/8/9 1.8 to 3.6 3.3 -40 to +85 100 100 650 kHz Oscillator, High-Efficiency Fractional mode, Low-Power Sleep

and Shutdown modes 10-Pin MSOP, 10-Pin 3x3 DFN

Power Management – Linear Regulators

Part # Max. Input

Voltage (V) Output

Current (mA) Junction Temp.

Range (°C) Typical Active

Current (mA)

Typical Dropout

Voltage of Rated

IOUT (mV)

Typical Output

Voltage

Accuracy (%) Features Packages

MCP1702 12 1.2, 1.5, 1.8, 2.5,

2.8, 3.0, 3.5, 4.0, 5.0 250 -40 to +125 2650 ±0.4 Ultra-low ground current, 12V max. input voltage 3-Pin SOT-23A, 3-Pin

SOT-89, 3-Pin TO-92

Power Management – Switching Regulators

Part # Description

Input

Voltage

(V) Output

Voltage (V)

Operating

Temp.

Range (°C) Control

Scheme Switching

Freq. (kHz) Typical Active

Current (mA) Output Current

(mA) Features Packages

MCP1603 Synchronous Buck

DC/DC Regulator 2.7 to 5.5 0.8 to 4.5 -40 to +85 PFM/

PWM 2000 35 500 PFM, PWM auto-switching, UVLO, soft-

start 5-Pin SOT-23, 8-Pin 2x3 DFN

Power Management – CPU/System Supervisors

Part # VCC Range

(V)

Operating

Temperature

Range (°C)

Nominal

Reset

Voltage (V) Reset Type Output

Typical Reset

Pulse Width

(ms) Typical Supply

Current (µA) Features Packages

MCP1316 1.0 to 5.5 -40 to +125 2.9, 4.6 Active-Low CMOS Push-Pull 200 5Watchdog Input (WDI time-out = 1.6s), Manual Reset 5-Pin SOT-23

PAGE 30

Analog/Interface

Family Products

MCP1317 1.0 to 5.5 -40 to +125 2.9, 4.6 Active-High CMOS Push-Pull 200 5 Watchdog Input (WDI time-out = 1.6s), Manual Reset 5-Pin SOT-23

MCP1318 1.0 to 5.5 -40 to +125 4.6 Active-Low/High CMOS Push-Pull 200 5Watchdog Input (WDI time-out = 1.6s) 5-Pin SOT-23

MCP1319 1.0 to 5.5 -40 to +125 4.6 Active-Low/High CMOS Push-Pull 200 1 Manual Reset 5-Pin SOT-23

MCP1320 1.0 to 5.5 -40 to +125 2.9, 4.6 Active-Low Open-Drain 200 5Watchdog Input (WDI time-out = 1.6x), Manual Reset 5-Pin SOT-23

MCP1321 1.0 to 5.5 -40 to +125 4.6 Active-Low Open-Drain/

CMOS Push-Pull 200 5 Watchdog Input (WDI time-out = 1.6s), Two Reset outputs

(Active-Low Open-Drain, Active-High Push-Pull) 5-Pin SOT-23

MCP1322 1.0 to 5.5 -40 to +125 4.6 Active-High Open-Drain/

CMOS Push-Pull 200 1Manual Reset, Two Reset outputs (Active-Low Open-Drain,

Active-High Push-Pull) 5-Pin SOT-23

Linear – Linear Gain Blocks

Part # Channels -3dB BW (kHz) IQ (μA) VOS

(mV) Operating

Voltage (V) Temperature

Range (°C) Gain Steps (V/V) Features Packages

MCP6G01 11000 120 31.8 to 5.5 -40 to +125 1, 10, 50 Tri-State Control Pin 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP6G02 2 1000 120 3 1.8 to 5.5 -40 to +125 1, 10, 50 Tri-State Control Pin 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP

MCP6G04 41000 120 31.8 to 5.5 -40 to +125 1, 10, 50 Tri-State Control Pin 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

Mixed Signal – Successive Approximation Register (SAR) A/D Converters

Part # Resolution

(bits)

Maximum

Sampling Rate

(ksamples/sec) # of Input

Channels Input Type Interface Input Voltage

Range (V)

Maximum

Supply current

(mA) Maximum INL

(LSB) Temperature

Range (°C) Packages

MCP3601 16 100 1Single-ended SPI 2.7 to 5.5 750 +3 -40 to +125 8-Pin PDIP, 8-Pin MSOP, 8-Pin SOIC

MCP3602 16 100 2 Single-ended SPI 2.7 to 5.5 1000 +3 -40 to +125 8-Pin PDIP, 8-Pin MSOP, 8-Pin SOIC

MCP3604 16 100 4Single-ended SPI 2.7 to 5.5 750 +3 -40 to +125 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP3608 16 100 8 Single-ended SPI 2.7 to 5.5 750 +3 -40 to +125 16-Pin PDIP, 16-Pin SOIC

Interface – Passive Access Products

Part # Operating

Voltage (V)

Operating

Temp. Range

(°C) Bus Type RF Carrier

Frequency Data Format Features Packages

MCP2030 1.8 to 3.6 -40 to +85 SPI 125 kHz NRZ Three axis signal conditioning devices for passive access applica-

tions, high-sensitivity, configurable smart wake-up filter 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

Power Management – CPU/System Supervisors (continued)

Part # VCC Range

(V)

Operating

Temperature

Range (°C)

Nominal

Reset

Voltage (V) Reset Type Output

Typical Reset

Pulse Width

(ms) Typical Supply

Current (µA) Features Packages

PAGE 31

PICmicro® MCU FAMILY

CURRENT PICmicro® MICROCONTROLLER FAMILY PRODUCTS

Baseline 8-Bit PICmicro® Microcontroller Family (12-bit Instruction Set)

Product

Program

Memory

Bytes & Type

(Words)

RAM

Bytes I/O

Pins Packages

Analog Digital M a x .

Speed

MHz IntOSC ICSPTM

BOR/

PBOR/

PLVD

ICD

# of

Breakpoints

Operating

Voltage

(V) Other Features

ADC Comp. Timers/WDT

PIC10FXXX: 500 ns Instruction Execution, 33 Instructions, 25 mA Source and Sink per I/O

PIC10F200 384 StdFI (256) 16 4 6OT, 8P — — 1-8 bit, 1-WDT 4 4 MHz ✓—1** 2.0-5.5

PIC10F202 768 StdFI (512) 24 46OT, 8P — — 1-8 bit, 1-WDT 44 MHz ✓— 1** 2.0-5.5

PIC10F204 384 StdFI (256) 16 4 6OT, 8P — 1 1-8 bit, 1-WDT 4 4 MHz ✓—1** 2.0-5.5 Band gap reference

PIC10F206 768 StdFI (512) 24 46OT, 8P — 1 1-8 bit, 1-WDT 44 MHz ✓— 1** 2.0-5.5 Band gap reference

PIC10F220 384 StdFl (256) 16 4 6OT, 8P 2x8-bit — 1-8 bit, 1-WDT 8 8 MHz ✓—1** 2.0-5.5 Band gap reference

PIC10F222 768 StdFl (512) 23 46OT, 8P 2x8-bit —1-8 bit, 1-WDT 88 MHz ✓— 1** 2.0-5.5 Band gap reference

PIC12FXXX: 500 ns Instruction Execution, 33 Instructions, 25 mA Source and Sink I/O

PIC12F508 768 StdFI (512) 25 6 8P, 8SN, 8MS — — 1-8 bit, 1-WDT 4 4 MHz ✓—1** 2.0-5.5

PIC12F509 1,536 StdFI

(1,024) 41 68P, 8SN, 8MS — — 1-8 bit, 1-WDT 44 MHz ✓— 1** 2.0-5.5

PIC12F510 1,536 StdFI

(1,024) 38 6 8P, 8SN, 8MS 3x8-bit 1 1-8 bit, 1-WDT 8 8 MHz ✓—1** 2.0-5.5 Band gap reference

PIC16F5XX: 100-200 ns Instruction Execution, 33 Instructions, 25 mA Source and Sink I/O

PIC16F505 1,536 StdFI

(1,024) 72 12 14P, 14JW, 14SL, 14ST — — 1-8 bit, 1-WDT 20 4 MHz ✓— 1** 2.0-5.5

PIC16F506 1,536 StdFl

(1,024) 67 12 14P, 14SO, 14ST 3x8-bit 2 1-8 bit, 1-WDT 20 8 MHz ✓—1** 2.0-5.5 Band gap reference

PIC16F54 768 StdFI (512) 25 12 18P, 18SO, 20SS — — 1-8 bit, 1-WDT 20 —✓— — 2.0-5.5

PIC16F57 3072 StdFI

(2048) 72 20 28P, 28SO, 28SS, 28SP — — 1-8 bit, 1-WDT 20 — ✓— — 2.0-5.5

PIC16F59 3,072 StdFI

(2,048) 134 32 40P, 44PT — — 1-8 bit, 1-WDT 20 —✓— — 2.0-5.5

PIC16C5X: 100-200 ns Instruction Execution, 33 Instructions, 25 mA Source and Sink I/O

PIC16C55A 768 OTP (512) 24 20 28P, 28JW, 28SP, 28SO,

28SS — — 1-8 bit, 1-WDT 40 — — — — 2.5 -5.5

PIC16C56A 1,536 OTP

(1,024) 25 12 18P, 18JW, 18SO, 20SS — — 1-8 bit, 1-WDT 40 — — — — 2.5-5.5

PIC16CR56A 1,536 ROM

(1,024) 25 12 18P, 18SO, 20SS — — 1-8 bit, 1-WDT 20 — — — — 2.5-5.5

PIC16C58B 3,072 OTP

(2,048) 73 12 18P, 18JW, 18SO, 20SS — — 1-8 bit, 1-WDT 40 — — — — 2.5-5.5

PIC16CR58B 3,072 ROM

(2,048) 73 12 18P, 18SO, 20SS — — 1-8 bit, 1-WDT 20 — — — — 2.5-5.5

PIC16HV540 768 OTP (512) 25 12 18P, 18JW, 18SO, 20SS — — 1-8 bit, 1-WDT 20 — — BOR — 3.5-15 8 high-voltage (15V) I/Os,

4 deep stack, 5 I/Os with wake-up-on-change

*Contact Microchip Technology for availability date.

** Requires ICD specific device with header module – refer to Development Tools.

Abbreviations are found on the last page of the Selector Guide.

E E E y

PAGE 32

PICmicro® MCU FAMILY

Mid-Range 8-Bit PICmicro® Microcontroller Family (14-bit Instruction Set)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages

Analog Digital M a x .

Speed

MHz IntOSC BOR/

PBOR

/PLVD

ICD # of

Breakpoints CCP/

ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

PIC12FXXX: 1 μs Instruction Execution, 35 Instructions, ICSP™

PIC12F629 1,792 StdFI

(1,024) 128 64 6 8P, 8SN, 8MF — 1 1-8 bit, 1-16 bit,

1-WDT — 20 4 MHz BOR 1** ——

PIC12F635 1,792 StdFI

(1,024) 128 64 68P, 8SN, 8MF — 1 1-8 bit, 1-16 bit,

1-WDT —20 8 MHz BOR/

PLVD 1** —✓KEELOQ® hardware peripheral, WUR

PIC12F675 1,792 StdFI

(1,024) 128 64 6 8P, 8SN, 8MF 4x10-bit 1 1-8 bit, 1-16 bit,

1-WDT — 20 4 MHz BOR 1** ——

PIC12F683 3,584 StdFI

(2,048) 256 128 68P, 8SN, 8MF 4x10-bit 11-16 bit, 2-8 bit,

1-WDT —20 8 MHz BOR 1** 1/0 ✓

PIC16FXXX: 200 ns Instruction Execution, 35 Instructions, ICSP™ (except ROM), 25 mA Source and Sink per I/O

PIC16F627A 1,792 StdFI

(1,024) 128 224 16 18P, 18SO, 20SS,

28ML — 2 1-16 bit, 2-8 bit,

1-WDT AUSART 20 4 MHz BOR 1** 1/0 ✓

PIC16F628A 3,584 StdFI

(2,048) 128 224 16 18P, 18SO, 20SS,

28ML —2

1-16 bit, 2-8 bit,

1-WDT AUSART 20 4 MHz BOR 1** 1/0 ✓

PIC16F648A 7,168 StdFI

(4,096) 256 256 16 18P, 18SO, 20SS,

28ML — 2 1-16 bit, 2-8 bit,

1-WDT AUSART 20 4 MHz BOR 1** 1/0 ✓

PIC16F630 1,792 StdFI

(1,024) 128 64 12 14P, 14SL, 14ST — 1 1-8-bit, 1-16 bit,

1-WDT — 20 4 MHz BOR 1** ——

PIC16F636 3,584 StdFI

(2,048) 256 128 12 14P, 14SL, 14ST — 2 1-8 bit, 1-16 bit,

1-WDT —20 8 MHz BOR/

PLVD 1** —✓KEELOQ® hardware peripheral

PIC16F639 3,584 StdFl

(2,048) 256 128 12 20P, 20SO, 20SS — 2 1-16 bit, 1-8 bit,

1-WDT — 20 8 MHz BOR 1** —✓Transponder Analog Front End,

KEELOQ® hardware peripheral

PIC16F676 1,792 StdFI

(1,024) 128 64 12 14P, 14SL, 14ST 8x10-bit 11-8 bit, 1-16 bit,

1-WDT —20 4 MHz BOR 1** — —

PIC16F684 3,584 StdFI

(2,048) 256 128 12 14P, 14SL, 14ST 8x10-bit 2 1-16 bit, 2-8 bit,

1-WDT — 20 8 MHz BOR 1** 0/1 ✓

PIC16F685 7,168 StdFl

(4,096) 256 256 18 20P, 20SO, 20SS 12x10-bit 21-16 bit, 2-8 bit,

1-WDT —20 8 MHz BOR 1** 0/1 ✓

PIC16F687 3,584 StdFl

(2,048) 256 128 18 20P, 20SO, 20SS 12x10-bit 2 1-16 bit, 1-8 bit,

1-WDT

EUSART,

I2C™/

SPI™ 20 8 MHz BOR 1** —✓

PIC16F688 7,168 StdFI

(4,096) 256 256 12 14P, 14SL, 14ST 8x10-bit 21-8 bit, 1-16 bit,

1-WDT EUSART 20 8 MHz BOR 1** —✓

PIC16F689 7,168 StdFl

(4,096) 256 256 18 20P, 20SO, 20SS 12x10-bit 2 1-16 bit, 1-8 bit,

1-WDT

EUSART,

I2C/SPI 20 8 MHz BOR 1** —✓

PIC16F690 7,168 StdFl

(4,096) 256 256 18 20P, 20SO, 20SS 12x10-bit 21-16 bit, 2-8 bit,

1-WDT EUSART,

I2C, SPI 20 8 MHz BOR 1** 0/1 ✓

PIC16F716 3,584 StdFI

(2,048) — 128 13 18P, 18SO, 20SS 4x8-bit — 1-16 bit, 2-8 bit,

1-WDT —20—BOR1** 0/1 —

PIC16F72 3,584 StdFI

(2,048) —128 22 28SP, 28SO, 28SS,

28ML 5x8-bit —1-16 bit, 2-8 bit,

1-WDT I2C/SPI 20 —BOR —1/0 —

PIC16F73 7,168 StdFI

(4,096) — 192 22 28SP, 28SO, 28SS,

28ML 5x8-bit — 1-16 bit, 2-8 bit,

1-WDT USART,

I2C/SPI 20 — BOR — 2/0 —

*Contact Microchip Technology for availability date.

** Requires ICD specific device with header module – refer to Development Tools.

Abbreviations are found on the last page of the Selector Guide.

PAGE 33

PICmicro® MCU FAMILY

PIC16FXXX: 200 ns Instruction Execution, 35 Instructions, ICSP™ (except ROM), 25 mA Source and Sink per I/O (continued)

PIC16F737 7,168 StdFI

(4,096) —368 25 28SP, 28SO, 28SS,

28ML 11x10-bit 21-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 8 MHz PBOR/

PLVD 13/0 ✓

PIC16F74 7,168 StdFI

(4,096) —19233

40P, 44ML, 44L,

44PT 8x8-bit — 1-16 bit, 2-8 bit,

1-WDT USART,

I2C/SPI 20 — BOR — 2/0 — PSP

PIC16F747 7,168 StdFl

(4,096) —368 36 40P, 44PT, 44ML 14x10-bit 21-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 8 MHz PBOR

/PLVD 13/0 ✓PSP

PIC16F76 14,336 StdFI

(8,192) —36822

28SP, 28SO, 28SS,

28ML 5x8-bit — 1-16 bit, 2-8 bit,

1-WDT USART,

I2C/SPI 20 — BOR — 2/0 —

PIC16F767 14,336 StdFI

(8,192) —368 25 28SP, 28SO, 28SS,

28ML 11x10-bit 21-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 8 MHz PBOR/

PLVD 13/0 ✓

PIC16F77 14,336 StdFI

(8,192) —36833

40P, 44ML, 44L,

44PT 8x8-bit — 1-16 bit, 2-8 bit,

1-WDT USART,

I2C/SPI 20 — BOR — 2/0 — PSP

PIC16F777 14,336 StdFI

(8,192) —368 36 40P, 44PT, 44ML 14x10-bit 21-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 8 MHz PBOR/

PLVD 13/0 ✓PSP

PIC16F785 3,584 StdFl

(2,048) 256 128 18 20P, 20SO, 20SS 12x10-bit 2 1-16 bit, 2-8 bit,

1-WDT — 20 8 MHz BOR 1** 1/0 ✓2-phase PWM, 2 x Op Amp, VREF

PIC16F818 1,792 EnhFI

(1,024) 128 128 16 18P, 18SO, 20SS,

28ML 5x10-bit —1-16 bit, 2-8 bit,

1-WDT I2C/SPI 20 8 MHz BOR 11/0 ✓

PIC16F819 3,584 EnhFI

(2048) 256 256 16 18P, 18SO, 20SS,

28ML 5x10-bit —1-16 bit, 2-8 bit,

1-WDT I2C/SPI 20 8 MHz BOR 1 1/0 ✓

PIC16F84A 1,792 StdFI

(1,024) 64 68 13 18P, 18SO, 20SS — — 1-8 bit, 1-WDT —20 — — — — —

PIC16F87 7,168 EnhFI

(4,096) 256 368 16 18P, 18SO, 20SS,

28ML —2

1-16 bit, 2-8 bit,

1-WDT

AUSART,

I2C/SPI 20 8 MHz BOR 1 1/0 ✓

PIC16F870 3,584 EnhFI

(2,048) 64 128 22 28SP, 28SO, 28SS 5x10-bit —1-16 bit, 2-8 bit,

1-WDT AUSART 20 —BOR 11/0 —

PIC16F871 3,584 EnhFI

(2,048) 64 128 33 40P, 44L, 44PT 8x10-bit — 1-16 bit, 2-8 bit,

1-WDT AUSART 20 — BOR 1 1/0 — PSP

PIC16F872 3,584 EnhFI

(2,048) 64 128 22 28SP, 28SO, 28SS 5x10-bit —1-16 bit, 2-8 bit,

1-WDT MI2C/SPI 20 —BOR 11/0 —

PIC16F873A 7,168 EnhFI

(4,096) 128 192 22 28SP, 28SO, 28SS,

28ML 5x10-bit 2 1-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 — BOR 1 2/0 —

PIC16F874A 7,168 EnhFI

(4,096) 128 192 33 40P, 44ML, 44L,

44PT 8x10-bit 21-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 —BOR 12/0 —PSP

PIC16F876A 14,336 EnhFI

(8,192) 256 368 22 28SP, 28SO, 28SS,

28ML 5x10-bit 2 1-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 — BOR 1 2/0 —

PIC16F877A 14,336 EnhFI

(8,192) 256 368 33 40P, 44ML, 44L,

44PT 8x10-bit 21-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 —BOR 12/0 —PSP

PIC16F88 7,168 EnhFI

(4,096) 256 368 16 18P, 18S0, 20SS,

28ML 7x10-bit 2 1-16 bit, 2-8 bit,

1-WDT AUSART,

I2C/SPI 20 8 MHz BOR 1 1/0 ✓

PIC16F913 7,168 StdFl

(4,096) 256 256 25 28P, 28SO, 28SS,

28ML 5x10-bit 22-8 bit, 1-16 bit,

1-WDT AUSART,

I2C/SPI 20 8 MHz BOR/

PLVD 11/0 ✓Integrated LCD control modules with

60 segments

Mid-Range 8-Bit PICmicro® Microcontroller Family (14-bit Instruction Set) (continued)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages

Analog Digital M a x .

Speed

MHz IntOSC BOR/

PBOR

/PLVD

ICD # of

Breakpoints CCP/

ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

*Contact Microchip Technology for availability date.

** Requires ICD specific device with header module – refer to Development Tools.

Abbreviations are found on the last page of the Selector Guide.

EW EW EW EW

PAGE 34

PICmicro® MCU FAMILY

PIC16FXXX: 200 ns Instruction Execution, 35 Instructions, ICSP™ (except ROM), 25 mA Source and Sink per I/O (continued)

PIC16F914 7,168 StdFl

(4,096) 256 256 36 40P, 44PT, 44ML 8x10-bit 2 2-8 bit, 1-16 bit,

1-WDT AUSART,

I2C/SPI 20 8 MHz BOR/

PLVD 12/0✓Integrated LCD control modules with

96 segments

PIC16F916 14,336 StdFl

(8,192) 256 352 25 28P, 28SO, 28SS,

28ML 5x10-bit 22-8 bit, 1-16 bit,

1-WDT

AUSART,

I2C/SPI 20 8 MHz BOR/

PLVD 11/0 ✓Integrated LCD control modules with

60 segments

PIC16F917 14,336 StdFl

(8,192) 256 352 36 40P, 44PT, 44ML 8x10-bit 2 2-8 bit, 1-16 bit,

1-WDT AUSART,

I2C/SPI 20 8 MHz BOR/

PLVD 12/0✓Integrated LCD control modules with

96 segments

PIC16F946 14,336 StdFl

(8,192) 256 336 53 64PT 8x10-bit 21-16 bit, 2-8 bit,

1-WDT AUSART/

I2C/SPI 20 8 MHz

32 kHz BOR/

PLVD 12/0 ✓Integrated LCD control modules with

168 segments

PIC16CXXX: 100-200 ns Instruction Execution, 35 Instructions, ICSP™ (except ROM), 25 mA Source and Sink per I/O

PIC14000 7,168 OTP

(4,096) — 192 20 28SP, 28SO, 28SS,

28JW 8 SLAC 2 1-8 bit, 1-16 bit,

1-WDT I2C/SMB 20 4 MHz — — — — Temperature Sensor, Program

Reference Generator

PIC16C432 3,584 OTP

(2,048) —128 12 20SS, 20P, 20JW — 2 1-8 bit, 1-WDT LIN 20 —BOR — — — LIN XCVR, 18V/40 mA

PIC16C433 3,584 OTP

(2,048) — 128 6 18SO, 18P, 18JW 4x8-bit — 1-8 bit, 1-WDT LIN 10 4 MHz — — — — LIN XCVR, 18V/40 mA

PIC16C554 896 OTP (512) —80 13 18P, 18SO, 18JW,

20SS — — 1-8 bit, 1-WDT —20 — — — — —

PIC16C558 3,584 OTP

(2,048) — 128 13 18P, 18SO, 18JW,

20SS — — 1-8 bit, 1-WDT — 20 — — — — —

PIC16C62B 3,584 OTP

(2,048) —128 22 28SP, 28SO, 28SS,

28JW, 28ML — — 1-16 bit, 2-8 bit,

1-WDT I2C/SPI 20 —BOR —1/0 —

PIC16C620A 896 OTP (512) — 96 13 18P, 18SO, 18JW,

20SS — 2 1-8 bit, 1-WDT — 40 — BOR — — —

PIC16CR620A 896 ROM (512) — 96 13 18P, 18SO, 20SS — 2 1-8 bit, 1-WDT — 20 — BOR — — —

PIC16C621A 1,792 OTP

(1,024) —96 13 18P, 18SO, 18JW,

20SS — 2 1-8 bit, 1-WDT —40 —BOR — — —

PIC16C622A 3,584 OTP

(2,048) — 128 13 18P, 18SO, 18JW,

20SS — 2 1-8 bit, 1-WDT — 40 — BOR — — —

PIC16C63A 7,168 OTP

(4,096) —192 22 28SP, 28SO, 28SS,

28JW, 28ML — — 1-16 bit, 2-8 bit,

1-WDT USART,

I2C/SPI 20 —BOR —2/0 —

PIC16CR63 7,168 ROM

(4,096) —192 22 28SP, 28SO, 28SS — — 1-16 bit, 2-8 bit,

1-WDT

USART,

I2C/SPI 20 —BOR —2/0 —

PIC16C65B 7,168 OTP

(4,096) — 192 33 40P, 40JW, 44L,

44PQ, 44PT ——

1-16 bit, 2-8 bit,

1-WDT USART,

I2C/SPI 20 — BOR — 2/0 — PSP

PIC16CR65 7,168 ROM

(4,096) — 192 33 40P, 44L, 44PQ,

44PT ——

1-16 bit, 2-8 bit,

1-WDT

USART,

I2C/SPI 20 — BOR — 2/0 — PSP

PIC16C717 3,584 OTP

(2,048) —256 16 18P, 18SO, 18JW,

20SS 6x10-bit —1-16 bit, 2-8 bit,

1-WDT MI2C/SPI 20 4 MHz PBOR/

PLVD —0/1 —

PIC16CR72 3,584 ROM

(2,048) — 128 22 28SP, 28SO, 28SS 5x8-bit — 1-16 bit, 2-8 bit,

1-WDT I2C/SPI 20 — BOR — 1/0 —

PIC16C745 14,336 OTP

(8,192) —256 22 28SP, 28SO, 28JW 5x8-bit —1-16 bit, 2-8 bit,

1-WDT

USART,

low-speed

USB 24 —BOR —2/0 —USB 1.1, 64 bytes dual port RAM

Mid-Range 8-Bit PICmicro® Microcontroller Family (14-bit Instruction Set) (continued)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages

Analog Digital M a x .

Speed

MHz IntOSC BOR/

PBOR

/PLVD

ICD # of

Breakpoints CCP/

ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

*Contact Microchip Technology for availability date.

** Requires ICD specific device with header module – refer to Development Tools.

Abbreviations are found on the last page of the Selector Guide.

PAGE 35

PICmicro® MCU FAMILY

PIC16CXXX: 100-200 ns Instruction Execution, 35 Instructions, ICSP™ (except ROM), 25 mA Source and Sink per I/O (continued)

PIC16C765 14,336 OTP

(8,192) — 256 33 40P, 40JW, 44L,

44PT 8x8-bit — 1-16 bit, 2-8 bit,

1-WDT

USART,

low-speed

USB 24 — BOR — 2/0 — USB 1.1, 64 bytes dual port RAM,

PSP

PIC16C770 3,584 OTP

(2,048) —256 16 20P, 20SO, 20JW,

20SS 6x12-bit —1-16 bit, 2-8 bit,

1-WDT MI2C/SPI 20 4 MHz PBOR/

PLVD —0/1 —

PIC16C771 7,168 OTP

(4,096) — 256 16 20P, 20SO, 20JW,

20SS 6x12-bit — 1-16 bit, 2-8 bit,

1-WDT MI2C/SPI 20 4 MHz PBOR/

PLVD —0/1—

PIC16C773 7,168 OTP

(4,096) —256 22 28SP, 28SO, 28SS,

28JW 6x12-bit —1-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 —PBOR/

PLVD —2/0 —

PIC16C774 7,168 OTP

(4,096) — 256 33 40P, 40JW, 44L,

44PQ, 44PT 10x12-bit — 1-16 bit, 2-8 bit,

1-WDT AUSART,

MI2C/SPI 20 — PBOR/

PLVD —2/0—PSP

PIC16C781 1,792 OTP

(1,024) —128 16 20P, 20SO, 20SS,

20JW 8x8-bit 21-16 bit, 2-8 bit,

1-WDT —20 4 MHz PBOR — — — Op Amp, PSMC, DAC

PIC16C782 3,584 OTP

(2,048) — 128 16 20P, 20SO, 20SS,

20JW 8x8-bit 2 1-16 bit, 2-8 bit,

1-WDT —204 MHz

PBOR/

PLVD — — — Op Amp, PSMC, DAC

PIC16C925 7,168 OTP

(4,096) —176 52 68CL, 68L, 64PT 5x10-bit —1-16 bit, 2-8 bit,

1-WDT I2C/SPI 20 —BOR —1/0 —LCD module, static, 1/2, 1/3, 1/4

multiplex

PIC16C926 14,336 OTP

(8,192) — 336 52 68CL, 68L, 64PT 5x10-bit — 1-16 bit, 2-8 bit,

1-WDT I2C/SPI 20 — BOR — 1/0 — LCD module, static, 1/2, 1/3, 1/4

multiplex

High-Performance

8-Bit PICmicro®

Microcontroller Family (16-bit Instruction Set)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O Pins Packages

Analog Digital Max.

Speed

MHz IntOSC BOR/

PBOR/

PLVD

ICD # of

Breakpoints CCP/ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

PIC18 Flash MCUs: 10 MIPS, VDD = 2.0 - 5.5V, Upwardly Compatible with PIC16C, 77 Instructions, C Compiler Efficient Instruction Set

PIC18C601 ROM-less —1536 26 64PT, 68L 8x10-bit

30 ksps —3-16 bit, 1-8 bit,

1-WDT AUSART,

MI2C/SPI 25 — — — 2/0 —256 KB EMA, Bootloader RAM

PIC18C801 ROM-less — 1536 37 80PT, 84L 12x10-bit

30 ksps —3-16 bit, 1-8 bit,

1-WDT AUSART,

MI2C/SPI 25 — — — 2/0 — 2 MB EMA, Bootloader RAM

PIC18F1220 4,096 EnhFI

(2,048) 256 256 16 18P, 18SO,

20SS, 28ML 7x10-bit

30 ksps —3-16 bit, 1-8 bit,

1-WDT EUSART 40 8 MHz

32 kHz PBOR/

PLVD 10/1 ✓

PIC18F1320 8,192 EnhFI

(4,096) 256 256 16 18P, 18SO,

20SS, 28ML 7x10-bit

30 ksps —3-16 bit, 1-8 bit,

1-WDT EUSART 40 8 MHz

32 kHz PBOR/

PLVD 10/1✓

PIC18F2220 4,096 EnhFI

(2,048) 256 512 25 28SP, 28SO 10x10-bit

30 ksps 23-16 bit, 1-8 bit,

1-WDT AUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 12/0 ✓

PIC18F2221*4,096 EnhFl

(2,048) 256 512 25 28SP, 28SO,

28ML 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0✓

PIC18F2320 8,192 EnhFI

(4,096) 256 512 25 28SP, 28SO 10x10-bit

30 ksps 23-16 bit, 1-8 bit,

1-WDT AUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 12/0 ✓

*Contact Microchip Technology for availability date.

Abbreviations are found on the last page of the Selector Guide.

Mid-Range 8-Bit PICmicro® Microcontroller Family (14-bit Instruction Set) (continued)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages

Analog Digital M a x .

Speed

MHz IntOSC BOR/

PBOR

/PLVD

ICD # of

Breakpoints CCP/

ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

*Contact Microchip Technology for availability date.

** Requires ICD specific device with header module – refer to Development Tools.

Abbreviations are found on the last page of the Selector Guide.

PAGE 36

PICmicro® MCU FAMILY

PIC18 Flash MCUs: 10 MIPS, VDD = 2.0 - 5.5V, Upwardly Compatible with PIC16C, 77 Instructions, C Compiler Efficient Instruction Set (continued)

PIC18F2321*8,192 EnhFl

(4,096) 256 512 25 28SP, 28SO,

28ML 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0✓

PIC18F2331 8,192 EnhFI

(4,096) 256 768 24 28SP, 28SO,

28MM 5x10-bit,

200 ksps —3-16 bit, 1-8 bit,

1-WDT EUSART,

I2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 12/0 ✓6-channel 14-bit Motor Control

PWMs, 2-ch Quadrature

Encoder

PIC18F2410 16,384 StdFI

(8,192) — 768 25 28SP, 28SO,

28ML 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0✓

PIC18F2420 16,384 EnhFI

(8,192) 256 768 25 28SP, 28SO,

28ML 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0 ✓

PIC18F2431 16,384 EnhFI

(8,192) 256 768 24 28SP, 28SO,

28MM 5x10-bit,

200 ksps —3-16 bit, 1-8 bit,

1-WDT EUSART,

I2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 12/0✓6-channel 14-bit Motor Control

PWMs, 2-ch Quadrature

Encoder

PIC18F2455 24,576 EnhFI

(12,288) 256 2048 23 28SP, 28SO 11x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

USB 2.0,

MI2C/SPI,

EUSART 48 8 MHz

32 kHz PBOR/

PLVD 32/0 ✓Full-Speed USB 2.0 Compliant

PIC18F2480 16,384 EnhFI

(8,192) 256 768 25 28SP, 28SO,

28ML 8x10-bit

100 ksps —3-16 bit, 1-8 bit,

1-WDT

CAN 2.0B,

MI2C/SPI,

EUSART 40 8 MHz

32 kHz PBOR/

PLVD 31/0✓ECAN™ technology

PIC18F2510 32,768 StdFI

(16,384) —1536 25 28SP, 28SO,

28ML 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0 ✓

PIC18F2520 32,768 EnhFI

(16,384) 256 1536 25 28SP, 28SO,

28ML 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0✓

PIC18F2515 49,152 StdFl

(24,576) —3968 25 28SP, 28SO 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0 ✓

PIC18F2525 49,152 EnhFI

(24,576) 1024 3968 25 28SP, 28SO 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0✓

PIC18F2550 32,768 EnhFI

(16,384) 256 2048 23 28SP, 28SO 11x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

USB 2.0,

MI2C/SPI,

EUSART 48 8 MHz

32 kHz PBOR/

PLVD 32/0 ✓Full-Speed USB 2.0 Compliant

PIC18F2580 32,768 EnhFI

(16,384) 256 1536 25 28SP, 28SO,

28ML 8x10-bit

100 ksps —3-16 bit, 1-8 bit,

1-WDT

CAN 2.0B,

MI2C/SPI,

EUSART 40 8 MHz

32 kHz PBOR/

PLVD 31/0✓ECAN™ technology

PIC18F2585 49,152 EnhFI

(24,576) 1024 3328 25 28SP, 28SO 8x10-bit

100 ksps —3-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/0 ✓ECAN™ technology

PIC18F2610 65,536 StdFI

(32,768) — 3968 25 28SP, 28SO 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0✓

PIC18F2620 65,536 EnhFI

(32,768) 1024 3968 25 28SP, 28SO 10x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/0 ✓

PIC18F2680 65,536 EnhFI

(32,768) 1024 3328 25 28SP, 28SO 8x10-bit

100 ksps —3-16 bit, 1-8 bit,

1-WDT

CAN 2.0B,

MI2C/SPI,

EUSART 40 8 MHz

32 kHz PBOR/

PLVD 31/0✓ECAN™ technology

PIC18F4220 4,096 EnhFI

(2,048) 256 512 36 40P, 44ML, 44PT 13x10-bit

30 ksps 23-16 bit, 1-8 bit,

1-WDT AUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 11/1 ✓PSP

High-Performance

8-Bit PICmicro®

Microcontroller Family (16-bit Instruction Set) (continued)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O Pins Packages

Analog Digital Max.

Speed

MHz IntOSC BOR/

PBOR/

PLVD

ICD # of

Breakpoints CCP/ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

*Contact Microchip Technology for availability date.

Abbreviations are found on the last page of the Selector Guide.

PAGE 37

PICmicro® MCU FAMILY

PIC18 Flash MCUs: 10 MIPS, VDD = 2.0 - 5.5V, Upwardly Compatible with PIC16C, 77 Instructions, C Compiler Efficient Instruction Set (continued)

PIC18F4221*4,096 EnhFl

(2,048) 256 512 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1✓PSP

PIC18F4320 8,192 EnhFI

(4,096) 256 512 36 40P, 44ML, 44PT 13x10-bit

30 ksps 23-16 bit, 1-8 bit,

1-WDT AUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 11/1 ✓PSP

PIC18F4321*8,192 EnhFl

(4,096) 256 512 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1✓PSP

PIC18F4331 8,192 EnhFI

(4,096) 256 768 36 40P, 44ML, 44PT 9x10-bit

200 ksps —3-16 bit, 1-8 bit,

1-WDT EUSART,

I2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 12/0 ✓8-channel 14-bit Motor Control

PWMs, 2-ch Quadrature

Encoder

PIC18F4410 16,384 StdFI

(8,192) — 768 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1✓PSP

PIC18F4420 16,384 EnhFI

(8,192) 256 768 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1 ✓PSP

PIC18F4431 16,384 EnhFI

(8,192) 256 768 36 40P, 44ML, 44PT 9x10-bit

200 ksps —3-16 bit, 1-8 bit,

1-WDT EUSART,

I2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 12/0✓8-channel 14-bit Motor Control

PWMs, 2-ch Quadrature

Encoder

PIC18F4455 24,576 EnhFI

(12,288) 256 2048 34 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

USB 2.0,

MI2C/SPI,

EUSART 48 8 MHz

32 kHz PBOR/

PLVD 31/1 ✓Full-Speed USB 2.0

Compliant, Streaming Port

PIC18F4480 16,384 EnhFI

(8,192) 256 768 36 40P, 44ML, 44PT 11x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

CAN 2.0B,

MI2C/SPI,

EUSART 40 8 MHz

32 kHz PBOR/

PLVD 31/1✓ECAN™ technology

PIC18F4510 32,768 StdFl

(16,384) —1536 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1 ✓PSP

PIC18F4520 32,768 EnhFI

(16384) 256 1536 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1✓PSP

PIC18F4515 49,152 StdFI

(24576) —3968 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1 ✓PSP

PIC18F4525 49,152 EnhFI

(24576) 1024 3968 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1✓PSP

PIC18F4580 32,768 EnhFI

(16384) 256 1536 36 40P, 44ML, 44PT 11x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

CAN 2.0B,

MI2C/SPI,

EUSART 40 8 MHz

32 kHz PBOR/

PLVD 31/1 ✓ECAN™ technology

PIC18F4550 32,768 EnhFI

(16,384) 256 2048 34 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

USB 2.0,

MI2C/SPI,

EUSART 48 8 MHz

32 kHz PBOR/

PLVD 31/1✓Full-Speed USB 2.0

Compliant, Streaming Port

PIC18F4585 49,152 EnhFI

(24,576) 1024 3328 36 40P, 44ML, 44PT 11x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

CAN 2.0B,

MI2C/SPI,

EUSART 40 8 MHz

32 kHz PBOR/

PLVD 31/1 ✓ECAN™ technology

PIC18F4610 65,536 StdFI

(32,768) — 3968 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1✓PSP

PIC18F4620 65,536 EnhFI

(32,768) 1024 3968 36 40P, 44ML, 44PT 13x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 31/1 ✓PSP

High-Performance

8-Bit PICmicro®

Microcontroller Family (16-bit Instruction Set) (continued)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O Pins Packages

Analog Digital Max.

Speed

MHz IntOSC BOR/

PBOR/

PLVD

ICD # of

Breakpoints CCP/ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

*Contact Microchip Technology for availability date.

Abbreviations are found on the last page of the Selector Guide.

PAGE 38

PICmicro® MCU FAMILY

PIC18 Flash MCUs: 10 MIPS, VDD = 2.0 - 5.5V, Upwardly Compatible with PIC16C, 77 Instructions, C Compiler Efficient Instruction Set (continued)

PIC18F4680 65,536 EnhFI

(32,768) 1024 3328 36 40P, 44ML, 44PT 11x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

CAN 2.0B,

MI2C/SPI,

EUSART 40 8 MHz

32 kHz PBOR/

PLVD 31/1✓ECAN

PIC18F6310 8,192 StdFI

(4,096) —768 54 64PT 12x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 40 8 MHz

32 kHz PBOR/

PLVD 33/0 3EMA

PIC18F6410 16,384 StdFI

(8,192) — 768 54 64PT 12x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 40 8 MHz

32 kHz PBOR/

PLVD 33/0✓EMA

PIC18F6390 8,192 StdFI

(4,096) —768 50 64PT 12x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 40 8 MHz

32 kHz PBOR/

PLVD 32/0 ✓LCD: up to 128 Segments

PIC18F6490 16,384 StdFI

(8,192) — 768 50 64PT 12x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 40 8 MHz

32 kHz PBOR/

PLVD 32/0✓LCD: up to 128 Segments

PIC18F6520 32,768 EnhFI

(16,384) 1024 2048 52 64PT 12x10-bit

30 ksps 23-16 bit, 2-8 bit,

1-WDT 2x AUSART,

MI2C/SPI 40 —PBOR/

PLVD 15/0 —PSP

PIC18F6527 49,152 EnhFl

(24,576) 1024 3936 54 64PT 12x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/3✓PSP

PIC18F6585 49,152 EnhFI

(24,576) 1024 3328 53 64PT, 68L 12x10-bit

30 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI,

CAN 2.0B 40 —PBOR/

PLVD 11/1 —ECAN

PIC18F6622 65,536 EnhFl

(32,768) 1024 3936 54 64PT 12x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/3✓PSP

PIC18F6627 98,304 EnhFI

(49,152) 1024 3936 54 64PT 12x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/3 ✓PSP

PIC18F6680 65,536 EnhFI

(32,768) 1024 3328 53 64PT, 68L 12x10-bit

30 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI,

CAN 2.0B 40 — PBOR/

PLVD 11/1—ECAN

PIC18F6722 131,072 EnhFI

(65,536) 1024 3936 54 64PT 12x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/3 ✓PSP

PIC18F8310 8,192 StdFI

(4,096) — 768 70 80PT 12x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART

40 8 MHz

32 kHz PBOR/

PLVD 33/0✓EMA

PIC18F8410 16,384 StdFI

(8192) —768 70 80PT 12x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 40 8 MHz

32 kHz PBOR/

PLVD 33/0 ✓EMA

PIC18F8390 8,192 StdFI

(4,096) — 768 66 80PT 12x10-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 40 8 MHz

32 kHz PBOR/

PLVD 32/0✓LCD: up to 192 Segments

PIC18F8490 16,384 StdFI

(8,192) —768 66 80PT 12x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 40 8 MHz

32 kHz PBOR/

PLVD 32/0 ✓LCD: up to 192 Segments

High-Performance

8-Bit PICmicro®

Microcontroller Family (16-bit Instruction Set) (continued)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O Pins Packages

Analog Digital Max.

Speed

MHz IntOSC BOR/

PBOR/

PLVD

ICD # of

Breakpoints CCP/ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

*Contact Microchip Technology for availability date.

Abbreviations are found on the last page of the Selector Guide.

wwwwwwwwwwwwww

PAGE 39

PICmicro® MCU FAMILY

PIC18 Flash MCUs: 10 MIPS, VDD = 2.0 - 5.5V, Upwardly Compatible with PIC16C, 77 Instructions, C Compiler Efficient Instruction Set (continued)

PIC18F8520 32,768 EnhFI

(16,384) 1024 2048 68 80PT 16x10-bit

30 ksps 22-8 bit, 3-16 bit,

1-WDT

2x AUSART,

MI2C/SPI 40 — PBOR/

PLVD 15/0—PSP, EMA

PIC18F8527 49,152 EnhFl

(24,576) 1024 3936 70 80PT 16x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/3 ✓PSP, EMA

PIC18F8585 49,152 EnhFI

(24,576) 1024 3328 69 80PT 16x10-bit

30 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI,

CAN 2.0B 40 — PBOR/

PLVD 11/1—ECAN, EMA

PIC18F8622 65,536 EnhFl

(32,768) 1024 3936 70 80PT 16x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/3 ✓PSP, EMA

PIC18F8627 98,304 EnhFI

(49,152) 1024 3936 70 80PT 16x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/3✓PSP, EMA

PIC18F8680 65,536 EnhFI

(32,768) 1024 3328 69 80PT 16x10-bit

30 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

MI2C/SPI,

CAN 2.0B 40 —PBOR/

PLVD 11/1 —ECAN, EMA

PIC18F8722 131,072 EnhFI

(65,536) 1024 3936 70 80PT 16x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

2xEUSART,

2xMI2C/SPI 40 8 MHz

32 kHz PBOR/

PLVD 32/3✓PSP, EMA

PIC18FXXJXX Flash MCUs: 10 MIPS, VDD = 2.0 - 3.6V, Self-Write, Upwardly Compatible with PIC18/PIC16, 77 Instructions, C Compiler Efficient Instruction Set

PIC18F24J10 16,384 StdFl

(8,192) —1024 21 28SP, 28SO,

28SS, 28ML 10x10-bit

100 ksps 22-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 32 kHz BOR 32/0 ✓

PIC18F25J10 32,768 StdFl

(16,384) — 1024 21 28SP, 28SO,

28SS, 28ML 10x10-bit

100 ksps 22-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 40 32 kHz BOR 3 2/0 ✓

PIC18F44J10 16,384 StdFl

(8,192) —1024 32 40P, 44ML, 44PT 13x10-bit

100 ksps 22-16 bit, 1-8 bit,

1-WDT

EUSART,

2xMI2C/SPI 40 32 kHz BOR 31/1 ✓PSP

PIC18F45J10 32,768 StdFl

(16,384) — 1024 32 40P, 44ML, 44PT 13x10-bit

100 ksps 22-16 bit, 1-8 bit,

1-WDT EUSART,

2xMI2C/SPI 40 32 kHz BOR 3 1/1 ✓PSP

PIC18F65J10 32,768 StdFl

(16,384) —2048 50 64PT 11x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 32/3 ✓PSP

PIC18F65J15 49,152 StdFl

(24,576) — 2048 50 64PT 11x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 3 2/3 ✓PSP

PIC18F66J10 65,536 StdFl

(32,768) —2048 50 64PT 11x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 32/3 ✓PSP

PIC18F66J15 98,304 StdFl

(49,152) — 3936 50 64PT 11x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 3 2/3 ✓PSP

PIC18F67J10 131,072 StdFL

(65,536) —3936 50 64PT 11x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 32/3 ✓PSP

PIC18F85J10 32,768 StdFL

(16,384) — 2048 66 80PT 15x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 3 2/3 ✓PSP, EMA

PIC18F85J15 49,152 StdFL

(24,576) —2048 66 80PT 15x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 32/3 ✓PSP, EMA

PIC18F86J10 65,536 StdFL

(32,768) — 2048 66 80PT 15x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

2x EUSART,

2x MI2C/SPI 40 32 kHz BOR 3 2/3 ✓PSP, EMA

PIC18F86J15 98,304 StdFL

(49,152) —3936 66 80PT 15x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 40 32 kHz BOR 32/3 ✓PSP, EMA

PIC18F87J10 131,072 StdFl

(65,536) — 3936 66 80PT 15x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

2x EUSART,

2x MI2C/SPI 40 32 kHz BOR 3 2/3 ✓PSP, EMA

High-Performance

8-Bit PICmicro®

Microcontroller Family (16-bit Instruction Set) (continued)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O Pins Packages

Analog Digital Max.

Speed

MHz IntOSC BOR/

PBOR/

PLVD

ICD # of

Breakpoints CCP/ECCP nW Other Features

ADC Ch Comp. Timers/WDT Serial I/O

*Contact Microchip Technology for availability date.

Abbreviations are found on the last page of the Selector Guide.

PAGE 40

PICmicro® MCU FAMILY

FUTURE PICmicro® MICROCONTROLLER FAMILY PRODUCTS

Mid-Range 8-Bit PICmicro® Microcontroller Family (14-bit Instruction Set)

Product

Program

Memory:

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages

Analog Digital Max.

Speed

MHz IntOSC BOR/PBOR/

PLVD ICD # of

Breakpoints CCP/

ECCP nW Other Features

ADC

Channels Comp. Timers/WDT Serial I/O

PIC12FXXX: 200 ns Instruction Execution, 35 Instructions, 25 mA Source and Sink per I/O

PIC12F615 1,792 StdFI

(1,024) — 64 6 8P, 8SN, 8MD 4x10-bit 1 1-16 bit, 2-8 bit, 1-WDT — 20 8 MHz

32 kHz BOR 1** 0/1 — High-Voltage Option with Internal

Regulator

PIC16FXXX: 200 ns Instruction Execution, 35 Instructions, ICSP™, 25 mA Source and Sink per I/O

PIC16F616 3,584 StdFI

(2,048) —128 12 14P, 14SL, 14ST,

16ML 8x10-bit 21-16 bit, 2-8 bit, 1-WDT —20 8 MHz

32 kHz BOR 1** 0/1 —High-Voltage Option with Internal

Regulator

PIC16F631 1,792 StdFI

(1,024) 128 64 18 20P, 20SO, 20SS — 2 1-16 bit, 1-8 bit, 1-WDT — 20 8 MHz

32 kHz BOR 1** —✓

PIC16F677 3,584 StdFI

(2,048) 256 128 18 20P, 20SO, 20SS 12x10-bit 21-16 bit, 1-8 bit, 1-WDT —20 8 MHz

32 kHz BOR 1** —✓

PIC16F883 7,168 EnhFl

(4,096) 256 256 25 28SP, 28SO,

28SS, 28ML 11x10-bit 2 1-16 bit, 2-8 bit, 1-WDT EUSART,

MI2C/SPI 20 8 MHz

32 kHz BOR 1 1/1 ✓

PIC16F884 7,168 EnhFl

(4,096) 256 256 36 40P, 44PT, 44ML 14x10-bit 21-16 bit, 2-8 bit, 1-WDT EUSART,

MI2C/SPI 20 8 MHz

32 kHz BOR 11/1 ✓

PIC16F886 14,336 EnhFl

(8,192) 256 368 25 28SP, 28SO,

28SS, 28ML 11x10-bit 2 1-16 bit, 2-8 bit, 1-WDT EUSART,

MI2C/SPI 20 8 MHz

32 kHz BOR 1 1/1 ✓

PIC16F887 14,336 EnhFl

(8,192) 256 368 36 40P, 44PT, 44ML 14x10-bit 21-16 bit, 2-8 bit, 1-WDT EUSART,

MI2C/SPI 20 8 MHz

32 kHz BOR 11/1 ✓

PIC16CRXX: 200 ns Instruction Execution, 35 Instructions, 25 mA Source and Sink per I/O

PIC16CR73 7,168 ROM

(4,096) — 192 22 28SP, 28SO,

28SS, 28ML 5x8-bit — 1-16 bit, 2-8 bit, 1-WDT USART,

I2C/SPI 20 — BOR — 2/0 —

PIC16CR74 7,168 ROM

(4,096) —192 33 40P, 44ML, 44L,

44PT 8x8-bit —1-16 bit, 2-8 bit, 1-WDT USART,

I2C/SPI 20 —BOR —2/0 —PSP

PIC16CR76 14,336 ROM

(8,192) — 368 22 28SP, 28SO,

28SS, 28ML 5x8-bit — 1-16 bit, 2-8 bit, 1-WDT USART,

I2C/SPI 20 — BOR — 2/0 —

PIC16CR77 14,336 ROM

(8,192) —368 33 40P, 44ML, 44L,

44PT 8x8-bit —1-16 bit, 2-8 bit, 1-WDT USART,

I2C/SPI 20 —BOR —2/0 —PSP

** Requires ICD specific device with header module – refer to Development Tools.

Abbreviations are found on the last page of the Selector Guide.

High-Performance

8-Bit PICmicro®

Microcontroller Family (16-bit Instruction Set)

Product

Program

Memory:

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog Digital Max.

Speed

MHz IntOSC BOR/PBOR/

PLVD ICD # of

Breakpoints CCP/

ECCP nW Other Features

PIC18FXXX: Upwardly Compatible with PIC16, 77 Instructions, C Compiler Efficient Instruction Set, Software Stack Capability, Table Read/Write, Switchable Oscillator Sources, 4x PLL, 10-12 MIPS, ICSP™

PIC18F1230 4,096 EnhFI

(2,048) 128 256 16 18P, 18SO,

20SS, 28ML 4x10-bit,

100 ksps 3 2-16 bit, 1-WDT EUSART 40 8 MHz

32 kHz PBOR/PLVD 3 — ✓6-channel 14-bit Motor Control

PWMs

PIC18F1330 8,192 EnhFI

(4,096) 128 256 16 18P, 18SO,

20SS, 28ML 4x10-bit,

100 ksps 32-16 bit, 1-WDT EUSART 40 8 MHz

32 kHz PBOR/PLVD 3 — ✓6-channel 14-bit Motor Control

PWMs

PIC18F2450 16,384 EnhFI

(8,192) — 768 23 28SP, 28SO,

28ML 10x10-bit,

100 ksps —2-16 bit, 1-8 bit,

1-WDT USB 2.0,

AUSART 48 8 MHz

32 kHz PBOR/PLVD 3 1/0 ✓Full-Speed USB 2.0 Compliant

PIC18F2523 32,768 EnhFl

(16,384) 256 1536 25 28SP, 28SO,

28ML 10x12-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 32 8 MHz

32 kHz PBOR/PLVD 32/0 ✓VDD = 2.7-3.6V

Abbreviations are found on the last page of the Selector Guide.

PAGE 41

PICmicro® MCU FAMILY

PIC18F4523 32,768 Enhl

(16,384) 256 1536 36 40P, 44ML, 44PT 13x12-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 32 8 MHz

32 kHz PBOR/PLVD 3 1/1 ✓VDD = 2.7-3.6V, PSP

PIC18F4450 16,384 EnhFI

(8,192) —768 34 40P, 44ML, 44PT 13x10-bit,

100 ksps —2-16 bit, 1-8 bit,

1-WDT USB 2.0,

AUSART 48 8 MHz

32 kHz PBOR/PLVD 31/0 ✓Full-Speed USB 2.0 Compliant

PIC18F6522 32,768 EnhFI

(16,384) 1024 2048 54 64PT 12x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 8 MHz

32 kHz PBOR 3 2/3 ✓PSP

PIC18F6493 16,384 StdFl

(8,192) —768 50 64PT 12x12-bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 32 8 MHz

32 kHz PBOR/PLVD 32/0 ✓VDD = 2.7-3.6V

LCD: up to 192 segments

PIC18F8493 16,384 StdFl

(8,192) — 768 66 80PT 12x12-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

MI2C/SPI,

EUSART,

AUSART 32 8 MHz

32 kHz PBOR/PLVD 3 2/0 ✓VDD = 2.7-3.6V

LCD: up to 192 segments

PIC18F8522 32,768 EnhFI

(16,384) 1024 2048 70 80PT 16x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 8 MHz

32 kHz PBOR 32/3 ✓PSP, EMA

PIC18FXXJXX: Flash and ROM MCUs: 10 MIPS, VDD = 2.0-3.6V, Self-Write Flash, Upwardly Compatible with PIC18/PIC16, 77 Instructions and C Compiler Efficient Instruction Set

PIC18F63J90 8,192 StdFI

(4,096) — 1024 49 64PT 12x10-bit,

100 ksps 23-16 bit, 1-8 bit,

1-WDT

AUSART,

EUSART,

MI2C/SPI 40 8 MHz

32 kHz BOR 3 2/0 ✓LCD: up to 128 segments

PIC18F64J90 16,384 StdFI

(8,192) —1024 49 64PT 12x10-bit,

100 ksps 23-16 bit, 1-8 bit,

1-WDT

AUSART,

EUSART,

MI2C/SPI 40 8 MHz

32 kHz BOR 32/0 ✓LCD: up to 128 segments

PIC18R65J10 32,768 ROM

(16,384) — 2048 50 64PT 11x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 3 2/3 ✓PSP

PIC18F65J50 32,768 StdFl

(16,384) —3936 49 64PT 8x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

USB 2.0,

2xEUSART,

2xMI2C/SPI 48 8 MHz

32 kHz BOR 32/3 ✓Full-Speed USB 2.0 Compliant

PMP

PIC18F65J90 32,768 StdFI

(16,384) — 2048 49 64PT 12x10-bit,

100 ksps 23-16 bit, 1-8 bit,

1-WDT

AUSART,

EUSART,

MI2C/SPI 40 8 MHz

32 kHz BOR 3 2/0 ✓LCD: up to 128 segments

PIC18R66J10 65,536 ROM

(32,768) —2048 50 64PT 11x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 32/3 ✓PSP

PIC18F66J50 65,536 ROM

(32,768) — 3936 49 64PT 8x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

USB 2.0,

2xEUSART,

2xMI2C/SPI

48 8 MHz

32 kHz BOR 3 2/3 ✓Full-Speed USB 2.0 Compliant

PMP

PIC18F66J60 65,536 StdFI

(32,768) —2048 39 64PT 11x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT EUSART,

MI2C/SPI 42 32 kHz BOR 32/3 ✓10Base-T Ethernet

PIC18F66J65 98,304 StdFI

(49,152) — 3808 39 64PT 11x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT EUSART,

MI2C/SPI 42 32 kHz BOR 3 2/3 ✓10Base-T Ethernet

PIC18R67J10 131,072 ROM

(65,536) —3936 50 64PT 11x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 32/3 ✓PSP

PIC18F67J50 131,072 StdFl

(65,536) — 3936 49 64PT 8x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

USB 2.0,

2xEUSART,

2xMI2C/SPI 48 8 MHz

32 kHz BOR 3 2/3 ✓Full-Speed USB 2.0 Compliant

PMP

PIC18F67J60 131,072 StdFI

(65,536) —3808 39 64PT 11x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT EUSART,

MI2C/SPI 42 32 kHz BOR 32/3 ✓10Base-T Ethernet

High-Performance

8-Bit PICmicro®

Microcontroller Family (16-bit Instruction Set) (continued)

Product

Program

Memory:

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog Digital Max.

Speed

MHz IntOSC BOR/PBOR/

PLVD ICD # of

Breakpoints CCP/

ECCP nW Other Features

Abbreviations are found on the last page of the Selector Guide.

PAGE 42

PICmicro® MCU FAMILY

PIC18FXXJXX: Flash and ROM MCUs: 10 MIPS, VDD = 2.0-3.6V, Self-Write Flash, Upwardly Compatible with PIC18/PIC16, 77 Instructions and C Compiler Efficient Instruction Set (continued)

PIC18F83J90 8,192 StdFI

(4,096) — 1024 64 80PT 12x10-bit,

100 ksps 23-16 bit, 1-8 bit,

1-WDT

AUSART,

EUSART,

MI2C/SPI

40 8 MHz

32 kHz BOR 3 2/0 ✓LCD: up to 192 segments

PIC18F84J90 16,384 StdFI

(8,192) —1024 64 80PT 12x10-bit,

100 ksps 23-16 bit, 1-8 bit,

1-WDT

AUSART,

EUSART,

MI2C/SPI 40 8 MHz

32 kHz BOR 32/0 ✓LCD: up to 192 segments

PIC18R85J10 32,768 ROM

(16,384) — 2048 66 80PT 15x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT

2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 3 2/3 ✓PSP, EMA

PIC18F85J50 32,768 StdFl

(16,384) —3936 66 80PT 12x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

USB 2.0,

2xEUSART,

2xMI2C/SPI 48 8 MHz

32 kHz BOR 32/3 ✓Full-Speed USB 2.0 Compliant

PMP, EMA

PIC18F85J90 32,768 StdFI

(16,384) — 2048 64 80PT 12x10-bit,

100 ksps 23-16 bit, 1-8 bit,

1-WDT

AUSART,

EUSART,

MI2C/SPI 40 8 MHz

32 kHz BOR 3 2/0 ✓LCD: up to 192 segments

PIC18R86J10 65,536 ROM

(32,768) —2048 66 80PT 15x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 32/3 ✓PSP, EMA

PIC18F86J50 65,536 StdFI

(32,768) — 3936 66 80PT 12x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT

USB 2.0,

2xEUSART,

2xMI2C/SPI 48 8 MHz

32 kHz BOR 3 2/3 ✓Full-Speed USB 2.0 Compliant

PMP, EMA

PIC18F86J60 65,536 StdFl

(32,768) —2048 55 80PT 15x10-bit

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

MI2C/SPI 42 32 kHz BOR 32/3 ✓10Base-T Ethernet

PIC18F86J65 98,304 StdFI

(49,152) — 3808 55 80PT 15x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

MI2C/SPI 42 32 kHz BOR 3 2/3 ✓10Base-T Ethernet

PIC18R87J10 131,072 ROM

(65,536) —3936 66 80PT 15x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT

2xEUSART,

2xMI2C/SPI 40 32 kHz BOR 32/3 ✓PSP, EMA

PIC18F87J50 131,072 StdFI

(65,536) — 3936 66 80PT 12x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT

USB 2.0,

2x EUSART,

2x MI2C/SPI 48 8 MHz

32 kHz BOR 3 2/3 ✓Full-Speed USB 2.0 Compliant

PMP, EMA

PIC18F87J60 131,072 StdFI

(65,536) —3808 55 80PT 15x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2xEUSART,

MI2C/SPI 42 32 kHz BOR 32/3 ✓10Base-T Ethernet

PIC18F96J60 65,536 StdFI

(32,768) — 2048 70 100PT 16x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT

2x EUSART,

2x MI2C/SPI 42 32 kHz BOR 3 2/3 ✓PSP, EMA, 10Base-T Ethernet

PIC18F96J65 98,304 StdFI

(49,152) —3808 70 100PT 16x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT 2x EUSART,

2x MI2C/SPI 42 32 kHz BOR 32/3 ✓PSP, EMA, 10Base-T Ethernet

PIC18F97J60 131,072 StdFI

(65,536) — 3808 70 100PT 16x10-bit,

100 ksps 23-16 bit, 2-8 bit,

1-WDT

2x EUSART,

2x MI2C/SPI 42 32 kHz BOR 3 2/3 ✓PSP, EMA, 10Base-T Ethernet

PIC18FXXKXX Flash MCUs: 16 MIPS, VDD = 1.8-3.6V, Self-Write

PIC18F25K20 32,768 EnhFl

(16,384) 256 1536 25 28SP, 28SO,

28SS, 28ML 11x10 bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 64 16 MHz

32 kHz PBOR/PLVD 31/1 ✓

PIC18F26K20 65,536 EnhFl

(32,768) 1024 3968 25 28SP, 28SO,

28SS, 28ML 11x10 bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

MI2C/SPI 64 16 MHz

32 kHz PBOR/PLVD 3 1/1 ✓

PIC18F45K20 32,768 EnhFl

(16,384) 256 1536 36 40P, 44ML, 44PT 14x10 bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT

EUSART,

Mi2C/SPI 40 8 MHz

32 kHz PBOR/PLVD 31/1 ✓PSP

PIC18F46K20 65,536 EnhFl

(32,768) 1024 3968 36 40P, 44ML, 44PT 14x10 bit

100 ksps 23-16 bit, 1-8 bit,

1-WDT EUSART,

Mi2C/SPI 40 8 MHz

32 kHz PBOR/PLVD 3 1/1 ✓PSP

High-Performance

8-Bit PICmicro®

Microcontroller Family (16-bit Instruction Set) (continued)

Product

Program

Memory:

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog Digital Max.

Speed

MHz IntOSC BOR/PBOR/

PLVD ICD # of

Breakpoints CCP/

ECCP nW Other Features

Abbreviations are found on the last page of the Selector Guide.

PAGE 43

PICmicro® MCU FAMILY

PIC24 16-Bit Microcontroller (MCU) Family

Product

Flash

Program

Memory

(Bytes)

RAM

(Bytes) I/O

Pins Packages

Analog Digital

CAN IntOSC Power On

Reset nW Other

Features

ADC Ch Comp. Timers

16-bit Input

Cap Output

Comp/PWM RTCC UART w/

IrDA®SPI™ I2C™

PIC24FJ128GA Family 16-bit Flash MCUs: 16 MIPS, VDD = 2.0 - 3.6V, Self-Write Flash

PIC24FJ64GA006 64K 8K 53 64PT 16 X 10-bit

500 ksps 255 5 ✓222—

8 MHz

32 kHz ✓✓

JTAG,

PMP

PIC24FJ64GA008 64K 8K 69 80PT 16 X 10-bit

500 ksps 2 5 5 5 ✓2 2 2 — 8 MHz

32 kHz ✓ ✓ JTAG,

PMP

PIC24FJ64GA010 64K 8K 85 100PT 16 X 10-bit

500 ksps 255 5 ✓222—

8 MHz

32 kHz ✓✓

JTAG,

PMP

PIC24FJ96GA006 96K 8K 53 64PT 16 X 10-bit

500 ksps 2 5 5 5 ✓2 2 2 — 8 MHz

32 kHz ✓ ✓ JTAG,

PMP

PIC24FJ96GA008 96K 8K 69 80PT 16 X 10-bit

500 ksps 255 5 ✓222—

8 MHz

32 kHz ✓✓

JTAG,

PMP

PIC24FJ96GA010 96K 8K 85 100PT 16 X 10-bit

500 ksps 2 5 5 5 ✓2 2 2 — 8 MHz

32 kHz ✓ ✓ JTAG,

PMP

PIC24FJ128GA006 128K 8K 53 64PT 16 X 10-bit

500 ksps 255 5 ✓222—

8 MHz

32 kHz ✓✓

JTAG,

PMP

PIC24FJ128GA008 128K 8K 69 80PT 16 X 10-bit

500 ksps 2 5 5 5 ✓2 2 2 — 8 MHz

32 kHz ✓ ✓ JTAG,

PMP

PIC24FJ128GA010 128K 8K 85 100PT 16 X 10-bit

500 ksps 255 5 ✓222—

8 MHz

32 kHz ✓✓

JTAG,

PMP

PIC24HJ256GP Family 16-bit Flash MCUs: 40 MIPS, VDD = 3.0 - 3.6V, Self-Write Flash

PIC24HJ64GP206 64 853 64PT 18 x 12-bit

500 ksps — 9 8 8 — 2 2 1 — 8 MHz

32 kHz ✓ ✓ JTAG,

DMA

PIC24HJ64GP210 64 8 85 100PT 32 x 12-bit

500 ksps —98 8 —2 22—

8 MHz

32 kHz ✓✓

JTAG,

DMA

PIC24HJ64GP506 64 853 64PT 18 x 12-bit

500 ksps — 9 8 8 — 2 2 2 1 8 MHz

32 kHz ✓ ✓ JTAG,

DMA

PIC24HJ64GP510 64 8 85 100PT 32 x 12-bit

500 ksps —98 8 —2 221

8 MHz

32 kHz ✓✓

JTAG,

DMA

PIC24HJ128GP206 128 853 64PT 18 x 12-bit

500 ksps — 9 8 8 — 2 2 1 — 8 MHz

32 kHz ✓ ✓ JTAG,

DMA

PIC24HJ128GP210 128 8 85 100PT 32 x 12-bit

500 ksps —98 8 —2 22—

8 MHz

32 kHz ✓✓

JTAG,

DMA

PIC24HJ128GP506 128 853 64PT 18 x 12-bit

500 ksps — 9 8 8 — 2 2 2 1 8 MHz

32 kHz ✓ ✓ JTAG,

DMA

Abbreviations are found on the last page of the Selector Guide.

PAGE 44

PICmicro® MCU FAMILY

PIC24HJ256GP Family 16-bit Flash MCUs: 40 MIPS, VDD = 3.0 - 3.6V, Self-Write Flash (continued)

PIC24HJ128GP510 128 8 85 100PT 32 x 12-bit

500 ksps —98 8 —2 221

8 MHz

32 kHz ✓✓

JTAG,

DMA

PIC24HJ128GP306 128 16 53 64PT 18 x 12-bit

500 ksps — 9 8 8 — 2 2 2 — 8 MHz

32 kHz ✓ ✓ JTAG,

DMA

PIC24HJ128GP310 128 16 85 100PT 32 x 12-bit

500 ksps —98 8 —2 22—

8 MHz

32 kHz ✓✓

JTAG,

DMA

PIC24HJ256GP206 256 16 53 64PT 18 x 12-bit

500 ksps — 9 8 8 — 2 2 2 — 8 MHz

32 kHz ✓ ✓ JTAG,

DMA

PIC24HJ256GP210 256 16 85 100PT 32 x 12-bit

500 ksps —98 8 —2 22—

8 MHz

32 kHz ✓✓

JTAG,

DMA

PIC24HJ256CP610 256 16 85 100PT (2) 16 x 12-bit

500 ksps — 9 8 8 — 2 2 2 2 8 MHz

32 kHz ✓ ✓ JTAG,

DMA

PIC24 16-Bit Microcontroller (MCU) Family (continued)

Product

Flash

Program

Memory

(Bytes)

RAM

(Bytes) I/O

Pins Packages

Analog Digital

CAN IntOSC Power On

Reset nW Other

Features

ADC Ch Comp. Timers

16-bit Input

Cap Output

Comp/PWM RTCC UART w/

IrDA®SPI™ I2C™

Abbreviations are found on the last page of the Selector Guide.

PAGE 45

PICmicro® MCU FAMILY

MATURE – PICmicro

MICROCONTROLLER FAMILY PRODUCTS

Not recommended for new designs.

Please use a device from the recommended column for new designs.

Product Program Memory

(Bytes/Words) Package Size Recommended Design-In Device

PIC12C508 768/512x12 8PIC12F508

PIC12C508A 768/512x12 8 PIC12F508

PIC12C509 1,536/1,024x12 8PIC12F509

PIC12C509A 1,536/1,024x12 8 PIC12F509

PIC12C671 1,536/1,024x14 8PIC12F675

PIC12C672 3,584/2,048x14 8 PIC12F683

PIC12CE673 1,792/1,024x14 8PIC12F675

PIC12CE674 3,584/2,048x14 8 PIC12F683

PIC12CE518 768/512x12 8PIC12F629

PIC12CE519 1,536/1,024x12 8 PIC12F629

PIC12CR509A 1,536/1,024x12 8PIC12F509

PIC16C505 1,536/1,024x12 14 PIC16F505

PIC16C54 768/512x12 18 PIC16F54

PIC16C54A 768/512x12 18 PIC16F54

PIC16C54C 768/512x12 18 PIC16F54

PIC16C55 768/512x12 28 PIC16C55A

PIC16C56 1,536/1,024x12 18 PIC16C56A

PIC16C57 3,072/2,048x12 28 PIC16F57

PIC16C57C 3,072/2,048x12 28 PIC16F57

PIC16C62A 3,584/2,048x14 28 PIC16C62B or PIC16F72

PIC16C620 896/2,048x14 18 PIC16C620A

PIC16C621 1,792/1,024x14 18 PIC16C621A

PIC16C622 3,584/2,048x14 18 PIC16C622A

PIC16C63 7,168/4,096x14 28 PIC16C63B or PIC16F73

PIC16C64A 3,584/2,048x14 40 PIC16F74

PIC16C642 7,168/4,096x14 28 PIC16F72

PIC16C65A 7,168/4,096x14 40 PIC16C65B or PIC16F74

PIC16C66 1,4336/8,192x14 28 PIC16F76

PIC16C662 7,168/4,096x14 40 PIC16F74

PIC16C67 14,336/8,192x14 40 PIC16F77

PIC16C71 1,792/1,024x14 18 PIC16F716

PIC16C72 3,584/2,048x14 28 PIC16F72

PIC16C72A 3,584/2,048x14 28 PIC16F72

PIC16C710 896/512x14 18 PIC16F716

PIC16C711 1,792/1,024x14 18 PIC16F716

PIC16C712 1,792/1,024x14 18 PIC16F716

PIC16C715 3,584/2,048x14 18 PIC16F716

PIC16C716 3,584/2,048x14 18 PIC16F716

PIC16C73A 7,168/4,096x14 28 PIC16F73

PIC16C73B 7,168/4,096x14 28 PIC16F73

PIC16C74A 7,168/4,096x14 40 PIC16F74

PIC16C74B 7,168/4,096x14 40 PIC16F74

PIC16C76 14,336/8,192x14 28 PIC16F76

PIC16C77 14,336/8,192x14 40 PIC16F77

PIC16C923 7,168/4,096x14 68 PIC16C925

PIC16C924 7,168/4,096x14 68 PIC16C925

PIC16CE623 896/512x14 18 PIC16F627A

PIC16CE624 1,792/1,024x14 18 PIC16F627A

PIC16CE625 3,584/2,048x14 18 PIC16F628A

PIC16CR54A 768/512x12 18 PIC16CR54C

PIC16CR54C 768/512x12 18 PIC16F54

PIC16CR57C 3,072/2,048x12 28 PIC16F57

PIC16CR83 896/512x14 18 PIC16F84A

PIC16CR84 1,792/1,024x14 18 PIC16F84A

PIC16F627 1,792/1,024x14 18 PIC16F627A

PIC16F628 3,584/2,048x14 18 PIC16F628A

PIC16F83 896/512x14 18 PIC16F84A

PIC16F84 1,792/1,024x14 18 PIC16F84A

PIC16F873 7,168/4,096x14 28 PIC16F873A

PIC16F874 7,168/4,096x14 28 PIC16F874A

PIC16F876 14,336/8,192x14 40 PIC16F876A

PIC16F877 14,336/8,192x14 40 PIC16F877A

PIC17C42A 4,096/2,048x16 40 PIC18F4220

PIC17C43 8,192/4,096x16 40 PIC18F4320

PIC17C44 16,384/8,192x16 40 PIC18F4420

PIC17C752 16,384/8,192x16 68 PIC18F6520

PIC17C756A 32,768/16,384x16 68 PIC18F6520

PIC17C762 16,384/8,192x16 84 PIC18F8520

PIC17C766 32,768/16,384x16 84 PIC18F8520

PIC18C242 16,384/8,192x16 28 PIC18F2420

PIC18C252 32,768/16,384x16 28 PIC18F2520

PIC18C442 16,384/8,192x16 40 PIC18F4420

Product Program Memory

(Bytes/Words) Package Size Recommended Design-In Device

PAGE 46

PICmicro® MCU FAMILY

PIC18C452 32,768/16,384x16 40 PIC18F4520

PIC18C658 32,768/16,384x16 68 PIC18F6585

PIC18C858 32,768/16,384x16 84 PIC18F8585

PIC18F242 16,384/8,192x16 28 PIC18F2420

PIC18F248 16,384/8,192x16 28 PIC18F2480

PIC18F252 32,768/16,384x16 28 PIC18F2520

PIC18F258 32,768/16,384x16 28 PIC18F2580

PIC18F442 16,384/8,192x16 40 PIC18F4420

PIC18F448 16,384/8,192x16 40 PIC18F4480

PIC18F452 32,768/16,384x16 40 PIC18F4520

PIC18F458 32,768/16,384x16 40 PIC18F4580

PIC18F2439 12,288/6,144x16 28 PIC18F2431

PIC18F2539 24,576/12,288x16 28 PIC18F2431

Product Program Memory

(Bytes/Words) Package Size Recommended Design-In Device

PIC18F4439 12,288/6,144x16 40 PIC18F4431

PIC18F4539 24,576/12,288x16 40 PIC18F4431

PIC18F6525 49,152/24,576x16 64 PIC18F6527

PIC18F6620 65,536/32,768x16 64 PIC18F6622

PIC18F6621 65,536/32,768x16 64 PIC18F6622

PIC18F6720 131,072/65,536x16 64 PIC18F6722

PIC18F8525 49,152/24,576x16 80 PIC18F8527

PIC18F8620 65,536/32,768x16 80 PIC18F8622

PIC18F8621 65,536/32,768x16 80 PIC18F8622

PIC18F8720 131,072/65,536x16 80 PIC18F8722

Product Program Memory

(Bytes/Words) Package Size Recommended Design-In Device

PAGE 47

Focused Solutions

FOCUSED SOLUTIONS

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O Pins Packages Analog

Peripherals

Digital

Peripherals

M a x .

Speed

MHz

ICD # of

Breakpoints

Function-Specific Features

Development Boards

ISO-

16845

Tested

Transmit

Buffers Receive

Buffers Configurabl

e RX/TX Acceptance

Filters/Mask

CAN Solutions

PIC18F2480 16 KB EnhFI

(8 KW) 256 768 25 28SP, 28SO, 28ML ADC EUSART, CCP 40 3Planned 3 2 6 16/2 DM163011 PICDEM™ CAN-LIN 2

PIC18F2580 32 KB EnhFI

(16 KW) 256 1536 25 28SP, 28SO, 28ML ADC EUSART, CCP 40 3 Planned 3 2 6 16/2 DM163011 PICDEM™ CAN-LIN 2

PIC18F2585 48 KB EnhFI

(24 KW) 1024 3328 25 28SP, 28SO ADC EUSART, CCP 40 3Planned 3 2 6 16/2 DM163011 PICDEM™ CAN-LIN 2

PIC18F2680 64 KB EnhFI

(32 KW) 1024 3328 25 28SP, 28SO ADC EUSART, CCP 40 3 Planned 3 2 6 16/2 DM163011 PICDEM™ CAN-LIN 2

PIC18F4480 16 KB EnhFI

(8 KW) 256 768 36 40P, 44PT, 44ML ADC/Comp EUSART,

CCP/ECCP 40 3Planned 3 2 6 16/2 DM163011 PICDEM™ CAN-LIN 2

PIC18F4580 32 KB EnhFI

(16 KW) 256 1536 36 40P, 44PT, 44ML ADC/Comp EUSART,

CCP/ECCP 40 3 Planned 3 2 6 16/2 DM163011 PICDEM™ CAN-LIN 2

PIC18F4585 48 KB EnhFI

(24 KW) 1024 3328 36 40P, 44PT, 44ML ADC/Comp EUSART,

CCP/ECCP 40 3Planned 3 2 6 16/2 DM163011 PICDEM™ CAN-LIN 2

PIC18F4680 64 KB EnhFI

(32 KW) 1024 3328 36 40P, 44PT, 44ML ADC/Comp EUSART,

CCP/ECCP 40 3 Planned 3 2 6 16/2 DM163011 PICDEM™ CAN-LIN 2

PIC18F6585 48 KB EnhFI

(24 KW) 1024 3328 53 64PT, 68L ADC/Comp EUSART,

CCP/ECCP 40 1Yes 3 2 6 16/2 DM163015 PICDEM™ CAN-LIN 3

PIC18F6680 64 KB EnhFI

(32 KW) 1024 3328 53 64PT, 68L ADC/Comp EUSART,

CCP/ECCP 40 1 Yes 3 2 6 16/2 DM163015 PICDEM™ CAN-LIN 3

PIC18F8585 48 KB EnhFI

(24 KW) 1024 3328 69 80PT ADC/Comp EUSART,

CCP/ECCP 40 1Yes 3 2 6 16/2 DM163015 PICDEM™ CAN-LIN 3

PIC18F8680 64 KB EnhFI

(32 KW) 1024 3328 69 80PT ADC/Comp EUSART,

CCP/ECCP 40 1 Yes 3 2 6 16/2 DM163015 PICDEM™ CAN-LIN 3

dsPIC30F4011 48 KB EnhFl

(16 KW) 1024 2048 30 40P, 44PT, 44ML

(8x8) ADC CAN, SPI, I2C,

2xUART 120 1Yes 3 2 0 4/2 DM300018 dsPICDEM™ 2

dsPIC30F4012 48 KB EnhFl

(16 KW) 1024 2048 20 28SP, 28SO, 44ML

(8x8) ADC CAN, SPI, I2C,

2xUART 120 1 Yes 3 2 0 4/2 DM300018 dsPICDEM™ 2

dsPIC30F4013 48 KB EnhFl

(16 KW) 1024 2048 30 40P, 44PT, 44ML

(8x8) ADC CAN, SPI, I2C,

2xUART 120 1Yes 3 2 0 4/2 DM300018 dsPICDEM™ 2

dsPIC30F5011 65 KB EnhFl

(22 KW) 1024 4096 52 64PT ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2 Yes 3 2 0 4/2 DM300014 dsPICDEM™ 1.1 GP

dsPIC30F5013 65 KB EnhFl

(22 KW) 1024 4096 68 80PT ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2Yes 3 2 0 4/2 DM300014 dsPICDEM™ 1.1 GP

dsPIC30F5015 66 KB EnhFl

(22 KW) 1024 2048 52 64PT ADC CAN, UART,

2xSPI, I2C120 2 Yes 3 2 0 4/2 DM300020***

dsPIC30F5016 66 KB EnhFl

(22 KW) 1024 2048 68 80PT ADC CAN, UART,

2xSPI, I2C120 2Yes 3 2 0 4/2 DM300020***

dsPIC30F6010 147 KB EnhFl

(49 KW) 4096 8192 68 80PF ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2 Yes 3 2 0 4/2 DM300020***

dsPIC30F6010A 144 KB EnhFl

(48 KW) 4096 8192 68 80PF, 80PT ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2Yes 3 2 0 4/2 DM300020***

dsPIC30F6011 131 KB EnhFl

(44 KW) 2048 6144 52 64PF ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2 Yes 3 2 0 4/2 DM300014 dsPICDEM™ 1.1 GP

dsPIC30F6011A 131 KB EnhFl

(44 KW) 2048 6144 52 64PF, 64PT ADC 2xCAN, 2xSPI,

I2C, 2xUARTC120 2Yes 3 2 0 4/2 DM300014 dsPICDEM™ 1.1 GP

PAGE 48

Focused Solutions

CAN Solutions (continued)

dsPIC30F6012 147 KB EnhFl

(49 KW) 4096 8192 52 64PF ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2 Yes 3 2 0 4/2 DM300014 dsPICDEM 1.1 GP

Board

dsPIC30F6012A 147 KB EnhFl

(49 KW) 4096 8192 52 64PF, 64PT ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2Yes 3 2 0 4/2 DM300014 dsPICDEM 1.1 GP

Board

dsPIC30F6013 131 KB EnhFl

(44 KW) 2048 6144 68 80PF ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2 Yes 3 2 0 4/2 DM300014 dsPICDEM 1.1 GP

Board

dsPIC30F6013A 131 KB EnhFl

(44 KW) 2048 6144 68 80PF, 80PT ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2Yes 3 2 0 4/2 DM300014 dsPICDEM 1.1 GP

Board

dsPIC30F6014 147 KB EnhFl

(49 KW) 4096 8192 68 80PF ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2 Yes 3 2 0 4/2 DM300014 dsPICDEM 1.1 GP

Board

dsPIC30F6014A 147 KB EnhFl

(49 KW) 4096 8192 68 80PF, 80PT ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2Yes 3 2 0 4/2

Refer to Connectivity Design Center on www.microchip.com/can for further details.

Abbreviations are found on the last page of the Selector Guide.

Part # Operating

Voltage (V) Temperature

Range (°C) Tx Buffers Rx Buffers Filters Masks Interrupt

Output Unique Features Packages

CAN Peripherals/Transceivers

MCP25152.7 to 5.5-40 to +1253262Yes

MCP2510 pin compatible upgrade with enhanced

features including higher throughput and data byte

filtering 18-Pin PDIP, 18-Pin SOIC, 20-Pin TSSOP

MCP25020 2.7 to 5.5 -40 to +125 3 2 2 1 N/A CAN 2.0B Active I/O Expander. See “Interface

Section” of the Analog/Interface Family Products. 14-Pin PDIP, 14-Pin SOIC

MCP250252.7 to 5.5-40 to +853221N/A

CAN 2.0B Active I/O Expander. See “Interface

Section” of the Analog/Interface Family Products. 14-Pin PDIP, 14-Pin SOIC

MCP25050 2.7 to 5.5 -40 to +125 3 2 2 1 N/A CAN 2.0B Active I/O Expander. See “Interface

Section” of the Analog/Interface Family Products. 14-Pin PDIP, 14-Pin SOIC

MCP250552.7 to 5.5-40 to +853221N/A

CAN 2.0B Active I/O Expander. See “Interface

Section” of the Analog/Interface Family Products. 14-Pin PDIP, 14-Pin SOIC

MCP2551 4.5 to 5.5 -40 to +125 n/a n/a n/a n/a N/A CAN 2.0B Active I/O Expander. See “Interface

Section” of the Analog/Interface Family Products. 8-Pin PDIP, 8-Pin SOIC

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O Pins Packages Analog

Peripherals

Digital

Peripherals

M a x .

Speed

MHz

ICD # of

Breakpoints

Function-Specific Features

Development Boards

ISO-

16845

Tested

Transmit

Buffers Receive

Buffers Configurabl

e RX/TX Acceptance

Filters/Mask

wwwwwwwww

PAGE 49

Focused Solutions

Product

Program

Memory Bytes

& Type

(Words)

EEPROM

Data

Memory

RAM

Bytes I/O Pins Packages Analog

Peripherals

Digital Periph-

erals

Max.

Speed

MHz

ICD # of

Breakpoints

Function-Specific Features

IEEE.802.3

Compliant MAC PHY TX/RX

Buffer

(bytes)

Ethernet Voltage

Range (V)

Ethernet Solutions – Integrated

PIC18F66J60*16,384 EnhFl

(8,192) — 2048 39 64PT ADC/Comp EUSART, CCP/

ECCP 42 3 Yes Yes 10 Base-T 8192 3.14 to 3.45

PIC18F66J65*32,768 EnhFl

(16,384) —3808 39 64PT ADC/Comp EUSART, CCP/

ECCP 42 3Yes Yes 10 Base-T 8192 3.14 to 3.45

PIC18F67J60*49,152 EnhFl

(24,576) — 3808 39 64PT ADC/Comp EUSART, CCP/

ECCP 42 3 Yes Yes 10 Base-T 8192 3.14 to 3.45

PIC18F86J60*65,536 EnhFl

(32,768) —2048 55 80PT ADC/Comp EUSART, CCP/

ECCP 42 3Yes Yes 10 Base-T 8192 3.14 to 3.45

PIC18F86J65*16,384 EnhFl

(8,192) — 3808 55 80PT ADC/Comp EUSART, CCP/

ECCP 42 3 Yes Yes 10 Base-T 8192 3.14 to 3.45

PIC18F87J60*32,768 EnhFl

(16,384) —3808 55 80PT ADC/Comp EUSART, CCP/

ECCP 42 3Yes Yes 10 Base-T 8192 3.14 to 3.45

PIC18F96J60*49,152 EnhFl

(24,576) — 3808 70 100PT ADC/Comp EUSART, CCP/

ECCP 42 3 Yes Yes 10 Base-T 8192 3.14 to 3.45

PIC18F96J65*65,536 EnhFl

(32,768) —3808 70 100PT ADC/Comp EUSART, CCP/

ECCP 42 3Yes Yes 10 Base-T 8192 3.14 to 3.45

PIC18F97J60*49,152 EnhFl

(24,576) — 3808 70 100PT ADC/Comp EUSART, CCP/

ECCP 42 3 Yes Yes 10 Base-T 8192 3.14 to 3.45

Abbreviations are found on the last page of the Selector Guide.

Product MAC PHY TX/RX Dual

Port RAM

Buffer Interrupts LEDs Operating

Voltage (V) Max. Speed

MHz Serial Features Package

Ethernet Solutions – Stand-Alone

ENC28J60 Yes 10 Base-T 8 KB 2 2 3.3 25 SPI Loopback Test modes, auto-polarity 28SO, 28SS, 28ML

Abbreviations are found on the last page of the Selector Guide.

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog

Peripherals

Digital

Peripherals

M a x .

Speed

MHz

ICD # of

Breakpoints

Function-Specific Features

Development Boards

Compliant Speed # of

Endpoints USB Buffer

(bytes) Streaming

Port

USB Solutions

PIC16C745 14,336 OTP

(8,192) —256 22 28SP, 28SO, 28JW ADC UART 24 —USB 1.1 Low-Speed

(1.5 Mbit/s) 16 64 —DM163010 PICDEM™ USB

PIC16C765 14,336 OTP

(8,192) — 256 33 40P, 40JW, 44L,

44PT ADC UART 24 — USB 1.1 Low-Speed

(1.5 Mbit/s) 16 64 — DM163010 PICDEM™ USB

PIC18F2450*16384 EnhFl

(8192) —768 23 28SP, 28SO, 28ML ADC/Comp USB 2.0,

AUSARtT 48 3USB 2.0 Full-Speed

(12 Mbit/s) 16 256 —DM163025 PICDEM™ FS-USB

PIC18F2455 24,576 EnhFI

(12,288) 256 2048 24 28SP, 28SO ADC/Comp EUSART,

MI2C/SPI 48 3 USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 — DM163025 PICDEM™ FS-USB

PIC18F2550 32,768 EnhFI

(16,384) 256 2048 24 28SP, 28SO ADC/Comp EUSART,

MI2C/SPI 48 3USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 —DM163025 PICDEM™ FS-USB

*Contact Microchip Technology Inc. for availability.

Refer to Connectivity Design Center on www.microchip.com/usb for further details.

Abbreviations are found on the last page of the Selector Guide.

PAGE 50

Focused Solutions

USB Solutions (continued)

PIC18F4450*16,384 EnhFl

(8183) — 768 34 40P, 44ML, 44PT ADC/Comp USB 2.0,

AUSART 48 3 USB 2.0 Full-Speed

(12 Mbit/s) 16 256 — DM163025 PICDEM™ FS-USB

PIC18F4455 24,576 EnhFI

(12,288) 256 2048 36 40P, 44PT, 44ML ADC/Comp EUSART,

MI2C/SPI 48 3USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 ✓DM163025 PICDEM™ FS-USB

PIC18F4550 32,768 EnhFI

(16,384) 256 2048 36 40P, 44PT, 44ML ADC/Comp EUSART,

MI2C/SPI 48 3 USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 ✓DM163025 PICDEM™ FS-USB

PIC18F65J50*32,768 StdFl

(16,384) 3936 50 64PT ADC/Comp USB 2.0,

2xEUSART,

2xMI2C/SPI 48 3USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 —

PIC18F66J50*65,536 StdFl

(32768) — 3936 50 64PT ADC/Comp USB 2.0,

2xEUSART,

2xMI2C/SPI 48 3 USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 —

PIC18F67J50*131,072 StdFl

(65536) —3936 50 64PT ADC/Comp USB 2.0,

2xEUSART,

2xMI2C/SPI 48 3USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 —

PIC18F85J50*32,768 StdFl

(16384) — 3936 66 80PT ADC/Comp USB 2.0,

2xEUSART,

2xMI2C/SPI 48 3 USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 —

PIC18F86J50*65,536 StdFl

(32,768) —3936 66 80PT ADC/Comp USB 2.0,

2xEUSART,

2xMI2C/SPI

48 3USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 —

PIC18F87J50*131,072 StdFl

(65,536) — 3936 66 80PT ADC/Comp USB 2.0,

2xEUSART,

2xMI2C/SPI

48 3 USB 2.0 Full-Speed

(12 Mbit/s) 16 1024 —

Part # Mode Cell Type # of Cells VCC Range (V) Max. Voltage

Regulation (%) Int/Ext FET Features Packages

USB Battery Chargers

MCP73853 Linear Li-Ion/Li-Polymer 14.5 to 5.5 +0.5 Int USB control, Safety charge timers, Temperature monitor, Thermal

regulation 16-Pin QFN (4x4)

MCP73855 Linear Li-Ion/Li-Polymer 1 4.5 to 5.5 +0.5 Int USB control, Safety charge timers, Thermal regulation 10-Pin DFN (3x3)

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog

Peripherals

Digital

Peripherals

M a x .

Speed

MHz

ICD # of

Breakpoints

Function-Specific Features

Development Boards

Compliant Speed # of

Endpoints USB Buffer

(bytes) Streaming

Port

*Contact Microchip Technology Inc. for availability.

Refer to Connectivity Design Center on www.microchip.com/usb for further details.

Abbreviations are found on the last page of the Selector Guide.

PAGE 51

Focused Solutions

Product Mode Cell Type # of Cells VIN Range (V) Max. Voltage

Regulation

(%) Int/Ext FET Features Package

Switching Battery Chargers

PS200*Switch Li-Ion / Li-Polymer 1-4 5-18 +1% Ext Voltage and current regulation, safety charge timers

and temperature limits, internal voltage regulator,

500 kHz (max.) PWM 20-Pin PDIP, SOIC, SSOP

* Contact Microchip Technology for availability.

Product Battery

Chemistry # of Cells Interface Data Set A/D

Converter Programmable

Memory Programmable

I/O Functions Accuracy Time Base Temp.

Sensor Packaging Description

Battery Fuel Gauge ICs

PS501 Li-Ion

NiMH 2-4

6-12 SMBus > 1% 16-bit

Sigma-Delta 16 Kbytes Flash,

256 bytes EEPROM 12 GPIO - On-chip On-chip

external 28-pin SSOP

Single chip field reprogrammable battery

manager IC reports capacity, current,

temperature, voltage and other status for

Li-Ion or Nickel batteries.

PS810 Li-Ion 1SMBus/SI -16-bit

Sigma-Delta 4k x 16 Flash 6 GPIO 1% On-chip On-chip 14-pin TSSOP,

16-pin QFN

Single cell Li-Ion fuel gauge provides

battery status such as run time to empty,

run time to full, relative state-of-charge and

battery state-of-health.

Radio Frequency Solutions

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O Pins Packages Analog

Peripherals Digital

Peripherals Max. Speed

(MHz)

Function-Specific Specifications

Development Boards

Modulation Data

Rate

(kbps)

Output

Power

(dBm)

Operating

Voltage (V)

Frequency

Range

(MHz)

rfPIC® Microcontrollers with UHF RF Transmitter, ICSP™

rfPIC12C509AF 1,536 OTP

(1,024) —41 620JW, 20SS —1-8 bit Timer, WDT 4FSK, ASK 40 22.5-5.5 310-440

rfPIC12C509AG 1,536 OTP

(1,024) — 41 6 18JW, 18SO — 1-8 bit Timer, WDT 4 ASK 40 2 2.5-5.5 310-440

rfPIC12F675F 1,792 StdFI

(1,024) 128 64 620SS 4x10-bit A/D, Comp 1-8 bit, 1-16 bit

Timer, WDT 20 FSK, ASK 40 10 2.0-5.5 380-450 DV164102 rfPIC® Development Kit

rfPIC12F675H 1,792 StdFI

(1,024) 128 64 6 20SS 4x10-bit A/D, Comp 1-8 bit, 1-16 bit

Timer, WDT 20 FSK, ASK 40 10 2.0-5.5 850-930 DV164102 rfPIC® Development Kit

rfPIC12F675K 1,792 StdFI

(1,024) 128 64 620SS 4x10-bit A/D, Comp 1-8 bit, 1-16 bit

Timer, WDT 20 FSK, ASK 40 10 2.0-5.5 290-350 DV164102 rfPIC® Development Kit

Product Transmission

Code Length

Bits

Code

Hopping

Bits

Programmable

Encryption Key

Bits Packages Protocols Function Codes Tunable

OSC CRC

Function-Specific Specifications

Development Boards

Modulation Output Power

(dBm) Operating

Voltage (V)

Frequency

Range

(MHz)

rfHCS KEELOQ® Encoders with UHF RF Transmitter

rfHCS362F 69 32 2 x 64 20SS PWM, Manchester 4 x 15 ✓✓FSK, ASK 2 2.2-5.5 310-440 DM303006 KEELOQ® Evaluation Kit II

rfHCS362G 69 32 2 x 64 18SO PWM, Manchester 4 x 15 ✓ ✓ ASK 22.2-5.5 310-440 DM303006 KEELOQ® Evaluation Kit II

wwwww

PAGE 52

Focused Solutions

Product Modulation Data Rate

(kbps) Frequency Range

(MHz) Sensitivity dBm

(FSK) IF Frequency

Range (MHz) Operating Voltage (V) Package Development Boards

UHF RF Receiver

rfRXD0420 ASK, FSK, FM 80 300-450 -111 0.455-21.4 2.5-5.5 32LQ DV164102 rfPIC® Development Kit

rfRXD0920 ASK, FSK, FM 80 800-930 -109 0.455-21.4 2.5-5.5 32LQ DV164102 rfPIC® Development Kit

Refer to Design pages on www.microchip.com for further details.

Abbreviations are found on the last page of the Selector Guide.

Product Carrier Frequency Programming Anticollision Memory Type Memory Size Protocols Packages Other

microID® RFID Tagging Devices

MCRF355 13.56 MHz Contact/Factory Yes R/W 154 bits ASK Manchester W, WF, S, WB, WFB, SB, P, SN –

MCRF360 13.56 MHz Contact/Factory Yes R/W 154 bits ASK Manchester W, WF, S, WB, WFB, SB, P, SN 100 pF res cap

MCRF450 13.56 MHz Contactless Yes R/W 1 Kbit PPM, ASK Manchester W, WF, S, WB, WFB, SB, P, SN 32-bit unique ID user

lock control by block

MCRF452 13.56 MHz Contactless Yes R/W 1 Kbit PPM, ASK Manchester W, WF, S, WB, WFB, SB, P, SN Dual 50 pF res cap

Product

Program

Memory

Bytes &

Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog

Peripherals

Digital

Peripherals

M a x .

Speed

MHz

ICD # of

Breakpoints

LCD Function-Specific Features

Development Boards

COMxSegment =

# Segments

Drive

Sleep

Software

Configurable

Driver Pins Direct Drive Intl.

Charge

Pump

LCD Solutions

PIC16C925 7,168 OTP

(4,096) — 176 52 64PT, 68CL, 68L ADC I2C/SPI 20 — 4x29 (116) Yes No Yes Yes DM163003 PICDEM™ 3 LCD

PIC16C926 14,336 OTP

(8,192) —336 52 64PT, 68CL, 68L ADC I2C/SPI 20 —4x29 (116) Yes No Yes Ye s DM163003 PICDEM™ 3 LCD

PIC16F913 7,168 StdFI

(4,096) 256 256 25 28P, 28SO, 28SS,

28ML ADC/Comp AUSART,

I2C/SPI 20 1 4x15 (60) Yes Yes Yes No DS163028 PICDEM™ LCD

PIC16F914 7,168 StdFI

(4,096) 256 256 36 40P, 44PT, 44ML ADC/Comp AUSART,

I2C/SPI 20 14x24 (96) Yes Yes Yes No DS163028 PICDEM™ LCD

PIC16F916 14,336 StdFI

(8,192) 256 352 25 28P, 28SO, 28SS,

28ML ADC/Comp AUSART,

I2C/SPI 20 1 4x15 (60) Yes Yes Yes No DS163028 PICDEM™ LCD

PIC16F917 14,336 StdFI

(8,192) 256 352 36 40P, 44PT, 44ML ADC/Comp AUSART,

I2C/SPI 20 14x24 (96) Yes Yes Yes No DS163028 PICDEM™ LCD

PIC16F946 14,336 StdFI

(8,192) 256 336 53 64PT ADC/Comp AUSART,

I2C/SPI 20 1 4x42 (168) Yes Yes Yes No DS163028 PICDEM™ LCD

PIC18F6390 8,192 StdFI

(4,096) —768 50 64PT ADC/Comp EUSART,

AUSART,

MI2C/SPI

40 34x32 (128) Yes Yes Yes No DM163028 PICDEM™ LCD

PIC18F63J90*8,192 StdFl

(4,096) — 1024 49 64PT ADC/Comp EUSART,

AUSART,

MI2C/SPI

40 3 4x32 (128) Yes Yes Yes Yes

PIC18F6490 1,6384 StdFI

(8,192) —768 50 64PT ADC/Comp

EUSART,

AUSART,

MI2C/SPI 40 34x32 (128) Yes Yes Yes No DM163028 PICDEM™ LCD

*Contact Microchip Technology Inc. for availability.

Refer to LCD Design Center on www.microchip.com/lcd for further details.

Abbreviations are found on the last page of the Selector Guide.

PAGE 53

Focused Solutions

LCD Solutions (continued)

PIC18F64J90*16,384 StdFl

(8,192) — 1024 49 64PT ADC/Comp EUSART,

AUSART,

MI2C/SPI 40 3 4x32 (128) Yes Yes Yes Yes

PIC18F65J90*32,768 StdFl

(16,384) —2048 49 64PT ADC/Comp EUSART,

AUSART,

MI2C/SPI 40 34x32 (128) Yes Yes Yes Yes

PIC18F8390 8,192 StdFI

(4,096) — 768 66 80PT ADC/Comp EUSART,

AUSART,

MI2C/SPI 40 3 4x48 (192) Yes Yes Yes No DM163028 PICDEM™ LCD

PIC18F83J90*8,192 StdFl

(4096) —1024 65 80PT ADC/Comp EUSART,

AUSART,

MI2C/SPI

40 34x48 (192) Yes Yes Yes Yes

PIC18F8490 16,384 StdFI

(8,192) — 768 66 80PT ADC/Comp EUSART,

AUSART,

MI2C/SPI

40 3 4x48 (128) Yes Yes Yes No DM163028 PICDEM™ LCD

PIC18F84J90*16,384 StdFl

(8,192) —1024 65 80PT ADC/Comp

EUSART,

AUSART,

MI2C/SPI 40 34x48 (192) Yes Yes Yes Yes

PIC18F85J90*32,768 StdFI

(16,384) — 2048 65 80PT ADC/Comp

EUSART,

AUSART,

MI2C/SPI 40 3 4x48 (192) Yes Yes Yes Yes

Display Solutions

Part # Display Type Supply Voltage (V) Resolution

(Digits) Resolution

(Counts) Power (mW) Temp. Range

(°C) Features Packages

TC820 LCD 9 3¾ ±4,000 10 0 to +70 DMM plus frequency counter and logic probe 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP

TC7106 LCD 93½ ±2,000 10 -25 to +85 For DMM, DPM, Data logger applications 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7106A LCD 9 3½ ±2,000 10 -25 to +85 For DMM, DPM, Data logger applications 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7116 LCD 93½ ±2,000 10 -25 to +85 Hold function 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7116A LCD 9 3½ ±2,000 10 -25 to +85 Hold function 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7126 LCD 93½ ±2,000 0.5 -25 to +85 Low-power TC7106 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7126A LCD 9 3½ ±2,000 0.5 -25 to +85 Low-power TC7106 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP,

40-Pin CerDIP

TC7129 LCD 94½ ±20,000 4.5 0 to +70 Lowest noise ±3 mV sensitivity 40-Pin PDIP, 44-Pin PLCC, 44-Pin MQFP

Product

Program

Memory

Bytes &

Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog

Peripherals

Digital

Peripherals

M a x .

Speed

MHz

ICD # of

Breakpoints

LCD Function-Specific Features

Development Boards

COMxSegment =

# Segments

Drive

Sleep

Software

Configurable

Driver Pins Direct Drive Intl.

Charge

Pump

*Contact Microchip Technology Inc. for availability.

Refer to LCD Design Center on www.microchip.com/lcd for further details.

Abbreviations are found on the last page of the Selector Guide.

PAGE 54

Focused Solutions

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog

Peripherals

Digital Periph-

erals

M a x .

Speed

MHz

ICD # of

Breakpoints

Function-Specific Features

Development Boards

Timers Input

Capture

Output

Comp/Std

PWM

Motor

Control

PWM

Quadrature

Encoder

Motor Control Solutions

PIC12F683 3,584 StdFI

(2,048) 256 128 6 8P, 8SN, 8MF ADC/Comp — 20 1 1-16 bit, 2-8 bit,

WDT 1 1x10 bit — — PICkit™ 1

PIC16F684 3,584 EnhFI

(2,048) 256 128 12 14P, 14SL, 14ST ADC/Comp —20 11-16 bit, 2-8 bit,

WDT 14x10 bit — — PICkit™ 1

PIC16F716 3,584 StdFI

(2,048) — 128 13 18P, 18SO, 20SS ADC — 20 1 1-16 bit, 2-8 bit,

WDT 1 4x10 bit — — DM163022 PICDEM™ 2 Plus

PIC16F737 7,168 StdFI

(4,096) —368 25 28SP, 28SO,

28SS, 28ML ADC/Comp USART,

MI2C/SPI 20 11-16 bit, 2-8 bit,

WDT 33x10 bit — — DM163022 PICDEM™ 2 Plus

PIC16F747 7,168 StdFI

(4,096) — 368 36 40P, 44PT, 44ML ADC/Comp USART,

MI2C/SPI 20 1 1-16 bit, 2-8 bit,

WDT 3 3x10 bit — — DM163022 PICDEM™ 2 Plus

PIC16F767 14,336 StdFl

(8,192) —368 25 28SP, 28SO,

28SS, 28ML ADC/Comp USART,

MI2C/SPI 20 11-16 bit, 2-8 bit,

WDT 33x10 bit — — DM163022 PICDEM™ 2 Plus

PIC16F777 14,336 StdFI

(8,192) — 368 36 40P, 44PT, 44ML ADC/Comp USART,

MI2C/SPI 20 1 1-16 bit, 2-8 bit,

WDT 3 3x10 bit — — DM163022 PICDEM™ 2 Plus

PIC18F1230*4,096 EnhFI

(2048) 128 256 16 18P, 18SO, 20SS,

28ML ADC/Comp EUSART 40 32-16 bit, 1-WDT — — 6 —

PIC18F1330*8,192 EnhFI

(4,096) 128 256 16 18P, 18SO, 20SS,

28ML ADC/Comp EUSART 40 3 2-16 bit, 1-WDT — — 6 —

PIC18F2331 8,192 EnhFI

(4,096) 256 768 22 28SP, 28SO,

28MM 200 ksps

ADC

EUSART,

I2C/SPI 40 1 3-16 bit, 1-8 bit,

WDT 32x10 bit 6Yes DM183011 PICDEM™ MC,

DM183021 PICDEM™ MC LV,

PIC18F4431 Plug-in Module

PIC18F2431 16,384 EnhFI

(8,192) 256 768 22 28SP, 28SO,

28MM 200 ksps

ADC

EUSART,

I2C/SPI 40 1 3-16 bit, 1-8 bit,

WDT 3 2x10 bit 6 Yes DM183011 PICDEM™ MC,

DM183021 PICDEM™ MC LV,

PIC18F4431 Plug-in Module

PIC18F4331 8,192 EnhFI

(4,096) 256 768 34 40P, 44PT, 44ML 200 ksps

ADC

EUSART,

I2C/SPI 40 13-16 bit, 1-8 bit,

WDT 32x10 bit 8Yes DM183011 PICDEM™ MC,

DM183021 PICDEM™ MC LV,

PIC18F4431 Plug-in Module

PIC18F4431 16,384 EnhFI

(8,192) 256 768 34 40P, 44PT, 44ML 200 ksps

ADC

EUSART,

I2C/SPI 40 1 3-16 bit, 1-8 bit,

WDT 3 2x10 bit 8 Yes DM183011 PICDEM™ MC,

DM183021 PICDEM™ MC LV,

PIC18F4431 Plug-in Module

dsPIC30F2010 12,288 EnhFl

(4,096) 1024 512 20 28SO, 28SP,

28MM (6x6) 1 msps ADC UART,

I2C/SPI 120 1 3-16 bit, WDT 4 2 6 Yes DM300020***

dsPIC30F3010 24,576 EnhFl

(8,102) 1024 1024 20 28SO, 28SP,

44ML (8x8) 1 msps ADC UART,

I2C/SPI 120 2 5-16 bit, WDT 4 2 6 Yes DM300020***

dsPIC30F3011 24,576 EnhFl

(8,102) 1024 1024 30 40P, 44PT,

44ML (8x8) 1 msps ADC 2xUART,

I2C/SPI 120 25-16 bit, WDT 4 4 6 Yes DM300020***

dsPIC30F4011 49,152 EnhFl

(16,384) 1024 2048 30 40P, 44PT,

44ML (8x8) 1 msps ADC 2xUART,

I2C/SPI, CAN 120 1 5-16 bit, WDT 4 4 6 Yes DM300020***

dsPIC30F4012 49,152 EnhFl

(16,384) 1024 2048 20 28SO, 28SP,

44ML (8x8) 1 msps ADC UART,

I2C/SPI, CAN 120 15-16 bit, WDT 4 2 6 Yes DM300020***

dsPIC30F5015 65,536 EnhFl

(21,845) 1024 2048 52 64PT 1 msps ADC CAN, I2C,

UART, 2xSPI 120 2 5-16 bit, WDT 4 4 8 Yes DM300020***

*Contact Microchip Technology Inc. for availability.

***Refer to dsPIC® DSC Brochure for further details.

Refer to Motor Control Design Center on www.microchip.com/motor for further details.

Abbreviations are found on the last page of the Selector Guide.

PAGE 55

Focused Solutions

Motor Control Solutions (continued)

dsPIC30F5016 65,536 EnhFl

(21,845) 1024 2048 68 80PT 1 msps ADC CAN, I2C,

UART, 2xSPI 120 25-16 bit WDT 4 4 8 Yes DM300020***

dsPIC30F6010 147,456 EnhFl

(49,152) 4096 8192 68 80PF 1 msps ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2 5-16 bit, WDT 8 8 8 Yes DM300020***

dsPIC30F6010A 144KB EnhFl

(48KW) 4096 8192 68 80PF, 80PT 1 msps ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 25-16 bit, WDT 8 8 8 Yes DM300020***

dsPIC30F6015 144KB EnhFl

(48KW) 4096 8192 52 64PT 1 msps ADC 2xCAN, 2xSPI,

I2C, 2xUART 120 2 5 16-bit, WDT 8 8 8 Yes DM300020***

Motor Control Solutions - MOSFET Drivers

Part # Configuration Operating

Temperature

Range (°C)

Peak Output

Current (A)

Output Resistance

(RH/RL)

(Max. Ω @ 25°C)

Max. Supply Voltage

(V) Input/Output Delay (td1, td2)(1)

(ns) Packages

TC1410 Single, Inverting -40 to +85 0.5 22/22 16 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1411 Single, Inverting -40 to +85 1 11/11 16 30/30 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1412 Single, Inverting -40 to +85 26/6 16 35/35 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC1413 Single, Inverting -40 to +85 3 4/4 16 35/35 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

TC4421 Single, Inverting -40 to +125 91.4 (typ)/1.7 18 30/33 8-Pin PDIP, 5-Pin TO-220, 8-Pin DFN

TC4422 Single, Non-inverting -40 to +125 9 1.4 (typ)/1.7 18 30/33 8-Pin PDIP, 5-Pin TO-220, 8-Pin DFN

TC4423 Dual, Inverting -40 to +125 35/5 18 33/38 8-Pin PDIP, 16-Pin SOIC (W), 8-Pin DFN

TC4425 Dual, Inverting and Non-inverting -40 to +125 3 5/5 18 33/38 8-Pin PDIP, 16-Pin SOIC (W), 8-Pin DFN

NOTE 1: *tD1 = delay time from input low-to-high transition to output transition. tD2 = delay time from input high-to-low transition to output transition.

Motor Control Solutions - LINEAR – Comparators

Part # # per

Package VREF (V) Typical

Propagation

Delay (μs)

IQ Typical

(μA) VOS Max (mV) Operating

Voltage (V) Temp. Range

(°C) Features Packages

TC1027 41.2 418 51.8 to 5.5 -40 to +85 On-board VREF, Rail-to-Rail Input/Output 16-Pin PDIP, 16-Pin QSOP, 16-Pin SOIC

TC1037 1 — 4 4 5 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output 5-Pin SOT-23A(S)

TC1038 1 — 4 4 5 1.8 to 5.5 -40 to +85 Shutdown pin, Rail-to-Rail Input/Output 6-Pin SOT-23A(S)

TC1039 1 1.2 4 6 5 1.8 to 5.5 -40 to +85 On-board VREF, Rail-to-Rail Input/Output 6-Pin SOT-23A(S)

TC1041 21.2 410 51.8 to 5.5 -40 to +85 On-board VREF, Programmable hysteresis, Rail-to-Rail

Input/Output 8-Pin MSOP, 8-Pin SOIC

Product

Program

Memory

Bytes & Type

(Words)

EEPROM

Data

Memory

Bytes

RAM

Bytes I/O

Pins Packages Analog

Peripherals

Digital Periph-

erals

M a x .

Speed

MHz

ICD # of

Breakpoints

Function-Specific Features

Development Boards

Timers Input

Capture

Output

Comp/Std

PWM

Motor

Control

PWM

Quadrature

Encoder

*Contact Microchip Technology Inc. for availability.

***Refer to dsPIC® DSC Brochure for further details.

Refer to Motor Control Design Center on www.microchip.com/motor for further details.

Abbreviations are found on the last page of the Selector Guide.

PAGE 56

Focused Solutions

MCP6541 1 — 4 1 5 1.6 to 5.5 -40 to +85 Push-Pull, Rail-to-Rail Input/Output 5-Pin SOT-23(S,R), 5-Pin SC-70(S),

8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6542 2 — 4 1 5 1.6 to 5.5 -40 to +85 Push-Pull, Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6543 1 — 4 1 5 1.6 to 5.5 -40 to +85 Push-Pull, Rail-to-Rail Input/Output, Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6544 4 — 4 1 5 1.6 to 5.5 -40 to +85 Push-Pull, Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6546 1 — 4 1 5 1.6 to 5.5 -40 to +85 Open-drain, 9V, Rail-to-Rail Input/Output 5-Pin SOT-23(S,R), 5-Pin SC-70(S),

8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6547 2 — 4 1 5 1.6 to 5.5 -40 to +85 Open-drain, 9V, Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6548 1 — 4 1 5 1.6 to 5.5 -40 to +85 Open-drain, 9V, Rail-to-Rail Input/Output, Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6549 4 — 4 1 5 1.6 to 5.5 -40 to +85 Open-drain, 9V, Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

Legend: S = Standard Pinout; R = Reverse Pinout

Part # # per Package GBWP IQ Typical

(μA) VOS Max

(mV)

Input Voltage

Noise Density

(nV/rtHz)

Operating Voltage

(V) Temp. Range

(°C) Features Packages

Motor Control Solutions - LINEAR – Op Amps

TC1034 190 kHz 61.5 125(1) 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output 5-Pin SOT-23A(R)

TC1035 1 90 kHz 6 1.5 125(1) 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output, Shutdown pin 6-Pin SOT-23A(R)

TC1029 290 kHz 12 1.5 125(1) 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin MSOP, 8-Pin SOIC

TC1030 4 90 kHz 5 1.5 125(1) 1.8 to 5.5 -40 to +85 Rail-to-Rail Input/Output, Shutdown pins 16-Pin QSOP

MCP6041 114 kHz 0.6 3170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP,

5-Pin SOT-23(S)

MCP6042 2 14 kHz 0.6 3 170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6043 114 kHz 0.6 3170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6044 4 14 kHz 0.6 3 170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP6141 1100 kHz 0.6 3170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, G>10 stable 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6142 2 100 kHz 0.6 3 170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, G>10 stable 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6143 1100 kHz 0.6 3170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, G>10 stable,

Chip Select 8-Pin PDIP, 8-Pin SOIC, 8-Pin MSOP

MCP6144 4 100 kHz 0.6 3 170(1) 1.4 to 5.5 -40 to +85 Rail-to-Rail Input/Output, G>10 stable 14-Pin PDIP, 14-Pin SOIC, 14-Pin TSSOP

MCP606 1155 kHz 19 0.25 38(1) 2.5 to 5.5 -40 to +85 Rail-to-Rail Output 8-Pin PDIP, 8-Pin SOIC, 8-Pin TSSOP,

5-Pin SOT23(S)

Legend: S = Standard Pinout; R = Reverse Pinout; U = Alternative Pinout

NOTE 1: Values are typical at 1 kHz

2: Values are typical at 10 kHz

Motor Control Solutions - LINEAR – Comparators (continued)

Part # # per

Package VREF (V) Typical

Propagation

Delay (μs)

IQ Typical

(μA) VOS Max (mV) Operating

Voltage (V) Temp. Range

(°C) Features Packages

PAGE 57

Focused Solutions

Motor Control Solutions - LINEAR – Op Amps (continued)
