ST7735R Preliminary by Adafruit Industries LLC Datasheet

ST

ST7735R

262K Color Single-Chip TFT Controller/Driver

V0.2 1 2009-8-5

1 Introduction

The ST7735R is a single-chip controller/driver for 262K-color, graphic type TFT-LCD. It consists of 396 source line and 162

gate line driving circuits. This chip is capable of connecting directly to an external microprocessor, and accepts Serial

Peripheral Interface (SPI), 8-bit/9-bit/16-bit/18-bit parallel interface. Display data can be stored in the on-chip display data

RAM of 132 x 162 x 18 bits. It can perform display data RAM read/write operation with no external operation clock to

minimize power consumption. In addition, because of the integrated power supply circuits necessary to drive liquid crystal,

it is possible to make a display system with fewer components.

2 Features

Single chip TFT-LCD Controller/Driver with RAM

On-chip Display Data RAM (i.e. Frame Memory)

132 (H) x RGB x 162 (V) bits

LCD Driver Output Circuits:

Source Outputs: 132 RGB channels

Gate Outputs: 162 channels

Common electrode output

Display Colors (Color Mode)

Full Color: 262K, RGB=(666) max., Idle Mode OFF

Color Reduce: 8-color, RGB=(111), Idle Mode ON

Programmable Pixel Color Format (Color Depth) for

Various Display Data input Format

12-bit/pixel: RGB=(444) using the 384k-bit frame memory

and LUT

16-bit/pixel: RGB=(565) using the 384k-bit frame memory

and LUT

18-bit/pixel: RGB=(666) using the 384k-bit frame memory

and LUT

Various Interfaces

Parallel 8080-series MCU Interface

(8-bit, 9-bit, 16-bit & 18-bit)

Parallel 6800-series MCU Interface

(8-bit, 9-bit, 16-bit & 18-bit)

3-line serial interface

4-line serial interface

Display Features

Support both normal-black & normal-white LC

Software programmable color depth mode

Built-in Circuits

DC/DC converter

Adjustable VCOM generation

Non-volatile (NV) memory to store initial register setting

Oscillator for display clock generation

Factory default value (module ID, module version, etc) are

stored in NV memory

Timing controller

Built-in NV Memory for LCD Initial Register Setting

7-bits for ID2

8-bits for ID3

7-bits for VCOM adjustment

Wide Supply Voltage Range

I/O Voltage (VDDI to DGND): 1.65V~3.7V (VDDI ≤ VDD)

Analog Voltage (VDD to AGND): 2.3V~4.8V

On-Chip Power System

Source Voltage (GVDD to AGND): 3.0V~4.5V

VCOM level (VCOM to AGND): -0.4V to -2.0V

Gate driver HIGH level (VGH to AGND): +10.0V to +15V

Gate driver LOW level (VGL to AGND): -13V to -7.5V

Operating Temperature: -30°C to +85°C

ST7735R Parallel Interface: 8080,6800(8-bit/9-bit/16-bit/18-bit)

Serial Interface: 3-line, 4-line

Sitronix Technology Corp. reserves the right to change the contents in this document without prior notice.

S T7735 R

ST7735R

V0.2 2 2009-08-05

3 Pad arrangement

3.1 Output Bump Dimension

C K

H

A

L

J

Boundary (Include scribe Lane)

Item Symbol Size

Bump pitch A 16 um

Bump width C 16 um

Bump height H 98 um

Bump gap1 (Vertical) J 19 um

Bump gap2 (Horizontal) K 16 um

Bump area C x H 1568 um2

Chip Boundary (include scribe Lane) L 59 um

S T7735 R

ST7735R

V0.2 3 2009-08-05

3.2 Input Bump Dimension

A2

H

C1

KK2

C2

K1 K1

A1

C2

L

Boundary (Include scribe Lane)

Item Symbol Size

Bump pitch 1 A1 67 um

Bump pitch 2 A2 50 um

Bump width 1 C1 33 um

Bump width 2 C2 38 um

Bump height H 88 um

Bump gap K 22 um

Bump gap1 K1 17 um

Bump gap2 K2 34 um

Bump area 1 C1 X H 2904 um2

Bump area 2 C2 X H 3344 um2

Chip Boundary(include scribe Lane) L 59 um

~+—+—+—+4

ST7735R

V0.2 4 2009-08-05

3.3 Alignment Mark Dimension

80

2015 1515 15

105

2015 1515 15

80

20 1515 1515

10 5

20 1515 1515

S T7735]? No.185 No.1 No.186 No.759

ST7735R

V0.2 5 2009-08-05

3.4 Chip Information

Chip size (um x um): 10080 x 670

PAD coordinate: pad center

Coordinate origin: chip center

Chip thickness (um): 300(TYP)

Bump height (um): 15(TYP)

Bump hardness (HV): 75(TYP)

No.1

No.185

No.186

No.759

S T7735 R

ST7735R

V0.2 6 2009-08-05

4 Pad Center Coordinates

No.

PAD Name

X Y No.

PAD Name

X Y

No.

PAD Name

X Y

1

Dummy

-

4750

-

231

5

1

VDD

-

2250

-

231

10

1

DGND

550

-

231

2

VDDIO

-

4700

-

231

5

2

VDD

-

2200

-

231

10

2

DGND

600

-

231

3

EXTC

-

4650

-

231

5

3

VDD

-

2150

-

231

10

3

VDDI

650

-

231

4

DGNDO

-

4600

-

231

5

4

VDD

-

2100

-

231

10

4

VDDI

700

-

231

5

IM[0]

-

4550

-

231

5

VDD

-

2050

-

231

10

5

VDDI

750

-

231

6

VDDIO

-

4500

-

231

5

6

VDD

-

2000

-

231

10

6

VDDI

800

-

231

7

IM[1]

-

4450

-

231

5

7

AGND

-

1950

-

231

10

7

VDDI

850

-

231

8

DGNDO

-

4400

-

231

5

8

AGND

-

1900

-

231

10

8

VDDI

900

-

231

9

P68

-

4350

-

231

5

9

AGND

-

1850

-

231

10

9

VPP

950

-

231

10

VDDIO

-

4300

-

231

6

0

AGND

-

1800

-

231

1

10

VPP

1000

-

231

11

TEST1P

-

4250

-

231

6

1

AGND

-

1750

-

231

1

11

VPP

1050

-

231

12

DGNDO

-

4200

-

231

6

2

AGND

-

1700

-

231

1

12

GVDD

1100

-

231

13

TEST2P

-

4150

-

231

6

3

RDX

-

1630

-

231

1

13

GVDD

1150

-

231

14

VDDIO

-

4100

-

231

6

4

D_CX

-

1570

-

231

1

14

GVDD

1200

-

231

15

SRGB

-

4050

-

231

6

5

TESEL

-

1510

-

231

1

15

VCC

1250

-

231

16

DGNDO

-

4000

-

231

66

DGNDO

-

1450

-

231

1

16

Dummy

1300

-

231

17

SMX

-

3950

-

231

6

7

D[17]

-

1390

-

231

1

17

Dummy

1350

-

231

18

VDDIO

-

3900

-

231

6

8

D[16]

-

1330

-

231

1

18

GVCL

1400

-

231

19

SMY

-

3850

-

231

6

9

D[15]

-

1270

-

231

1

19

Dummy

1450

-

231

20

DGNDO

-

3800

-

231

7

0

D[14]

-

1210

-

231

1

20

AVDD

1500

-

231

21

Dummy

-

3750

-

231

7

1

D[13]

-

1150

-

231

1

21

AVDD

1550

-

231

22

VDDIO

-

3700

-

231

7

2

D[12]

-

1090

-

231

1

22

AVDD

1600

-

231

23

Dummy

-

365

0

-

231

7

3

D[11]

-

1030

-

231

1

23

AVDD

1650

-

231

24

DGNDO

-

3600

-

231

7

4

D[10]

-

970

-

231

1

24

AVDD

1700

-

231

25

Dummy

-

3550

-

231

7

5

D[9]

-

910

-

231

1

25

Dummy

1750

-

231

26

VDDIO

-

3500

-

231

7

6

D[8]

-

850

-

231

1

26

Dummy

1800

-

231

27

Dummy

-

3450

-

231

7

D[1]

-

790

-

231

1

27

Dummy

1850

-

231

28

DGNDO

-

3400

-

231

7

8

D[3]

-

730

-

231

1

28

Dummy

1900

-

231

29

Dummy

-

3350

-

231

7

9

D[5]

-

670

-

231

1

29

Dummy

1950

-

231

30

VDDIO

-

3300

-

231

8

0

D[7]

-

610

-

231

1

30

Dummy

2000

-

231

31

LCM

-

3250

-

231

8

1

TE

-

550

-

231

1

31

Dummy

2050

-

231

32

DGNDO

-

3200

-

231

8

2

RESX

-

490

-

231

1

32

Dummy

2100

-

231

33

Dummy

-

3150

-

231

8

3

CSX

-

430

-

231

1

33

Dummy

2150

-

231

34

VDDIO

-

3100

-

231

8

4

D[6]

-

370

-

231

1

34

Dummy

2200

-

231

35

Dummy

-

3050

-

231

8

5

D[4]

-

310

-

231

1

35

Dummy

225

0

-

231

36

DGNDO

-

3000

-

231

8

6

D[2]

-

250

-

231

1

36

Dummy

2300

-

231

37

GM[1]

-

2950

-

231

8

7

IM[2]

-

190

-

231

1

37

Dummy

2350

-

231

38

VDDIO

-

2900

-

231

8

D[0]

-

130

-

231

1

38

Dummy

2400

-

231

39

GM[0]

-

2850

-

231

8

9

WRX

-

70

-

231

1

39

Dummy

2450

-

231

40

DGNDO

-

2800

-

231

9

0

Dummy

0

-

231

1

40

Dummy

2500

-

231

41

Dummy

-

2750

-

231

91

Dummy

50

-

231

1

41

Dummy

2550

-

231

42

GS

-

2700

-

231

92

Dummy

100

-

231

1

42

Dummy

2600

-

231

43

SPI4W

-

2650

-

231

93

Dummy

150

-

231

1

43

Dummy

2650

-

231

44

VDDIO

-

2600

-

231

94

TESTOP[3]

200

-

231

1

44

Dummy

2700

-

231

45

TESTOP[8]

-

2550

-

231

95

TESTOP[2]

250

-

231

1

45

Dummy

2750

-

231

46

TESTOP[7]

-

2500

-

231

96

TESTOP[1]

300

-

231

1

46

AGND

2800

-

231

47

TESTOP[6]

-

2450

-

231

97

DGND

350

-

231

1

47

AGND

2850

-

231

48

TESTOP[5]

-

2400

-

231

98

DGND

400

-

231

1

48

AGND

2900

-

231

49

TESTOP[4]

-

2350

-

231

99

DGND

450

-

231

1

49

AVCL

2950

-

231

50

OSC

-

2300

-

231

100

DGND

500

-

231

1

50

AVCL

3000

-

231

S T7735 R

ST7735R

V0.2 7 2009-08-05

No.

PAD Name

X Y

No.

PAD Name

X Y

No.

PAD Name

X Y

15

1

AVCL

3050

-

231

201

G136

4532

227

251

G36

3732

227

15

2

Dummy

3100

-

231

202

G134

4516

110

252

G34

3716

110

15

3

Dummy

3150

-

231

203

G132

4500

227

253

G32

3700

227

15

4

Dummy

3200

-

231

204

G130

4484

110

254

G30

3684

110

15

5

Dummy

3250

-

231

205

G128

4468

227

255

G28

3668

227

15

6

Dummy

3300

-

231

206

G126

4452

110

256

G26

3652

110

15

7

Dummy

3350

-

231

207

G124

4436

227

257

G24

3636

227

15

8

Dummy

3400

-

231

208

G122

4420

110

258

G22

3620

110

15

9

Dummy

3450

-

231

209

G120

4404

227

259

G20

3604

227

160

Dummy

3500

-

23

1

210

G118

4388

110

260

G18

3588

110

161

Dummy

3550

-

231

211

G116

4372

227

261

G16

3572

227

162

Dummy

3600

-

231

212

G114

4356

110

262

G14

3556

110

16

3

Dummy

3650

-

231

213

G112

4340

227

263

G12

3540

227

16

4

Dummy

3700

-

231

214

G110

4324

110

26

4

G10

3524

110

1

6

5

Dummy

3750

-

231

215

G108

4308

227

265

G8

3508

227

1

6

Dummy

3800

-

231

216

G106

4292

110

266

G6

3492

110

1

6

7

Dummy

3850

-

231

217

G104

4276

227

267

G4

3476

227

1

6

8

Dummy

3900

-

231

218

G102

4260

110

268

G2

3460

110

1

6

9

Dummy

39

50

-

231

219

G100

4244

227

269

Dummy

3444

227

17

0

VGL

4000

-

231

220

G98

4228

110

270

Dummy

3428

110

17

1

Dummy

4050

-

231

221

G96

4212

227

271

Dummy

3412

227

172

Dummy

4100

-

231

222

G94

4196

110

272

Dummy

3396

110

173

VGH

4150

-

231

223

G92

4180

2

27

273

S396

3380

227

174

Dummy

4200

-

231

224

G90

4164

110

274

S395

3364

110

175

Dummy

4250

-

231

225

G88

4148

227

275

S394

3348

227

176

Dummy

4300

-

231

226

G86

4132

110

276

S393

3332

110

177

Dummy

4350

-

231

227

G84

4116

227

277

S392

3316

227

1

78

Dummy

4400

-

231

228

G82

4100

110

278

S391

3300

110

179

Dummy

4450

-

231

229

G80

4084

227

279

S390

3284

227

180

Dummy

4500

-

231

230

G78

4068

110

280

S389

3268

110

181

Dummy

4550

-

231

G76

4052

227

281

S388

3252

227

182

VCOM

4600

-

231

232

G74

4036

110

282

S387

3236

110

183

VCOM

4650

-

231

233

G72

4020

227

283

S386

3220

227

184

VCOM

4700

-

231

234

G70

4004

110

284

S385

3204

110

185

Dummy

4750

-

231

235

G68

3988

227

285

S384

3188

227

186

Dummy

4772

110

236

G66

3972

110

286

S383

3172

110

187

Dummy

4756

227

237

G64

3956

227

287

S382

3156

227

188

G162

4740

110

238

G62

3940

110

288

S381

3140

110

189

G160

4724

227

239

G60

3924

227

289

S380

3124

227

190

G158

4708

110

240

G58

3908

110

290

S379

3108

110

191

G156

4692

227

241

G56

3892

227

291

S378

3092

227

192

G154

4676

110

242

G54

3876

110

292

S377

3076

110

193

G152

4660

227

243

G52

3860

227

293

S376

3060

227

194

G150

4644

110

244

G50

3844

110

294

S375

3044

110

195

G148

4628

227

245

G48

3828

227

295

S374

3028

227

19

6

G146

4612

110

246

G46

3812

110

296

S373

3012

110

197

G144

4596

227

247

G44

3796

227

297

S372

2996

227

198

G142

4580

110

248

G42

3780

110

298

S371

2980

110

199

G140

4564

227

249

G40

3764

227

299

S370

2964

227

200

G138

4548

110

250

G38

3748

11

0

300

S369

2948

110

S T7735 R

ST7735R

V0.2 8 2009-08-05

No.

PAD Name

X Y No.

PAD Name

X Y

No.

PAD Name

X Y

30

1

S368

2932

227

35

1

S318

2132

227

401

S268

1332

227

30

2

S367

2916

110

35

2

S317

2116

110

402

S267

1316

110

30

3

S366

2900

227

35

3

S316

2100

227

403

S266

1300

227

30

4

S365

2884

110

35

4

S315

2084

110

404

S265

1284

110

30

5

S364

2868

227

35

5

S314

2068

227

405

S264

1268

227

30

6

S363

2852

110

35

6

S313

2052

110

406

S263

1252

110

30

7

S362

2836

227

35

7

S312

2036

227

407

S262

1236

227

30

8

S361

2820

110

35

8

S311

2020

1

10

408

S261

1220

110

30

9

S360

2804

227

35

9

S310

2004

227

409

S260

1204

227

3

10

S359

2788

110

36

0

S309

1988

110

410

S259

1188

110

3

11

S358

2772

227

36

1

S308

1972

227

411

S258

1172

227

3

12

S357

2756

110

36

2

S307

1956

110

412

S257

1156

110

3

13

S356

2740

227

36

3

S306

1940

227

413

S256

1140

227

3

14

S355

2724

110

36

4

S305

1924

110

414

S255

1124

110

3

15

S354

2708

227

36

5

S304

1908

227

415

S254

1108

227

3

16

S353

2692

110

366

S303

1892

110

416

S253

1092

110

3

17

S352

2676

227

36

7

S302

1876

227

417

S252

1076

227

3

18

S351

2660

110

36

8

S301

1860

110

418

S251

1060

110

3

19

S350

2644

227

36

9

S300

1844

227

419

S250

1044

227

3

20

S349

2628

110

37

0

S299

1828

110

420

S249

1028

110

3

21

S348

2612

227

37

1

S298

1812

227

421

S248

1012

227

3

22

S347

2596

110

37

2

S297

1796

110

422

S247

996

110

3

23

S346

2580

227

37

3

S296

1780

227

423

S246

980

227

3

24

S345

2564

110

37

4

S295

1764

110

424

S245

964

110

3

25

S344

2548

227

37

5

S294

1748

227

425

S244

948

227

3

26

S343

2532

110

37

6

S293

1732

110

426

S243

932

110

3

27

S342

2516

227

37

7

S292

1716

227

427

S242

916

227

3

28

S341

2500

110

37

8

S291

1700

110

428

S241

900

110

3

29

S340

2484

227

37

9

S290

1684

227

429

S240

884

227

3

30

S339

2468

110

38

0

S289

1668

110

430

S239

868

110

3

31

S338

245

2

227

38

1

S288

1652

227

431

S238

852

227

3

32

S337

2436

110

38

2

S287

1636

110

432

S237

836

110

3

33

S336

2420

227

38

3

S286

1620

227

433

S236

820

227

3

34

S335

2404

110

38

4

S285

1604

110

434

S235

804

110

3

35

S334

2388

227

38

5

S284

1588

227

435

S234

788

227

3

36

S333

2372

110

38

6

S283

1572

110

436

S233

772

110

3

37

S332

2356

227

38

7

S282

1556

227

437

S232

756

227

3

38

S331

2340

110

38

8

S281

1540

110

438

S231

740

110

3

39

S330

2324

227

38

9

S280

1524

227

439

S230

724

227

3

40

S329

2308

110

3

9

0

S279

1508

110

440

S229

708

110

3

41

S328

2292

227

391

S278

1492

227

441

S228

692

227

3

42

S327

2276

110

392

S277

1476

110

442

S227

676

110

3

43

S326

2260

227

393

S276

1460

227

443

S226

660

227

3

44

S325

2244

110

394

S275

1444

110

444

S225

644

1

10

3

45

S324

2228

227

395

S274

1428

227

445

S224

628

227

3

46

S323

2212

110

396

S273

1412

110

446

S223

612

110

3

47

S322

2196

227

397

S272

1396

227

447

S222

596

227

3

48

S321

2180

110

398

S271

1380

110

448

S221

580

110

3

49

S320

2164

227

399

S270

1364

227

449

S220

564

227

3

50

S319

2148

110

400

S269

1348

110

450

S219

548

110

S T7735 R

ST7735R

V0.2 9 2009-08-05

No.

PAD Name

X Y No.

PAD Name

X Y

No.

PAD Name

X Y

451

S218

532

227

501

S172

-

644

110

551

S122

-

1444

110

452

S217

516

110

502

S171

-

660

227

552

S121

-

1460

227

4

53

S216

500

227

503

S170

-

676

110

553

S120

-

1476

110

454

S215

484

110

504

S169

-

692

227

554

S119

-

1492

227

455

S214

468

227

505

S168

-

708

110

555

S118

-

1508

110

456

S213

452

110

506

S167

-

724

227

556

S117

-

1524

227

457

S212

436

227

507

S166

-

7

40

110

557

S116

-

1540

110

458

S211

420

110

508

S165

-

756

227

558

S115

-

1556

227

459

S210

404

227

509

S164

-

772

110

559

S114

-

1572

110

460

S209

388

110

510

S163

-

788

227

560

S113

-

1588

227

461

S208

372

227

511

S162

-

804

110

561

S112

-

1604

110

462

S207

356

110

512

S161

-

820

227

562

S111

-

1620

227

463

S206

340

227

513

S160

-

836

110

563

S110

-

1636

110

464

S205

324

110

514

S159

-

852

227

564

S109

-

1652

227

465

S204

308

227

515

S158

-

868

110

565

S108

-

1668

110

466

S203

292

110

516

S157

-

884

227

566

S107

-

1684

227

467

S202

276

227

517

S156

-

900

110

567

S106

-

1700

110

468

S201

260

110

518

S155

-

916

227

568

S105

-

1716

227

469

S200

244

227

519

S154

-

932

110

569

S104

-

1732

110

470

S199

228

110

520

S153

-

948

227

570

S103

-

1748

227

471

Dummy

212

227

521

S152

-

964

110

571

S102

-

1764

110

472

Dummy

196

110

522

S151

-

980

227

572

S101

-

1780

227

473

Dummy

-

196

110

523

S150

-

996

110

573

S100

-

1796

110

474

Dummy

-

212

227

524

S149

-

1012

227

574

S99

-

1812

227

475

S198

-

228

110

52

5

S148

-

1028

110

575

S98

-

1828

110

476

S197

-

244

227

526

S147

-

1044

227

576

S97

-

1844

227

477

S196

-

260

110

527

S146

-

1060

110

577

S96

-

1860

110

478

S195

-

276

227

528

S145

-

1076

227

578

S95

-

1876

227

479

S194

-

292

110

529

S144

-

1092

110

579

S94

-

1892

110

480

S193

-

308

227

530

S143

-

1108

227

580

S93

-

1908

227

481

S192

-

324

110

531

S142

-

1124

110

581

S92

-

1924

110

482

S191

-

340

227

532

S141

-

1140

227

582

S91

-

1940

227

483

S190

-

356

110

533

S140

-

1156

110

583

S90

-

1956

110

484

S189

-

3

72

227

534

S139

-

1172

227

584

S89

-

1972

227

485

S188

-

388

110

535

S138

-

1188

110

585

S88

-

1988

110

486

S187

-

404

227

536

S137

-

1204

227

586

S87

-

2004

227

487

S186

-

420

110

537

S136

-

1220

110

587

S86

-

2020

110

488

S185

-

436

227

538

S135

-

1236

2

27

588

S85

-

2036

227

489

S184

-

452

110

539

S134

-

1252

110

589

S84

-

2052

110

490

S183

-

468

227

540

S133

-

1268

227

590

S83

-

2068

227

491

S182

-

484

110

541

S132

-

1284

110

591

S82

-

2084

110

492

S181

-

500

227

542

S131

-

1300

227

592

S81

-

2100

227

4

93

S180

-

516

110

543

S130

-

1316

110

593

S80

-

2116

110

494

S179

-

532

227

544

S129

-

1332

227

594

S79

-

2132

227

495

S178

-

548

110

545

S128

-

1348

110

595

S78

-

2148

110

496

S177

-

564

227

546

S127

-

1364

227

596

S77

-

2164

227

497

S176

-

580

110

547

S126

-

1380

110

597

S76

-

2180

110

498

S175

-

596

227

548

S125

-

1396

227

598

S75

-

2196

227

499

S174

-

612

110

549

S124

-

1412

110

599

S74

-

2212

110

500

S173

-

628

227

550

S123

-

1428

227

600

S73

-

2228

227

S T7735 R

ST7735R

V0.2 10 2009-08-05

No.

PAD Name

X Y No.

PAD Name

X Y

No.

PAD Name

X Y

601

S72

-

2244

110

651

S22

-

3044

110

701

G49

-

3844

110

602

S71

-

2260

227

652

S21

-

3060

227

702

G51

-

3860

227

603

S70

-

2276

110

653

S20

-

3076

110

703

G53

-

3876

110

604

S69

-

2292

227

654

S19

-

3092

227

704

G55

-

3892

227

605

S68

-

2308

110

6

55

S18

-

3108

110

705

G57

-

3908

110

606

S67

-

2324

227

656

S17

-

3124

227

706

G59

-

3924

227

607

S66

-

2340

110

657

S16

-

3140

110

707

G61

-

3940

110

608

S65

-

2356

227

658

S15

-

3156

227

708

G63

-

3956

227

609

S64

-

2372

110

659

S14

-

3172

110

709

G65

-

3

972

110

610

S63

-

2388

227

660

S13

-

3188

227

710

G67

-

3988

227

611

S62

-

2404

110

661

S12

-

3204

110

711

G69

-

4004

110

612

S61

-

2420

227

662

S11

-

3220

227

712

G71

-

4020

227

613

S60

-

2436

110

663

S10

-

3236

110

713

G73

-

4036

110

614

S59

-

2452

227

664

S9

-

3252

227

714

G75

-

4052

227

615

S58

-

2468

110

665

S8

-

3268

110

715

G77

-

4068

110

616

S57

-

2484

227

666

S7

-

3284

227

716

G79

-

4084

227

617

S56

-

2500

110

667

S6

-

3300

110

717

G81

-

4100

110

618

S55

-

2516

227

668

S5

-

3316

227

718

G83

-

4116

227

619

S54

-

2532

110

669

S4

-

3332

110

719

G85

-

4132

110

620

S53

-

2548

227

670

S3

-

3348

227

720

G87

-

4148

227

621

S52

-

2564

110

671

S2

-

3364

110

721

G89

-

4164

110

622

S51

-

2580

227

672

S1

-

3380

227

722

G91

-

4180

227

623

S50

-

2596

110

673

Dummy

-

3396

110

723

G93

-

4196

110

624

S49

-

2612

227

674

Dummy

-

3412

227

724

G95

-

4212

227

625

S48

-

2628

110

675

Dummy

-

3428

110

725

G97

-

4228

110

626

S47

-

2644

227

676

Dummy

-

3444

227

726

G99

-

4244

227

627

S46

-

2660

110

677

G1

-

3460

110

727

G101

-

4260

110

628

S45

-

2676

227

678

G3

-

3476

227

728

G103

-

4276

227

629

S44

-

2692

110

679

G5

-

3492

110

729

G105

-

4292

110

630

S43

-

2708

227

680

G7

-

3508

227

730

G107

-

4308

227

631

S42

-

2724

110

681

G9

-

3524

110

731

G109

-

4324

110

632

S41

-

2740

227

682

G11

-

3540

227

732

G111

-

4340

227

633

S40

-

2756

110

683

G13

-

3556

110

733

G113

-

4356

110

634

S39

-

2772

227

684

G15

-

3572

227

734

G115

-

4372

227

635

S38

-

2788

110

685

G17

-

3588

110

735

G117

-

4388

110

636

S37

-

2804

227

686

G19

-

3604

227

736

G119

-

4404

227

637

S36

-

2820

110

687

G21

-

3620

110

737

G121

-

4420

110

638

S35

-

2836

227

688

G23

-

3636

227

738

G123

-

4436

227

639

S34

-

2852

110

689

G25

-

3652

110

739

G125

-

4452

110

640

S33

-

2868

227

690

G27

-

3668

227

740

G127

-

4468

227

641

S32

-

2884

110

691

G29

-

3684

110

741

G129

-

4484

110

642

S31

-

2900

227

692

G31

-

3700

227

742

G131

-

4500

227

643

S30

-

2916

110

693

G33

-

3716

110

743

G133

-

4516

110

644

S29

-

2932

227

694

G35

-

3732

227

744

G135

-

4532

227

645

S28

-

2948

110

695

G37

-

3748

110

745

G137

-

4548

110

646

S27

-

2964

227

696

G39

-

3764

227

746

G139

-

4564

227

647

S26

-

2980

110

697

G41

-

3780

110

747

G141

-

4580

110

648

S25

-

2996

227

698

G43

-

3796

227

748

G143

-

4596

227

649

S24

-

3012

110

699

G45

-

3812

110

749

G145

-

4612

110

650

S23

-

3028

227

700

G47

-

3828

227

750

G147

-

4628

227

S T7735 R ALIGNMENT L

ST7735R

V0.2 11 2009-08-05

No.

PAD Name X Y

75

1

G149

-

4644

110

75

2

G151

-

4660

227

75

3

G153

-

4676

110

75

4

G155

-

4692

227

75

5

G157

-

4708

110

75

6

G159

-

4724

227

75

7

G161

-

4740

110

75

8

Dummy

-

4756

227

75

9

Dummy

-

47

72

110

ALIGNMENT_R

4841

-

220

ALIGNMENT_

L

-

4841

-

220

S T7735 R

ST7735R

V0.2 12 2009-08-05

5 Block diagram

396 Source Buffer

DAC

Level Shifter

Data Latch

Color conversion

LUT table

Display Ram

132 x 162 x 18 bits

Voltage

Reference

Gamma Circuit

Gamma Table

Display control

162 Gate Buffer

Level Shifter

Gate

Decoder

Vcom generator

OSC

Booster 1/2/4

Instruction

Register NVM

MCU IF

SDA

LCM

SRGB

GS

WRX (R/WX)

RDX (E)

CSX

DC/X (SCL)

IM [2:0]

EXTC

SMX

SMY

D[17:0]

AVDD

VDDI

VDD

GVDD

VCOM

GVCL

AVCL

VGH

VGL

TESEL

S T7735 H

ST7735R

V0.2 13 2009-08-05

6 Driver IC Pin Description

6.1 Power Supply Pin

Name

I/O Description Connect pin

VDD I Power supply for analog, digital system and booster circuit. VDD

VDDI I Power supply for I/O system. VDDI

AGND

I System ground for analog system and booster circuit. GND

DGND

I System ground for I/O system and digital system. GND

6.2 Interface logic pin

Name I/O Description Connect pin

P68 I

-8080/6800 MCU interface mode select.

-P68=’1’, select 6800 MCU parallel interface.

-P68=’0’, select 8080 MCU parallel interface.

-If not used, please fix this pin at DGND level.

DGND/VDDI

IM2 I

MCU Parallel interface bus and Serial interface select

IM2=’1’, Parallel interface

IM2=’0’, Serial interface

DGND/VDDI

IM1,IM0

I

- MCU parallel interface type selection

-If not used, please fix this pin at VDDI or DGND level.

IM1 IM0 Parallel interface

0 0 MCU 8-bit parallel

0 1 MCU 16-bit parallel

1 0 MCU 9-bit parallel

1 1 MCU 18-bit parallel

DGND/VDDI

SPI4W

I

- SPI4W=’0’, 3-line SPI enable.

- SPI4W=’1’, 4-line SPI enable.

-If not used, please fix this pin at DGND level.

DGND/VDDI

RESX I

-This signal will reset the device and it must be applied to properly

initialize the chip.

-Signal is active low.

MCU

CSX I -Chip selection pin

-Low enable. MCU

D/CX

(SCL) I

-Display data/command selection pin in MCU interface.

-D/CX=’1’: display data or parameter.

-D/CX=’0’: command data.

-In serial interface, this is used as SCL.

-If not used, please fix this pin at VDDI or DGND level.

MCU

RDX I -Read enable in 8080 MCU parallel interface.

-If not used, please fix this pin at VDDI or DGND level. MCU

S T7735 R

ST7735R

V0.2 14 2009-08-05

WRX

(D/CX)

I

-Write enable in MCU parallel interface.

-In 4-line SPI, this pin is used as D/CX (data/ command selection).

-If not used, please fix this pin at VDDI or DGND level.

MCU

D[17:0]

I/O

-D[17:0] are used as MCU parallel interface data bus.

-D0 is the serial input/output signal in serial interface mode.

-In serial interface, D[17:1] are not used and should be fixed at VDDI or

DGND level.

MCU

TE O

-Tearing effect output pin to synchronies MCU to frame rate, activated

by S/W command.

-If not used, please open this pin.

MCU

OSC O

-Monitoring pin of internal oscillator clock and is turned ON/OFF by

S/W command.

-When this pin is inactive (function OFF), this pin is DGND level.

-If not used, please open this pin.

-

Note1. When in parallel mode, no use data pin must be connected to “1” or “0”.

Note2. When CSX=”1”, there is no influence to the parallel and serial interface.

ST7735FI

ST7735R

V0.2 15 2009-08-05

6.3 Mode selection pin

Name

I/O Description Connect pin

EXTC

I

-During normal operation, please open this pin.

EXTC Enable/disable modification of extend command

0 Normal operation mode

1 Use NVM command set

Open

GM1,

GM0 I

-Panel resolution selection pins.

G

M

1

G

M

0

Selection of panel resolution

0

132RGB x 162 (S1~S396 & G1~G162 output)

1

128RGB x 160 (S7~S390 & G2~G161 output)

VDDI/DGND

SRGB

I

-RGB direction select H/W pin for color filter setting.

SRGB RGB arrangement

0 S1, S2, S3 filter order = ’R’, ’G’, ’B’

1 S1, S2, S3 filter order = ‘B’, ‘G’, ‘R’

VDDI/DGND

SMX I

-Module source output direction H/W selection pin.

SMX Scanning direction of source output

GM= ‘00’ GM= ‘11’

0 S1 -> S396 S7 -> S390

1 S396 -> S1 S390 -> S7

VDDI/DGND

SMY I

-Module Gate output direction H/W selection pin.

SMY Scanning direction of gate output

GM= ‘00’ GM= ‘11’

0 G1 -> G162 G2 -> G161

1 G162 -> G1 G161 -> G2

VDDI/DGND

LCM I

-Liquid crystal (LC) type selection pins.

LCM Selection of LC type

0 Normally white LC type

1 Normally black LC type

VDDI/DGND

GS I

-Gamma curve selection pin.

GS Selection of gamma curve

0 GC0=1.0, GC1=2.5, GC2=2.2, GC3=1.8

1 GC0=2.2, GC1=1.8, GC2=2.5, GC3=1.0

VDDI/DGND

S T7735 Ff

ST7735R

V0.2 16 2009-08-05

VPP I When writing NVM, it needs external power supply voltage (7.5V).

TESEL

I

Input pin to select horizontal line number in TE signal.

This pin is only for GM[1:0]=’00’ mode

TESEL

Selection of gamma curve

0 TE output 162 lines

1 TE output 160 lines

VDDI/DGND

6.4 Driver output pins

Name I/O

Description Connect pin

S1 to S396 O - Source driver output pins. -

G1 to G162 O - Gate driver output pins. -

AVDD O Power pin for analog circuits.

Connect a capacitor for stabilization. Capacitor

AVCL O

- A power supply pin for generating GVCL.

- Connect a capacitor for stabilization. Capacitor

VGH O - Power output pin for gate driver

VGL O - Power output (Negative) pin for gate driver

GVDD O

- A power output of grayscale voltage generator.

- When internal GVDD generator is not used, connect an external

power supply (AVDD-0.5V) to this pin.

GVCL O

- A power output(Negative) of grayscale voltage generator.

- When internal GVCL generator is not used, connect an external

power supply (AVCL+0.5V) to this pin.

-

VCOM O - A power supply for the TFT-LCD common electrode. Common

electrode

VCC O - Monitoring pin of internal digital reference voltage.

- Please open these pins.

VDDIO O - VDDI voltage output level for monitoring. -

DGNDO O - DGND voltage output level for monitoring. -

S T7735 R

ST7735R

V0.2 17 2009-08-05

6.5 Test pins

Name I/O

Description Connect pin

TEST2P

TEST1P I

-These test pins for Driver vender test used.

-Please connect these pins to DGND. DGND

TESTOP[8]

TESTOP[7]

TESTOP[6]

TESTOP[5]

TESTOP[4]

TESTOP[3]

TESTOP[2]

TESTOP[1]

O

-These test pins for Driver vender test used.

-Please open these pins. Open

Dummy -

-These pins are dummy (have no function inside).

-Can allow signal traces pass through these pads on TFT glass.

-Please open these pins.

Open

S T7735 R

ST7735R

V0.2 18 2009-08-05

7 Driver electrical characteristics

7.1 Absolute operation range

Item Symbol Rating Unit

Supply voltage VDD - 0.3 ~ +4.6 V

Supply voltage (Logic) VDDI - 0.3 ~ +4.6 V

Supply voltage (Digital) VCC -0.3 ~ +1.95 V

Driver supply voltage VGH-VGL -0.3 ~ +30.0 V

Logic input voltage range VIN 0.3 ~ VDDI + 0.3 V

Logic output voltage range VO 0.3 ~ VDDI + 0.3 V

Operating temperature range TOPR -30 ~ +85 ℃

Storage temperature range TSTG -40 ~ +125 ℃

Note: If one of the above items is exceeded its maximum limitation momentarily, the quality of the product may be degraded. Absolute

maximum limitation, therefore, specify the values exceeding which the product may be physically damaged. Be sure to use the

product within the recommend range.

S T7735 R

ST7735R

V0.2 19 2009-08-05

7.2 DC characteristic

Specification

Parameter Symbo

l Condition Min Typ Max

Uni

t

Power & operation voltage

System voltage VDD Operating voltage

2.3 2.75 4.8 V

Interface operation

voltage VDDI I/O supply voltage

1.65 1.8 3.7 V

Gate driver high voltage VGH 10 15 V

Gate driver low voltage VGL -12.4 -7.5 V

Gate driver supply voltage

| VGH-VGL | 17.5 27.5 V

Input / Output

Logic-high input voltage VIH 0.7VDDI

VDDI V Note 1

Logic-low input voltage VIL VSS 0.3VDDI

V Note 1

Logic-high output voltage

VOH IOH = -1.0mA 0.8VDDI

VDDI V Note 1

Logic-low output voltage VOL IOL = +1.0mA VSS 0.2VDDI

V Note 1

Logic-high input current IIH VIN = VDDI 1 uA

Note 1

Logic-low input current IIL VIN = VSS -1 uA

Note 1

Input leakage current IIL IOH = -1.0mA -0.1 +0.1 uA

Note 1

VCOM voltage

VCOM amplitude VCOM

-2 -0.425 V

Source driver

Source output range Vsout

0.1 GVDD V

Gamma reference voltage

GVDD

3.0 5.0 V

Source output settling

time Tr Below with 99%

precision 20 us Note 2

Output offset voltage Voffset

35 mV

Note 3

Notes:

1. TA= -30 to 85

℃

.

2. Source channel loading= 2K

Ω

+12pF/channel, Gate channel loading=5K

Ω

+40pF/channel.

3. The Max. value is between measured point of source output and gamma setting value.

S T7735 R

ST7735R

V0.2 20 2009-08-05

7.3 Power consumption

Ta=25℃, Frame rate = 60Hz, the registers setting are IC default setting.

Current consumption

Typical Maximum

Operation mode Image

IDDI

(mA)

IDD

(mA)

IDDI

(mA)

IDD

(mA)

Note 1

TBD TBD TBD TBD

Normal mode Note 2

TBD TBD TBD TBD

Note 1

TBD TBD TBD TBD

Partial + Idle mode (40 lines)

Note 2

TBD TBD TBD TBD

Sleep-in mode N/A TBD TBD TBD TBD

Notes:

1. All pixels black.

2. All pixels white.

3. The Current Consumption is DC characteristics of ST7735R.

4. Typical: VDDI=1.8V, VDD=2.75V; Maximum: VDDI=1.65 to 3.7V, VDD=2.3 to 4.8V

S T7735 R &g $ csx V‘ T w “ﬁg 1 \ FT—cs’} W” ‘ ‘ 1T” \ \ Vw WX‘: 1: 4><11 ‘="" ‘="" ‘="" ,="" ‘="" ‘="" turk="" ,4="" twc="" \="" \="" tan="" \="" 1="" \="" wrx="" haw="" hwﬁ‘="" vu="" ‘="" 1="" ‘="" w="" \="" w="" w="" \="" d[17="" o]="" ‘="" write="" 1="" w="" w="" \="" ‘="" tm/tmm="" tm="" }="" ‘="" ‘="" ‘="" \="" \="" \="" j34="" ‘="" tar/tam="" i="" \="" |="" \="" \="" vw="" rdx="" ‘v="" ﬂy="" \="" tam/tmm="" i="" m="" h—h="" \="" |="" \="" \="" ‘="" tmﬂmw="" l_.:="" f%="" d[17="" 0]="" vm="" read="" v‘l="" i="" \="">

ST7735R

V0.2 21 2009-08-05

8 Timing chart

8.1 Parallel interface characteristics: 18, 16, 9 or 8-bit bus (8080 series MCU interface)

Figure 8.1.1 Parallel interface timing characteristics (8080 series MCU interface)

Ta=25 ℃, VDDI=1.65~3.7V, VDD=2.3~4.8V

Signal Symbol Parameter Min Max Unit Description

TAST Address setup time 10 ns

D/CX TAHT Address hold time (Write/Read) 10 ns -

TCHW Chip select “H” pulse width 0 ns

TCS Chip select setup time (Write) 15 ns

TRCS Chip select setup time (Read ID) 45 ns

TRCSFM Chip select setup time (Read FM) 355 ns

TCSF Chip select wait time (Write/Read) 10 ns

CSX

TCSH Chip select hold time 10 ns

-

TWC Write cycle 66 ns

TWRH Control pulse “H” duration 15 ns

WRX

TWRL Control pulse “L” duration 15 ns

TRC Read cycle (ID) 160 ns

TRDH Control pulse “H” duration (ID) 90 ns

RDX (ID)

TRDL Control pulse “L” duration (ID) 45 ns

When read ID data

TRCFM Read cycle (FM) 450 ns

TRDHFM Control pulse “H” duration (FM) 90 ns

RDX (FM)

TRDLFM Control pulse “L” duration (FM) 355 ns

When read from frame

memory

TDST Data setup time 10 ns

TDHT Data hold time 10 ns

TRAT Read access time (ID) 40 ns

TRATFM Read access time (FM) 340 ns

D[17:0]

TODH Output disable time 20 80 ns

For CL=30pF

Table 8.1.1 8080 parallel Interface Characteristics

wH=0.7 x VDDI v.L=o.3 x VDDI TR:T;<:1 5ns="" csx="" wrx="" r="" dx="" wrx="" ,_.="" rdx="" tm="" ‘="" tum/now="">

ST7735R

V0.2 22 2009-08-05

Figure

8.1.2 Rising and falling timing for input and output signal

Figure 8.1.3 Chip selection (CSX) timing

Figure 8.1.4 Write-to-read and read-to-write timing

Note: The rising time and falling time (Tr, Tf) of input signal are specified at 15 ns or less. Logic high and low levels are specified as 30%

and 70% of VDDI for Input signals.

S T7735 R ‘ Tog CSX ‘ 3 Twcs/TRCSFM D/CX /\NX D[1 7:0] wme RX D[17,0] read

ST7735R

V0.2 23 2009-08-05

8.2 Parallel interface characteristics: 18, 16, 9 or 8-bit bus (6800 series MCU interface)

Figure 8.2.1Parallel interface timing characteristics (6800-series MCU interface)

Ta=25 ℃, VDDI=1.65~3.7V, VDD=2.3~4.8V

Signal Symbol Parameter Min Max Unit Description

T

AST

Address setup time 10 ns

D/CX T

AHT

Address hold time (Write/Read) 10 ns -

T

CHW

Chip select “H” pulse width 0 ns

T

CS

Chip select setup time (Write) 15 ns

T

RCS

Chip select setup time (Read ID) 45 ns

T

RCSFM

Chip select setup time (Read FM) 355 ns

T

CSF

Chip select wait time (Write/Read) 10 ns

CSX

T

CSH

Chip select hold time 10 ns

-

T

WC

Write cycle 66 ns

T

WRH

Control pulse “H” duration 15 ns

WRX

T

WRL

Control pulse “L” duration 15 ns

T

RC

Read cycle (ID) 160 ns

T

RDH

Control pulse “H” duration (ID) 90 ns

RDX (ID) T

RDL

Control pulse “L” duration (ID) 45 ns When read ID data

T

RCFM

Read cycle (FM) 450 ns

T

RDHFM

Control pulse “H” duration (FM) 90 ns

RDX (FM)

T

RDLFM

Control pulse “L” duration (FM) 355 ns

When read from frame

memory

T

DST

Data setup time 10 ns

T

DHT

Data hold time 10 ns

D[17:0]

T

ODH

Output disable time 20 80 ns

For maximum CL=30pF

For minimum CL=8pF

Table 8.2.1 6800 parallel Interface Characteristics

Note: The rising time and falling time (Tr, Tf) of input signal are specified at 15 ns or less. Logic high and low levels are specified as 30%

and 70% of VDDI for Input signals.

S T7735 R TSDH Dala hold lime

ST7735R

V0.2 24 2009-08-05

8.3 Serial interface characteristics (3-line serial)

CSX VIH

VIL TCHW

TCSH

TOH

TCSS

SCL

SDA

(DOUT)

TSCC

TSCYCW/TSCYCR

TACC

VIH

VIL

VIH

VIL

VIH

VIL

VIH

VIL

TSDS TSDH

TSHW/TSHR

TSLW/TSLR

Figure 8.3.1 3-line serial interface timing

Ta=25 ℃, VDDI=1.65~3.7V, VDD=2.3~4.8V

Signal Symbol Parameter Min Max Unit Description

TCSS Chip select setup time (write) 15 ns

TCSH Chip select hold time (write) 15 ns

TCSS Chip select setup time (read) 60 ns

TSCC Chip select hold time (read) 65 ns

CSX

TCHW Chip select “H” pulse width 40 ns

TSCYCW Serial clock cycle (Write) 66 ns

TSHW SCL “H” pulse width (Write) 15 ns

TSLW SCL “L” pulse width (Write) 15 ns

TSCYCR Serial clock cycle (Read) 150 ns

TSHR SCL “H” pulse width (Read) 60 ns

SCL

TSLR SCL “L” pulse width (Read) 60 ns

TSDS Data setup time 10 ns

TSDH Data hold time 10 ns

TACC Access time 10 50 ns

SDA

(DIN)

(DOUT) TOH Output disable time 15 50 ns

For maximum CL=30pF

For minimum CL=8pF

Table 8.3.1 3-line Serial Interface Characteristics

Note : The rising time and falling time (Tr, Tf) of input signal are specified at 15 ns or less. Logic high and low levels are specified as 30%

and 70% of VDDI for Input signals.

S T7735 R Descri ﬁon .m U X A M Tscvcm/TSCVCR TsDH ; DCH M Ts H—* g Tsns Parameter VM V‘L Va Vu. S bol SDA D/CX SDA (noun

ST7735R

V0.2 25 2009-08-05

8.4 Serial interface characteristics (4-line serial)

Figure 8.4.1 4-line serial interface timing

Ta=25 ℃, VDDI=1.65~3.7V, VDD=2.3~4.8V

Signal Symbol Parameter MIN MAX

Unit

Description

TCSS Chip select setup time (write) 45 ns

TCSH Chip select hold time (write) 45 ns

TCSS Chip select setup time (read) 60 ns

TSCC Chip select hold time (read) 65 ns

CSX

TCHW Chip select “H” pulse width 40 ns

TSCYCW Serial clock cycle (Write) 66 ns

TSHW SCL “H” pulse width (Write) 15 ns

TSLW SCL “L” pulse width (Write) 15 ns

-write command & data

ram

TSCYCR Serial clock cycle (Read) 150 ns

TSHR SCL “H” pulse width (Read) 60 ns

SCL

TSLR SCL “L” pulse width (Read) 60 ns

-read command & data

ram

TDCS D/CX setup time 10 ns

D/CX TDCH D/CX hold time 10 ns

TSDS Data setup time 10 ns

TSDH Data hold time 10 ns

TACC Access time 10 50 ns

SDA

(DIN)

(DOUT) TOH Output disable time 15 50 ns

For maximum CL=30pF

For minimum CL=8pF

Table 8.4.1 4-line Serial Interface Characteristics

Note : The rising time and falling time (Tr, Tf) of input signal are specified at 15 ns or less. Logic high and low levels are specified as 30%

and 70% of VDDI for Input signals.

S T7735 R

ST7735R

V0.2 26 2009-08-05

9 Function description

9.1 Interface type selection

The selection of given interfaces are done by setting IM2, IM1, and IM0 pins as shown in following table.

P68 IM2 IM1 IM0 Interface Read back selection

- 0 - - 3-line serial interface Via the read instruction

0 1 0 0 8080 MCU 8-bit parallel RDX strobe (8-bit read data and 8-bit read parameter)

0 1 0 1 8080 MCU 16-bit parallel RDX strobe (16-bit read data and 8-bit read parameter)

0 1 1 0 8080 MCU 9-bit parallel RDX strobe (9-bit read data and 8-bit read parameter)

0 1 1 1 8080 MCU 18-bit parallel RDX strobe (18-bit read data and 8-bit read parameter)

- 0 - - 3-line serial interface Via the read instruction

1 1 0 0 6800 MCU 8-bit parallel E strobe (8-bit read data and 8-bit read parameter)

1 1 0 1 6800 MCU 16-bit parallel E strobe (16-bit read data and 8-bit read parameter)

1 1 1 0 6800 MCU 9-bit parallel E strobe (9-bit read data and 8-bit read parameter)

1 1 1 1 6800 MCU 18-bit parallel E strobe (18-bit read data and 8-bit read parameter)

Table 9.1.1 Selection of MCU interface

P68 IM2 IM1 IM0 Interface RDX WRX D/CX

Read back selection

- 0 - - 3-line serial interface Note1

Note1

SCL D[17:1]: unused, D0: SDA

0 1 0 0 8080 8-bit parallel RDX WRX D/CX

D[17:8]: unused, D7-D0: 8-bit data

0 1 0 1 8080 16-bit parallel RDX WRX D/CX

D[17:16]: unused, D15-D0: 16-bit

data

0 1 1 0 8080 9-bit parallel RDX WRX D/CX

D[17:9]: unused, D8-D0: 9-bit data

0 1 1 1 8080 18-bit parallel RDX WRX D/CX

D17-D0: 18-bit data

- 0 - - 3-line serial interface Note1

D/CX

SCL D[17:1]: unused, D0: SDA

1 1 0 0 6800 8-bit parallel E WRX RS D[17:8]: unused, D7-D0: 8-bit data

1 1 0 1 6800 16-bit parallel E WRX RS D[17:16]: unused, D15-D0: 16-bit

data

1 1 1 0 6800 9-bit parallel E WRX RS D[17:9]: unused, D8-D0: 9-bit data

1 1 1 1 6800 18-bit parallel E WRX RS D17-D0: 18-bit data

Table 9.1.2 Pin connection according to various MCU interface

Note: Unused pins can be open, or connected to DGND or VDDI.

S T7735 R

ST7735R

V0.2 27 2009-08-05

9.2 8080-series MCU parallel interface (P68 = ‘0’)

The MCU can use one of following interfaces: 11-lines with 8-data parallel interface, 12-lines with 9-data parallel interface,

19-line with 16-data parallel interface or 21-lines with 18-data parallel interface. The chip-select CSX (active low)

enables/disables the parallel interface. RESX (active low) is an external reset signal. WRX is the parallel data write enable,

RDX is the parallel data read enable and D[17:0] is parallel data bus.

The LCD driver reads the data at the rising edge of WRX signal. The D/CX is the data/command flag. When D/CX=’1’,

D[17:0] bits is either display data or command parameter. When D/C=’0’, D[17:0] bits is command. The interface functions

of 8080-series parallel interface are given in following table.

IM2

IM1

IM0

Interface D/CX

RDX

WRX

Read back selection

0 1 ↑ Write 8-bit command (D7 to D0)

1 1 ↑ Write 8-bit display data or 8-bit parameter (D7 to D0)

1 ↑ 1 Read 8-bit display data (D7 to D0)

1 0 0 8-bit

parallel

1 ↑ 1 Read 8-bit parameter or status (D7 to D0)

0 1 ↑ Write 8-bit command (D7 to D0)

1 1 ↑ Write 16-bit display data or 8-bit parameter (D15 to D0)

1 ↑ 1 Read 16-bit display data (D15 to D0)

1 0 1 16-bit

parallel

1 ↑ 1 Read 8-bit parameter or status (D7 to D0)

0 1 ↑ Write 8-bit command (D7 to D0)

1 1 ↑ Write 9-bit display data or 8-bit parameter (D8 to D0)

1 ↑ 1 Read 9-bit display data (D8 to D0)

1 1 0 9-bit

parallel

1 ↑ 1 Read 8-bit parameter or status (D7 to D0)

0 1 ↑ Write 8-bit command (D7 to D0)

1 1 ↑ Write 18-bit display data or 8-bit parameter (D17 to D0)

1 ↑ 1 Read 18-bit display data (D17 to D0)

1 1 1 18-bit

parallel

1 ↑ 1 Read 8-bit parameter or status (D7 to D0)

Table 9.2.1 the function of 8080-series parallel interface

Note: applied for command code: DAh, DBh, DCh, 04h, 09h, 0Ah, 0Bh, 0Ch, 0Dh, 0Eh, 0Fh

S T7735 R XX X X X X

ST7735R

V0.2 28 2009-08-05

9.2.1 Write cycle sequence

The write cycle means that the host writes information (command or/and data) to the display via the interface. Each write

cycle (WRX high-low-high sequence) consists of 3 control signals (D/CX, RDX, WRX) and data signals (D[17:0]). D/CX bit

is a control signal, which tells if the data is a command or a data. The data signals are the command if the control signal is

low (=’0’) and vice versa it is data (=’1’).

WRX

D[17:0]

The host starts to control D[17:0]

lines when there is a falling edge

of the WRX.

The display writes D[17:0] lines

when there is a rising edge of

WRX.

The host stops to

control D[17:0] lines.

Figure 9.2.1 8080-series WRX protocol

Note: WRX is an unsynchronized signal (It can be stopped).

CMD CMD PA1 CMD PA1PAN-2 PAN-1

S P

CMD CMD PA1 CMD PA1PAN-2 PAN-1

S P

CMD CMD PA1 CMD PA1PAN-2 PAN-1

S P

D[17:0]

RESX

CSX

D/CX

RDX

WRX

D[17:0]

Host D[17:0]

Host to LCD

Driver D[17:0]

LCD to Host

“1”

Hi-Z

1-byte

command

2-byte

command

N-byte

command

CMD: write command code

PA: parameter or display data

Signals on D[17:0], D/CX, R/WX, E

pins during CSX=1 are ignored.

Figure 9.2.2 8080-series parallel bus protocol, write to register or display RAM

S T7735 R RDX / \ The dhver stops to The dhver star‘s to control The host read [1170] llnes V D[17,0] hnes when there T5 3 when there Ts a nsmg edge a! comfol D{17'0]|mes falhng edge loe RDX. RDX.

ST7735R

V0.2 29 2009-08-05

9.2.2 Read cycle sequence

The read cycle (RDX high-low-high sequence) means that the host reads information from LCD driver via interface. The

driver sends data (D[17:0]) to the host when there is a falling edge of RDX and the host reads data when there is a rising

edge of RDX.

Figure 9.2.3 8080-series RDX protocol

Note: RDX is an unsynchronized signal (It can be stopped).

CMD DM PA CMD DM & data Data DataS P

D[17:0]

RESX

CSX

D/CX

RDX

WRX

D[17:0]

Host D[17:0]

Host to LCD

Driver D[17:0]

LCD to Host

“1”

Hi-Z

Read parameter Read display data

CMD: write command code

PA: parameter or display data

Signals on D[17:0], D/CX, R/WX, E

pins during CSX=1 are ignored.

DM PA1 DM & data PAN-2 PAN-1 PS

CMD CMDS P

Hi-Z Hi-Z

Hi-Z

Figure 9.2.4 8080-series parallel bus protocol, read data from register or display RAM

S T7735 R 68 M2 |M1 IMO Imeﬂace D/CX R/WX E Function me 8-be command D7 Io D0 v | | . A A A The hos‘ smns lo connol The dwsp‘ay writes Bum] The "05‘ S‘OPS to own] lmes when Ihere IS lines when there IS a falling control DWVO] Imesv a nsmg edge oflhe EV edge 0! EV

ST7735R

V0.2 30 2009-08-05

9.3 6800-series MCU parallel interface (P68 = ‘1’)

The MCU uses one of following interface: 11-lines with 8-data parallel interface, 12-lines with 9-data parallel interface,

19-lines with 16-data parallel interface, or 21-lines with 18-data parallel interface. The chip-select CSX(active low) enables

and disables the parallel interface. RESX (active low) is an external reset signal. The R/WX is the Read/Write flag and

D[17:0] is parallel data bus.

The LCD driver reads the data at the falling edge of E signal when R/WX= ‘1’ and Writes the data at the falling of the E

signal when R/WX=’0’. The D/CX is the data/command flag. When D/CX=’1’, D[17:0] bits are display RAM data or

command parameters. When D/C= ‘0’, D[17:0] bits are commands.

The 6800-series bi-directional interface can be used for communication between the micro controller and LCD driver. The

selection of this interface is done when P68 pin is high state (VDDI). Interface bus width can be selected with IM2, IM1 and

IM0.The interface functions of 6800-series parallel interface are given in Table 8.1.1.

P68

IM2

IM1

IM0

Interface D/CX

R/WX

E Function

0 0 ↓ Write 8-bit command (D7 to D0)

1 0 ↓ Write 8-bit display data or 8-bit parameter (D7 to D0)

1 1 ↓ Read 8-bit Display data (D7 to D0)

1 1 0 0 8-bit Parallel

1 1 ↓ Read 8-bit parameter or status (D7 to D0)

0 0 ↓ Write 8-bit command (D7 to D0)

1 0 ↓ Write 16-bit display data or 8-bit parameter (D15 to D0)

1 1 ↓ Read 16-bit Display data (D15 to D0)

1 1 0 1 16-bit Parallel

1 1 ↓ Read 8-bit parameter or status (D7 to D0)

0 0 ↓ Write 8-bit command (D7 to D0)

1 0 ↓ Write 9-bit display data or 8-bit parameter (D8 to D0)

1 1 ↓ Read 9-bit Display data (D8 to D0)

1 1 1 0 9-bit Parallel

1 1 ↓ Read 8-bit parameter or status (D7 to D0)

0 0 ↓ Write 8-bit command (D7 to D0)

1 0 ↓ Write 18-bit display data or 8-bit parameter (D17 to D0)

1 1 ↓ Read 18-bit Display data (D17 to D0)

1 1 1 1 18-bit Parallel

1 1 ↓ Read 8-bit parameter or status (D7 to D0)

Table 9.3.1 The function of 6800-series parallel interface

Note: applied for command code: DAh, DBh, DCh, 04h, 09h, 0Ah, 0Bh, 0Ch, 0Dh, 0Eh, 0Fh.

9.3.1 Write cycle sequence

The write cycle means that the host writes information (command or/and data) to the display via the interface. Each write

cycle (E low-high-low sequence) consists of 3 control signals (D/CX, E, R/WX) and data signals (D[17:0]). D/CX bit is a

control signal, which tells if the data is a command or a data. The data signals are the command if the control signal is low

(=’0’) and vice versa it is data (=’1’).

Figure 9.3.1 6800-Series Write Protocol

Note: E is an unsynchronized signal (It can be stopped)

S T7735 R 1

ST7735R

V0.2 31 2009-08-05

Figure 9.3.2 6800-series parallel bus protocol, write to register or display RAM

S T7735 R R/WX E [117.0] The dnver starts to contro‘ The host read D[17'0] lines The driver stops m D[17,0] lmes when Ihere is when (here Is a fal‘lng edge of 0°"th DI17'0] lines a rismg edge oilhe E. RDX. Read parameter Read dismay data D[17:O] X s CMD DM X PA CMD DM & data X Data Data P RESX “1" Hos‘ 17:0 HIVZ HoslgLCEJ X 5 CM” iiiiii Dnver D[17:0 HLZ HI—Z LCDtoHost'X s >‘“ D” P“ 1 -- CMD: write command code Signals on [11710], D/CX, R/WX, E PA: parameter or dxsplay data W‘s dunng C5X=1 are Ignored.

ST7735R

V0.2 32 2009-08-05

9.3.2 9.3.2 Read cycle sequence

The read cycle (E low-high-low sequence) means that the host reads information from LCD driver via interface. The driver

sends data (D[17:0]) to the host when there is a rising edge of E and the host reads data when there is a falling edge of E.

Figure 9.3.3 6800-series read protocol

Note: E is an unsynchronized signal (It can be stopped)

Figure 9.3.4 6800-series parallel bus protocol, read data form register or display RAM

S T7735 R 34ine serial data stream format Transmwsswon [)er (TB) may be command urdala /—/% D/CX D7 D6 D5 D4 D3 D2 D1 D0 TB TB A A \ r \ DICX D7 D6 D5 D4 D3 D2 D1 D0 D/CX D7 D6 D5 D4 D3 D2 D1 D0 4—line serial data stream format Transmisslon byte 1TB) may bewmmand urdata D7 D6 D5 D4 D3 D2 D1 D0 TB TB A A r V \ D7 D6 D5 D4 D3 D2 D1 D0 D7 D6 D5 D4 D3 D2 DI DD

ST7735R

V0.2 33 2009-08-05

9.4 Serial interface

The selection of this interface is done by IM2. See the Table 9.4.1.

IM2 4WSPI Interface Read back selection

0 0 3-line serial interface Via the read instruction (8-bit, 24-bit and 32-bit read parameter)

0 1 4-line serial interface Via the read instruction (8-bit, 24-bit and 32-bit read parameter)

Table 9.4.2 Selection of serial interface

The serial interface is either 3-lines/9-bits or 4-lines/8-bts bi-directional interface for communication between the micro

controller and the LCD driver. The 3-lines serial interface use: CSX (chip enable), SCL (serial clock) and SDA (serial data

input/output), and the 4-lines serial interface use: CSX (chip enable), D/CX (data/ command flag), SCL (serial clock) and

SDA (serial data input/output). Serial clock (SCL) is used for interface with MCU only, so it can be stopped when no

communication is necessary.

9.4.1 Command Write Mode

The write mode of the interface means the micro controller writes commands and data to the LCD driver. 3-lines serial data

packet contains a control bit D/CX and a transmission byte. In 4-lines serial interface, data packet contains just

transmission byte and control bit D/CX is transferred by the D/CX pin. If D/CX is “low”, the transmission byte is interpreted

as a command byte. If D/CX is “high”, the transmission byte is stored in the display data RAM (memory write command), or

command register as parameter.

Any instruction can be sent in any order to the driver. The MSB is transmitted first. The serial interface is initialized when

CSX is high. In this state, SCL clock pulse or SDA data have no effect. A falling edge on CSX enables the serial interface

and indicates the start of data transmission.

Figure 9.4.1 Serial interface data stream format

When CSX is “high”, SCL clock is ignored. During the high period of CSX the serial interface is initialized. At the falling edge

of CSX, SCL can be high or low (see Figure 9.4.2). SDA is sampled at the rising edge of SCL. D/CX indicates whether the

byte is command (D/CX=’0’) or parameter/RAM data (D/CX=’1’). D/CX is sampled when first rising edge of SCL (3-lines

serial interface) or 8th rising edge of SCL (4-lines serial interface). If CSX stays low after the last bit of command/data byte,

the serial interface expects the D/CX bit (3-lines serial interface) or D7 (4-lines serial interface) of the next byte at the next

rising edge of SCL..

S T7735 Ff Command ‘ ‘ Command/Parameuer CSX can be “H"belween parameter/command and parameter/command SOL and SDA during CSX="H" is ignored. Host . (MCU to driver) Command 1 1 Command/Parameler CSX can be “H"belween parameter/command and parameler/command SCL and SDA during CSX="H" is ignored.

ST7735R

V0.2 34 2009-08-05

Figure 9.4.3 3-line serial interface write protocol (write to register with control bit in transmission)

Figure 9.4.4 4-line serial interface write protocol (write to register with control bit in transmission)

9.4.2 Read Functions

The read mode of the interface means that the micro controller reads register value from the driver. To achieve read

function, the micro controller first has to send a command (read ID or register command) and then the following byte is

transmitted in the opposite direction. After that CSX is required to go to high before a new command is send (see the below

figure). The driver samples the SDA (input data) at rising edge of SCL, but shifts SDA (output data) at the falling edge of

SCL. Thus the micro controller is supported to read at the rising edge of SCL.

After the read status command has been sent, the SDA line must be set to tri-state no later than at the falling edge of SCL of

the last bit.

S T7735 R U 2 DA E (300) CSX I 0°; SCL SDA a 5' (390) CSX I “S. SCI. w H..z wunsmwmmw @ {Bi ﬂﬂﬂﬂﬂ,,ﬂ.ﬂﬂﬂ mmmmrreeaa Dummy m cycle @ rs mz wmmmwmww @ f“ Hm , m w m w- w- , 9999 Dummy new Lyda

ST7735R

V0.2 35 2009-08-05

9.4.3 3-line serial protocol

3-line serial protocol (for RDID1/RDID2/RDID3/0Ah/0Bh/0Ch/0Dh/0Eh/0Fh command: 8-bit read):

3-line serial protocol (for RDDID command: 24-bit read)

3-line Serial Protocol (for RDDST command: 32-bit read)

Figure 9.4.5 3-line serial interface read protocol

S T7735 R rs TB CSX 5 f0 ‘ w m (gm) mmmmmmmww 0 g (536% "‘2 EEGQQEQQ TE @ 'E CSX g: 5“ WNW ....... m 3 w >I< (53.143="" wwwmmmmw="" "*2="" u="" e'="" (nsé’ﬁ‘n="" "*1="" ﬁﬁﬂﬁ="" dummy="" cloak="" cycle="" rs="" @="" rs="" 53%="" mmmmmmmm="" "*2="" .......="" (336%="" w="" m="" moms="" dummy="" cloak="" cycle="">

ST7735R

V0.2 36 2009-08-05

9.4.4 4-line serial protocol

4-line serial protocol (for RDID1/RDID2/RDID3/0Ah/0Bh/0Ch/0Dh/0Eh/0Fh command: 8-bit read):

4-line serial protocol (for RDDID command: 24-bit read)

4-line Serial Protocol (for RDDST command: 32-bit read)

Host Driver

Figure 9.4.6 4-line serial interface read protocol

S T7735 Ff (As/mp 0) new) ISOH (3% W W m ZED [— Waw ormorelhamoms SCLﬂITIITIT 5“ ,999999ﬂ //,999999997/1 ﬂﬂﬂﬂﬂﬂﬂﬂﬂﬂ Command/Parameter/Dala ‘ K Command SCL and SDA during RESX=" L" IS \nvahd and next byte becomes command (9% m csx j I %%%@ TH E H SCL 5“ I: , 999999 ,ﬂﬂﬂﬂﬂﬂﬂﬂnﬂ 2%@Qaaaaaaaaa j Command/Parameter/Data Break Command/Parameter/Dala

ST7735R

V0.2 37 2009-08-05

9.5 Data Transfer Break and Recovery

If there is a break in data transmission by RESX pulse, while transferring a command or frame memory data or multiple

parameter command data, before Bit D0 of the byte has been completed, then driver will reject the previous bits and have

reset the interface such that it will be ready to receive command data again when the chip select line (CSX) is next

activated after RESX have been HIGH state. See the following example

Host

(MCU to driver)

Figure 9.5.1 Serial bus protocol, write mode – interrupted by RESX

If there is a break in data transmission by CSX pulse, while transferring a command or frame memory data or multiple

parameter command data, before Bit D0 of the byte has been completed, then driver will reject the previous bits and have

reset the interface such that it will be ready to receive the same byte re-transmitted when the chip select line (CSX) is next

activated. See the following example

Figure 9.5.2 Serial bus protocol, write mode – interrupted by CSX

If 1, 2 or more parameter commands are being sent and a break occurs while sending any parameter before the last one

and if the host then sends a new command rather than re-transmitting the parameter that was interrupted, then the

parameters that were successfully sent are stored and the parameter where the break occurred is rejected. The interface is

ready to receive next byte as shown below.

S T7735 Ff Pam 1 is successruuy sem but pera12 is broken and needs :0 be lransler again ' Pm“ i Com mand1 with 15' parameter (paraT 1) should be executed again to wire remained parameter (paraT 2. para13) Para11 is successfully sent but other parameters are not sent and me break happens by anomer command. [ Para“ Command1 with 1SK parameter(para1 1) should be executed again to write remained parameter(para12. para13)

ST7735R

V0.2 38 2009-08-05

Figure 9.5.3 Write interrupts recovery (serial interface)

If a 2 or more parameter commands are being sent and a break occurs by the other command before the last one is sent,

then the parameters that were successfully sent are stored and the other parameter of that command remains previous

value.

Figure 9.5.4 Write interrupts recovery (both serial and parallel Interface)

S T7735 H csx ‘\ r (mummy) SBA I 7 «666666 7 ‘6‘666666 Command/Parameter/Dala Command/Parameter/Data SCL and SDA during Csxd'HWs mvana. CSX \_l D/CX < x="" rdx="" x="" pause="" wrx="" d[1="" 7:0]="" |_t="" |_t="" c="" x="" d[17:0]="" x="" command/parameter="" pause="" x="" d[17:0]="" command/parameter="">

ST7735R

V0.2 39 2009-08-05

9.6 Data transfer pause

It will be possible when transferring a command, frame memory data or multiple parameter data to invoke a pause in the

data transmission. If the chip select line is released after a whole byte of a frame memory data or multiple parameter data

has been completed, then driver will wait and continue the frame memory data or parameter data transmission from the

point where it was paused. If the chip select Line is released after a whole byte of a command has been completed, then

the display module will receive either the command‘s parameters (if appropriate) or a new command when the chip select

line is next enabled as shown below.

This applies to the following 4 conditions:

1) Command-Pause-Command

2) Command-Pause-Parameter

3) Parameter-Pause-Command

4) Parameter-Pause-Parameter

9.6.1 Serial interface pause

Figure 9.6.1 Serial interface pause protocol (pause by CSX)

9.6.2 Parallel interface pause

Figure 9.6.2 Parallel bus pause protocol (paused by CSX)

S T7735 R Start Stop Stan frame Frame 1 Frame 2 Frame 3 Memory wrtte Image data Image data Image data ....... Any command Stan Start frame Frame 1 Start frame Frame 2 Memory write Image date Any command Memory write Image data Any command W, Any command

ST7735R

V0.2 40 2009-08-05

9.7 Data Transfer Modes

The module has three kinds color modes for transferring data to the display RAM. These are 12-bit color per pixel, 16-bit

color per pixel and 18-bit color per pixel. The data format is described for each interface. Data can be downloaded to the

frame memory by 2 methods.

9.7.1 Method 1

The image data is sent to the frame memory in successive frame writes, each time the frame memory is filled, the frame

memory pointer is reset to the start point and the next frame is written.

9.7.2 Method 2

The image data is sent and at the end of each frame memory download, a command is sent to stop frame memory write.

Then start memory write command is sent, and a new frame is downloaded.

Note 1: These apply to all data transfer Color modes on both serial and parallel interfaces.

Note 2: The frame memory can contain both odd and even number of pixels for both methods. Only complete pixel data will be stored in

the frame memory.

ST7735R

V0.2 41 2009-08-05

9.8 Data Color Coding

9.8.1 8-bit Parallel Interface (IM2, IM1, IM0= “100”)

Different display data formats are available for three Colors depth supported by listed below.

- 4k colors, RGB 4,4,4-bit input.

- 65k colors, RGB 5,6,5-bit input.

- 262k colors, RGB 6,6,6-bit input.

9.8.2 8-bit data bus for 12-bit/pixel (RGB 4-4-4-bit input), 4K-Colors, 3AH= “03h”

R1, Bit 3 B1, Bit 3 G2, Bit 3 R3, Bit 30

R1, Bit 2 B1, Bit 2 G2, Bit 2 R3, Bit 20

R1, Bit 1 B1, Bit 1 G2, Bit 1 R3, Bit 11

R1, Bit 0 B1, Bit 0 G2, Bit 0 R3, Bit 00

G1, Bit 3 R2, Bit 3 B2, Bit 3 G3, Bit 31

G1, Bit 2 R2, Bit 2 B2, Bit 2 G3, Bit 21

G1, Bit 1 R2, Bit 1 B2, Bit 1 G3, Bit 10

G1, Bit 0 R2, Bit 0 B2, Bit 0 G3, Bit 00

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“1 ”

“1 ”“1 ”

“1 ”

“

““

“100”

””

”

WRX

RDX “

““

“1”

””

”

D7

D6

D5

D4

D3

D2

D1

D0

Pixel n Pixel n+1

Look-up table for 4096 color data mapping (12 bits to 18 bits)

12 bits 12 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

18 bits

Frame memory

Note 1: The data order is as follows, MSB=D7, LSB=D0 and picture data is MSB=Bit 3, LSB=Bit 0 for Red, Green and Blue data.

Note 2: 3-time transfer is used to transmit 1 pixel data with the 12-bit color depth information.

Note 3: ‘-‘ = Don't care - Can be set to '0' or '1'

..

ST7735R

V0.2 42 2009-08-05

9.8.3 8-bit data bus for 16-bit/pixel (RGB 5-6-5-bit input), 65K-Colors, 3AH= “05h”

There is 1 pixel (3 sub-pixels) per 2-byte

R1, Bit 4 G1, Bit 20

R1, Bit 3 G1, Bit 10

R1, Bit 2 G1, Bit 01

R1, Bit 1 B1, Bit 40

R1, Bit 0 B1, Bit 31

G1, Bit 5 B1, Bit 21

G1, Bit 4 B1, Bit 10

G1, Bit 3 B1, Bit 00

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“100”

””

”

WRX

RDX

“

““

“1”

””

”

D7

D6

D5

D4

D3

D2

D1

D0

Pixel n Pixel n+1

Look-up table for 65k color data mapping (16 bits to 18 bits)

16 bits 16 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

18 bits

Frame memory

R2, Bit 4 G2, Bit 2

R2, Bit 3 G2, Bit 1

R2, Bit 2 G2, Bit 0

R2, Bit 1 B2, Bit 4

R2, Bit 0 B2, Bit 3

G2, Bit 5 B2, Bit 2

G2, Bit 4 B2, Bit 1

G2, Bit 3 B2, Bit 0

Note 1: The data order is as follows, MSB=D7, LSB=D0 and picture data is MSB=Bit 5, LSB=Bit 0 for Green and MSB=Bit 4, LSB=Bit 0 for

Red and Blue data.

Note 2: 2-times transfer is used to transmit 1 pixel data with the 16-bit color depth information.

Note 3: ‘-‘ = Don't care - Can be set to '0' or '1'

ST7735R

V0.2 43 2009-08-05

9.8.4 8-bit data bus for 18-bit/pixel (RGB 6-6-6-bit input), 262K-Colors, 3AH= “06h”

There is 1 pixel (3 sub-pixels) per 3-bytes.

R1, Bit 4

0

R1, Bit 3

0

R1, Bit 2

1

R1, Bit 1

0

R1, Bit 0

1

R1, Bit 5

1

- -0

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“100”

””

”

WRX

RDX

“

““

“1”

””

”

D7

D6

D5

D4

D3

D2

D1

D0

Pixel n Pixel n+1

18 bits 18 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

Frame memory

- -

G1, Bit 4

G1, Bit 3

G1, Bit 2

G1, Bit 1

G1, Bit 0

G1, Bit 5

B1, Bit 4

B1, Bit 3

B1, Bit 2

B1, Bit 1

B1, Bit 0

B1, Bit 5

R2, Bit 4

R2, Bit 3

R2, Bit 2

R2, Bit 1

R2, Bit 0

R2, Bit 5

Note 1: The data order is as follows, MSB=D7, LSB=D0 and picture data is MSB=Bit 5, LSB=Bit 0 for Red, Green and Blue data.

Note 2: 3-times transfer is used to transmit 1 pixel data with the 18-bit color depth information.

Note 3: ‘-‘ = Don't care - Can be set to '0' or '1'

ST7735R

V0.2 44 2009-08-05

9.8.5 16-Bit Parallel Interface (IM2,IM1, IM0= “101”)

Different display data formats are available for three colors depth supported by listed below.

- 4k colors, RGB 4,4,4-bit input

- 65k colors, RGB 5,6,5-bit input

- 262k colors, RGB 6,6,6-bit input

9.8.6 16-bit data bus for 12-bit/pixel (RGB 4-4-4-bit input), 4K-Colors, 3AH= “03h”

There is 1 pixel (3 sub-pixels) per 1 byte

-

G1, Bit 3

-

G1, Bit 2

-

G1, Bit 1

-

G1, Bit 0

-

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“101”

””

”

WRX

RDX

“

““

“1”

””

”

D15

D14

D13

D12

D11

D10

D9

D8

Pixel n Pixel n+1

12 bits 12 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

18 bits

Frame memory

R1, Bit 3

0

R1, Bit 2

0

R1, Bit 1

1

R1, Bit 0

0

1

0

D7

D6

D5

D4

D3

D2

D1

D0

-

B1, Bit 3

B1, Bit 2

B1, Bit 1

B1, Bit 0

G2, Bit 3

G2, Bit 2

G2, Bit 1

G2, Bit 0

R2, Bit 3

R2, Bit 2

R2, Bit 1

R2, Bit 0

-

B2, Bit 3

B2, Bit 2

B2, Bit 1

B2, Bit 0

G3, Bit 3

G3, Bit 2

G3, Bit 1

G3, Bit 0

R3, Bit 3

R3, Bit 2

R3, Bit 1

R3, Bit 0

-

B3, Bit 3

B3, Bit 2

B3, Bit 1

B3, Bit 0

G4, Bit 3

G4, Bit 2

G4, Bit 1

G4, Bit 0

R4, Bit 3

R4, Bit 2

R4, Bit 1

R4, Bit 0

-

B4, Bit 3

B4, Bit 2

B4, Bit 1

B4, Bit 0

Pixel n+2 Pixel n+3

Look-up table for 4096 color data mapping (12 bits to 18 bits)

Note 1: The data order is as follows, MSB=D11, LSB=D0 and picture data is MSB=Bit 3, LSB=Bit 0 for Red, Green and Blue data.

Note 2: 1-times transfer (D11 to D0) is used to transmit 1 pixel data with the 12-bit color depth information.

3: .. 5.. .. 5.. .. s: g .. g: N. 3

ST7735R

V0.2 45 2009-08-05

9.8.7 16-bit data bus for 16-bit/pixel (RGB 5-6-5-bit input), 65K-Colors, 3AH= “05h”

There is 1 pixel (3 sub-pixels) per 1 byte

-

G1, Bit 3

-

G1, Bit 2

-

G1, Bit 1

-

G1, Bit 0

-

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“101”

””

”

WRX

RDX

“

““

“1”

””

”

D15

D14

D13

D12

D11

D10

D9

D8

Pixel n Pixel n+1

16 bits 16 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

18 bits

Frame memory

R1, Bit 3

0

R1, Bit 2

0

R1, Bit 1

1

R1, Bit 0

0

1

0

D7

D6

D5

D4

D3

D2

D1

D0

B1, Bit 3

B1, Bit 2

B1, Bit 1

B1, Bit 0

G2, Bit 3

G2, Bit 2

G2, Bit 1

G2, Bit 0

R2, Bit 3

R2, Bit 2

R2, Bit 1

R2, Bit 0

B2, Bit 3

B2, Bit 2

B2, Bit 1

B2, Bit 0

G3, Bit 3

G3, Bit 2

G3, Bit 1

G3, Bit 0

R3, Bit 3

R3, Bit 2

R3, Bit 1

R3, Bit 0

B3, Bit 3

B3, Bit 2

B3, Bit 1

B3, Bit 0

G4, Bit 3

G4, Bit 2

G4, Bit 1

G4, Bit 0

R4, Bit 3

R4, Bit 2

R4, Bit 1

R4, Bit 0

B4, Bit 3

B4, Bit 2

B4, Bit 1

B4, Bit 0

Pixel n+2 Pixel n+3

Look-up table for 65k color data mapping (16 bits to 18 bits)

B1, Bit 4 B2, Bit 4 B3, Bit 4 B4, Bit 4

R1, Bit 4 R2, Bit 4 R3, Bit 4 R4, Bit 4

G1, Bit 5

G1, Bit 4

G2, Bit 5

G2, Bit 4

G3, Bit 5

G3, Bit 4

G4, Bit 5

G4, Bit 4

Note 1: The data order is as follows, MSB=D15, LSB=D0 and picture data is MSB=Bit 5, LSB=Bit 0 for Green, and MSB=Bit 4, LSB=Bit 0

for Red and Blue data.

Note 2: 1-times transfer (D15 to D0) is used to transmit 1 pixel data with the 16-bit color depth information.

Note 3: ‘-‘ = Don't care - Can be set to '0' or '1'

ST7735R

V0.2 46 2009-08-05

9.8.8 16-bit data bus for 18-bit/pixel (RGB 6-6-6-bit input), 262K-Colors, 3AH= “06h”

There are 2 pixels (6 sub-pixels) per 3 bytes

-

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“101”

””

”

WRX

RDX

“

““

“1”

””

”

D15

D14

D13

D12

D11

D10

D9

D8

Pixel n Pixel n+1

18 bits 18 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

Frame memory

R1, Bit 3

0

R1, Bit 2

0

R1, Bit 1

1

R1, Bit 0

0

1

0

D7

D6

D5

D4

D3

D2

D1

D0

B1, Bit 3

B1, Bit 2

B1, Bit 1

B1, Bit 0

B2, Bit 3

B2, Bit 2

B2, Bit 1

B2, Bit 0

B1, Bit 4

B2, Bit 4

R1, Bit 4

G1, Bit 3

G1, Bit 2

G1, Bit 1

G1, Bit 0

G3, Bit 3

G3, Bit 2

G3, Bit 1

G3, Bit 0

G1, Bit 5

G1, Bit 4

G3, Bit 5

G3, Bit 4

R1, Bit 5

- - - -

B1, Bit 5

B2, Bit 5

- - - -

R2, Bit 3

R2, Bit 2

R2, Bit 1

R2, Bit 0

R2, Bit 4

R2, Bit 5

G2, Bit 3

G2, Bit 2

G2, Bit 1

G2, Bit 0

G2, Bit 5

G2, Bit 4

R3, Bit 3

R3, Bit 2

R3, Bit 1

R3, Bit 0

R3, Bit 4

R3, Bit 5

Note 1: The data order is as follows, MSB=D15, LSB=D0 and picture data is MSB=Bits 5, LSB=Bit 0 for Red, Green and Blue data.

Note 2: 3-times transfer is used to transmit 1 pixel data with the 18-bit color depth information.

Note 3: ‘-‘ = Don't care - Can be set to '0' or '1'

ST7735R

V0.2 47 2009-08-05

9.8.9 9-Bit Parallel Interface (IM2, IM1, IM0=“110”)

Different display data formats are available for three colors depth supported by listed below.

-262k colors, RGB 6,6,6-bit input

9.8.10 Write 9-bit data for RGB 6-6-6-bit input (262k-color)

There is 1 pixel (6 sub-pixels) per 3 bytes

R1, Bit 40

R1, Bit 30

R1, Bit 21

R1, Bit 10

R1, Bit 01

R1, Bit 5

1

0

8080-series control

pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“110”

””

”

WRX

RDX

“

““

“1”

””

”

D7

D6

D5

D4

D3

D2

D1

D0

Pixel n Pixel n+1

18 bits 18 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

Frame memory

G1, Bit 4

G1, Bit 3

G1, Bit 2

G1, Bit 1

G1, Bit 0

B1, Bit 4

B1, Bit 3

B1, Bit 2

B1, Bit 1

B1, Bit 0

B1, Bit 5

R2, Bit 4

R2, Bit 3

R2, Bit 2

R2, Bit 1

R2, Bit 0

R2, Bit 5-

G1, Bit 5

D8

G2, Bit 4

G2, Bit 3

G2, Bit 5

B2, Bit 4

B2, Bit 3

B2, Bit 2

B2, Bit 1

B2, Bit 0

B2, Bit 5

G2, Bit 2

G2, Bit 1

G2, Bit 0

Note 1: The data order is as follows, MSB=D8, LSB=D0 and picture data is MSB=Bit 5, LSB=Bit 0 for Red, Green and Blue data.

Note 2: 3-times transfer is used to transmit 1 pixel data with the 18-bit color depth information.

Note 3: ‘-‘ = Don't care - Can be set to '0' or '1'

ST7735R

V0.2 48 2009-08-05

9.8.11 18-Bit Parallel Interface (IM2, IM1, IM0=“111”)

Different display data formats are available for three colors depth supported by listed below.

- 4k colors, RGB 4,4,4-bit input

- 65k colors, RGB 5,6,5-bit input

- 262k colors, RGB 6,6,6-bit input.

9.8.12 18-bit data bus for 12-bit/pixel (RGB 4-4-4-bit input), 4K-Colors, 3AH=“03h”

There is 1 pixel (3 sub-pixels) per 1 byte

-

G1, Bit 3

-

G1, Bit 2

-

G1, Bit 1

-

G1, Bit 0

-

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“111”

””

”

WRX

RDX “

““

“1”

””

”

D15

D14

D13

D12

D11

D10

D9

D8

Pixel n Pixel n+1

12 bits 12 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

18 bits

Frame memory

R1, Bit 3

0

R1, Bit 2

0

R1, Bit 1

1

R1, Bit 0

0

1

0

D7

D6

D5

D4

D3

D2

D1

D0

-

B1, Bit 3

B1, Bit 2

B1, Bit 1

B1, Bit 0

G2, Bit 3

G2, Bit 2

G2, Bit 1

G2, Bit 0

R2, Bit 3

R2, Bit 2

R2, Bit 1

R2, Bit 0

-

B2, Bit 3

B2, Bit 2

B2, Bit 1

B2, Bit 0

G3, Bit 3

G3, Bit 2

G3, Bit 1

G3, Bit 0

R3, Bit 3

R3, Bit 2

R3, Bit 1

R3, Bit 0

-

B3, Bit 3

B3, Bit 2

B3, Bit 1

B3, Bit 0

G4, Bit 3

G4, Bit 2

G4, Bit 1

G4, Bit 0

R4, Bit 3

R4, Bit 2

R4, Bit 1

R4, Bit 0

-

B4, Bit 3

B4, Bit 2

B4, Bit 1

B4, Bit 0

Pixel n+2 Pixel n+3

Look-Up Table for 4096 Color data mapping (12 bits to 18 bits)

-

D17 -

-

D16

Note 1: The data order is as follows, MSB=D11, LSB=D0 and picture data is MSB=Bit 3, LSB=Bit 0 for Red, Green and Blue data.

Note 2: 1-times transfer is used to transmit 1 pixel data with the 12-bit color depth information.

ST7735R

V0.2 49 2009-08-05

9.8.13 18-bit data bus for 16-bit/pixel (RGB 5-6-5-bit input), 65K-Colors, 3AH=“05h”

There is 1 pixel (3 sub-pixels) per 1 byte

-

G1, Bit 3

-

G1, Bit 2

-

G1, Bit 1

-

G1, Bit 0

-

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“111”

””

”

WRX

RDX

“

““

“1”

””

”

D15

D14

D13

D12

D11

D10

D9

D8

Pixel n Pixel n+1

16 bits 16 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

18 bits

Frame memory

R1, Bit 3

0

R1, Bit 2

0

R1, Bit 1

1

R1, Bit 0

0

1

0

D7

D6

D5

D4

D3

D2

D1

D0

B1, Bit 3

B1, Bit 2

B1, Bit 1

B1, Bit 0

G2, Bit 3

G2, Bit 2

G2, Bit 1

G2, Bit 0

R2, Bit 3

R2, Bit 2

R2, Bit 1

R2, Bit 0

B2, Bit 3

B2, Bit 2

B2, Bit 1

B2, Bit 0

G3, Bit 3

G3, Bit 2

G3, Bit 1

G3, Bit 0

R3, Bit 3

R3, Bit 2

R3, Bit 1

R3, Bit 0

B3, Bit 3

B3, Bit 2

B3, Bit 1

B3, Bit 0

G4, Bit 3

G4, Bit 2

G4, Bit 1

G4, Bit 0

R4, Bit 3

R4, Bit 2

R4, Bit 1

R4, Bit 0

B4, Bit 3

B4, Bit 2

B4, Bit 1

B4, Bit 0

Pixel n+2 Pixel n+3

Look-up table for 65k color data mapping (16 bits to 18 bits)

-

D17

-

D16

R1, Bit 4 R2, Bit 4 R3, Bit 4 R4, Bit 4

G1, Bit 5

G1, Bit 4

G2, Bit 5

G2, Bit 4

G3, Bit 5

G3, Bit 4

G4, Bit 5

G4, Bit 4

B1, Bit 4 B2, Bit 4 B3, Bit 4 B4, Bit 4

Note 1: The data order is as follows, MSB=D15, LSB=D0 and picture data is MSB=Bit 5, LSB=Bit 0 for Green, and MSB=Bit 4, LSB=Bit 0

for Red and Blue data.

Note 2: 1-time transfer is used to transmit 1 pixel data with the 16-bit color depth information.

3..

ST7735R

V0.2 50 2009-08-05

9.8.14 18-bit data bus for 18-bit/pixel (RGB 6-6-6-bit input), 262K-Colors, 3AH=“06h”

There is 1 pixel (3 sub-pixels) per 1 byte

-

G1, Bit 3

-

G1, Bit 2

-

G1, Bit 1

-

G1, Bit 0

-

8080-series control pins

RESX

IM[2:0]

CSX

D/CX

“

““

“1”

””

”

“

““

“111”

””

”

WRX

RDX

“

““

“1”

””

”

D15

D14

D13

D12

D11

D10

D9

D8

Pixel n Pixel n+1

18 bits 18 bits

R1 G1 B1 R2 G2 B2 R3 G3 B3

Frame memory

R1, Bit 3

0

R1, Bit 2

0

R1, Bit 1

1

R1, Bit 0

0

1

0

D7

D6

D5

D4

D3

D2

D1

D0

B1, Bit 3

B1, Bit 2

B1, Bit 1

B1, Bit 0

G2, Bit 3

G2, Bit 2

G2, Bit 1

G2, Bit 0

R2, Bit 3

R2, Bit 2

R2, Bit 1

R2, Bit 0

B2, Bit 3

B2, Bit 2

B2, Bit 1

B2, Bit 0

G3, Bit 3

G3, Bit 2

G3, Bit 1

G3, Bit 0

R3, Bit 3

R3, Bit 2

R3, Bit 1

R3, Bit 0

B3, Bit 3

B3, Bit 2

B3, Bit 1

B3, Bit 0

G4, Bit 3

G4, Bit 2

G4, Bit 1

G4, Bit 0

R4, Bit 3

R4, Bit 2

R4, Bit 1

R4, Bit 0

B4, Bit 3

B4, Bit 2

B4, Bit 1

B4, Bit 0

Pixel n+2 Pixel n+3

-

D17

D16

R1, Bit 4 R2, Bit 4 R3, Bit 4 R4, Bit 4

G1, Bit 5

G1, Bit 4

G2, Bit 5

G2, Bit 4

G3, Bit 5

G3, Bit 4

G4, Bit 5

G4, Bit 4

B1, Bit 4 B2, Bit 4 B3, Bit 4 B4, Bit 4

R1, Bit 5 R2, Bit 5 R3, Bit 5 R4, Bit 5

B1, Bit 5 B2, Bit 5 B3, Bit 5 B4, Bit 5

Note 1: The data order is as follows, MSB=D17, LSB=D0 and picture data is MSB=Bit 5, LSB=Bit 0 for Read, Green and Blue data.

Note 2: 1-times transfer (D17o D0) is used to transmit 1 pixel data with the 18-bit color depth information.

RESX ”1n IM2 ImwMHMk‘D‘ CSX mmDeDstaDzmmoamusnsmmnzmmmmneusmmmmDo 59“ C) ‘ @Eﬁﬁﬁﬂﬁﬁﬂﬂﬁﬁ “QEEQIQEQQEEEI Puxew n mew rm SCL 12m 1st Look-up table {or 4096 color data mapping (12biIsI018biIs) * 18m: ‘ ‘ ‘ ‘ ‘ Frame memory (31 . ‘

ST7735R

V0.2 51 2009-08-05

9.8.15 3-line serial Interface

Different display data formats are available for three colors depth supported by the LCM listed below.

4k colors, RGB 4-4-4-bit input

65k colors, RGB 5-6-5-bit input

262k colors, RGB 6-6-6-bit input

9.8.16 Write data for 12-bit/pixel (RGB 4-4-4-bit input), 4K-Colors, 3AH=“03h”

Note 1: Pixel data with the 12-bit color depth information

Note 2: The most significant bits are: Rx3, Gx3 and Bx3

Note 3: The least significant bits are: Rx0, Gx0 and Bx0

SDA C) \M2=wn 4Mm'0‘ men n D8D7mD5D4D3D2D1mDBD7mD5DAD3D2DIDO DamneDsDADammno; 555555555 men m Look-up table for 55k onlor data mapping (16 mg m 18 bits) Frame memory

ST7735R

V0.2 52 2009-08-05

9.8.17 Write data for 16-bit/pixel (RGB 5-6-5-bit input), 65K-Colors, 3AH=“05h”

Note 1: Pixel data with the 16-bit color depth information

Note 2: The most significant bits are: Rx4, Gx5 and Bx4

Note 3: The least significant bits are: Rx0, Gx0 and Bx0

RESX '1" W2 \M2=\Ml=wlk"0‘ CSX DBWDGDSDADSDZDWDOD8D7D6D5D4D3D2DIDUDEWDSDSDADSDZDWDO 50" C) ‘ @ﬂﬂ@ﬂﬂiiﬂﬂﬂﬂﬂﬂﬂllﬂﬂﬂﬂﬂﬂﬂi , men n \ ‘ Habns ‘ ‘ ‘ ‘ v Frame memory maimmezaznaa'slss

ST7735R

V0.2 53 2009-08-05

9.8.18 Write data for 18-bit/pixel (RGB 6-6-6-bit input), 262K-Colors, 3AH=“06h”

Note 1: Pixel data with the 18-bit color depth information

Note 2: The most significant bits are: Rx5, Gx5 and Bx5

Note 3: The least significant bits are: Rx0, Gx0 and Bx0

RESX "" |M2 CSX D/CX SDA SCL -r F68:"0‘, \wqwamk-‘o‘ mew n 0706050403920101307060504030szDoD7DstDADsDszo1 O@@@@@@@@@@@@@ "a @ﬁééaéﬁﬁﬁI men ml LDDk—Lp 'able for 4096 onlclr data mappmg (12 DIE lo 18 bits) yam; Frame memnw HIHHHEEIH

ST7735R

V0.2 54 2009-08-05

9.8.19 4-line serial Interface

Different display data formats are available for three colors depth supported by the LCM listed below.

4k colors, RGB 4-4-4-bit input

65k colors, RGB 5-6-5-bit input

262k colors, RGB 6-6-6-bit input

9.8.20 Write data for 12-bit/pixel (RGB 4-4-4-bit input), 4K-Colors, 3AH=“03h”

Note 1. pixel data with the 12-bit color depth information

Note 2. The most significant bits are: Rx3, Gx3 and Bx3

Note 3. The least significant bits are: Rx0, Gx0 and Bx0

RESX “1" M '11' Psasvx 1M2=1M1=IW"U‘ CSX D/CX 1 D7D6D5D4D3D2D1DOD7D5D5D4D3D2D1DOD7D6D5D4D3D2D1D01 8mQaaammaaaeaaaaeaaaaaaaaaa P1xeln P1xe1n+1 1 SCL \v15bﬂs 16bus Look-upheb‘e (or 65k color data mapping (15 bus lo 18 ms) 1 1 IE D1151 1 1 1 1 1 mee memo}; 7 7 R1G1B1R282Hm6333 RESX “" IM2 csx D/CX '1' D7D5D5DAD$DQDIDOD7D5D5DAD$D2D1D007D5D5D4D3D201Do 5mOﬂﬂﬂﬁﬂﬂllﬂaﬁ@QQQQQQQQQQQI P1xe1 n 1 1 1 lmbus 1 1 Frame memory R1G1B1R26252R36353

ST7735R

V0.2 55 2009-08-05

9.8.21 Write data for 16-bit/pixel (RGB 5-6-5-bit input), 65K-Colors, 3AH=“05h”

Note 1. pixel data with the 16-bit color depth information

Note 2. The most significant bits are: Rx4, Gx5 and Bx4

Note 3. The least significant bits are: Rx0, Gx0 and Bx0

9.8.22 Write data for 18-bit/pixel (RGB 6-6-6-bit input), 262K-Colors, 3AH=“06h”

Note 1. pixel data with the 18-bit color depth information

Note 2. The most significant bits are: Rx5, Gx5 and Bx5

Note 3. The least significant bits are: Rx0, Gx0 and Bx0

TFVLED panel (132x RGB x162) Dwm darn RAM (132 X16). X lS-bns) L1 nc add! us coumer Scan add! us coumer [\ICL ,, . W 4» LL I Ru .» Add! a» LOLHHL‘V Com mn add! us Hon interface counm I

ST7735R

V0.2 56 2009-08-05

9.9 Display Data RAM

9.9.1 Configuration (GM[1:0] = “00”)

The display module has an integrated 132x162x18-bit graphic type static RAM. This 384,912-bit memory allows storing

on-chip a 132xRGBx162 image with an 18-bpp resolution (262K-color). There will be no abnormal visible effect on the

display when there is a simultaneous Panel Read and Interface Read or Write to the same location of the Frame Memory.

Figure 9.9.1Display data RAM organization

ST7735R

V0.2 57 2009-08-05

9.9.2 Memory to Display Address Mapping

9.9.3 When using 128RGB x 160 resolution (GM[1:0] = “11”, SMX=SMY=SRGB= ‘0’)

--------

Gate Out

S7 S8 S9 S10 S11 S12 -------- S385 S386 S387 S388 S389 S390

MY=' 0 ' MY=' 1 ' ML=' 0 ' ML=' 1 '

2 0 159 R0 G0 B0 R1 G1 B1 -------- R126 G126 B126 R127 G127 B127 0 159

3 1 158 -------- 1 158

4 2 157 -------- 2 157

5 3 156 -------- 3 156

6 4 155 -------- 4 155

7 5 154 -------- 5 154

8 6 153 -------- 6 153

9 7 152 -------- 7 152

|

154 152 7 -------- 152 7

155 153 6 -------- 153 6

156 154 5 -------- 154 5

157 155 4 -------- 155 4

158 156 3 -------- 156 3

159 157 2 -------- 157 2

160 158 1 -------- 158 1

161 159 0 -------- 159 0

MX=' 0 ' --------

MX=' 1 ' --------

Pixel 1 Pixel 2 Pixel 127 Pixel 128

Source Out

RGB=0

RGB=1

RGB=0

RGB=1

RGB

Order

RGB=0

RGB=1

RGB=0

RGB=1

RA SA

CA 0 1 126 127

127 126 1 0

Note

RA = Row Address,

CA = Column Address

SA = Scan Address

MX = Mirror X-axis (Column address direction parameter), D6 parameter of MADCTL command

MY = Mirror Y-axis (Row address direction parameter), D7 parameter of MADCTL command

ML = Scan direction parameter, D4 parameter of MADCTL command

RGB = Red, Green and Blue pixel position change, D3 parameter of MADCTL command

1(11 RU ' ' R131 0131 15131 R132 (1132 15132 100 15‘? 15?; 157 150 155 15-1

ST7735R

V0.2 58 2009-08-05

9.9.4 When using 132RGB x 162 resolution (GM[1:0] = “00”, SMX=SMY=SRGB= ‘0’)

--------

Gate Out

S1 S2 S3 S4 S5 S6 -------- S391 S392 S393 S394 S395 S396

MY=' 0 ' MY=' 1 ' ML=' 0 ' ML=' 1 '

1 0 161 R0 G0 B0 R1 G1 B1 -------- R131 G131 B131 R132 G132 B132 0 161

2 1 160 -------- 1 160

3 2 159 -------- 2 159

4 3 158 -------- 3 158

5 4 157 -------- 4 157

6 5 156 -------- 5 156

7 6 155 -------- 6 155

8 7 154 -------- 7 154

|

155 154 7 -------- 154 7

156 155 6 -------- 155 6

157 156 5 -------- 156 5

158 157 4 -------- 157 4

159 158 3 -------- 158 3

160 159 2 -------- 159 2

161 160 1 -------- 160 1

162 161 0 -------- 161 0

MX=' 0 ' --------

MX=' 1 ' --------

Pixel 1 Pixel 2 Pixel 131 Pixel 132

Source Out

RGB=0

RGB=1

RGB=0

RGB=1

RGB

Order

RGB=0

RGB=1

RGB=0

RGB=1

RA SA

CA 0 1 130 131

131 130 1 0

Note

RA = Row Address,

CA = Column Address

SA = Scan Address

MX = Mirror X-axis (Column address direction parameter), D6 parameter of MADCTL command

MY = Mirror Y-axis (Row address direction parameter), D7 parameter of MADCTL command

ML = Scan direction parameter, D4 parameter of MADCTL command

RGB = Red, Green and Blue pixel position change, D3 parameter of MADCTL command

UH 9L

ST7735R

V0.2 59 2009-08-05

9.9.5 Normal Display On or Partial Mode On

9.9.6 When using 128RGB x 160 resolution (GM[1:0] = “11”)

In this mode, the content of the frame memory within an area where column pointer is 00h to 7Fh and page pointer is 00h to

9Fh is displayed. To display a dot on leftmost top corner, store the dot data at (column pointer, row pointer) = (0, 0).

1). Example for Normal Display On (MX=MY=ML=’0’, SMX=SMY=’0’)

2). Example for Partial Display On (PSL[7:0]=04h,PEL[7:0]=9Bh, MX=MV=ML=’0’ ,SMX=SMY=’0’)

128 Columns

00h 01h ---- ---- 76h 77h ---- 7Fh 83h

00h 00 01 0Y 0Z 1

01h 10 11 1Y 1Z 2

02h 20 21 2Y 2Z 3

| 30 31 3Y 3Z |

| 40 41 4Y 4Z |

| 50 51 5Y 5Z |

| 60 6Z |

| |

| X0 X1 X2 XX XY XZ 158

9Eh Y0 Y1 Y2 Y3 YW YX YY YZ 159

9Fh Z0 Z1 Z2 Z3 ZW ZX ZY ZZ 160

A0h

A1h

128 x 160 x18bit

Frame RAM

128 Columns

160 Lines

Display area =160 lines

Scan

Order

00 01 02 03 0W 0X 0Y 0Z G2

10 11 12 13 1W 1X 1Y 1Z G3

20 21 22 2X 2Y 2Z G4

30 31 32 3X 3Y 3Z |

40 41 42 4X 4Y 4Z |

50 51 5Y 5Z |

60 6Z |

|

S0 SZ |

U0 U1 UY UZ |

V0 V1 V2 VX VY VZ |

W0 W1 W2 WX WY WZ |

X0 X1 X2 XX XY XZ G159

Y0 Y1 Y2 Y3 YW YX YY YZ G160

Z0 Z1 Z2 Z3 ZW ZX ZY ZZ G161

128RGB x 160

LCD Panel

128 Columns

160 Lines

Scan

Order

00 01 02 03 0W 0X 0Y 0Z G2

10 11 12 13 1W 1X 1Y 1Z G3

20 21 22 2X 2Y 2Z G4

30 31 32 3X 3Y 3Z |

40 41 42 4X 4Y 4Z |

50 51 5Y 5Z |

60 6Z |

|

S0 SZ |

U0 U1 UY UZ |

V0 V1 V2 VX VY VZ |

W0 W1 W2 WX WY WZ |

X0 X1 X2 XX XY XZ G159

Y0 Y1 Y2 Y3 YW YX YY YZ G160

Z0 Z1 Z2 Z3 ZW ZX ZY ZZ G161

128RGB x 160

LCD Panel

Non-Display

area =4 lines

Display area

=152 lines

Non-Display

area =4 lines

00h 01h ---- ---- 76h 77h ---- 7Fh 83h

00h 00 01 0Y 0Z 1

01h 10 11 1Y 1Z 2

02h 20 21 2Y 2Z 3

| 30 31 3Y 3Z |

| 40 41 4Y 4Z |

| 50 51 5Y 5Z |

| 60 6Z |

| |

| U0 U1 UY UZ |

| V0 V1 VX VY VZ |

| W0 W1 W2 WX WY WZ |

| X0 X1 X2 XX XY XZ 158

9Eh Y0 Y1 Y2 Y3 YW YX YY YZ 159

9Fh Z0 Z1 Z2 Z3 ZW ZX ZY ZZ 160

A0h

A1h

128 x 160 x18bit

Frame RAM

mm m (3160 (3161 (3162

ST7735R

V0.2 60 2009-08-05

9.9.7 When using 132RGB x 162 resolution (GM[1:0] = “00”)

In this mode, contents of the frame memory within an area where column pointer is 00h to 83h and page pointer is 00h to

A1h is displayed. To display a dot on leftmost top corner, store the dot data at (column pointer, row pointer) = (0, 0)

1). Example for Normal Display On (MX=MY=ML=’0’, SMX=SMY=’0’)

2). Example for Partial Display On (PSL[7:0]=04h,PEL[7:0]=9Dh, MX=MV=ML=’0’ ,SMX=SMY=’0’)

132 Columns

00h 01h ---- ---- ---- ---- ---- 81h 83h

00h 00 01 02 03 0W 0X 0Y 0Z 1

01h 10 11 12 13 1W 1X 1Y 1Z 2

02h 20 21 22 2X 2Y 2Z 3

| 30 31 32 3X 3Y 3Z |

| 40 41 42 4X 4Y 4Z |

| 50 51 5Y 5Z |

| 60 6Z |

| |

| S0 SZ |

| U0 U1 UY UZ |

| V0 V1 V2 VX VY VZ |

| W0 W1 W2 WX WY WZ |

9Fh X0 X1 X2 XX XY XZ 160

A0h Y0 Y1 Y2 Y3 YW YX YY YZ 161

A1h Z0 Z1 Z2 Z3 ZW ZX ZY ZZ 162

132 x 162 x18 bit

Frame RAM

132 Columns

162 Lines

Display area =162 lines

Scan

Order

00 01 02 03 0W 0X 0Y 0Z G1

10 11 12 13 1W 1X 1Y 1Z G2

20 21 22 2X 2Y 2Z G3

30 31 32 3X 3Y 3Z |

40 41 42 4X 4Y 4Z |

50 51 5Y 5Z |

60 6Z |

|

S0 SZ |

U0 U1 UY UZ |

V 0 V 1 V 2 V X V Y V Z |

W0 W1 W 2 WX WY WZ |

X0 X1 X2 X X XY X Z

G160

Y0 Y 1 Y2 Y 3 YW YX YY YZ

G161

Z0 Z 1 Z2 Z 3 ZW ZX ZY ZZ

G162

132R G B x 162

132R G B x 162132R G B x 162

132R G B x 162

LC D Panel

LC D PanelLC D Panel

LC D Panel

132 Columns

00h 01h ---- ---- ---- ---- ---- 81h 83h

00h 00 01 02 03 0W 0X 0Y 0Z 1

01h 10 11 12 13 1W 1X 1Y 1Z 2

02h 20 21 22 2X 2Y 2Z 3

| 30 31 32 3X 3Y 3Z |

| 40 41 42 4X 4Y 4Z |

| 50 51 5Y 5Z |

| 60 6Z |

| |

| S0 SZ |

| U0 U1 UY UZ |

9Dh V0 V1 V2 VX VY VZ |

9Eh W0 W1 W2 WX WY WZ |

9Fh X0 X1 X2 XX XY XZ 160

A0h Y0 Y1 Y2 Y3 YW YX YY YZ 161

A1h Z0 Z1 Z2 Z3 ZW ZX ZY ZZ 162

132 x 162 x18 bit

Frame RAM

132 Columns

162 Lines

Scan

Order

00 01 02 03 0W 0X 0Y 0Z G1

10 11 12 13 1W 1X 1Y 1Z G2

20 21 22 2X 2Y 2Z G3

30 31 32 3X 3Y 3Z |

40 41 42 4X 4Y 4Z |

50 51 5Y 5Z |

60 6Z |

|

S0 SZ |

U0 U1 UY UZ |

V0 V1 V2 VX VY VZ |

W0 W1 W2 WX WY WZ |

X0 X1 X2 XX XY XZ G160

Y0 Y1 Y2 Y3 YW YX YY YZ G161

Z0 Z1 Z2 Z3 ZW ZX ZY ZZ G162

132RGB x 162

LCD Panel

Non-Displa

y area =4

lines

Display

area =155

lines

Non-Displa

y area

=4lines

ST7735R

V0.2 61 2009-08-05

9.10 Address Counter

The address counter sets the addresses of the display data RAM for writing and reading.

Data is written pixel-wise into the RAM matrix of DRIVER. The data for one pixel or two pixels is collected (RGB 6-6-6-bit),

according to the data formats. As soon as this pixel-data information is complete the “Write access” is activated on the RAM.

The locations of RAM are addressed by the address pointers. The address ranges are X=0 to X=131 (83h) and Y=0 to

Y=161 (A1h). Addresses outside these ranges are not allowed. Before writing to the RAM, a window must be defined that

will be written. The window is programmable via the command registers XS, YS designating the start address and XE, YE

designating the end address.

For example the whole display contents will be written, the window is defined by the following values: XS=0 (0h) YS=0 (0h)

and XE=127 (83h), YE=161 (A1h).

In vertical addressing mode (MV=1), the Y-address increments after each byte, after the last Y-address (Y=YE), Y wraps

around to YS and X increments to address the next column. In horizontal addressing mode (V=0), the X-address

increments after each byte, after the last X-address (X=XE), X wraps around to XS and Y increments to address the next

row. After the every last address (X=XE and Y=YE) the address pointers wrap around to address (X=XS and Y=YS).

For flexibility in handling a wide variety of display architectures, the commands “CASET, RASET and MADCTL” (see

section 10 command list), define flags MX and MY, which allows mirroring of the X-address and Y-address. All combinations

of flags are allowed. Section 9.10 show the available combinations of writing to the display RAM. When MX, MY and MV will

be changed the data bust be rewritten to the display RAM.

For each image condition, the controls for the column and row counters apply as section 9.11 below

Condition Column Counter Row Counter

When RAMWR/RAMRD command is accepted Return to

“Start Column (XS)”

Return to

“Start Row (YS)”

Complete Pixel Read / Write action Increment by 1 No change

The Column counter value is larger than “End Column (XE)” Return to

“Start Column (XS)” Increment by 1

The Column counter value is larger than “End Column (XE)” and the Row

counter value is larger than “End Row (YE)”

Return to

“Start Column (XS)”

Return to

“Start Row (YS)”

D17 D16 D15 D14 D13 D12 D11 D10 DQ D8 D7 D5 B5 D3 D’Z D1 D0 B3 B2 B1 B0 88‘ E?

ST7735R

V0.2 62 2009-08-05

9.11 Memory Data Write/ Read Direction

The data is written in the order illustrated above. The Counter which dictates where in the physical memory the data is to be

written is controlled by “Memory Data Access Control” Command, bits B5 (MV), B6 (MX), B7 (MY) as described below.

Figure 9.11.1Data streaming order

9.11.1 When 128RGBx160 (GM= “11”)

MV

MX

MY

CASET RASET

0 0 0 Direct to Physical Column Pointer Direct to Physical Row Pointer

0 0 1 Direct to Physical Column Pointer Direct to (159-Physical Row Pointer)

0 1 0 Direct to (127-Physical Column Pointer) Direct to Physical Row Pointer

0 1 1 Direct to (127-Physical Column Pointer) Direct to (159-Physical Row Pointer)

1 0 0 Direct to Physical Row Pointer Direct to Physical Column Pointer

1 0 1 Direct to (159-Physical Row Pointer) Direct to Physical Column Pointer

1 1 0 Direct to Physical Row Pointer Direct to (127-Physical Column Pointer)

1 1 1 Direct to (159-Physical Row Pointer) Direct to (127-Physical Column Pointer)

9.11.2 When 132RGBx162 (GM= “00”)

MV

MX

MY

CASET RASET

0 0 0 Direct to Physical Column Pointer Direct to Physical Row Pointer

0 0 1 Direct to Physical Column Pointer Direct to (161-Physical Row Pointer)

0 1 0 Direct to (131-Physical Column Pointer) Direct to Physical Row Pointer

0 1 1 Direct to (131-Physical Column Pointer) Direct to (161-Physical Row Pointer)

1 0 0 Direct to Physical Row Pointer Direct to Physical Column Pointer

1 0 1 Direct to (161-Physical Row Pointer) Direct to Physical Column Pointer

1 1 0 Direct to Physical Row Pointer Direct to (131-Physical Column Pointer)

1 1 1 Direct to (161-Physical Row Pointer) Direct to (131-Physical Column Pointer)

Note: Data is always written to the Frame Memory in the same order, regardless of the Memory Write Direction set by MADCTL bits B7

(MY), B6 (MX), B5 (MV). The write order for each pixel unit is

One pixel unit represents 1 column and 1page counter value on the Frame Memory.

Panel

m m m m m w w w g $ $ $ m m m m a a a a a a a a a .4 .4 a v. v. y. X X X E a E ““““““ 3T “““““ vA “““““ a r , ““““““ 4 “““““ , , A ““““““ + H , _H , , , , W H— , , , A ““““““ H , ““““““ v4 “““““ ‘ ¢ 5 A “““““ ﬁa ““““““ .755 ““““““ mm; W mm mm mm m mm m mu, m om m mo w om w ns n n ms m gm m mg m gm m we m mu m mm m mm m on as o d a do 5 pm m «w p mm p mp w my m wm w my. m vm m HX H XH H HX H XH H ,E 37777777,,» 7» $77,777,".

ST7735R

V0.2 63 2009-08-05

9.11.3 Frame Data Write Direction According to the MADCTL parameters (MV, MX and MY)

MADCTL

Parameter

Display Data

Direction MV

MX

MY

Image in the Host

(MPU) Image in the Driver

(DDRAM)

Normal 0 0 0

Y-Mirror 0 0 1

X-Mirror 0 1 0

X-Mirror

Y-Mirror 0 1 1

X-Y Exchange 1 0 0

X-Y Exchange

Y-Mirror 1 0 1

X-Y Exchange

X-Mirror 1 1 0

X-Y Exchange

X-Mirror

Y-Mirror 1 1 1

1 Tm 1 Tm 1 ﬁ—w—H Venical ximing scale / \ 1 21 \ 1 Thdl Than 1H1 1 1 1 1 Vertical liming scale W 1 ‘ 1 ‘V-syn 1 1 1 1 1l >1 — _ _ l 1 1 Invisible 15‘ 2"“ 161‘" 162‘h line line line line line ‘ 1 Bottom 1inc 1 1 1 Top lmc 1 1 1 1 1 1 2nd linc 1 1 1 1 1- I7 I7 TI TI iLLIULHJL .,..,1LLLLL|L1L1L 11, model T111.

ST7735R

V0.2 64 2009-08-05

9.12 Tearing Effect Output Line

The Tearing Effect output line supplies to the MPU a Panel synchronization signal. This signal can be enabled or disabled

by the Tearing Effect Line Off & On commands. The mode of the Tearing Effect signal is defined by the parameter of the

Tearing Effect Line On command. The signal can be used by the MPU to synchronize Frame Memory Writing when

displaying video images.

9.12.1 Tearing Effect Line Modes

Mode 1, the Tearing Effect Output signal consists of V-Blanking Information only:

tvdh= The LCD display is not updated from the Frame Memory

tvdl= The LCD display is updated from the Frame Memory (except Invisible Line – see above)

Mode 2, the Tearing Effect Output signal consists of V-Blanking and H-Blanking Information, there is one V-sync and 162

H-sync pulses per field.

thdh= The LCD display is not updated from the Frame Memory

thdl= The LCD display is updated from the Frame Memory (except Invisible Line – see above)

Note: During Sleep In Mode, the Tearing Output Pin is active Low.

| Tvdl ‘ Tvd h . r—u \ : Vertical \ 1 I | \ \ | | | Horizontal ‘ ‘ V} )Hd).8““VDDI Vm :().2">'\/DDI ;! i "F i

ST7735R

V0.2 65 2009-08-05

9.12.2 Tearing Effect Line Timings

The Tearing Effect signal is described below:

Table 9.12.1 AC characteristics of Tearing Effect Signal Idle Mode Off (Frame Rate = 60 Hz, Ta=25°C)

Note: The timings in Table 9.10.1 apply when MADCTL ML=0 and ML=1

The signal’s rise and fall times (tf, tr) are stipulated to be equal to or less than 15ns.

The Tearing Effect Output Line is fed back to the MPU and should be used as shown below to avoid Tearing Effect:

Symbol Parameter min max unit description

tvdl Vertical Timing Low Duration 13 - ms

tvdh Vertical Timing High Duration 1000 - µs

thdl Horizontal Timing Low Duration 33 - µs

thdh Horizontal Timing Low Duration 25 500 µs

.\I('I ' In ‘Wr‘mwu TEU._1pu, >1ng v In LCD [mugs (m LCD Data to be sent Image on LCD 1* 162" mm- mm- mm- 14 my c d II

ST7735R

V0.2 66 2009-08-05

9.12.3 Example 1: MPU Write is faster than panel read

Data write to Frame Memory is now synchronized to the Panel Scan. It should be written during the vertical sync pulse of

the Tearing Effect Output Line. This ensures that data is always written ahead of the panel scan and each Panel Frame

refresh has a complete new image:

mu m memm'} TE nquuI 5mm Mfmoly to LCD Image on LCD Data to be sent Image on LCD i l“ 1 02”“ ume ume a W 1 52“ C d ume

ST7735R

V0.2 67 2009-08-05

9.12.4 Example 2: MPU write is slower than panel read

The MPU to Frame Memory write begins just after Panel Read has commenced i.e. after one horizontal sync pulse of the

Tearing Effect Output Line. This allows time for the image to download behind the Panel Read pointer and finishing

download during the subsequent Frame before the Read Pointer “catches” the MPU to Frame memory write position.

B

ST7735R

V0.2 68 2009-08-05

9.13 Power ON/OFF Sequence

VDD must be powered on before the VDDI.

VDDI must be powered off before the VDD.

During power off, if LCD is in the Sleep Out mode, VDD and VDDI must be powered down minimum 120msec after RESX

has been released.

During power off, if LCD is in the Sleep In mode, VDDI or VDD can be powered down minimum 0msec after RESX has

been released.

CSX can be applied at any timing or can be permanently grounded. RESX has priority over CSX.

Note 1: There will be no damage to the display module if the power sequences are not met.

Note 2: There will be no abnormal visible effects on the display panel during the Power On/Off Sequences.

Note 3: There will be no abnormal visible effects on the display between end of Power On Sequence and before receiving Sleep Out

command. Also between receiving Sleep In command and Power Off Sequence.

Note 4: If RESX line is not held stable by host during Power On Sequence as defined in the sequence below, then it will be necessary to

apply a Hardware Reset (RESX) after Host Power On Sequence is complete to ensure correct operation. Otherwise function is not

guaranteed.

The power on/off sequence is illustrated below

Timing when the latter signal rises up to 90% of its typical value.

e.g. When VDD comes later, this timing is defined at the cross

point of 90% of 2.75V, not 90% of 2.6V.

Timing when the latter signal falls up to 90% of its typical value.

e.g. When VDD comes later, this timing is defined at the cross

point of 90% of 2.75V, not 90% of 2.6V.

H or L

TrPW-CSX = +/- no limit TfPW-CSX = +/- no limit

30%

TrPW-RESX = + no limit

TfPW-RESX1 = min

120ms

TfPW-RESX2 = min 0ms

TfPW-RESx1 is applied to RESX falling in the Sleep Out Mode.

TfPW-RESx2 is applied to RESX falling in the Sleep In Mode.

VDD

VDDI

CSX

RESX

(Power down in

sleep-out mode)

RESX

(Power down in

sleep-in mode)

TrPW  0ns TfPW  0ns

9.13.1 Uncontrolled Power Off

The uncontrolled power-off means a situation which removed a battery without the controlled power off sequence. It will

neither damage the module or the host interface.

If uncontrolled power-off happened, the display will go blank and there will not any visible effect on the display (blank

display) and remains blank until “Power On Sequence” powers it up.

ST7735R

V0.2 69 2009-08-05

9.14 Power Level Definition

9.14.1 Power Level

6 level modes are defined they are in order of Maximum Power consumption to Minimum Power Consumption

1. Normal Mode On (full display), Idle Mode Off, Sleep Out.

In this mode, the display is able to show maximum 262,144 colors.

2. Partial Mode On, Idle Mode Off, Sleep Out.

In this mode part of the display is used with maximum 262,144 colors.

3. Normal Mode On (full display), Idle Mode On, Sleep Out.

In this mode, the full display area is used but with 8 colors.

4. Partial Mode On, Idle Mode On, Sleep Out.

In this mode, part of the display is used but with 8 colors.

5. Sleep In Mode

In this mode, the DC: DC converter, internal oscillator and panel driver circuit are stopped. Only the MCU interface and

memory works with VDDI power supply. Contents of the memory are safe.

6. Power Off Mode

In this mode, both VDD and VDDI are removed.

Note: Transition between modes 1-5 is controllable by MCU commands. Mode 6 is entered only when both Power supplies are removed.

Sleep out Sleep in

ST7735R

V0.2 70 2009-08-05

9.14.2 Power Flow Chart

Sleep out

Normal display mode on

Idle mode off

Sleep in

Normal display mode on

Idle mode off

Sleep out

Normal display mode on

Idle mode on

Sleep in

Normal display mode on

Idle mode on

Sleep out

Partial display mode on

Idle mode off

Sleep in

Partial display mode on

Idle mode off

Sleep out

Partial display mode on

Idle mode on

Sleep in

Partial display mode on

Idle mode on

SLP IN

SLP OUT

IDM ON IDM OFF

PTL ON

NOR ON

PTL ON

NOR ON

IDM ON IDM OFF

PTL ON

NOR ON

PTL ON

NOR ON

IDM ON IDM OFF

Power on sequence

HW reset

SW reset

Normal display mode on = NOR ON

Partial display mode on = PTL ON

Idle mode off = IDM OFF

Idle mode on = IDM ON

Sleep out = SLP OUT

Sleep in = SLP IN

ST7735R

V0.2 71 2009-08-05

9.15 Reset Table

9.15.1 Reset Table (Default Value, GM[1:0]=“11”, 128RGB x 160)

Item After Power On After H/W Reset After S/W Reset

Frame memory Random No Change No Change

Sleep In/Out In In In

Display On/Off Off Off Off

Display mode (normal/partial) Normal Normal Normal

Display Inversion On/Off Off Off Off

Display Idle Mode On/Off Off Off Off

Column: Start Address (XS) 0000h 0000h 0000h

Column: End Address (XE) 007Fh 007Fh 007Fh (127d) (when MV=0)

009Fh (159d) (when MV=1)

Row: Start Address (YS) 0000h 0000h 0000h

Row: End Address (YE) 009Fh 009Fh 009Fh (159d) (when MV=0)

007Fh (127d) (when MV=1)

Gamma setting GC0 GC0 GC0

RGB for 4k and 65k Color Mode Random values Random values No Change

Partial: Start Address (PSL) 0000h 0000h 0000h

Partial: End Address (PEL) 009Fh 009Fh 009Fh

Tearing: On/Off Off Off Off

Tearing Effect Mode (*1) 0 (Mode1) 0 (Mode1) 0 (Mode1)

Memory Data Access Control (MY/MX/MV/ML/RGB) 0/0/0/0/0 0/0/0/0/0 No Change

Interface Pixel Color Format 6 (18-Bit/Pixel) 6 (18-Bit/Pixel) No Change

RDDPM 08h 08h 08h

RDDMADCTL 00h 00h No Change

RDDCOLMOD 6 (18-Bit/Pixel) 6 (18-Bit/Pixel) No Change

RDDIM 00h 00h 00h

RDDSM 00h 00h 00h

ID2 NV value NV value NV value

ID3 NV value NV value NV value

Note: TE Mode 1 means Tearing Effect Output Line consists of V-Blanking Information only

ST7735R

V0.2 72 2009-08-05

9.15.2 Reset Table (GM[1:0]= “00”, 132RGB x 162)

Item After Power On After H/W Reset After S/W Reset

Frame memory Random No Change No Change

Sleep In/Out In In In

Display On/Off Off Off Off

Display mode (normal/partial) Normal Normal Normal

Display Inversion On/Off Off Off Off

Display Idle Mode On/Off Off Off Off

Column: Start Address (XS) 0000h 0000h 0000h

Column: End Address (XE) 0083h 0083h 0083h (131d) (when MV=0)

00A1h (161d) (when MV=1)

Row: Start Address (YS) 0000h 0000h 0000h

Row: End Address (YE) 00A1h 00A1h 00A1h (161d) (when MV=0)

0083h (131d) (when MV=1)

Gamma setting GC0 GC0 GC0

RGB for 4k and 65k Color Mode Random values Random values No Change

Partial: Start Address (PSL) 0000h 0000h 0000h

Partial: End Address (PEL) 00A1h 00A1h 00A1h

Tearing: On/Off Off Off Off

Tearing Effect Mode (*1) 0 (Mode1) 0 (Mode1) 0 (Mode1)

Memory Data Access Control (MY/MX/MV/ML/RGB) 0/0/0/0/0 0/0/0/0/0 No Change

Interface Pixel Color Format 6 (18-Bit/Pixel) 6 (18-Bit/Pixel) No Change

RDDPM 08h 08h 08h

RDDMADCTL 00h 00h No Change

RDDCOLMOD 6 (18-Bit/Pixel) 6 (18-Bit/Pixel) No Change

RDDIM 00h 00h 00h

RDDSM 00h 00h 00h

ID2 NV value NV value NV value

ID3 NV value NV value NV value

Note: TE Mode 1 means Tearing Effect Output Line consists of V-Blanking Information only

ST7735R

V0.2 73 2009-08-05

9.16 Module Input/Output Pins

9.16.1 Output or Bi-directional (I/O) Pins

Note: There will be no output from D7-D0 during Power On/Off sequence, Hardware Reset and Software Reset.

Output or Bi-directional pins After Power On After Hardware Reset After Software Reset

TE Low Low Low

D7 to D0 (Output driver) High-Z (Inactive) High-Z (Inactive) High-Z (Inactive)

Input pins During Power

On Process After Power On After Hardware

Reset After Software

Reset During Power

Off Process

RESX See 9.14 Input valid Input valid Input valid See 9.14

CSX Input invalid Input valid Input valid Input valid Input invalid

D/CX Input invalid Input valid Input valid Input valid Input invalid

WRX Input invalid Input valid Input valid Input valid Input invalid

RDX Input invalid Input valid Input valid Input valid Input invalid

D7 to D0 Input invalid Input valid Input valid Input valid Input invalid

Shorter than Sus 1 TRESY ‘—“ Ini‘ial s‘atus Normal operation X Reseﬂing X: (Deigﬁ'ﬁkgfﬂwgseo ‘ RESX Pulse Resel u accepled 1m 2011‘: mm posmz'e 5pm \ull be nelecled

ST7735R

V0.2 74 2009-08-05

9.17 Reset Timing

Related Pins Symbol Parameter MIN MAX Unit

tRESW Reset pulse duration 10 - us

- 5 ms

RESX tREST Reset cancel 120 ms

Table 9.17.1 Reset timing

Notes:

1. The reset cancel includes also required time for loading ID bytes, VCOM setting and other settings from NVM (or similar

device) to registers. This loading is done every time when there is HW reset cancel time (tRT) within 5 ms after a rising

edge of RESX.

2. Spike due to an electrostatic discharge on RESX line does not cause irregular system reset according to the table below:

RESX Pulse Action

Shorter than 5us Reset Rejected

Longer than 9us Reset

Between 5us and 9us Reset starts

3. During the Resetting period, the display will be blanked (The display is entering blanking sequence, which maximum time

is 120 ms, when Reset Starts in Sleep Out –mode. The display remains the blank state in Sleep In -mode.) and then return

to Default condition for Hardware Reset.

4. Spike Rejection also applies during a valid reset pulse as shown below:

5. When Reset applied during Sleep In Mode.

6. When Reset applied during Sleep Out Mode.

7. It is necessary to wait 5msec after releasing RESX before sending commands. Also Sleep Out command cannot be sent

for 120msec.

ST7735R

V0.2 75 2009-08-05

9.18 Color Depth Conversion Look Up Tables

9.18.1 65536 Color to 262,144 Color

Look Up Table Input Data

Color Look Up Table Output

Frame Memory Data (6-bits) RGBSET

Parameter 65k Color (5-bits)

R005 R004 R003 R002 R001 R000 1 00000

R015 R014 R013 R012 R011 R010 2 00001

R025 R024 R023 R022 R021 R020 3 00010

R035 R034 R033 R032 R031 R030 4 00011

R045 R044 R043 R042 R041 R040 5 00100

R055 R054 R053 R052 R051 R050 6 00101

R065 R064 R063 R062 R061 R060 7 00110

R075 R074 R073 R072 R071 R070 8 00111

R085 R084 R083 R082 R081 R080 9 01000

R095 R094 R093 R092 R091 R090 10 01001

R105 R104 R103 R102 R101 R100 11 01010

R115 R114 R113 R112 R111 R110 12 01011

R125 R124 R123 R122 R121 R120 13 01100

R135 R134 R133 R132 R131 R130 14 01101

R145 R144 R143 R142 R141 R140 15 01110

R155 R154 R153 R152 R151 R150 16 01111

R165 R164 R163 R162 R161 R160 17 10000

R175 R174 R173 R172 R171 R170 18 10001

R185 R184 R183 R182 R181 R180 19 10010

R195 R194 R193 R192 R191 R190 20 10011

R205 R204 R203 R202 R201 R200 21 10100

R215 R214 R213 R212 R211 R210 22 10101

R225 R224 R223 R222 R221 R220 23 10110

R235 R234 R233 R232 R231 R230 24 10111

R245 R244 R243 R242 R241 R240 25 11000

R255 R254 R253 R252 R251 R250 26 11001

R265 R264 R263 R262 R261 R260 27 11010

R275 R274 R273 R272 R271 R270 28 11011

R285 R284 R283 R282 R281 R280 29 11100

R295 R294 R293 R292 R291 R290 30 11101

R305 R304 R303 R302 R301 R300 31 11110

RED

R315 R314 R313 R312 R311 R310 32 11111

Look Up Table Input Data

Color Look Up Table Output

Frame Memory Data (6-bits) RGBSET

Parameter 65k Color (5-bits)

G005 G004 G003 G002 G001 G000 33 000000

G015 G014 G013 G012 G011 G010 34 000001

G025 G024 G023 G022 G021 G020 35 000010

G035 G034 G033 G032 G031 G030 36 000011

G045 G044 G043 G042 G041 G040 37 000100

G055 G054 G053 G052 G051 G050 38 000101

G065 G064 G063 G062 G061 G060 39 000110

G075 G074 G073 G072 G071 G070 40 000111

G085 G084 G083 G082 G081 G080 41 001000

G095 G094 G093 G092 G091 G090 42 001001

G105 G104 G103 G102 G101 G100 43 001010

G115 G114 G113 G112 G111 G110 44 001011

G125 G124 G123 G122 G121 G120 45 001100

G135 G134 G133 G132 G131 G130 46 001101

G145 G144 G143 G142 G141 G140 47 001110

G155 G154 G153 G152 G151 G150 48 001111

G165 G164 G163 G162 G161 G160 49 010000

G175 G174 G173 G172 G171 G170 50 010001

G185 G184 G183 G182 G181 G180 51 010010

G195 G194 G193 G192 G191 G190 52 010011

GREEN

G205 G204 G203 G202 G201 G200 53 010100

G215G21AG21SG21262116210 010101

ST7735R

V0.2 76 2009-08-05

G215 G214 G213 G212 G211 G210 54 010101

G225 G224 G223 G222 G221 G220 55 010110

G235 G234 G233 G232 G231 G230 56 010111

G245 G244 G243 G242 G241 G240 57 011000

G255 G254 G253 G252 G251 G250 58 011001

G265 G264 G263 G262 G261 G260 59 011010

G275 G 274 G273 G272 G271 G270 60 011011

G285 G 284 G283 G282 G281 G280 61 011100

G295 G 294 G293 G292 G291 G290 62 011101

G305 G 304 G303 G302 G301 G300 63 011110

G315 G 314 G313 G312 G311 G310 64 011111

G325 G324 G323 G322 G321 G320 65 100000

G335 G334 G333 G332 G331 G330 66 100001

G345 G344 G343 G342 G341 G340 67 100010

G355 G354 G353 G352 G351 G350 68 100011

G365 G364 G363 G362 G361 G360 69 100100

G375 G374 G373 G372 G371 G370 70 100101

G385 G384 G383 G382 G381 G380 71 100110

G395 G394 G393 G392 G391 G390 72 100111

G405 G404 G403 G402 G401 G400 73 101000

G415 G414 G413 G412 G411 G410 74 101001

G425 G424 G423 G422 G421 G420 75 101010

G435 G434 G433 G432 G431 G430 76 101011

G445 G444 G443 G442 G441 G440 77 101100

G455 G454 G453 G452 G451 G450 78 101101

G465 G464 G463 G462 G461 G460 79 101110

G475 G474 G473 G472 G471 G470 80 101111

G485 G484 G483 G482 G481 G480 81 110000

G495 G494 G493 G492 G491 G490 82 110001

G505 G504 G503 G502 G501 G500 83 110010

G515 G514 G513 G512 G511 G510 84 110011

G525 G524 G523 G522 G521 G520 85 110100

G535 G534 G533 G532 G531 G530 86 110101

G545 G544 G543 G542 G541 G540 87 110110

G555 G554 G553 G552 G551 G550 88 110111

G565 G564 G563 G562 G561 G560 89 111000

G575 G574 G573 G572 G571 G570 90 111001

G585 G584 G583 G582 G581 G580 91 111010

G595 G594 G593 G592 G591 G590 92 111011

G605 G604 G603 G602 G601 G600 93 111100

G615 G614 G613 G612 G611 G610 94 111101

G625 G624 G623 G622 G621 G620 95 111110

G635 G634 G633 G632 G631 G630 96 111111

Look Up Table Input Data

Color Look Up Table Output

Frame Memory Data (6-bits) RGBSET

Parameter 65k Color (5-bits)

B005 B004 B003 B002 B001 B000 97 00000

B015 B014 B013 B012 B011 B010 98 00001

B025 B024 B023 B022 B021 B020 99 00010

B035 B034 B033 B032 B031 B030 100 00011

B045 B044 B043 B042 B041 B040 101 00100

B055 B054 B053 B052 B051 B050 102 00101

B065 B064 B063 B062 B061 B060 103 00110

B075 B074 B073 B072 B071 B070 104 00111

B085 B084 B083 B082 B081 B080 105 01000

B095 B094 B093 B092 B091 B090 106 01001

B105 B104 B103 B102 B101 B100 107 01010

B115 B114 B113 B112 B111 B110 108 01011

B125 B124 B123 B122 B121 B120 109 01100

B135 B134 B133 B132 B131 B130 110 01101

B145 B144 B143 B142 B141 B140 111 01110

B155 B154 B153 B152 B151 B150 112 01111

BLUE

B165 B164 B163 B162 B161 B160 113 10000

ST7735R

V0.2 77 2009-08-05

B175 B174 B173 B172 B171 B170 114 10001

B185 B184 B183 B182 B181 B180 115 10010

B195 B194 B193 B192 B191 B190 116 10011

B205 B204 B203 B202 B201 B200 117 10100

B215 B214 B213 B212 B211 B210 118 10101

B225 B224 B223 B222 B221 B220 119 10110

B235 B234 B233 B232 B231 B230 120 10111

B245 B244 B243 B242 B241 B240 121 11000

B255 B254 B253 B252 B251 B250 122 11001

B265 B264 B263 B262 B261 B260 123 11010

B275 B274 B273 B272 B271 B270 124 11011

B285 B284 B283 B282 B281 B280 125 11100

B295 B294 B293 B292 B291 B290 126 11101

B305 B304 B303 B302 B301 B300 127 11110

B315 B314 B313 B312 B311 B310 128 11111

ST7735R

V0.2 78 2009-08-05

9.18.2 4096 Color to 262,144 Color

Look Up Table Input Data

Color Look Up Table Output

Frame Memory Data (6-bits) RGBSET

Parameter 4k Color (4-bits)

R005 R004 R003 R002 R001 R000 1 0000

R015 R014 R013 R012 R011 R010 2 0001

R025 R024 R023 R022 R021 R020 3 0010

R035 R034 R033 R032 R031 R030 4 0011

R045 R044 R043 R042 R041 R040 5 0100

R055 R054 R053 R052 R051 R050 6 0101

R065 R064 R063 R062 R061 R060 7 0110

R075 R074 R073 R072 R071 R070 8 0111

R085 R084 R083 R082 R081 R080 9 1000

R095 R094 R093 R092 R091 R090 10 1001

R105 R104 R103 R102 R101 R100 11 1010

R115 R114 R113 R112 R111 R110 12 1011

R125 R124 R123 R122 R121 R120 13 1100

R135 R134 R133 R132 R131 R130 14 1101

R145 R144 R143 R142 R141 R140 15 1110

R155 R154 R153 R152 R151 R150 16 1111

R165 R164 R163 R162 R161 R160 17

| |

RED

R315 R314 R313 R312 R311 R310 32

Not used

G005 G004 G003 G002 G001 G000 33 0000

G015 G014 G013 G012 G011 G010 34 0001

G025 G024 G023 G022 G021 G020 35 0010

G035 G034 G033 G032 G031 G030 36 0011

G045 G044 G043 G042 G041 G040 37 0100

G055 G054 G053 G052 G051 G050 38 0101

G065 G064 G063 G062 G061 G060 39 0110

G075 G074 G073 G072 G071 G070 40 0111

G085 G084 G083 G082 G081 G080 41 1000

G095 G094 G093 G092 G091 G090 42 1001

G105 G104 G103 G102 G101 G100 43 1010

G115 G114 G113 G112 G111 G110 44 1011

G125 G124 G123 G122 G121 G120 45 1100

G135 G134 G133 G132 G131 G130 46 1101

G145 G144 G143 G142 G141 G140 47 1110

G155 G154 G153 G152 G151 G150 48 1111

G165 G164 G163 G162 G161 G160 49

| |

GREEN

G635 G634 G633 G632 G631 G630 96

Not used

B005 B004 B003 B002 B001 B000 97 0000

B015 B014 B013 B012 B011 B010 98 0001

B025 B024 B023 B022 B021 B020 99 0010

B035 B034 B033 B032 B031 B030 100 0011

B045 B044 B043 B042 B041 B040 101 0100

B055 B054 B053 B052 B051 B050 102 0101

B065 B064 B063 B062 B061 B060 103 0110

B075 B074 B073 B072 B071 B070 104 0111

B085 B084 B083 B082 B081 B080 105 1000

B095 B094 B093 B092 B091 B090 106 1001

B105 B104 B103 B102 B101 B100 107 1010

B115 B114 B113 B112 B111 B110 108 1011

B125 B124 B123 B122 B121 B120 109 1100

B135 B134 B133 B132 B131 B130 110 1101

B145 B144 B143 B142 B141 B140 111 1110

B155 B154 B153 B152 B151 B150 112 1111

B165 B164 B163 B162 B161 B160 113

| |

BLUE

B315 B314 B313 B312 B311 B310 128

Not used

ON DMON L a eramn «ware reset ead Drs \a ID umm read D1 read D2 read D3 read ead Drs \a Status umm read DMON LO 0N umm read 0N ead Drs \a umm read ead Drs \a umm read ead Drs \a umm read ead Drs \a umm read

ST7735R

V0.2 79 2009-08-05

10 Command

10.1 System function Command List and Description

Table 10.1.1 System Function command List (1)

Instruction

Refer

D/CX

WRX

RDX

D17-8

D7 D6

D5

D4 D3 D2

D1

D0 Hex

Function

NOP 10.1.1

0

↑

1

- 0 0 0 0 0 0 0 0 (00h)

No Operation

SWRESET

10.1.2

0

↑

1

- 0 0 0 0 0 0 0 1 (01h)

Software reset

0

↑

1

- 0 0 0 0 0 1 0 0 (04h)

Read Display ID

1

↑

- - - - - - - - -

Dummy read

1

↑

- ID17

ID16

ID15

ID14

ID13

ID12

ID11

ID10

ID1 read

1

↑

- 1 ID26

ID25

ID24

ID23

ID22

ID21

ID20

ID2 read

RDDID

10.1.3

1

↑

- ID37

ID36

ID35

ID34

ID33

ID32

ID31

ID30

I

D3 read

0

↑

1

- 0 0 0 0 1 0 0 1 (09h)

Read Display Status

1

↑

- - - - - - - - -

Dummy read

1

↑

- BSTON

MY

MX

MV ML RGB

MH

ST24

-

1

↑

- ST23

IFPF2

IFPF1

IFPF0

IDMON

PTLON

SLOUT

NORON

-

1

↑

- VSSON

ST14

INVON

ST12

ST11

DISON

TEON

GCS2

-

RDDST

10.1.4

1

↑

- GCS1

GCS0

TEM

ST4 ST3

ST2

ST1

ST0

-

0

↑

1

- 0 0 0 0 1 0 1 0 (0Ah)

Read Display Power

1

↑

- - - - - - - - -

Dummy

read

RDDPM

10.1.5

1

↑

- BSTON

IDMON

PTLON

SLPOUT

NORON

DISON

- -

-

0

↑

1

- 0 0 0 0 1 0 1 1 (0Bh)

Read Display

1

↑

- - - - - - - - -

Dummy read

RDD

MADCTL

10.1.6

1

↑

- MY

MX

MV

ML RGB

MH

- -

-

0

↑

1

- 0 0 0 0 1 1 0 0 (0Ch)

Read Display Pixel

1

↑

- - - - - - - - -

Dummy read

RDD

COLMOD

10.1.7

1

↑

- 0 0 0 0 - IFPF2

IFPF1

IFPF0

-

0

↑

1

- 0 0 0 0 1 1 0 1 (0Dh)

Read Display Image

1

↑

- - - - - - - - -

Dummy read

RDDIM

10.1.8

1

↑

- VSSON

D6

INVON

- - GCS2

GCS1

GCS0

-

0

↑

1

- 0 0 0 0 1 1 1 0 (0Eh)

Read Display Signal

1

↑

- - - - - - - - -

Dummy read

RDDSM

10.1.9

1

↑

- TEON

TEM

- - - - - -

-

“-“: Don’t care

D1 R002 R001 R000 (5003 G002 6001 G000 S‘ee m K booster on See out & hamster an Pama‘ mode on Pama‘ a" N0rma‘ Us a mverswdn 0" Us a mverswdn 0n Gamma curve se‘ect Us a 0" Us a an Column address set Row address set Memo wnte Wnte data LUT ldr 4k 65 262k com! Red (one 0 Red (one "a" Green tone 0 Green (one "D" B‘ue tune O B‘ue tune "0" Memo read Dumm read Read data

ST7735R

V0.2 80 2009-08-05

Table 10.1.2 System Function command List (2)

Instructio Refer

D/C WR RDX

D17- D7

D6

D5

D4

D3

D2

D1

D0

Hex

Function

SLPIN 10.1.10

0 ↑ 1

- 0 0 0 1 0 0 0 0 (10h)

Sleep in & booster off

SLPOUT

10.1.11

0 ↑ 1

- 0 0 0 1 0 0 0 1 (11h)

Sleep out & booster on

PTLON

10.1.12

0 ↑ 1

- 0 0 0 1 0 0 1 0 (12h)

Partial mode on

NORON

10.1.13

0 ↑ 1

- 0 0 0 1 0 0 1 1 (13h)

Partial off (Normal)

INVOFF

10.1.14

0 ↑ 1

- 0 0 1 0 0 0 0 0 (20h)

Display inversion off

INVON

10.1.15

0 ↑ 1

- 0 0 1 0 0 0 0 1 (21h)

Display inversion on

0 ↑ 1

- 0 0 1 0 0 1 1 0 (26h)

Gamma curve selec

t

GAMSET

10.1.16

1 ↑ 1

- - - - - GC3

GC2

GC1

GC0

-

DISPOFF

10.1.17

0 ↑ 1

- 0 0 1 0 1 0 0 0 (28h)

Display off

DISPON

10.1.18

0 ↑ 1

- 0 0 1 0 1 0 0 1 (29h)

Display on

0 ↑ 1

- 0 0 1 0 1 0 1 0 (2Ah)

Column address set

1 ↑ 1

- XS15

XS14

XS13

XS12

XS11

XS10

XS9

XS8

1 ↑ 1

- XS7

XS6

XS5

XS4

XS3

XS2

XS1

XS0

X address start: 0≦XS≦X

1 ↑ 1

- XE15

XE14

XE13

XE12

XE11

XE10

XE9

XE8

CASET

10.1.19

1 ↑ 1

- XE7

XE6

XE5

XE4

XE3

XE2

XE1

XE0

X address end: S≦XE≦X

0 ↑ 1

- 0 0 1 0 1 0 1 1 (2Bh)

Row address set

1 ↑ 1

- YS15

YS14

YS13

YS12

YS11

YS10

YS9

YS8

1 ↑ 1

- YS7

YS6

YS5

YS4

YS3

YS2

YS1

YS0

Y address start: 0≦YS≦Y

1 ↑ 1

- YE15

YE14

YE13

YE12

YE11

YE10

YE9

YE8

RASET

10.1.20

1 ↑ 1

- YE7

YE6

YE5

YE4

YE3

YE2

YE1

YE0

Y address end:S≦YE≦Y

0 ↑ 1

- 0 0 1 0 1 1 0 0 (2Ch)

Memory write

RAMWR

10.1.21

1 ↑ 1

- D7

D6

D5

D4

D3

D2

D1

D0

Write data

0 ↑ 1

- 0 0 1 0 1 1 0 1 (2Dh)

LUT for 4k,65k,262k color

1 ↑ 1

- - - R005

R004

R003

R002

R001

R000

Red tone 0

1 ↑ 1

- - - : : : : : :

:

1 ↑ 1

- - - Ra5

Ra4

Ra3

Ra2

Ra1

Ra0

Red tone

“

a

”

1 ↑ 1

- - - G005

G004

G003

G002

G001

G000

Green tone 0

1 ↑ 1

- - - : : : : : :

:

1 ↑ 1

- - - Gb5

Gb4

Gb3

Gb2

Gb1

Gb0

Green tone

“

b

”

1 ↑ 1

- - - B005

B004

B003

B002

B001

B000

Blue tone 0

1 ↑ 1

- - - : : : : : :

:

RGBSET

10.1.22

1 ↑ 1

- - - Bc5

Bc4

Bc3

Bc2

Bc1

Bc0

Blue tone

“

c

”

0 ↑ 1

- 0 0 1 0 1 1 1 0 (2Eh)

Memory read

1 1

↑ - - - - - - - - -

Du

mmy read

RAMRD

10.1.23

1 1

↑ - D7

D6

D5

D4

D3

D2

D1

D0

Read data

“-“: Don’t care

(30h) Partral stam’end address set (34h) eari enecmnean (35h) eari elreclmode selamn (36h) emu data access comer (38h) We mode 0" (3%) We made on h) \nterrace ’ el ﬁdrmat \nterrace lormal h) Read \D! Dumm read Read arameter h) Read \D2 Dumm read Read arameter DC”) Read \DS Dumm read Read arameter

ST7735R

V0.2 81 2009-08-05

Table 10.1.3 System Function command List (3)

Instruction

Refer

D/CX

WRX

RDXD17-8

D7

D6

D5

D4

D3

D2

D1

D0

Hex

Function

0

↑

1

- 0 0 1 1 0 0 0

0

(30h)

Partial start/end address set

1

↑

1

- PSL15

PSL14

PSL13PSL12

PSL11

PSL10 PSL9

PSL8

1

↑

1

- PSL7

PSL6

PSL5

PSL4

PSL3

PSL2

PSL1

PSL0

Partial start address (0,1,2, ..P)

1

↑

1

- PEL15

PEL14

PEL13PEL12

PEL11

PEL10 PEL9

PEL8

PTLAR

10.1.24

1

↑

1

- PEL7

PEL6

PEL5

PEL4

PEL3

PEL2

PEL1

PEL0

Partial end address (0,1,2, .., P)

TEOFF

10.1.25 0

↑

1

- 0 0 1 1 0 1 0

0

(34h)

Tearing effect line off

0

↑

1

- 0 0 1 1 0 1 0

1

(35h)

Tearing effect mode set & on

TEON 10.1.26 1

↑

1

- - - - - - - - TEM

Mode1: TEM=”0”

Mode2: TEM=”1”

0

↑

1

- 0 0 1 1 0 1 1

0

(36h)

Memo

ry data access control

MADCTL

10.1.27 1

↑

1

- MY

MX

MV

ML

RGB

MH

- -

-

IDMOFF

10.1.28 0

↑

1

- 0 0 1 1 1 0 0

0

(38h)

Idle mode off

IDMON

10.1.29 0

↑

1

- 0 0 1 1 1 0 0

1

(39h)

I

dle mode on

0

↑

1

- 0 0 1 1 1 0 1

0

(3Ah)

Interface pixel format

COLMOD

10.1.30 1

↑

1

- - - - - - IFPF2

IFPF1IFPF0

Interface format

0

↑

1

- 1 1 0 1 1 0 1

0

(DAh)

Read ID1

1

↑

- - - - - - - - -

Dummy read

RDID1

10.1.31

1

↑

- ID17

ID16

ID15

ID14

ID13

ID12

ID11

ID10

Read parameter

0

↑

1

- 1 1 0 1 1 0 1

1

(DBh)

Read ID2

1

↑

- - - - - - - - -

Dummy read

RDID2

10.1.32

1

↑

- 1 ID26

ID25

ID24

ID23

ID22

ID21

ID20

Read parameter

0

↑

1

- 1 1 0 1 1 1 0

0

(DCh)

Read ID3

1

↑

- - - - - - - - -

Dummy read

RDID3

10.1.33

1

↑

- ID37

ID36

ID35

ID34

ID33

ID32

ID31

ID30

Read parameter

“-“: Don’t care

Note 1: After the H/W reset by RESX pin or S/W reset by SWRESET command, each internal register becomes default state (Refer

“RESET TABLE” section)

Note 2: Undefined commands are treated as NOP (00 h) command.

Note 3: B0 to D9 and DA to F are for factory use of driver supplier.

Note 4: Commands 10h, 12h, 13h, 20h, 21h, 26h, 28h, 29h, 30h, 33h, 36h (ML parameter only), 37h, 38h and 39h are updated during

V-sync when Module is in Sleep Out Mode to avoid abnormal visual effects. During Sleep In mode, these commands are updated

immediately. Read status (09h), Read Display Power Mode (0Ah), Read Display MADCTL (0Bh), Read Display Pixel Format

(0Ch), Read Display Image Mode (0Dh), Read Display Signal Mode (0Eh).

ST7735R

V0.2 82 2009-08-05

10.1.1 NOP (00h)

00H NOP (No Operation)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

NOP 0 ↑ 1 - 0 0 0 0 0 0 0 0 (00h)

Parameter

No Parameter -

Description

This command is empty command.

“-“ Don’t care

are

ST7735R

V0.2 83 2009-08-05

10.1.2 SWRESET (01h): Software Reset

01H SWRESET (Software Reset)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

SWRESET

0 ↑ 1 - 0 0 0 0 0 0 0 1 (01h)

Parameter

No Parameter -

Description

“-“ Don’t care

-If Software Reset is applied during Sleep In mode, it will be necessary to wait 120msec before sending next command.

-The display module loads all default values to the registers during 120msec.

-If Software Reset is applied during Sleep Out or Display On Mode, it will be necessary to wait 120msec before sending

next command.

Flow Chart

SWRESET

Set

Commands

to S/W

Default

Value

Display whole

blank screen

Sleep In Mode

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

ST7735R

V0.2 84 2009-08-05

10.1.3 RDDID (04h): Read Display ID

04H RDDID (Read Display ID)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDDID 0 ↑ 1 - 0 0 0 0 0 1 0 0 (04h)

1

st

parameter

1 1 ↑ - - - - - - - - - -

2

nd

parameter

1 1 ↑ - ID17

ID16

ID15

ID14

ID13

ID12

ID11

ID10

3

rd

parameter

1 1 ↑ - 1 ID26

ID25

ID24

ID23

ID22

ID21

ID20

4

th

parameter

1 1 ↑ - ID37

ID36

ID35

ID34

ID33

ID32

ID31

ID30

Description

-This read byte returns 24-bit display identification information.

-The 1st parameter is dummy data

-The 2nd parameter (ID17 to ID10): LCD module’s manufacturer ID.

-The 3rd parameter (ID26 to ID20): LCD module/driver version ID

-The 4th parameter (ID37 to UD30): LCD module/driver ID.

-Commands RDID1/2/3(DAh, DBh, DCh) read data correspond to the parameters 2,3,4 of the command 04h,

respectively.

“-“ Don’t care

Default

Default Value

Status ID1 ID2 ID3

Power On Sequence - NV Value NV Value

S/W Reset - NV Value NV Value

H/W Reset - NV Value NV Value

Flow Chart

Read 04h Read 04h

Dummy

Clock

Dummy

Read

Send 2nd

parameter

Send 2nd

parameter

Send 3rd

parameter

Send 3rd

parameter

Send 4th

parameter

Send 4th

parameter

Serial I/F Mode Parallel I/F Mode

Host

Display

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

IDMON PTLON SLPOUT For Future Use For Future Use Idte Mode On/Otl Partwat Mode OmOtt Slee \n/Out Vemcat Scrothn Status Nat Used ‘1 : Scrolt an,”0 : Scratl ott Horizontal Scrolt Status Not Used ‘0‘ Inversmn Status All waets On Not Used All waets 0" Not Used

ST7735R

V0.2 85 2009-08-05

10.1.4 RDDST (09h): Read Display Status

09H RDDST (Read Display Status)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDDST 0 ↑ 1 - 0 0 0 0 1 0 0 1 (09h)

1

st

parameter

1 1 ↑ - - - - - - - - - -

2

nd

parameter

1 1 ↑ - BSTON

MY MX MV ML RGB

MH ST24

3

rd

parameter

1 1 ↑ - ST23

IFPF2

IFPF1

IFPF0

IDMON

PTLON

SLOUT

NORON

4

th

parameter

1 1 ↑ - ST15

ST14

INVON

ST12

ST11

DISON

TEON

GCS2

5

th

parameter

1 1 ↑ - GCS1

GCS0

TEM

ST4 ST3 ST2 ST1 ST0

Description

This command indicates the current status of the display as described in the table below:

Bit Description Value

BSTON Booster Voltage Status ‘1’ =Booster on,

‘0’ =Booster off

MY Row Address Order (MY) ‘1’ =Decrement, (Bottom to Top, when MADCTL (36h) D7=’1’)

‘0’ =Increment, (Top to Bottom, when MADCTL (36h) D7=’0’)

MX Column Address Order (MX) ‘1’ =Decrement, (Right to Left, when MADCTL (36h) D6=’1’)

‘0’ =Increment, (Left to Right, when MADCTL (36h) D6=’1’)

MV Row/Column Exchange (MV) ‘1’ = Row/column exchange, (when MADCTL (36h) D5=’1’)

‘0’ = Normal, (when MADCTL (36h) D5=’0’

ML Scan Address Order (ML) ‘0’ =Decrement,

(LCD refresh Top to Bottom, when MADCTL (36h) D4=’0’)

‘1’=Increment,

(LCD refresh Bottom to Top, when MADCTL (36h) D4=’1’)

RGB RGB/ BGR Order (RGB) ‘1’ =BGR, (When MADCTL (36h) D3=’1’)

‘0’ =RGB, (When MADCTL (36h) D3=’0’)

MH Horizontal Order

‘0’ =Decrement,

(LCD refresh Left to Right, when MADCTL (36h) D2=’0’)

‘1’ =Increment,

(LCD refresh Right to Left, when MADCTL (36h) D2=’1’)

ST24

For Future Use

‘0’

ST23

For Future Use

‘0’

IFPF2

IFPF1

IFPF0

Interface Color Pixel Format

Definition

“011” = 12-bit / pixel,

“101” = 16-bit / pixel,

“110” = 18-bit / pixel, others are no define

IDMON

Idle Mode On/Off

‘1’ = On, “0” = Off

PTLON

Partial Mode On/Off

‘1’ = On, “0” = Off

SLPOUT

Sleep In/Out

‘1’ = Out, “0” =

In

NORON Display Normal Mode On/Off ‘1’ = Normal Display,

‘0’ = Partial Display

ST15

Vertical Scrolling Status

(Not Used)

‘1’ = Scroll on,“0” = Scroll off

ST14

Horizontal Scroll Status

(Not Used)

‘0’

INVON

Inversion Status

‘1’ = On, “0” = Off

ST12

All Pixels On (Not Used)

‘0’

ST11

All Pixels Off (Not Used)

‘0’

DlSON DlSDlaV On/O" 0M TEON Tearlng ellecl llne on/Dll 0" TEM Tearlng ellecl llne mode ST4 Fol Fulule Use ‘0‘ ST3 Fol Fulule Use ‘0‘ ST2 Fol Fulule Use ‘0‘ STl Fol Fulule Use ‘0‘ Serial |/F Mode Parallel |/F Mode RDDST 09h RDDST 09h Dummy Dummy Clock Read Send 2nd Send 2nd parameter parameter Send 3rd / Send 3rd parameter parameter Send 4th Send 4th parameter parameter / Send an / Sendlh parameter parameter Acllun Sequential Iranslerr

ST7735R

V0.2 86 2009-08-05

D

ISON

Display On/Off

‘1’ = On, “0” = Off

TEON

Tearing effect line on/off

‘1’ = On, “0” = Off

GCSEL2

GCSEL1

GCSEL0

Gamma Curve Selection

“000” = GC0

“001” = GC1

“010” = GC2

“011” = GC3

”100” to “111” = Not defined

TE

M

Tearing effect line mode

‘0’ =

mode1, ‘1’ = mode2

ST4

For Future Use

‘0’

ST3

For Future Use

‘0’

ST2

For Future Use

‘0’

ST1

For Future Use

‘0’

ST0 For Future Use ‘0’

“-“ Don’t care

Default

Status Default Value (ST31 to ST0)

ST[31-24] ST[23-16] ST[15-8] ST[7-0]

Power On Sequence 0000-0000 0110-0001 0000-0000 0000-0000

S/W Reset 0xxx0xx00 0xxx-0001 0000-0000 0000-0000

H/W Reset 0000-0000 0110-0001 0000-0000 0000-0000

Flow Chart

er S OUT NORON Serlal Ill: Mode Parallel l/F Mode mm W l mm 0A.. ﬂ,—— Send 2nd Dammt‘: 50an 2nd vnmr‘lr‘ 5m ”mm-n m mm

ST7735R

V0.2 87 2009-08-05

10.1.5 RDDPM (0Ah): Read Display Power Mode

0AH RDDPM (Read Display Power Mode)

Inst / Para

D/CX

WRX

RDX

D17-8

D7

D6

D5

D4

D3

D2

D1

D0

HEX

RDDPM 0 ↑ 1 - 0 0 0 0 1 0 1 0 (0Ah)

1

st

parameter

1 1 ↑ - - - - - - - - - -

2

nd

parameter

1 1 ↑

BSTON

IDMON

PTLON

SLPOUT

NORON

DISON

D1

D0

Description

This command indicates the current status of the display as described in the table below:

“-“ Don’t care

Bit Description Value

BSTON Booster Voltage Status ‘1’ =Booster on,

‘0’ =Booster off

IDMON Idle Mode On/Off ‘1’ = Idle Mode On,

‘0’ = Idle Mode Off

PTLON Partial Mode On/Off ‘1’ = Partial Mode On,

‘0’ = Partial Mode Off

SLPON Sleep In/Out ‘1’ = Sleep Out,

‘0’ = Sleep In

NORON Display Normal Mode On/Off ‘1’ = Normal Display,

‘0’ = Partial Display

DISON Display On/Off ‘1’ = Display On,

‘0’ = Display Off

D1 Not Used ‘0’

D0 Not Used ‘0’

Default

Status Default Value (D7 to D0)

Power On Sequence 0000_1000(08h)

S/W Reset 0000_1000(08h)

H/W Reset 0000_1000(08h)

Flow Chart

D1778 Serial l/F Mode 5m: 2111} hm :Imrlm Parallel I/F Mode Room/man can Send 2nd Dalnmcu‘l Pardmexel Mime smumum lvnnewr

ST7735R

V0.2 88 2009-08-05

10.1.6 RDDMADCTL (0Bh): Read Display MADCTL

0BH RDDMADCTL (Read Display MADCTL)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDDMADCTL

0 ↑ 1 - 0 0 0 0 1 0 1 1 (0Bh)

1

st

parameter 1 1 ↑ - - - - - - - - - -

2

nd

parameter 1 1 ↑ MY MX MV ML RGB

MH D1 D0

Description

This command indicates the current status of the display as described in the table below:

“-“ Don’t care

Bit Description Value

MX Column Address Order ‘1’ = Right to Left (When MADCTL B6=’1’)

‘0’ = Left to Right (When MADCTL B6=’0’)

MY Row Address Order ‘1’ = Bottom to Top (When MADCTL B7=’1’)

‘0’ = Top to Bottom (When MADCTL B7=’0’)

MV Row/Column Order (MV) ‘1’ = Row/column exchange (MV=1)

‘0’ = Normal (MV=0)

ML Vertical Refresh Order ‘1’ =LCD Refresh Bottom to Top

‘0’ =LCD Refresh Top to Bottom

RGB RGB/BGR Order ‘1’ =BGR, “0”=RGB

MH Horizontal Refresh Order

LCD horizontal refresh direction control

‘0’ = LCD horizontal refresh Left to right

‘1’ = LCD horizontal refresh right to left

D1 Not Used ‘0’

D0 Not Used ‘0’

Default

Status Default Value (D7 to D0)

Power On Sequence 0000_0000 (00h)

S/W Reset No change

H/W Reset 0000_0000 (00h)

Flow Chart

Serial |/F Mode 'F'ébbCOLMOD Parallel |/F Mode 'RbbCOLMOD 00h 00h l Host l Display Send 2nd Dummy parameter ,’ Read _V— ’/ Send 2nd / parameter // Aclion | I Sequential I lran’srt/errn __

ST7735R

V0.2 89 2009-08-05

10.1.7 RDDCOLMOD (0Ch): Read Display Pixel Format

0CH RDDCOLMOD (Read Display Pixel Format)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDDCOLMOD

0 ↑ 1 - 0 0 0 0 1 1 0 0 (0Ch)

1

st

parameter 1 1 ↑ - - - - - - - - - -

2

nd

parameter 1 1 ↑ - 0 0 0 0 - IFPF2

IFPF1

IFPF0

Description

This command indicates the current status of the display as described in the table below:

IFPF[2:0] MCU Interface Color Format

011 12-bit/pixel

101 16-bit/pixel

110 18-bit/pixel

111 No used

Others are no define and invalid

“-“ Don’t care

Default

Status Default Value

IFPF[2:0]

Power On Sequence 0110 (18 bits/pixel)

S/W Reset No Change

H/W Reset 0110 (18 bits/pixel)

Flow Chart

D1778 Serial IlF Mode RDD‘M 0cm Paralle‘ I/F Mode H 051 V Send7nd , mammals! , Display Legend Command ,’ Para mmcr ,’ Dwsp‘ay Acuan Mode 1 Seimerma‘ xrans‘e; , | | | | ,, I | | | | L;_J

ST7735R

V0.2 90 2009-08-05

10.1.8 RDDIM (0Dh): Read Display Image Mode

0DH RDDIM (0Dh): Read Display Image Mode

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDDIM 0 ↑ 1 - 0 0 0 0 1 1 0 1 (0Dh)

1

st

parameter 1 1 ↑ - - - - - - - - - -

2

nd

parameter 1 1 ↑ - VSSON

D6 INVON

D4 D3 GCS2

GCS1

GCS0

Description

This command indicates the current status of the display as described in the table below:

“-“ Don’t care

Bit Description Value

VSSON Reversed “0”

D6 Reversed “0”

INVON Inversion On/Off “1” = Inversion is On,

“0” = Inversion is Off

D4 All Pixels On “0” (Not used)

D3 All Pixels Off “0” (Not used)

GCS2

GCS1

GCS0

Gamma Curve Selection

“000” = GC0,

“001” = GC1,

“010” = GC2,

“011” = GC3, ”100” to “111” = Not defined

Default

Status Default Value(D7 to D0)

Power On Sequence 0000_0000 (00h)

S/W Reset 0000_0000 (00h)

H/W Reset 0000_0000 (00h)

Flow Chart

ST7735R

V0.2 91 2009-08-05

10.1.9 RDDSM (0Eh): Read Display Signal Mode

0EH RDDSM (0Eh): Read Display Signal Mode

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDDSM 0 ↑ 1 - 0 0 0 0 1 1 1 0 (0Eh)

1

st

parameter 1 1 ↑ - - - - - - - - - -

2

nd

parameter 1 1 ↑ - TEON

TEM

D5 D4 D3 D2 D1 D0

Description

This command indicates the current status of the display as described in the table below:

“-“ Don’t care

Bit Description Value

TEON Tearing Effect Line On/Off “1” = On,

“0” = Off

TEM Tearing effect line mode “1” = mode2,

“0” = mode1

D5 Not Used “1” = On,

“0” = Off

D4 Not Used “1” = On,

“0” = Off

D3 Not Used “1” = On,

“0” = Off

D2 Not Used “1” = On,

“0” = Off

D1 Not Used “1” = On,

“0” = Off

D0 Not Used “1” = On,

“0” = Off

Default

Status Default Value(D7~D0)

Power On Sequence 0000_0000 (00h)

S/W Reset 0000_0000 (00h)

H/W Reset 0000_0000 (00h)

Serial l/F Mode Parallel l/F Mode Read RDDSM Read RDDSM Hosl Send 2nd Dummy parameter Read Send 2nd parameler Display '____ I Legend | Command Parameter Display \\_ I \ Mode \ Sequenual Iransler , I____

ST7735R

V0.2 92 2009-08-05

Flow Chart

ST7735R

V0.2 93 2009-08-05

10.1.10 SLPIN (10h): Sleep In

10H SLPIN (Sleep In)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

SLPIN 0 ↑ 1 - 0 0 0 1 0 0 0 0 (10h)

Parameter No Parameter -

Description -This command causes the LCD module to enter the minimum power consumption mode.

-In this mode the DC/DC converter is stopped, Internal display oscillator is stopped, and panel scanning is stopped.

Restriction

-This command has no effect when module is already in Sleep In

mode. Sleep In Mode can only be exit by the Sleep Out

Command (11h).

-

When IC is in Sleep Out or Display On mode, it is necessary to wait 120msec before sending next command because of

the stabilization timing for the supply voltages and clock circuits.

Default

Status Default Value

Power On Sequence Sleep in mode

S/W Reset Sleep in mode

H/W Reset Sleep in mode

Flow Chart

SLPIN

Display whole

blank screen

(Automatic No effect

to DISP ON/OFF

Commands)

Drain

Charge

From LCD

Panel

Stop

DC-DC

Converter

Stop

Internal

Oscillator

Sleep In Mode

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

on no 9"

ST7735R

V0.2 94 2009-08-05

10.1.11 SLPOUT (11h): Sleep Out

11H SLPOUT (Sleep Out)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

SLPOUT 0 ↑ 1 - 0 0 0 1 0 0 0 1 (11h)

Parameter No Parameter -

Description -This command turns off sleep mode.

-In this mode the DC/DC converter is enabled, Internal display oscillator is started, and panel scanning is started.

Restriction

-This command has no ef

fect when module is already in sleep out mode. Sleep Out Mode can only be exit by the Sleep In

Command (10h).

-

When IC is in Sleep In mode, it is necessary to wait 120msec before sending next command because of the stabilization

timing for the supply voltages and clock circuits.

-When IC is in Sleep Out or Display On mode, it is necessary to wait 120msec before sending next command due to the

download of default value of registers and the execution of self-diagnostic function.

Default

Status Default Value

Power On Sequence Sleep in mode

S/W Reset Sleep in mode

H/W Reset Sleep in mode

Flow Chart

SLPOUT

Start

Internal

Oscillator

Start up

DC:DC

Converter

Display whole blank

screen for 2 firames

(Automatic No effect

to DISP ON/OFF

Commands)

Display Memory

contents In

accordance with

the current

command table

settings

Sleep Out mode

Charge

Offset

voltage for

LCD

Panel

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

ST7735R

V0.2 95 2009-08-05

10.1.12 PTLON (12h): Partial Display Mode On

12H PTLON (12h): Partial Display Mode On

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

PTLON 0 ↑ 1 - 0 0 0 1 0 0 1 0 (12h)

Parameter No Parameter -

Description

-This command turns on Partial mode. The partial mode window is described by the Partial Area command (30h)

-To leave Partial mode, the Normal Display Mode On command (13h) should be written.

“-“ Don’t care

Default

Status Default Value

Power On Sequence Normal Mode On

S/W Reset Normal Mode On

H/W Reset Normal Mode On

Flow Chart

See Partial Area (30h)

ST7735R

V0.2 96 2009-08-05

10.1.13 NORON (13h): Normal Display Mode On

13H NORON (Normal Display Mode On)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

NORON 0 ↑ 1 - 0 0 0 1 0 0 1 1 (13h)

Parameter No Parameter -

Description

-This command returns the display to normal mode.

-Normal display mode on means Partial mode off.

-Exit from NORON by the Partial mode On command (12h)

“-“ Don’t care

Default

Status Default Value

Power On Sequence Normal Mode On

S/W Reset Normal Mode On

H/W Reset Normal Mode On

Flow Chart

See Partial Area Definition Descriptions for details of when to use this command

\HHH

ST7735R

V0.2 97 2009-08-05

10.1.14 INVOFF (20h): Display Inversion Off

20H IVNOFF (Normal Display Mode Off)

Inst / Para D/CX

WRX

RDX

D17-8 D7 D6 D5 D4 D3 D2 D1 D0 HEX

INVOFF 0 ↑ 1 - 0 0 1 0 0 0 0 0 (20h)

Parameter No Parameter -

Description

-This command is used to recover from display inversion mode.

“-“ Don’t care

Default

Status Default Value

Power On Sequence Display Inversion off

S/W Reset Display Inversion off

H/W Reset Display Inversion off

Flow Chart

INVOFF (20h)

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

Display

Inversion On

Mode

Display

Inversion OFF

Mode

Top-Left

(0,0)

(Example)

Memory Display

HIHH

ST7735R

V0.2 98 2009-08-05

10.1.15 INVON (21h): Display Inversion On

21H IVNOFF (Display Inversion On)

Inst / Para D/CX WRX RDX D17-8 D7

D6

D5

D4

D3

D2

D1

D0

HEX

INVON 0 ↑ 1 - 0 0 1 0 0 0 0 1 (21h)

Parameter No Parameter -

Description

-This command is used to enter into display inversion mode

-To exit from Display Inversion On, the Display Inversion Off command (20h) should be written.

“-“ Don’t care

Default

Status Default Value

Power On Sequence Display Inversion off

S/W Reset Display Inversion off

H/W Reset Display Inversion off

Flow Chart

INVON (21h)

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

Display

Inversion OFF

Mode

Display

Inversion ON

Mode

Top-Left

(0,0)

(Example)

Memory

Display

GAMSET (26h) 15! para meter: GCU:0] ” New Loaded '____ Legend C—ommand Parameter / " Display | | | —| | :I ‘ | | | | | | | ' Action Mode Sequenlial transler , I____

ST7735R

V0.2 99 2009-08-05

10.1.16 GAMSET (26h): Gamma Set

26H GAMSET (Gamma Set)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

GAMSET 0 ↑ 1 - 0 0 1 0 0 1 1 0 (26h)

Parameter 1 ↑ 1 - - - - - GC3

GC2

GC1

GC0

Description

-This command is used to select the desired Gamma curve for the current display. A maximum of 4 curves can be

selected. The curve is selected by setting the appropriate bit in the parameter as described in the Table.

GC [7:0] Parameter Curve Selected

GS=1 GS=0

01h GC0 Gamma Curve 1 (G2.2) Gamma Curve 1 (G1.0)

02h GC1 Gamma Curve 2 (G1.8) Gamma Curve 2 (G2.5)

04h GC2 Gamma Curve 3 (G2.5) Gamma Curve 3 (G2.2)

08h GC3 Gamma Curve 4 (G1.0) Gamma Curve 4 (G1.8)

Note: All other values are undefined.

Default

Status Default Value

Power On Sequence 01h

S/W Reset 01h

H/W Reset 01h

Flow Chart

,/'/Dlsplay0n '\ \ \ Mode /' /’ DISp‘ay on x‘ \ \ DISPOFF \ Mode Sequential lransler

ST7735R

V0.2 100 2009-08-05

10.1.17 DISPOFF (28h): Display Off

28H DISPOFF (Display Off)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

DISPOFF 0 ↑ 1 - 0 0 1 0 1 0 0 0 (28h)

Parameter No Parameter -

Description

- This command is used to enter into DISPLAY OFF mode. In this mode, the output from Frame Memory is

disabled and blank page inserted.

- This command makes no change of contents of frame memory.

- This command does not change any other status.

- There will be no abnormal visible effect on the display.

- Exit from this command by Display On (29h)

Default

Status Default Value

Power On Sequence Display off

S/W Reset Display off

H/W Reset Display off

Flow Chart

(Example)

Memory Display

ST7735R

V0.2 101 2009-08-05

(Example)

Memory Display

10.1.18 DISPON (29h): Display On

29H DISPON (Display On)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

DISPON 0 ↑ 1 - 0 0 1 0 1 0 0 1 (29h)

Parameter No Parameter -

Description

- This command is used to recover from DISPLAY OFF mode.

- Output from the Frame Memory is enabled.

- This command makes no change of contents of frame memory.

- This command does not change any other status.

Default

Status Default Value

Power On Sequence Display off

S/W Reset Display off

H/W Reset Display off

Flow Chart

Display Off

Mode

DISPON

Display On

Mode

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

ST7735R

V0.2 102 2009-08-05

10.1.19 CASET (2Ah): Column Address Set

2AH CASET(Column Address Set)_

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

CASET(2Ah)

0 ↑ 1 - 0 0 1 0 1 0 1 0 (2Ah)

1

st

parameter

1 ↑ 1 - XS15

XS14

XS13

XS12

XS11

XS10

XS9

XS8

2

nd

parameter

1 ↑ 1 - XS7

XS6

XS5

XS4

XS3

XS2

XS1

XS0

3

rd

parameter

1 ↑ 1 - XE15

XE14

XE13

XE12

XE11

XE10

XE9

XE8

4

th

parameter

1 ↑ 1 - XE7

XE6

XE5

XE4

XE3

XE2

XE1

XE0

Description

-The value of XS [7:0] and XE [7:0] are referred when RAMWR command comes.

-Each value represents one column line in the Frame Memory.

XS[7:0] XE[7:0]

Restriction

XS [15:0] always must be equal to or less than XE [15:0]

When XS [15:0] or XE [15:0] is greater than maximum address like below, data of out of range will be ignored.

1. 128X160 memory base (GM = ’11’)

(Parameter range: 0 < XS [15:0] < XE [15:0] < 127 (007Fh)): MV=”0”)

(Parameter range: 0 < XS [15:0] < XE [15:0] < 159 (009Fh)): MV=”1”)

2. 132X162 memory base (GM = ’00’)

(Parameter range: 0 < XS [15:0] < XE [15:0] < 131 (0083h)): MV=”0”)

(Parameter range: 0 < XS [15:0] < XE [15:0] < 161 (00A1h)): MV=”1”)

Default

Default Value

GM Status Status XS [7:0] XE [7:0] (MV=’0 ’) XE [7:0] (MV=’1’)

Power On

Sequence 0000h 007Fh (127)

S/W Reset 0000h 007Fh (127) 009Fh (159)

GM=’11’

(128x160

memory base)

H/W Reset 0000h 007Fh (127)

Power On

Sequence 0000h 0083h (131)

S/W Reset 0000h 0083h (131) 00A1h (161)

GM=’00’

(132x162

memory base)

H/W Reset 0000h 0083h (131)

1s| parameter x3150] / 2nd uaramelev XE[15'0] / % PASET \ 1s| parameter v31 50] / 2nd uaramelev YE[15'0] Acuon RAMWR pepeeu Jl Sequential IransteL Any Command

ST7735R

V0.2 103 2009-08-05

Flow Chart

100mm),

ST7735R

V0.2 104 2009-08-05

10.1.20 RASET (2Bh): Row Address Set

2BH RASET (Row Address Set)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RASET (2Bh)

0 ↑ 1 - 0 0 1 0 1 0 1 1 (2Bh)

1

st

parameter

1 ↑ 1 - YS15

YS14

YS13

YS12

YS11

YS10

YS9

YS8

2

nd

parameter

1 ↑ 1 - YS7

YS6

YS5

YS4

YS3

YS2

YS1

YS0

3

rd

parameter

1 ↑ 1 - YE15

YE14

YE13

YE12

YE11

YE10

YE9

YE8

4

th

parameter

1 ↑ 1 - YE7

YE6

YE5

YE4

YE3

YE2

YE1

YE0

Description

The value of YS [7:0] and YE [7:0] are referred when RAMWR command comes.

Each value represents one column line in the Frame Memory.

YS[7:0]

YE[7:0]

Restriction

YS [15:0] always must be equal to or less than YE [15:0]

When YS [15:0] or YE [15:0] are greater than maximum row address like below, data of out of range will be ignored.

1. 128X160 memory base (GM = ’11’)

(Parameter range: 0 < YS [15:0] < YE [15:0] < 159 (009Fh)): MV=”0”

(Parameter range: 0 < YS [15:0] < YE [15:0] < 127 (007Fh)): MV=”1”

2. 132X162 memory base (GM = ’00’)

(Parameter range: 0 < YS [15:0] < YE [15:0] < 161 (00A1h)): MV=”0”

(Parameter range: 0 < YS [15:0] < YE [15:0] < 131 (0083h)): MV=”1”

Default

Default Value

GM status Status YS [15:0] YE [15:0] (MV=’0 ’)

YE [15:0] (MV=’1’)

Power On

Sequence 0000h 009Fh (159)

S/W Reset 0000h 009Fh (159) 007Fh (127)

GM=’11’

(128x160

memory base)

H/W Reset 0000h 009Fh (159)

Power On

Sequence 0000h 00A1h (161)

S/W Reset 0000h 00A1h (161) 0083h (131)

GM=’00’

(132x162

memory base)

H/W Reset 0000h 00A1h (161)

= $33 = $88

ST7735R

V0.2 105 2009-08-05

Flow Chart

CASET

1st parameter XS[15:0]

2nd parameter XE[15:0]

PASET

1st parameter YS[15:0]

2nd parameter YE[15:0]

RAMWR

Image Data

D1[7:0],D2[7:0]

…….Dn[7:0]

Any Command

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

ST7735R

V0.2 106 2009-08-05

10.1.21 RAMWR (2Ch): Memory Write

2CH RAMWR (Memory Write)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RAMWR 0 ↑ 1 - 0 0 1 0 1 1 0 0 (2Ch)

1st parameter 1 ↑ 1 D17-8

D7 D6 D5 D4 D3 D2 D1 D0

∣ 1 ↑ 1 ∣ ∣ ∣ ∣ ∣ ∣ ∣ ∣ ∣

Nth parameter 1 ↑ 1 D17-8

D7 D6 D5 D4 D3 D2 D1 D0

Description

In all color modes, there is no restriction on length of parameters.

1. 128X160 memory base (GM = ‘11’)

128x160x18-bit memory can be written by this command

Memory range: (0000h, 0000h) -> (007Fh, 09Fh)

2. 132x162 memory base (GM = ‘00’)

132x162x18-bit memory can be written on this command.

Memory range: (0000h, 0000h) -> (0083h, 00A1h)

Default

Status Default Value

Power On Sequence Contents of memory is set randomly

S/W Reset Contents of memory is not cleared

H/W Reset Contents of memory is not cleared

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

RAMWR

Image Data D1[7:0],D2[7:0]

…….Dn[7:0]

Any Command

Legend I’M/r Command | | | ‘ RGBSET (2Dh) I/ V 151 parameter. «a I \_ 128m parameter: / // Parameter / | | I | a | Display 1 / | | | | | _| __\ Seq uenual lransler I% | | | | | | | |_

ST7735R

V0.2 107 2009-08-05

10.1.22 RGBSET (2Dh): Color Setting for 4K, 65K and 262K

2DH RGBSET (Color Set for 4K, 65K, 262K and 16.7M)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RGBSET 0 ↑ 1 - 0 0 1 0 1 1 0 1 (2Dh)

1st parameter 1 ↑ 1 - - - R005

R004

R003

R002

R001

R000

∣ 1 ↑ 1 - - - Rnn5

Rnn4

Rnn3

Rnn2

Rnn1

Rnn0

∣ 1 ↑ 1 - - - R315

R314

R313

R312

R311

R310

∣ 1 ↑ 1 - - - G005

G004

G003

G002

G001

G000

∣ 1 ↑ 1 - - - Gnn5

Gnn4

Gnn3

Gnn2

Gnn1

Gnn0

∣ 1 ↑ 1 - - - G635

G634

G633

G632

G631

G630

∣ 1 ↑ 1 - - - B005

B004

B003

B002

B001

B000

∣ 1 ↑ 1 - - - Bnn5

Bnn4

Bnn3

Bnn2

Bnn1

Bnn0

128th parameter

1 ↑ 1 - - - B315

B314

B313

B312

B311

B310

Description

This command is used to define the LUT for 12bits-to-16bits / 16-bit-to- 18bits color depth conversations.

128-Bytes must be written to the LUT regardless of the color mode. Only the values in Section 9.18 are referred.

In this condition, 4K-color (4-4-4) and 65K-color(5-6-5) data input are transferred 6(R)-6(G)-6(B) through RGB LUT

table.

This command has no effect on other commands/parameters and Contents of frame memory.

Visible change takes effect next time the Frame Memory is written to.

Do not send any command before the last data is sent or LUT is not defined correctly.

Default

Status Default Value

Power On Sequence Random

S/W Reset Contents of the look-up table protected

H/W Reset Random

Flow Chart

\mage Data mnmmmq Dung Any Commanﬂ '____ I Legend Command / Parameter / /, D‘leay 1 sequenual Hensley \. 4 | I____

ST7735R

V0.2 108 2009-08-05

10.1.23 RAMRD (2Eh): Memory Read

2EH RAMHD (Memory Read)

Inst / Para D/CX WRX

RDX

D17-8 D7

D6

D5

D4

D3

D2

D1

D0

HEX

RAMHD 0 ↑ 1 - 0 0 1 0 1 1 1 0 (2Eh)

1

st

parameter 1 1 ↑ - - - - - - - - -

2

nd

parameter 1 1 ↑ D17-8 D7

D6

D5

D4

D3

D2

D1

D0

∣ 1 1 ↑ ∣ ∣

∣

(N+1)th parameter

1 1 ↑ D17-8 D7

D6

D5

D4

D3

D2

D1

D0

Description

-This command is used to transfer data from frame memory to MCU.

-When this command is accepted, the column register and the row register are reset to the Start Column/Start

Row positions.

-The Start Column/Start Row positions are different in accordance with MADCTL setting.

-Then D[17:0] is read back from the frame memory and the column register and the row register incremented as

section 9.10

-Frame Read can be cancelled by sending any other command.

-The data color coding is fixed to 18-bit in reading function. Please see section 9.8 “Data color coding” for color

coding (18-bit cases), when there is used 8, 9, 16 and 18-bit data lines for image data.

Note1: The Command 3Ah should be set to 66h when reading pixel data from frame memory. Please check the

LUT in chapter 9.17 when using memory read function.

Default

Status Default Value

Power On Sequence Contents of memory is set randomly

S/W Reset Contents of memory is not cleared

H/W Reset Contents of memory is not cleared

Flow Chart

ST7735R

V0.2 109 2009-08-05

10.1.24 PTLAR (30h): Partial Area

30H PTLAR (Partial Area)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

PTLAR 0 ↑ 1 - 0 0 1 1 0 0 0 0 (30h)

1st parameter

1 ↑ 1 - PSL15

PSL14

PSL13

PSL12

PSL11

PSL10

PSL9

PSL8

2nd parameter

1 ↑ 1 - PSL7

PSL6

PSL5

PSL4

PSL3

PSL2

PSL1

PSL0

3rd parameter

1 ↑ 1 - PEL15

PEL14

PEL13

PEL12

PEL11

PEL10

PEL9

PEL8

4th parameter

1 ↑ 1 - PEL7

PEL6

PEL5

PEL4

PEL3

PEL2

PEL1

PEL0

Description

-This command defines the partial mode’s display area.

-There are 4 parameters associated with this command, the first defines the Start Row (PSL) and the second the End

Row (PEL), as illustrated in the figures below. PSL and PEL refer to the Frame Memory row address counter.

-If End Row > Start Row, when MADCTL ML=’0’

Non-display area

Partial display area

PSL [7:0]

PEL [7:0]

Start row

End row

-If End Row > Start Row, when MADCTL ML=’1’

Non-display area

Partial display area

PSL [7:0]

PEL [7:0]

Start row

End row

-If End Row < Start Row, when MADCTL ML=’0’

Partial display area

PSL [7:0]

PEL [7:0]

Start row

End row

Non-display area

Partial display area

-If End Row = Start Row then the Partial Area will be one row deep.

Default

Default Value

Status PSL [15:0] PEL [15:0]

GM[1:0] “xx” GM[1:0]=”11” GM[1:0]=”00”

Power On Sequence 0000h 009Fh 00A1h

S/W Reset 0000h 009Fh 00A1h

H/W Reset 0000h 009Fh 00A1h

1. To Enter Partial Mode: \ I: Pama‘ Mode '\ 2. Leave Partial Mode Pama‘ Mode 7 DISPOFF Optional) To prevent Tearing Eﬁem Image dlsp‘ayed DISPON Command I Parameter Sequentia‘ Irans‘erri ,

ST7735R

V0.2 110 2009-08-05

Flow Chart

ST7735R

V0.2 111 2009-08-05

10.1.25 TEOFF (34h): Tearing Effect Line OFF

34H TEOFF (Tearing Effect Line OFF)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

TEOFF 0 ↑ 1 - 0 0 1 1 0 1 0 0 (34h)

Parameter No Parameter -

Description -This command is used to turn OFF (Active Low) the Tearing Effect output signal from the TE signal line.

Default

Status Default Value

Power On Sequence OFF

S/W Reset OFF

H/W Reset OFF

Flow Chart

TE Line Output

ON

TEOFF

TE Line Output

OFF

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

ST7735R

V0.2 112 2009-08-05

10.1.26 TEON (35h): Tearing Effect Line ON

35H TEON (Tearing Effect Line ON)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

TEON 0 ↑ 1 - 0 0 1 1 0 1 0 1 (35h)

Parameter 1 ↑ 1 - 0 0 0 0 0 0 0 TEM

Description

-This command is used to turn ON the Tearing Effect output signal from the TE signal line.

-This output is not affected by changing MADCTL bit ML.

-The Tearing Effect Line On has one parameter, which describes the mode of the Tearing Effect Output Line:

-When TEM =’0’: The Tearing Effect output line consists of V-Blanking information only

T

vdl

T

vdh

Vertical time scale

-When TEM =’1’: The Tearing Effect output Line consists of both V-Blanking and H-Blanking information

T

vdl

T

vdh

Vertical time scale

Note: During Sleep In Mode with Tearing Effect Line On, Tearing Effect Output pin will be active Low.

Default

Status Default Value

Power On Sequence Tearing effect off & TEM=0

S/W Reset Tearing effect off & TEM=0

H/W Reset Tearing effect off & TEM=0

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

TE Line Output

OFF

TEON

TE Line Output

ON

TELOM

\#> HHH l—> HHH l—‘>

ST7735R

V0.2 113 2009-08-05

10.1.27 MADCTL (36h): Memory Data Access Control

36H MADCTL (Memory Data Access Control)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

MADCTL 0 ↑ 1 - 0 0 1 1 0 1 1 0 (36h)

Parameter 1 ↑ 1 - MY MX MV ML RGB

MH - -

Description

-This command defines read/ write scanning direction of frame memory.

-Bit Assignment

Send first

Send 2nd

Send 3rd

Send last

Memory Display

Top-left (0, 0)

ML="0"

Send first

Send 2nd

Send 3rd

Send last

Memory Display

Top-left (0, 0)

ML="1"

Top-left (0, 0)

R G B R G B R G B

SIG1 SIG2 SIG132

Driver IC

RGB="0"

R G B R G B R G B

SIG1 SIG2 SIG132

Driver IC

RGB="1"

R G B

SIG1

R G B

SIG2

R G B

SIG132

RGB

SIG1

RGB

SIG2

RGB

SIG132

LCD panel LCD panel

Bit NAME DESCRIPTION

MY Row Address Order

MX Column Address Order

MV Row/Column Exchange

These 3bits controls MCU to memory

write/read direction.

ML Vertical Refresh Order

LCD vertical refresh direction control

‘0’ = LCD vertical refresh Top to Bottom

‘1’ = LCD vertical refresh Bottom to Top

RGB RGB-BGR ORDER

Color selector switch control

‘0’ =RGB color filter panel,

‘1’ =BGR color filter panel)

MH Horizontal Refresh Order

LCD horizontal refresh direction control

‘0’ = LCD horizontal refresh Left to right

‘1’ = LCD horizontal refresh right to left

ST7735R

V0.2 114 2009-08-05

Memory

Display

Top-left (0, 0)

ML="0"

Memory

Display

Top-left (0, 0)

ML="1"

Send first

Send 2nd

Send 3rd

Send last

Send first

Send 2nd

Send 3rd

Send last

Top-left (0, 0)

Default

Status Default Value

Power On Sequence MY=0,MX=0,MV=0,ML=0,RGB=0,MH=0

S/W Reset No Change

H/W Reset MY=0,MX=0,MV=0,ML=0,RGB=0,MH=0

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

MADCTL

1st parameter

B[7:0]

\ Idle on mode ‘ /, IDMOFF / r \ Idle off mode ‘ I S(illuential I translef ,

ST7735R

V0.2 115 2009-08-05

10.1.28 IDMOFF (38h): Idle Mode Off

38H IDMOFF (Idle Mode Off)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

IDMOFF 0 ↑ 1 - 0 0 1 1 1 0 0 0 (38h)

Parameter No Parameter -

Description

-This command is used to recover from Idle mode on.

-In the idle off mode,

1. LCD can display 4096, 65k or 262k colors.

2. Normal frame frequency is applied.

Default

Status Default Value

Power On Sequence Idle Mode Off

S/W Reset Idle Mode Off

H/W Reset Idle Mode Off

Flow Chart

ST7735R

V0.2 116 2009-08-05

10.1.29 IDMON (39h): Idle Mode On

39H IDMON (Idle Mode On)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

IDMOFF 0 ↑ 1 - 0 0 1 1 1 0 0 1 (39h)

Parameter No Parameter -

Description

-This command is used to enter into Idle mode on.

-There will be no abnormal visible effect on the display mode change transition.

-In the idle on mode,

1. Color expression is reduced. The primary and the secondary colors using MSB of each R,G and B in the Frame

Memory, 8 color depth data is displayed.

2. 8-Color mode frame frequency is applied.

3. Exit from IDMON by Idle Mode Off (38h) command

Color R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B4 B1 B0

Black 0xxxxx 0xxxxx 0xxxxx

Blue 0xxxxx 0xxxxx 1xxxxx

Red 1xxxxx 0xxxxx 0xxxxx

Magenta 1xxxxx 0xxxxx 1xxxxx

Green 0xxxxx 1xxxxx 0xxxxx

Cyan 0xxxxx 1xxxxx 1xxxxx

Yellow 1xxxxx 1xxxxx 0xxxxx

White 1xxxxx 1xxxxx 1xxxxx

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out No

Partial Mode On, Idle Mode On, Sleep Out No

Sleep In Yes

Default

Status Default Value

Power On Sequence Idle Mode Off

S/W Reset Idle Mode Off

H/W Reset Idle Mode Off

Top-Left

(0,0)

(Example)

Memory

Display

ST7735R

V0.2 117 2009-08-05

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

Idle off mode

IDMON

Idle on mode

1&bw/wae\ Made ,! COLMOD V 15\ Paramexer f , 15bvaxxe‘Mnde \ '____ Legend Command Paramexer ,r/ Dwsp‘ay Amwun Made Sequenua‘ vanslev |____

ST7735R

V0.2 118 2009-08-05

10.1.30 COLMOD (3Ah): Interface Pixel Format

3AH COLMOD (3Ah): Interface Pixel Format

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

COLMOD 0 ↑ 1 - 0 0 1 1 1 0 1 0 (3Ah)

Parameter 1 ↑ 1 - - - - - - IFPF2

IFPF1

IFPF0

Description

This command is used to define the format of RGB picture data, which is to be transferred via the

MCU interface. The formats are shown in the table:

IFPF[2:0] MCU Interface Color Format

011 3 12-bit/pixel

101 5 16-bit/pixel

110 6 18-bit/pixel

111 7 No used

Note1: In 12-bit/Pixel, 16-bit/Pixel or 18-bit/Pixel mode, the LUT is applied to transfer data into the Frame Memory.

Note2: The Command 3Ah should be set at 55h when writing 16-bit/pixel data into frame m

emory, but 3Ah should be

re-set to 66h when reading pixel data from frame memory. Please check the LUT in chapter 9.17 when using

memory read function.

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out No

Partial Mode On, Idle Mode On, Sleep Out No

Sleep In Yes

Default

Status Default Value

IFPF[2:0] VIPF[3:0]

Power On Sequence 0110(18-bit/Pixel) 0110(18-bit/Pixel)

S/W Reset No Change No Change

H/W Reset 0110(18-bit/Pixel) 0110(18-bit/Pixel)

Flow Chart

ST7735R

V0.2 119 2009-08-05

10.1.31 RDID1 (DAh): Read ID1 Value

DAH RDID1 (Read ID1 Value)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDID1 0 ↑ 1 - 1 1 0 1 1 0 1 0 (DAh)

1st parameter

1 1 ↑ - - - - - - - - - -

2nd parameter

1 1 ↑ - ID17

ID16

ID15

ID14

ID13

ID12

ID11

ID10

Description

-This read byte returns 8-bit LCD module’s manufacturer ID

-The 1st parameter is dummy data

-The 2nd parameter (ID17 to ID10): LCD module’s manufacturer ID.

NOTE: See command RDDID (04h), 2nd parameter.

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out No

Partial Mode On, Idle Mode On, Sleep Out No

Sleep In Yes

Default

Status Default Value

Power On Sequence -

S/W Reset -

H/W Reset -

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

Read ID1 Read ID1

Send 2nd

parameter

Dummy

Read

Send 2nd

parameter

Serial I/F Mode Parallel I/F Mode

Serial |/F Mode Parallel |/F Mode Read |D2 l Send 2nd parameter Send 2nd parameter Sequential lransler ,

ST7735R

V0.2 120 2009-08-05

10.1.32 RDID2 (DBh): Read ID2 Value

DBH RDID2 (Read ID2 Value)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDID2 0 ↑ 1 - 1 1 0 1 1 0 1 1 (DBh)

1

st

parameter 1 1 ↑ - - - - - - - - - -

2

nd

parameter

1 1 ↑ - 1 ID26

ID25

ID24

ID23

ID22

ID21

ID20

Description

-This read byte returns 8-bit LCD module/driver version ID

-The 1st parameter is dummy data

-The 2nd parameter (ID26 to ID20): LCD module/driver version ID

-Parameter Range: ID=80h to FFh

ID26 to ID20 Version Changes

80h

81h

82h

83h

NOTE: See command RDDID (04h), 3rd parameter.

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out No

Partial Mode On, Idle Mode On, Sleep Out No

Sleep In Yes

Default

Status Default Value

Power On Sequence NV Value

S/W Reset NV Value

H/W Reset NV Value

Flow Chart

ST7735R

V0.2 121 2009-08-05

10.1.33 RDID3 (DCh): Read ID3 Value

DCH RDID3 (Read ID2 Value)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

RDID3 0 ↑ 1 - 1 1 0 1 1 1 0 0 (DCh)

1

st

parameter

1 1 ↑ - - - - - - - - - -

2

nd

parameter

1 1 ↑ - ID37

ID36

ID35

ID34

ID33

ID32

ID31

ID30

Description

-This read byte returns 8-bit LCD module/driver ID.

-The 1st parameter is dummy data

-The 2nd parameter (ID37 to ID30): LCD module/driver ID.

NOTE: See command RDDID (04h), 4th parameter.

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out No

Partial Mode On, Idle Mode On, Sleep Out No

Sleep In Yes

Default

Status Default Value

Power On Sequence NV Value

S/W Reset NV Value

H/W Reset NV Value

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

Read ID3 Read ID3

Send 2nd

parameter

Dummy

Read

Send 2nd

parameter

Serial I/F Mode Parallel I/F Mode

Host

Display

ax nza-e m) ode 3 2 I 0 ”e 4 4 2h) ode 3 2 I 0 ”e 4 4 + an) N03 N02 NC1 NCO c4 et CA 01 mnt N03 ND2 Nm NDO back D4 D4 D1 4h) on et

ST7735R

V0.2 122 2009-08-05

10.2 Panel Function Command List and Description

Table 10.2.1 Panel Function Command List (1)

Instruction

Refer

D/CX

WRX

RDX

D23-8

D7

D6

D5

D4

D3 D2 D1 D0 Hex

Function

0 ↑ 1

- 1

0

1 1 0 0 0 1 (B1h)

In

normal mode

(Full colors)

1 ↑ 1

-

RTNA3

RTNA2

RTNA1

RTNA0

1 ↑ 1

-

FPA5

FPA4

FPA3

FPA2

FPA1

FPA0

FRMCTR1

10.2.1

1 ↑ 1

-

BPA5

BPA4

BPA3

BPA2

BPA1

BPA0

RTNA set 1-

line

period

FPA: front porch

BPA: back porch

0 ↑ 1

- 1

0

1 1 0 0 1 0 (B2h)

In Idle mode

(8-colors)

1 ↑ 1

-

RTNB3

RTNB2

RTNB1

RTNB0

1 ↑ 1

-

FPB5

FPB4

FPB3

FPB2

FPB1

FPB0

FRMCTR2

10.2.2

1 ↑ 1

-

BPB5

BPB4

BPB3

BPB2

BPB1

BPB0

RTNB: set 1-

line

period

FPB: front porch

BPB: back porch

0 ↑ 1

- 1

0

1 1 0 0 1 1 (B3h)

In partial mode +

Full colors

1 ↑ 1

-

RTNC3

RTNC2

RTNC1

RTNC0

1 ↑ 1

-

FPC5

FPC4

FPC3

FPC2

FPC1

FPC0

1 ↑ 1

-

BPC5

BPC4

BPC3

BPC2

BPC1

BPC0

1 ↑ 1

-

RTND3

RTND2

RTND1

RTND0

1 ↑ 1

-

FPD5

FPD4

FPD3

FPD2

FPD1

FPD0

FRMCTR3

10.2.3

1 ↑ 1

-

BPD5

BPD4

BPD3

BPD2

BPD1

BPD0

RTNC,RTND

: set

1-line period

FPC,FPD: front

porch

BPC,BPD: back

porch

0 ↑ 1

- 1

0

1 1 0 1 0 0 (B4h)

Display inversion

control

INVCTR

10.2.4

1 ↑ 1

- 0

0

0 0 0 NLA

NLB

NLC

NLA,NLB,NLC set

inversion

on (con) P DD (cm) P 3 GL | (02h) he D e O (can) I he D e 0 (04h) I co he a D e DCCU (can) 10 (07h) S rm R 11 0 (pm) 5 12

ST7735R

V0.2 123 2009-08-05

Table 10.2.2 Panel Function Command List (2)

Instruction

Refer

D/CX

WRX

RDX

D17-8

D7

D6

D5

D4

D3

D2

D1

D0

Hex

Function

0 ↑ 1 - 1 1 0 0 0 0 0 0 (C0h)

Power control setting

1 ↑ 1 - AVDD[

2]

AVDD[

1]

AVDD

[0]

VRHP

4

VRHP

3

VRHP

2

VRHP

1

VRHP

0

1 ↑ 1 - 0 0 0 VRHN

4

VRHN

3

VRHN

2

VRHN

1

VRHN

0

PWCTR1

10.2.5

1 ↑ 1 MODE

[1]

MODE

[0]

0 0 0 1 0 0

VRH: Set the GVDD

voltage

0 ↑ 1 - 1 1 0 0 0 0 0 1 (C1h)

Power control setting

PWCTR2

10.2.6

1 ↑ 1 - VGH2

5[1]

VGH2

5[0]

- -

VGLSEL

[1]

VGLSEL

[0]

VGHBT[

1]

VGHBT[

0]

BT: set VGH/ VGL

voltage

0 ↑ 1 - 1 1 0 0 0 0 1 0 (C2h)

In normal mode (Full

colors)

- DCA9

DCA8

SAPA

2

SAPA

1

SAPA

0 APA2

APA1

APA0

PWCTR3

10.2.7

1 ↑ 1

- DCA7

DCA6

DCA5

DCA4

DCA3

DCA2

DCA1

DCA0

AP

A

: adjust the

operational amplifier

DCA: adjust the bo

oster

Voltage

0 ↑ 1 - 1 1 0 0 0 0 1 1 (C3h)

In Idle mode (8-colors)

- DCB9

DCB8

SAPB

2

SAPB

1

SAPB

0 APB2

APB1

APB0

PWCTR4

10.2.8

1 ↑ 1

- DCB7

DCB6

DCB5

DCB4

DCB3

DCB2

DCB1

DCB0

AP

B

: adjust the

operational amplifier

DCB

: adjust the booster

Voltage

0 ↑ 1 - 1 1 0 0 0 1 0 0 (C4h)

In partial mode + Full

colors

1 ↑ 1 - DCC9

DCC8

SAPC

2

SAPC

1

SAPC

0

APC2

APC1

APC0

PWCTR5

10.2.9

1 ↑ 1 - DCC7

DCC6

DCC5

DCC4

DCC3

DCC2

DCC1

DCC0

AP

C

: adjust the

operational amplifier

DCC

: adjust the booster

circuit for Idle mode

0 ↑ 1 - 1 1 0 0 0 1 0 1 (C5h)

VCOM control 1

VMCTR1

10.2.10

1 ↑ 1 - - -

VCOMS

5

VCOMS

4

VCOMS

3

VCOMS

2

VCOMS

1

VCOMS

0

VCOM voltage control

0 ↑ 1 - 1 1 0 0 0 1 1 1 (C7h)

Set VCOM offset control

VMOFCTR

10.2.11

1 ↑ 1 - - - - VMF4

VMF3

VMF2

VMF1

VMF0

0 ↑ 1 - 1 1 0 1 0 0 0 1 (D1h)

Set LCM version code

WRID2

10.2.12

1 ↑ 1 - - ID2[6]

ID2[5]

ID2[4]

ID2[3]

ID2[2]

ID2[1]

ID2[0]

“-“: Don’t care

Note 1: C0h to C7h are fixed for about power controller

13 (BEN 14 15 and ode 16 and CMD7 CMDB CMDE CMDA CMDS CMD2 CMD! CMDO

ST7735R

V0.2 124 2009-08-05

Table 10.2.3 Panel Function Command List (3)

Instruction

Refer

D/CX

WRX

RDX

D17-8

D7

D6

D5

D4

D3

D2

D1

D0

Hex

Function

0 ↑ 1 - 1 1 0 1 0 0 1 0 (D2h)

Customer Project

code

WRID3

10.2.13

1 ↑ 1 - ID37

ID36

ID35

ID34

ID33

ID32

ID31

ID30

Set the project code

at ID3

0 ↑ 1 - 1 1 0 1 1 0 0 1 (D9)

NVCTR1

10.2.14

1 ↑ 1 - 0 VMF

_EN

ID2

_EN

0 0 0 0 EXT_

R

NVM control status

0 ↑ 1 - 1 1 0 1 1 1 1 0 (DEh)

NVM Read Command

NVCTR2

10.2.15

1 ↑ 1 - 1 0 1 0 0 1 0 1 A5

Action code

0 ↑ 1 - 1 1 0 1 1 1 1 1 (DFh)

NVM Write Command

1 ↑ 1 - NVM_

IB7

NVM _

IB6

NVM _

IB5

NVM _

IB4

NVM _

IB3

NVM _

IB2

NVM _

IB1

NVM _

IB0

1 ↑ 1 - NVM _

CMD7

NVM _

CMD6

NVM _

CMD5

NVM _

CMD4

NVM _

CMD3

NVM _

CMD2

NVM _

CMD1

NVM _

CMD0

NVCTR3

10.2.16

1 ↑ 1 - 1 0 1 0 0 1 0 1 A5

“-“: Don’t care

Note 1: The D1h to D3h registers are fixed for about ID code setting.

Note 2: The D9h, DEh and DFh registers are used for NV Memory function controller. (Ex: write, clear, etc.)

, SELVD 5 53qu SELVON3 5mm 2 savam SELVOND

ST7735R

V0.2 125 2009-08-05

Table 10.2.4 Panel Function Command List (4)

Instruction

Refer

D/CX

WRX

RDXD17-8

D7

D6

D5 D4 D3 D2 D1 D0 Hex

Function

0

↑

1

- 1 1 1 0 0 0 0 0 (E0h)

Set

1

↑

1

- ---

---

VRFP[5]

VRFP[4] VRFP[3] VRFP[2] VRFP[1] VRF0P[0]

1

↑

1

- ---

---

VOS0P[5]

VOS0P[4]

VOS0P[3] VOS0P[2] VOS0P[1] VOS0P[0]

1

↑

1

- ---

---

PKP0[5]

PKP0[4] PKP0[3] PKP0[2] PKP0[1] PKP0[0]

1

↑

1

- ---

---

PKP1[5]

PKP1[4] PKP1[3] PKP1[2] PKP1[1] PKP1[0]

1

↑

1

- ---

---

PKP2[5]

PKP2[4] PKP2[3] PKP2[2] PKP2[1] PKP2[0]

1

↑

1

- ---

---

PKP3[5]

PKP3[4] PKP3[3] PKP3[2] PKP3[1] PKP3[0]

1

↑

1

- ---

---

PKP4[5]

PKP4[4] PKP4[3] PKP4[2] PKP4[1] PKP4[0]

1

↑

1

- ---

---

PKP5[5]

PKP5[4] PKP5[3] PKP5[2] PKP5[1] PKP5[0]

1

↑

1

- ---

---

PKP6[5]

PKP6[4] PKP6[3] PKP6[2] PKP6[1] PKP6[0]

1

↑

1

- ---

---

PKP7[5]

PKP7[4] PKP7[3] PKP7[2] PKP7[1] PKP7[0]

1

↑

1

- ---

---

PKP8[5]

PKP8[4] PKP8[3] PKP8[2] PKP8[1] PKP8[0]

1

↑

1

---

PKP9[5]

PKP9[4] PKP9[3] PKP9[2] PKP9[1] PKP9[0]

1

↑

1

- ---

---

SELV0P[5]

SELV0P[4]

SELV0P[3]

SELV0P[2]

SELV0P[1]

SELV0P[0]

1

↑

1

- ---

---

SELV1P[5]

SELV1P[4]

SELV1P[3]

SELV1P[2]

SELV1P[1]

SELV1P[0]

1

↑

1

---

SELV62P[5]

SELV62P[4]

SELV62P[3]

SELV62P[2]

SELV62P[1]

SELV62P[0]

GAMCTRP1

10.2.17

1

↑

1

- ---

---

SELV63P[5]

SELV63P[4]

SELV63P[3]

SELV63P[2]

SELV63P[1]

SELV63P[0]

Gamma

adjustment

(+ polarity)

0

↑

1

- 1 1

1 0 0 0 0 1

(E1h)

Set

1

↑

1

- ---

---

VRF0N[5]

VRF0N[4]

VRF0N[3] VRF0N[2] VRF0N[1] VRF0N[0]

1

↑

1

- ---

---

VOS0N[5]

VOS0N[4]

VOS0N[3] VOS0N[2] VOS0N[1] VOS0N[0]

1

↑

1

- ---

---

PKN0[5]

PKN0[4] PKN0[3] PKN0[2] PKN0[1] PKN0[0]

1

↑

1

- ---

---

PKN1[5]

PKN1[4] PKN1[3] PKN1[2] PKN1[1] PKN1[0]

1

↑

1

- ---

---

PKN2[5]

PKN2[4] PKN2[3] PKN2[2] PKN2[1] PKN2[0]

1

↑

1

- ---

---

PKN3[5]

PKN3[4] PKN3[3] PKN3[2] PKN3[1] PKN3[0]

1

↑

1

- ---

---

PKN4[5]

PKN4[4] PKN4[3] PKN4[2] PKN4[1] PKN4[0]

1

↑

1

- ---

---

PKN5[5]

PKN5[4] PKN5[3] PKN5[2] PKN5[1] PKN5[0]

1

↑

1

- ---

---

PKN6[5]

PKN6[4] PKN6[3] PKN6[2] PKN6[1] PKN6[0]

1

↑

1

- ---

---

PKN7[5]

PKN7[4] PKN7[3] PKN7[2] PKN7[1] PKN7[0]

1

↑

1

- ---

---

PKN8[5]

PKN8[4] PKN8[3] PKN8[2] PKN8[1] PKN8[0]

1

↑

1

- ---

---

PKN9[5]

PKN9[4] PKN9[3] PKN9[2] PKN9[1] PKN9[0]

1

↑

1

-

---

SELV0N[5]

SELV0N[4]

SELV0N[3]

SELV0N[2]

SELV0N[1]

SELV0

N[0]

1

↑

1

- ---

---

SELV1N[5]

SELV1N[4]

SELV1N[3]

SELV1N[2]

SELV1N[1]

SELV1N[0]

1

↑

1

- ---

---

SELV62N[5]

SELV62N[4]

SELV62N[3]

SELV62N[2]

SELV62N[1]

SELV62N[0]

GAMCTRN110.2.18

1

↑

1

- ---

---

SELV63N[5]

SELV63N[4]

SELV63N[3]

SELV63N[2]

SELV63N[1]

SELV63N[0]

Gamma

adjustment

(- polarity)

“-“: Don’t care

Note 1: E0-E1 registers are fixed for adjusting Gamma

V FRMCTR‘I 1st Parameter 2nd parameter I Sequential lransley ,

ST7735R

V0.2 126 2009-08-05

10.2.1 FRMCTR1 (B1h): Frame Rate Control (In normal mode/ Full colors)

B1H FRMCTR1 (Frame Rate Control)

Inst / Para D/CX

WRX

RDX

D17-8

D7

D6

D5

D4

D3

D2

D1

D0

HEX

FRMCTR1 0 ↑ 1 - 1 0 1 1 0 0 0 1

(B1h)

1

st

parameter

1 ↑ 1 - - -

- - RTNA3

RTNA2

RTNA1

RTNA0

2

nd

parameter

1 ↑ 1 - - -

FPA5 FPA4 FPA3 FPA2 FPA1 FPA0

3

rd

parameter

1 ↑ 1 - - -

BPA5 BPA4 BPA3 BPA2 BPA1 BPA0

Description

-Set the frame frequency of the full colors normal mode.

- Frame rate=fosc/((RTNA x 2 + 40) x (LINE + FPA + BPA))

-fosc = 625kHz

Default

Status Default Value

GM[1:0] = “00” GM[1:0] = “11”

Power On Sequence 01h/2Ch/2Dh 01h/2Ch/2Bh

S/W Reset 01h/2Ch/2Dh 01h/2Ch/2Bh

H/W Reset 01h/2Ch/2Dh 01h/2Ch/2Bh

Flow Chart

w I FRMCTF22 Parameter /I | Display \\ / / 1st Parameter \ 2nd parameter Action \ / SeCluenlial Minster , |————

ST7735R

V0.2 127 2009-08-05

10.2.2 FRMCTR2 (B2h): Frame Rate Control (In Idle mode/ 8-colors)

B2H FRMCTR2 (Frame Rate Control)

Inst / Para D/CX

WRX

RDX

D17-8

D7

D6

D5 D4 D3 D2 D1 D0

HEX

FRMCTR2 0 ↑ 1 - 1 0 1 1 0 0 1 0

(B2h)

1

st

parameter

1

↑ 1

- - -

- - RTNB3

RTNB2

RTNB1

RTNB0

2

nd

parameter

1

↑ 1

- - -

FPB5 FPB4 FPB3 FPB2 FPB1 FPB0

3

rd

parameter

1

↑ 1

- - -

BPB5 BPB4 BPB3 BPB2 BPB1 BPB0

Description

-Set the frame frequency of the Idle mode.

- Frame rate=fosc/((RTNB x 2 + 40) x (LINE + FPB + BPB))

-fosc = 625kHz

Default

Status Default Value

GM[1:0] = “00” GM[1:0] = “11”

Power On Sequence 01h/2Ch/2Dh 01h/2Ch/2Bh

S/W Reset 01h/2Ch/2Dh 01h/2Ch/2Bh

H/W Reset 01h/2Ch/2Dh 01h/2Ch/2Bh

Flow Chart

V FRMCTRG 1st Parameter | 6nd parameter Sequential lranslef ,

ST7735R

V0.2 128 2009-08-05

10.2.3 FRMCTR3 (B3h): Frame Rate Control (In Partial mode/ full colors)

B3H FRMCTR3 (Frame Rate Control)

Inst / Para D/CX

WRX

RDX

D17-8

D7

D6

D5 D4 D3 D2 D1 D0 HE

FRMCTR3 0 ↑ 1 - 1 0 1 1 0 0 1 1 (B3

1

st

parameter

1

↑ 1

- - - - - RTNC RTNC RTNC RTNC

2

nd

parameter

1

↑ 1

- - - FPC5

FPC4

FPC3

FPC2

FPC1

FPC0

3

rd

parameter

1

↑ 1

- - - BPC5

BPC4

BPC3

BPC2

BPC1

BPC0

4

th

parameter

1

↑ 1

- - - - - RTND RTND RTND RTND

5

th

parameter

1

↑ 1

- - - FPD5

FPD4

FPD3

FPD2

FPD1

FPD0

6

th

parameter

1

↑ 1

- - - BPD5

BPD4

BPD3

BPD2

BPD1

BPD0

Description

-Set the frame frequency of the Partial mode/ full colors.

- 1st parameter to 3rd parameter are used in dot inversion mode.

- 4th parameter to 6th parameter are used in line inversion mode.

- Frame rate=fosc/((RTNC x 2 + 40) x (LINE + FPC + BPC))

-fosc = 625kHz

Default

Status Default Value

GM[1:0] = “00” GM[1:0] = “11”

Power On Sequence 01h/2Ch/2Dh/01h/2Ch/2Dh 01h/2Ch/2Bh/01h/2Ch/2Bh

S/W Reset 01h/2Ch/2Dh/01h/2Ch/2Dh 01h/2Ch/2Bh/01h/2Ch/2Bh

H/W Reset 01h/2Ch/2Dh/01h/2Ch/2Dh 01h/2Ch/2Bh/01h/2Ch/2Bh

Flow Chart

NLC INVCTR / | I I

ST7735R

V0.2 129 2009-08-05

10.2.4 INVCTR (B4h): Display Inversion Control

B4H INVCTR (Display Inversion Control)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

INVCTR 0 ↑ 1 - 1 0 1 1 0 1 0 0 (B4h)

Parameter 1 ↑ 1 - 0 0 0 0 0 NLA

NLB

NLC

Description

-Display Inversion mode control

-NLA: Inversion setting in full colors normal mode (Normal mode on)

NLA Inversion setting in full Colors normal mode

0 Dot Inversion

1 Line Inversion

-NLB: Inversion setting in Idle mode (Idle mode on)

NLB Inversion setting in Idle mode

0 Dot Inversion

1 Line Inversion

-NLC: Inversion setting in full colors partial mode (Partial mode on / Idle mode off)

NLC Inversion setting in full Colors partial mode

0 Dot Inversion

1 Line Inversion

Default

Status Default Value

B4h

Power On Sequence 03h

S/W Reset 03h

H/W Reset 03h

Flow Chart

4 RHN4 RHN3 RHNZ RHN1 RHNO

ST7735R

V0.2 130 2009-08-05

10.2.5 PWCTR1 (C0h): Power Control 1

C0H PWCTR1 (Power Control 1)

Inst / Para

D/CX WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

PWCTR1 0 ↑ 1 - 1 1 0 0 0 0 0 0 (C0h)

1

st

parameter

1 ↑ 1 - AVDD[2]

AVDD[1]

AVDD[0]

VRHP4

VRHP3

VRHP2

VRHP1

VRHP0

2

nd

parameter

1 ↑ 1 - 0 0 0 VRHN4

VRHN3

VRHN2

VRHN1

VRHN0

3

rd

parameter

1 ↑ 1 - MODE[1]

MODE[0] 0 0 0 1 0 0

Description

AVDD[2:0] AVDD MODE[1:0] FUNCTION

000 4.5 00 2X

001 4.6 01 3X

010 4.7 10 AUTO

011 4.8 11 3X

100 4.9

101 5

110 5.1

111 Don’t use this setting,

reserve for testing.

VRHP[4:0] GVDD VRHN[4:0] GVCL

00000 4.7 00000 -4.7

00001 4.65 00001 -4.65

00010 4.6 00010 -4.6

00011 4.55 00011 -4.55

00100 4.5 00100 -4.5

00101 4.45 00101 -4.45

00110 4.4 00110 -4.4

00111 4.35 00111 -4.35

01000 4.3 01000 -4.3

01001 4.25 01001 -4.25

01010 4.2 01010 -4.2

01011 4.15 01011 -4.15

01100 4.1 01100 -4.1

01101 4.05 01101 -4.05

01110 4 01110 -4

01111 3.95 01111 -3.95

10000 3.9 10000 -3.9

10001 3.85 10001 -3.85

10010 3.8 10010 -3.8

10011 3.75 10011 -3.75

10100 3.7 10100 -3.7

10101 3.65 10101 -3.65

10110 3.6 10110 -3.6

10111 3.55 10111 -3.55

11000 3.5 11000 -3.5

11001 3.45 11001 -3.45

11010 3.4 11010 -3.4

11011 3.35 11011 -3.35

11100 3.3 11100 -3.3

11101 3.25 11101 -3.25

11110 3.2 11110 -3.2

11111 3.15 11111 -3.15

'____ Legend ' '| Command I 77 PWCTR1 / 151 Parameter 2nd parameter Sequenlial Iranslef ,

ST7735R

V0.2 131 2009-08-05

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out Yes

Partial Mode On, Idle Mode On, Sleep Out Yes

Sleep In Yes

Default

Status Default Value

C0h

Power On Sequence 82h/02h/84h

S/W Reset 82h/02h/84h

H/W Reset 82h/02h/84h

Flow Chart

Delault Value

ST7735R

V0.2 132 2009-08-05

10.2.6 PWCTR2 (C1h): Power Control 2

C1H PWCTR2 (Power Control 2)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4

D3 D2 D1 D0 HEX

PWCTR2

0

↑ 1 - 1 1 0 0 0 0 0 1 (C1h)

1

st

parameter

1

↑ 1 VGH25[1]

VGH25[0]

- - VGLSEL[1]

VGLSEL[0]

VGHBT[1]

VGHBT[0]

Description

-Set the VGH and VGL supply power level

VGH25[1:0] V25

00 2.1

01 2.2

10 2.3

11 2.4

VGHBT[1:0] VGH

00 2*AVDD+VGH25

01 3*AVDD

10 3*AVDD+VGH25

11 Don’t use this setting, reserve for testing.

VGLSEL[1:0] VGL

00 -7.5

01 -10

10 -12.5

11 -13

Restriction

-The deviation value of VGH/ VGL between with Measurement and Specification: Max <= 1V

-VGH-VGL <= 32V

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out Yes

Partial Mode On, Idle Mode On, Sleep Out Yes

Sleep In Yes

Default

Status Default Value

C1h

Power On Sequence C5h

S/W Reset C5h

H/W Reset C5h

PWCTR2 1:! Parameter [ Command Parameter Seq uemial tra nsxa

ST7735R

V0.2 133 2009-08-05

Flow Chart

ST7735R

V0.2 134 2009-08-05

10.2.7 PWCTR3 (C2h): Power Control 3 (in Normal mode/ Full colors)

C2H PWCTR3 (Power Control 3)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

PWCTR3 0 ↑ 1 - 1 1 0 0 0 0 1 0 (C2h)

1

st

parameter

1 ↑ 1 - DCA9

DCA8

SAPA2

SAPA1

SAPA0

APA2

APA1

APA0

2

nd

parameter

1 ↑ 1 - DCA7

DCA6

DCA5

DCA4

DCA3

DCA2

DCA1

DCA0

Description

-Set the amount of current in Operational amplifier in normal mode/full colors.

-Adjust the amount of fixed current from the fixed current source in the operational amplifier for the source

driver.

AP[2:0] Amount of Current in Operational Amplifier

000 Operation of the operational amplifier stops

001 Small

010 Medium Low

011 Medium

100 Medium High

101 Large

110 Reserved

111 Reserved

SAP[2:0] Amount of Current in Operational Amplifier

000 Operation of the operational amplifier stops

001 Small

010 Medium Low

011 Medium

100 Medium High

101 Large

110 Reserved

111 Reserved

-Set the Booster circuit Step-up cycle in Normal mode/ full colors.

DCA[9:8] DCA[7:6] DCA[5:4] DCA[3:2] DCA[1:0]

00 BCLK/1 BCLK/1 BCLK/1 BCLK/1 BCLK/1

01 BCLK/1.5 BCLK/1.5 BCLK/1.5 BCLK/1.5 BCLK/1.5

10 BCLK/2 BCLK/2 BCLK/2 BCLK/2 BCLK/2

11 BCLK/4 BCLK/4 BCLK/4 BCLK/4 BCLK/4

Note: BCLK is Clock frequency for Booster circuit

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out Yes

Partial Mode On, Idle Mode On, Sleep Out Yes

Sleep In Yes

Default

Status Default Value

C2h

Power On Sequence 0Ah/00h

S/W Reset 0A h/00h

H/W Reset 0A h/00h

PWCTR3 } Isl Parameter 2nd paramexer

ST7735R

V0.2 135 2009-08-05

Flow Chart

ST7735R

V0.2 136 2009-08-05

10.2.8 PWCTR4 (C3h): Power Control 4 (in Idle mode/ 8-colors)

C3H PWCTR4 (Power Control 4)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

PWCTR4 0 ↑ 1 - 1 1 0 0 0 0 1 1 (C3h)

1

st

parameter

1 ↑ 1 - DCB9

DCB8

SAPB2

SAPB1

SAPB0

APB2

APB1

APB0

2

nd

parameter

1 ↑ 1 - DCB7

DCB6

DCB5

DCB4

DCB3

DCB2

DCB1

DCB0

Description

-Set the amount of current in Operational amplifier in Idle mode/8 colors.

-Adjust the amount of fixed current from the fixed current source in the operational amplifier for the source

driver.

AP[2:0] Amount of Current in Operational Amplifier

000 Operation of the operational amplifier stops

001 Small

010 Medium Low

011 Medium

100 Medium High

101 Large

110 Reserved

111 Reserved

SAP[2:0] Amount of Current in Operational Amplifier

000 Operation of the operational amplifier stops

001 Small

010 Medium Low

011 Medium

100 Medium High

101 Large

110 Reserved

111 Reserved

-Set the Booster circuit Step-up cycle in Idle mode/8 colors.

DCB[9:8] DCB[7:6] DCB[5:4] DCB[3:2] DCB[1:0]

00 BCLK/1 BCLK/1 BCLK/1 BCLK/1 BCLK/1

01 BCLK/1.5 BCLK/1.5 BCLK/1.5 BCLK/1.5 BCLK/1.5

10 BCLK/2 BCLK/2 BCLK/2 BCLK/2 BCLK/2

11 BCLK/4 BCLK/4 BCLK/4 BCLK/4 BCLK/4

Note: BCLK is Clock frequency for Booster circuit

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out Yes

Partial Mode On, Idle Mode On, Sleep Out Yes

Sleep In Yes

Default

Status Default Value

C3h

Power On Sequence 8Ah/2Eh

S/W Reset 8Ah/2Eh

H/W Reset 8Ah/2Eh

PWCTRA 151 Parameter 2nd paramelar "___| I Legend | mm | 7 | I/W/I | Display Amen Sequenual «ansxer ,

ST7735R

V0.2 137 2009-08-05

Flow Chart

ST7735R

V0.2 138 2009-08-05

10.2.9 PWCTR5 (C4h): Power Control 5 (in Partial mode/ full-colors)

C4H PWCTR5 (Power Control 5)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

PWCTR5 0 ↑ 1 - 1 1 0 0 0 1 0 0 (C4h)

1

st

parameter

1 ↑ 1 - DCC9

DCC8

SAPC2

SAPC1

SAPC0

APC2

APC1

APC0

2

nd

parameter

1 ↑ 1 - DCC7

DCC6

DCC5

DCC4

DCC3

DCC2

DCC1

DCC0

Description

-Set the amount of current in Operational amplifier in Partial mode/ full-colors.

-Adjust the amount of fixed current from the fixed current source in the operational amplifier for the source

driver.

AP[2:0] Amount of Current in Operational Amplifier

000 Operation of the operational amplifier stops

001 Small

010 Medium Low

011 Medium

100 Medium High

101 Large

110 Reserved

111 Reserved

SAP[2:0] Amount of Current in Operational Amplifier

000 Operation of the operational amplifier stops

001 Small

010 Medium Low

011 Medium

100 Medium High

101 Large

110 Reserved

111 Reserved

-Set the Booster circuit Step-up cycle in Partial mode/ full-colors.

DCC[9:8] DCC[7:6] DCC[5:4] DCC[3:2] DCC[1:0]

00 BCLK/1 BCLK/1 BCLK/1 BCLK/1 BCLK/1

01 BCLK/1.5 BCLK/1.5 BCLK/1.5 BCLK/1.5 BCLK/1.5

10 BCLK/2 BCLK/2 BCLK/2 BCLK/2 BCLK/2

11 BCLK/4 BCLK/4 BCLK/4 BCLK/4 BCLK/4

Note: BCLK is Clock frequency for Booster circuit

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out Yes

Partial Mode On, Idle Mode On, Sleep Out Yes

Sleep In Yes

Default

Status Default Value

C4h

Power On Sequence 8Ah/AAh

S/W Reset 8Ah/AAh

H/W Reset 8Ah/AAh

ST7735R

V0.2 139 2009-08-05

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

PWCTR5

1st Parameter

2nd parameter

ST7735R

V0.2 140 2009-08-05

10.2.10 VMCTR1 (C5h): VCOM Control 1

C5H VMCTR1 (VCOM Control 1)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

VMCTR1 0 ↑ 1 - 1 1 0 0 0 1 0 1 (C5h)

1

st

parameter

1 ↑ 1 - - -

VCOMS5

VCOMS 4

VCOMS 3

VCOMS 2

VCOMS 1

VCOMS 0

Description

VCOM voltage setting.

VCOMS

[5:0] VCOM

VCOMS

[5:0] VCOM

VCOMS

[5:0] VCOM

VCOMS

[5:0] VCOM

0

000000

-0.425 16

010000

-0.825 32

100000

-1.225

48

110000

-1.625

1

000001

-0.45 17

010001

-0.85 33

100001

-1.25 49

110001

-1.65

2

000010

-0.475 18

010010

-0.875 34

100010

-1.275

50

110010

-1.675

3

000011

-0.5 19

010011

-0.9 35

100011

-1.3 51

110011

-1.7

4

000100

-0.525 20

010100

-0.925 36

100100

-1.325

52

110100

-1.725

5

000101

-0.55 21

010101

-0.95 37

100101

-1.35 53

110101

-1.75

6

000110

-0.575 22

010110

-0.975 38

100110

-1.375

54

110110

-1.775

7

000111

-0.6 23

010111

-1 39

100111

-1.4 55

110111

-1.8

8

001000

-0.625 24

011000

-1.025 40

101000

-1.425

56

111000

-1.825

9

001001

-0.65 25

011001

-1.05 41

101001

-1.45 57

111001

-1.85

10

001010

-0.675 26

011010

-1.075 42

101010

-1.475

58

111010

-1.875

11

001011

-0.7 27

011011

-1.1 43

101011

-1.5 59

111011

-1.9

12

001100

-0.725 28

011100

-1.125 44

101100

-1.525

60

111100

-1.925

13

001101

-0.75 29

011101

-1.15 45

101101

-1.55 61

111101

-1.95

14

001110

-0.775 30

011110

-1.175 46

101110

-1.575

62

111110

-1.975

15

001111

-0.8 31

011111

-1.2 47

101111

-1.6 63

111111

-2

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out Yes

Partial Mode On, Idle Mode On, Sleep Out Yes

Sleep In Yes

Default

Status Default Value

C5h

Power On Sequence 04h

S/W Reset 04h

H/W Reset 04h

/ VMCTR1 1st Parameter 2nd parameter / "__—| I Legendr I Command ' I I Parameter Display j Sequential lransleL ,

ST7735R

V0.2 141 2009-08-05

Flow Chart

VMOFCTR (cm i VMFIAC'] Enable CMD DBh Pmaaon l Momly VMFI‘ a] veg‘sm, CMD cm Pave xxh i vmmu} msame CMD Dan Pam Don L // EEPROM pron Now/ / / Legend Command Parame|ev Dwsn‘a Made | | l | | y | . | | | | | 5mm "5.45.9; V

ST7735R

V0.2 142 2009-08-05

10.2.11 VMOFCTR (C7h): VCOM Offset Control

C7H VMOFCTR (VCOM Offset Control)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

VMOFCTR

0 ↑ 1 - 1 1 0 0 0 1 1 1 (C7h)

Parameter

1 ↑ 1 - - - - VMF4

VMF3

VMF2

VMF1

VMF0

Description

-Set VCOM Voltage level for reduce the flicker issue

-Before use command 0xC7, the bit VMF_EN of command 0xD9 must be enabled (set to 1).

VMF[4] VMF[3:0] VCOM Output Level

0 0000 “VCOMS”-16d

0 0001 “VCOMS”-15d

0 | |

0 1110 “VCOMS”-2d

0 1111 “VCOMS”-1d

1 0000 “VCOMS”

1 0001 “VCOMS”+1d

1 0010 “VCOMS”+2d

1 | |

1 1110 “VCOMS”+14d

1 1111 “VCOMS”+15d

- 1d=25mV, 2d=50mV 3d=75mv....

Register

Availability

Status Availability

Normal Mode On, Idle Mode Off, Sleep Out Yes

Normal Mode On, Idle Mode On, Sleep Out Yes

Partial Mode On, Idle Mode Off, Sleep Out Yes

Partial Mode On, Idle Mode On, Sleep Out Yes

Sleep In Yes

Default

Status Default Value

C7h

Power On Sequence 10h

S/W Reset 10h

H/W Reset 10h

Flow Chart

|D21 \DZO , , |D26 \D25 \D24 |D23 |D22 Parameter NVCTR3(D1h) V ID2[6:O] Enable CMD D9h , / Para 10h /, V ModiVy ID2[6:0] register , CMD D1h Para ><>

ST7735R

V0.2 143 2009-08-05

10.2.12 WRID2 (D1h): Write ID2 Value

D1H WRID2 (Write ID2 Value)

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

WRID2 0 ↑ 1 - 1 1 0 1 0 0 0 1 (D1h)

Parameter

1

↑

1

-

ID26

ID25

ID24

ID23

ID22

ID21

ID20

-

Description

-Write 7-bit data of LCD module version to save it to NVM.

-The parameter ID2[6:0] is LCD Module version ID.

Flow Chart

(Dzh) D35 ”NWRIDS (D2h) 1st Parameter I I \\ / I (/ Actio \ I \_/ I \ I / I Sequenlia tranlsler I

ST7735R

V0.2 144 2009-08-05

10.2.13 WRID3 (D2h): Write ID3 Value

D2H WRID3 (Write ID3 Value)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

WRID3 0 ↑ 1 - 1 1 0 1 0 0 1 0 (D2h)

Parameter 1 ↑ 1 - ID37

ID36

ID35

ID34

ID33

ID32

ID31

ID30

-

Description -Write 8-bit data of project code module to save it to NVM.

-The parameter ID3[7:0] is product project ID.

Flow Chart

NVFCTR (Ugh) / 1st Parameter / / / Acllon I Sequenlial I lransqu

ST7735R

V0.2 145 2009-08-05

10.2.14 NVFCTR1 (D9h): NVM Control Status

D9H NVFCTR1 (NV Memory Function Controller 1)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

NVFCTR1 0 ↑ 1 - 1 1 0 0 1 0 0 1 (D9h)

parameter 1 1 ↑ - 0 VMF_EN

ID2_EN

0 0 0 0 EXT_R

Description

-NVM control status

Bit Value

VMF_EN “1” = Command C7h enable ; “0” = Command C7h disable

ID2_EN “1” = Command D1h enable ; “0” = Command D1h disable

EXT_R Read: extension command status, “1” for enable, “0” for disable.

Write: Don’t care

Default

Status Default Value

D9h

Power On Sequence 00h

S/W Reset 00h

H/W Reset 00h

Flow Chart

___'| Legend Command NVFCTRZ / Parameter/ | | 1 /| _ Dﬁphy \I \ , | 1st Para: F577 I | | | | _| / 2'“ Para : A577 / Action Mode \ , / Sequenua‘ Iransler , | | | | | / | | | | | |

ST7735R

V0.2 146 2009-08-05

10.2.15 NVFCTR2 (DEh): NVM Read Command

DEH NVFCTR1 (NV Memory Function Controller 2)

Inst / Para D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

NVFCTR2 0 ↑ 1 - 1 1 0 1 1 1 1 0 (DEh)

1

st

parameter 1 ↑ 1 1 1 1 1 0 1 0 1 F5

2

nd

parameter 1 ↑ 1 1 0 1 0 0 1 0 1 A5

Description NVM Read Command

NOTE: “-“ Don’t care

Flow Chart

1||lll||l||||

ST7735R

V0.2 147 2009-08-05

10.2.16 NVFCTR3 (DFh): NVM Write Command

DFH NVFCTR1 (NV Memory Function Controller 3

Inst / Para

D/CX

WRX

RDX

D17-8

D7 D6 D5 D4 D3 D2 D1 D0 HEX

NVFCTR1

0 ↑ 1

- 1 1 0 1 1 1 1 1 (DFh)

1

st

parameter

1 ↑ 1

NVM_CMD7

NVM_CMD6

NVM_CMD5

NVM_CMD4

NVM_CMD3

NVM_CMD2

NVM_CMD1

NVM_CMD0

2

nd

parameter

1 ↑ 1

1 0 1 0 0 1 0 1 A5

Description

-NVM Write Command

-NVM_CMD[7:0] : Select to Program/Erase ; Program command : 3Ah ; Erase command : C5h

NOTE: “-“ Don’t care

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

Wait 20ms

Modify CMD register

(C7h/D1h/D2h)

Enable NVM :

EXTC = “1”

CMD F1h, 44h

External VPP = 7.5V ON

NVM Program Flow

Erase

CMD DFh

1st Para C5h

2nd Para A5h

Program

CMD DFh

1st Para 3Ah

2nd Para A5h

Wait 20ms

Disable NVM :

EXTC = “0”

CMD F1h, 04h

External VPP = 7.5V OFF

D1775 [4 Register Group Positive Polarity Sewn Contents Hrgh level adlustmenl VRFOP[5,0] Variable reSlslor VRHP SELVUP[5,0] The voltage at vo grayscale is selected by the 64 tc l selector SELVI P[5,0] The voltage at Vt grayscale is selected by the 64 tc l selector PKOP[5.U] The voltage at v3 grayscale is selected by the 64 tc l selector PK1P[5.U] The voltage at v4 grayscale is selected by the 64 tc l selector PK2P[5.U] The voltage at V12 grayscale is selected by the 64 tc l selector PK3P[5.U] The voltage at v20 grayscale is selected by the 64 tc l selector PK4P[5.U] The voltage at V28 grayscale is selected b the 64 tc l selector PK5P[5.U] The voltage at v35 grayscale is selected by the 64 tc l selector PK6P[5.U] The voltage at v44 grayscale is selected b the 64 tc l selector PK7P[5.U] The voltage at v52 grayscale is selected b the 64 tc l selector PKaP[5.U] The voltage at v55 grayscale is selected by the 64 tc l selector PK9P[5.U] The voltage at Van grayscale is selected b the 64 tc l selector SELV62P[5 0] The voltage at v52 grayscale is selected by the 64 tc l selector SELV63P[5 0] The voltage at v53 grayscale is selected by the 64 tc l selector Low level adjustment VosuP[5 0] Variable reSlslor VRLP

ST7735R

V0.2 148 2009-08-05

10.2.17 GMCTRP1 (E0h): Gamma (‘+’polarity) Correction Characteristics Setting

E0H GMCTRP0 (Gamma ‘+’polarity Correction Characteristics Setting)

Inst / Para

D/CX

WRX

RDX

D17-8

D7

D6

D5 D4 D3 D2 D1 D0 HEX

GMCTRP1

0

↑

1

- 1

1

1 0 0 0 0 0 (E0h)

1

st

parameter

1

↑

1

- -

- VRF0P[5]

VRF0P[4]

VF0P[3]

VRF0P[2]

VRF0P[1]

VRF0P[0]

2

nd

parameter

1

↑

1

- -

- VOS0P[5]

VOS0P[4]

VOS0P[3]

VOS0P[2]

VOS0P[1]

VOS0P[0]

3

rd

parameter

1

↑

1

- -

- PK0P[5]

PK0P[4]

PK0P[3]

PK0P[2]

PK0P[1]

PK0P[0]

4

th

parameter

1

↑

1

- -

- PK1P[5]

PK1P[4]

PK1P[3]

PK1P[2]

PK1P[1]

PK1P[0]

5

th

parameter

1

↑

1

- -

- PK2P[5]

PK2P[4]

PK2P[3]

PK2P[2]

PK2P[1]

PK2P[0]

6

th

parameter

1

↑

1

- -

- PK3P[5]

PK3P[4]

PK3P[3]

PK3P[2]

PK3P[1]

PK3P[0]

7

th

parameter

1

↑

1

- -

- PK4P[5]

PK4P[4]

PK4P[3]

PK4P[2]

PK4P[1]

PK4P[0]

8

th

parameter

1

↑

1

- -

- PK5P[5]

PK5P[4]

PK5P[3]

PK5P[2]

PK5P[1]

PK5P[0]

9

th

parameter

1

↑

1

- -

- PK6P[5]

PK6P[4]

PK6P[3]

PK6P[2]

PK6P[1]

PK6P[0]

10

th

parameter

1

↑

1

- -

- PK7P[5]

PK7P[4]

PK7P[3]

PK7P[2]

PK7P[1]

PK7P[0]

11

th

parameter

1

↑

1

- -

- PK8P[5]

PK8P[4]

PK8P[3]

PK8P[2]

PK8P[1]

PK8P[0]

12

th

parameter

1

↑

1

- -

- PK9P[5]

PK9P[4]

PK9P[3]

PK9P[2]

PK9P[1]

PK9P[0]

13

th

parameter

1

↑

1

- -

- SELV0P[5]

SELV0P[4]

SELV0P[3]

SELV0P[2]

SELV0P[1]

SELV0P[0]

14

th

parameter

1

↑

1

- -

- SELV1P[5]

SELV1P[4]

SELV1P[3]

SELV1P[2]

SELV1P[1]

SELV1P[0]

15

th

parameter

1

↑

1

- -

- SELV62P[5]

SELV62P[4]

SELV62P[3]

SELV62P[2]

SELV62P[1]

SELV62P[0]

16

th

parameter

1

↑

1

- -

- SELV63P[5]

SELV63P[4]

SELV63P[3]

SELV63P[2]

SELV63P[1]

SELV63P[0]

Description

Register Group

Positive

Polarity

Set

-

up Contents

High level adjustment

V

RF

0P

[

5

:0]

Variable resistor VRHP

SELV0P

[5:0]

The voltage of

V0

grayscale is selected by the 64 to 1 sele

ctor

SELV1P

[5:0]

The voltage of

V1

grayscale

is selected by the 64 to 1 selector

PK

0P

[5:0]

The voltage of

V3

grayscale

is selected by the 64 to 1 selector

PK

1P

[5:0]

The voltage of

V

4

grayscale

is selected by the 64 to 1 selector

PK

2P

[5:0]

The volta

ge of

V1

2

grayscale

is selected by the 64 to 1 selector

PK

3P

[5:0]

The voltage of

V

20

grayscale is selected by the 64 to 1 selector

PK

4P

[5:0]

The voltage of

V

28

grayscale is selected by the 64 to 1 selector

PK

5P

[5:0]

The voltage of

V36

grayscale is se

lected by the 64 to 1 selector

PK

6P

[5:0]

The voltage of

V44

grayscale

is selected by the 64 to 1 selector

PK

7P

[5:0]

The voltage of

V52

grayscale

is selected by the 64 to 1 selector

PK

8P

[5:0]

The voltage of

V5

6

grayscale

is selected by the 64 to 1 sel

ector

PK

9P

[5:0]

The voltage of

V60

grayscale

is selected by the 64 to 1 selector

SELV62P

[5:0]

The voltage of

V62

grayscale

is selected by the 64 to 1 selector

Mid level adjustment

SELV63P

[5:0]

The voltage of

V63

grayscale

is selected by the 64 to 1 selector

Low level ad

justment

V

OS

0P

[

5

:0]

Variable resistor VRLP

ST7735R

V0.2 149 2009-08-05

Flow Chart

CX DI 775 e e e e e e S S S S S S e S S S S S S Register Graun Negative Falamv Setrun Contents Htgh tewet adtustment VRFON[5.0] Vanabte resistar VRHN SELVON[5.0] The wattage 0| v0 grayscate ts setected by the 64 ta t setector SELV1N[5.0] The wattage 0| Vt gra scate ts setected b the 64 tat setector PKUN[5.U] The wattage 0| v3 grayscate ts setected by the 64 ta t setector PKIN[5.U] The wattage at V4 grayscate ts setected by the 64 ta t setector PK2N[5.U] The wattage 0| V12 grayscate t5 setected by the 64 to t seteclctr PK3N[5.U] The wattage 0| v2u grayscate t5 setected by the 64 to t seteclctr PK4N[5.U] The wattage 0| v25 grayscate t5 setected by the 64 to t seteclctr PK5N[5.U] The wattage 0| V36 grayscate t5 setected by the 64 to t seteclctr PK6N[5.U] The wattage 0| v44 grayscate t5 setected by the 64 to t seteclctr PK7N[5.U] The wattage 0| v52 grayscate t5 setected by the 64 to t seteclctr PKaNtsm The wattage at we grayscate t5 setected by the 64 to t seteclctr PKgNtsm The wattage at Van grayscate t5 setected by the 64 to t seteclctr SELV62N[5,0] The wattage 0| vez grayscate t5 setected by the 64 to t seteclctr SELV63N[5,0] The wattage 0| vea grayscate t5 setected by the 64 to t seteclctr Lctw tewet adtustment vosoNtsm Vanabte resistar VRLN

ST7735R

V0.2 150 2009-08-05

10.2.18 GMCTRN1 (E1h): Gamma ‘-’polarity Correction Characteristics Setting

E1H GMCTRP0 (Gamma ‘+’polarity Correction Characteristics Setting)

Inst / Para

D/CX

WRX

RDX

D17-8

D7

D6

D5 D4 D3 D2 D1 D0 HEX

GMCTRP1

0 ↑ 1 - 1 1 1 0 0 0 0 1 (E1h)

1

st

parameter

1 ↑ 1 - - - VRF0N[5]

VRF0N[4]

VF0N[3]

VRF0N[2]

VRF0N[1]

VRF0N[0]

2

nd

parameter

1 ↑ 1 - - - VOS0N[5]

VOS0N[4]

VOS0N[3]

VOS0N[2]

VOS0N[1]

VOS0N[0]

3

rd

parameter

1 ↑ 1 - - - PK0N[5]

PK0N[4]

PK0N[3]

PK0N[2]

PK0N[1]

PK0N[0]

4

th

parameter

1 ↑ 1 - - - PK1N[5]

PK1N[4]

PK1N[3]

PK1N[2]

PK1N[1]

PK1N[0]

5

th

parameter

1 ↑ 1 - - - PK2N[5]

PK2N[4]

PK2N[3]

PK2N[2]

PK2N[1]

PK2N[0]

6

th

parameter

1 ↑ 1 - - - PK3N[5]

PK3N[4]

PK3N[3]

PK3N[2]

PK3N[1]

PK3N[0]

7

th

parameter

1 ↑ 1 - - - PK4N[5]

PK4N[4]

PK4N[3]

PK4N[2]

PK4N[1]

PK4N[0]

8

th

parameter

1 ↑ 1 - - - PK5N[5]

PK5N[4]

PK5N[3]

PK5N[2]

PK5N[1]

PK5N[0]

9

th

parameter

1 ↑ 1 - - - PK6N[5]

PK6N[4]

PK6N[3]

PK6N[2]

PK6N[1]

PK6N[0]

10

th

parameter

1 ↑ 1 - - - PK7N[5]

PK7N[4]

PK7N[3]

PK7N[2]

PK7N[1]

PK7N[0]

11

th

parameter

1 ↑ 1 - - - PK8N[5]

PK8N[4]

PK8N[3]

PK8N[2]

PK8N[1]

PK8N[0]

12

th

parameter

1 ↑ 1 - - - PK9[5] PK9N[4]

PK9N[3]

PK9N[2]

PK9N[1]

PK9N[0]

13

th

parameter

1 ↑ 1 - - - SELV0N[5]

SELV0N[4]

SELV0N[3]

SELV0N[2]

SELV0N[1]

SELV0N[0]

14

th

parameter

1 ↑ 1 - - - SELV1N[5]

SELV1N[4]

SELV1N[3]

SELV1N[2]

SELV1N[1]

SELV1N[0]

15

th

parameter

1 ↑ 1 - - - SELV62N[5]

SELV62N[4]

SELV62N[3]

SELV62N[2]

SELV62N[1]

SELV62N[0]

16

th

parameter

1 ↑ 1 - - - SELV63N[5]

SELV63N[4]

SELV63N[3]

SELV63N[2]

SELV63N[1]

SELV63N[0]

Description

Register Group

Negative Polarity

Set

-

up Contents

High level adjustment

V

RF

0N

[

5

:0]

Variable resistor VRH

N

SELV0N

[5:0]

The voltage of

V0

gra

yscale is selected by the 64 to 1 selector

SELV1N

[5:0]

The voltage of

V1

grayscale is selected by the 64 to 1 selector

PK

0N

[5:0]

The voltage of

V3

grayscale is selected by the 64 to 1 selector

PK

1N

[5:0]

The voltage of

V

4

g

rayscale

is selected by the

64 to 1 selector

PK

2N

[5:0]

The voltage of

V1

2

grayscale is selected by the 64 to 1 selector

PK

3N

[5:0]

The voltage of

V

20

grayscale is selected by the 64 to 1 selector

PK

4N

[5:0]

The voltage of

V2

8

grayscale is selected by the 64 to 1 selector

PK

5N

[5

:0]

The voltage of

V36

grayscale is selected by the 64 to 1 selector

PK

6N

[5:0]

The voltage of

V44

grayscale is selected by the 64 to 1 selector

PK

7N

[5:0]

The voltage of

V52

grayscale is selected by the 64 to 1 selector

PK

8N

[5:0]

The voltage of

V5

6

gr

ayscale is selected by the 64 to 1 selector

PK

9N

[5:0]

The voltage of

V60

grayscale is selected by the 64 to 1 selector

SELV62N

[5:0]

The voltage of

V62

grayscale is selected by the 64 to 1 selector

Mid level adjustment

SELV63N

[5:0]

The voltage of

V63

grayscale is selected

by the 64 to 1 selector

Low level adjustment

V

OS

0N

[

5

:0]

Variable resistor VRL

N

ST7735R

V0.2 151 2009-08-05

Flow Chart

Command

Parameter

Display

Action

Mode

Legend

Sequential

transter

GMCTRN1

1st Parameter

2nd Parameter

|

VDD=2.3 V "4.8V AGN D=0V VGH=10V~15V / AVDD=4.5V"‘5.1V GVDD = 3.15V'4.7V VCOM = -0.425V'—2V GVCL = -3.15V"-4.7V AVCL=-4.5V"-5.5V 3V”- .5V

ST7735R

V0.2 152 2009-08-05

11 Power Structure

11.1 Driver IC Operating Voltage Specification

Fig 11.1.1 Power Booster Level

@L “W ”W

ST7735R

V0.2 153 2009-08-05

11.2 Power Booster Circuit

Charge Pump 1

Reference

Voltage

generator

Charge Pump 2

Gray reference

Circuit Block

( Gamma )

Source Output

Circuit Block

Gate

Driver

REGP

Vci1

AVDD

AVCL

AGND

VDD

CAVDD

VDD

Charge Pump 4

VDD

Vci1

AVCL

CVCL

AVDD

AGND

S1

|

S 396

AVDD

AGND

GVDD

VGH

VGL

VDDI

VCOM

G1

|

G 162

Reference

Voltage

generator

ST7735R

V0.2 154 2009-08-05

11.2.1 EXTERNAL COMPONENTS CONNECTION

Pad Name Connection Rated (Min)

Voltage

Typical

capacitance value

AVDD Connect to Capacitor: AVDD -------||-------- GND 6.3V 1.0 uF

AVCL Connect to Capacitor: AVCL -------||-------- GND 6.3V 1.0 uF

ST7735R

V0.2 155 2009-08-05

12 Gamma structure

12.1 TRUCTURE OF GRAYSCALE AMPLIFIER

16 voltage levels (VIN0-VIN15) between GVDD and VSS are determined by the high/ mid/ low level adjustment registers.

Each mid-adjustment level is split into 64 levels again by the internal ladder resistor network. As a result, grayscale

amplifier generates 64 voltage levels ranging from V0 to V63 and outputs one of 64 levels.

12.2 Gamma Voltage Formula (Positive/ Negative Polarity)

Gray Level Voltage Formula (Positive) Voltage Formula (Negative)

0 VINP0 VINP0

1 VINP1 VINP1

2 VINP2 VINP2

3 VINP3 VINP3

4 VINP4 VINP4

5 V4-(V4-V12)*(4/32) V4-(V4-V12)*(4/32)

6 V4-(V4-V12)*(8/32) V4-(V4-V12)*(8/32)

7 V4-(V4-V12)*(12/32) V4-(V4-V12)*(12/32)

8 V4-(V4-V12)*(16/32) V4-(V4-V12)*(16/32)

9 V4-(V4-V12)*(20/32) V4-(V4-V12)*(20/32)

10 V4-(V4-V12)*(24/32) V4-(V4-V12)*(24/32)

11 V4-(V4-V12)*(28/32) V4-(V4-V12)*(28/32)

12 VINP5 VINP5

13 V12-(V12-V20)*(4/32) V12-(V12-V20)*(4/32)

14 V12-(V12-V20)*(8/32) V12-(V12-V20)*(8/32)

15 V12-(V12-V20)*(12/32) V12-(V12-V20)*(12/32)

16 V12-(V12-V20)*(16/32) V12-(V12-V20)*(16/32)

17 V12-(V12-V20)*(20/32) V12-(V12-V20)*(20/32)

18 V12-(V12-V20)*(24/32) V12-(V12-V20)*(24/32)

19 V12-(V12-V20)*(28/32) V12-(V12-V20)*(28/32)

20 VINP6 VINP6

21 V20-(V20-V28)*(4/32) V20-(V20-V28)*(4/32)

22 V20-(V20-V28)*(8/32) V20-(V20-V28)*(8/32)

23 V20-(V20-V28)*(12/32) V20-(V20-V28)*(12/32)

24 V20-(V20-V28)*(16/32) V20-(V20-V28)*(16/32)

25 V20-(V20-V28)*(20/32) V20-(V20-V28)*(20/32)

26 V20-(V20-V28)*(24/32) V20-(V20-V28)*(24/32)

27 V20-(V20-V28)*(28/32) V20-(V20-V28)*(28/32)

28 VINP7 VINP7

29 V28-(V28-V36)* (4/32) V28-(V28-V36)* (4/32)

30 V28-(V28-V36)* (8/32) V28-(V28-V36)* (8/32)

31 V28-(V28-V36)* (12/32) V28-(V28-V36)* (12/32)

32 V28-(V28-V36)* (16/32) V28-(V28-V36)* (16/32)

33 V28-(V28-V36)* (20/32) V28-(V28-V36)* (20/32)

34 V28-(V28-V36)* (24/32) V28-(V28-V36)* (24/32)

35 V28-(V28-V36)* (28/32) V28-(V28-V36)* (28/32)

ST7735R

V0.2 156 2009-08-05

36 VINP8 VINP8

37 V36-(V36-V44)*(4/32) V36-(V36-V44)*(4/32)

38 V36-(V36-V44)*(8/32) V36-(V36-V44)*(8/32)

39 V36-(V36-V44)*(12/32) V36-(V36-V44)*(12/32)

40 V36-(V36-V44)*(16/32) V36-(V36-V44)*(16/32)

41 V36-(V36-V44)*(20/32) V36-(V36-V44)*(20/32)

42 V36-(V36-V44)*(24/32) V36-(V36-V44)*(24/32)

43 V36-(V36-V44)*(28/32) V36-(V36-V44)*(28/32)

44 VINP9 VINP9

45 V44-(V44-V52)*(4/32) V44-(V44-V52)*(4/32)

46 V44-(V44-V52)*(8/32) V44-(V44-V52)*(8/32)

47 V44-(V44-V52)*(12/32) V44-(V44-V52)*(12/32)

48 V44-(V44-V52)*(16/32) V44-(V44-V52)*(16/32)

49 V44-(V44-V52)*(20/32) V44-(V44-V52)*(20/32)

50 V44-(V44-V52)*(24/32) V44-(V44-V52)*(24/32)

51 V44-(V44-V52)*(28/32) V44-(V44-V52)*(28/32)

52 VINP10 VINP10

53 V52-(V52-V56)*(1/4) V52-(V52-V56)*(1/4)

54 V52-(V52-V56)*(2/4) V52-(V52-V56)*(2/4)

55 V52-(V52-V56)*(3/4) V52-(V52-V56)*(3/4)

56 VINP11 VINP11

57 V56-(V56-V60)*(1/4) V56-(V56-V60)*(1/4)

58 V56-(V56-V60)*(2/4) V56-(V56-V60)*(2/4)

59 V56-(V56-V60)*(3/4) V56-(V56-V60)*(3/4)

60 VINP12 VINP12

61 VINP13 VINP13

62 VINP14 VINP14

63 VINP15 VINP15

Driver IC (Dump down) :1 $965: w, mu Vlll mz Driver IC (Dump down) :1 $965: w, mu Vlll pm <32><34 1="" (350="" (3152="" -="" direction="" default="" setting="" (hnv)="" smx="" 0'="" smy="" ,="" 0'="" srgb="" :="" ‘0'="" s1="" :="" filler="" r="" 82="illerG" s3="Filler" b="" -="" display="" direction="" control="" (snv)="" -x—mirror="" comrol="" by="" mx="" -y—mirror="" control="" by="" my="" -xy-exchange="" control="" by="" mv="" c="" (e="" down)="" as="" c="" tft="" glass="" -="" direction="" default="" setting="" (hnv)="" smx="" '0'="" smy="" —="" 0'="" srgb="" :="" ‘1'="" s1="" :="" filler="" b="" 82="illerG" s3="Filler" r="" -="" display="" direction="" control="" (snv)="" -x—mirror="" comrol="" by="" mx="" -y—mirror="" comrol="" by="" my="" -xy-exchange="" control="" by="" mv="" c="" (e="" down)="" as="" c="" tft="" glass="">

ST7735R

V0.2 157 2009-08-05

13 Example Connection with Panel direction and Different Resolution

13.1 Application of connection with panel direction

Case 1: (This is default case)

- 1

st

Pixel is at Left Top of the panel

- RGB filter order = RGB

1st pixel

IC (Bump down)

LCD Front side

CF Glass

TFT Glass

Case 2:

- 1

st

Pixel is at Left Top of the panel

- RGB filter order = BGR

1st pixel

IC (Bump down)

LCD Front side

CF Glass

TFT Glass

D ver IC (Dump down) :1 $9652 m, mu Pm mz Driver IC (Dump down) Si S9661 m, mu Vlll pm (32 (34 r (350 (3162 - Direction default setting (HNV) $2 = ilter G S3 = Filter B - Display direction control (SNV) - X—Mirror control by MX - Y-Mirror control by MY -XY-Exchange control by MV C (E down) as C TFT Glass - Direction default setting (HNV) SMX ‘1' S1 = Filter B 82 = ilter G S3 = Filter R - Display direction control (SNV) - X—Mirror control by MX - Y-Mirror control by MY -XY-Exchange control by MV C (E down) TFT Glass

ST7735R

V0.2 158 2009-08-05

Case 3:

- 1

st

Pixel is at Right Bottom of the panel

- RGB filter order = RGB

IC (Bump down)

LCD Front side

CF Glass

TFT Glass

1st pixel

Case 4:

- 1

st

Pixel is at Right Bottom of the panel

- RGB filter order = BGR

IC (Bump down)

LCD Front side

CF Glass

TFT Glass

1st pixel

GRAM size = max Isox IE-biis M27, ‘59) GRAM size =128x 160 x mans “27, my;

ST7735R

V0.2 159 2009-08-05

13.2 Application of connection with Different resolution

Case1 of Resolution (128RGB x 160) (GM[1:0] = “11”)

RAM size=128 x 160 x 18-bit (Used)

Display size = 128RGB x 160

1). Example for SMX=SMY=’0’

G1

G2

G3

G4

G157

G159

G160

G158

Driver IC (bump down)

G3G161 G2 G160S7 S390

00h 01h 02h 7Eh 7Fh 83h

00h

01h

02h

A1h

9Fh

- Display direction control (S/W)

- X-Mirror control by MX

- Y-Mirror control by MY

- XY-Exchange control by MV

- Direction default setting (H/W)

SMX = '0'

SMY = '0'

SRGB = '0'

P1 P2 P3 P126 P127 P128

2). Example for SMX=SMY=’1’

P1 P2 P3

G1

G2

G3

G4

G157

G159

G160

G158

Driver IC (bump down)

G3G161 G2 G160S7 S390

00h 01h 02h 7Eh 7Fh 83h

00h

01h

02h

A1h

9Fh

- Display direction control (S/W)

- X-Mirror control by MX

- Y-Mirror control by MY

- XY-Exchange control by MV

- Direction default setting (H/W)

SMX = '1'

SMY = '1'

SRGB = '0'

P126 P127 P128

Driverlc (bump down) 57 sign 52 (131,151) - Display aireuion mmrol (51w; - X—error 00an by MX . . . - Y—error oolllrol by My - Dilacnm deﬁaun 991mm (HM!) -xv-Exmange mmml by MV SMX sulv = v SRGE = u DmerlC (oi-up am) 53 S SIN E GRAM size =132 X162X1B—DiE (131,161) - Display direction oomml (smo - x-Miirui Dollmal by MX - v-Minu mmwl by MY - XY-Exdlangs comml by W

ST7735R

V0.2 160 2009-08-05

Case2 of Resolution (132RGB x 162) (GM[1:0] = “00”)

RAM size=132 x 162 x 18-bit (Used)

Display size = 132RGB x 162

1). Example for SMX=SMY=’0’

2). Example for SMX=SMY=’1’

ST7735R

V0.2 161 2009-08-05

13.3 Microprocessor Interface applications

13.3.1 8080-Series MCU Interface for 8-bit data bus (P68=0, IM2, IM1, IM0=”100”)

80 Serial MPU 8-Bit Bus

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

D/CX (SCL)

WRX (R/WX)

D7 to D0

D17 to D8

GND

RESX

CSX

WRX

D7 to D0

RDX (E)

RDX

D/CX

GND

VDDI

P68

13.3.2 8080-Series MCU Interface for 16-bit data bus (P68=0, IM2, IM1, IM0=”101”)

80 Serial MPU 16-Bit Bus

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

D/CX (SCL)

WRX (R/WX)

D15 to D0

D17 to D16

GND

RESX

CSX

WRX

D15 to D0

RDX (E)

RDX

D/CX

GND

VDDI

P68

13.3.3 8080-Series MCU Interface for 9-bit data bus (P68=0, IM2, IM1, IM0=”110”)

80 Serial MPU 9-Bit Bus

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

D/CX (SCL)

WRX (R/WX)

D9 to D0

D17 to D9

VDDI GND

RESX

CSX

WRX

D8 to D0

RDX (E)

RDX

D/CX

GND P68

ST7735R

V0.2 162 2009-08-05

13.3.4 8080-Series MCU Interface for 18-bit data bus (P68=0, IM2, IM1, IM0=”111”)

80 Serial MPU 18-Bit Bus

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

D/CX (SCL)

WRX (R/WX)

D17 to D0

GND

RESX

CSX

WRX

D17 to D0

RDX (E)

RDX

D/CX

GND

VDDI

P68

13.3.5 6800-Series MCU Interface for 8-bit data bus (P68=1, IM2, IM1, IM0=”100”)

68 Serial MPU 8-Bit Bus

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

D/CX (SCL)

WRX (R/WX)

D7 to D0

D17 to D8

GND

RESX

CSX

R/WX

D7 to D0

RDX (E)

E

D/CX

GND

VDDI

P68

VDDI

13.3.6 6800-Series MCU Interface for 16-bit data bus (P68=1, IM2, IM1, IM0=”101”)

68 Serial MPU 16-Bit Bus

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

D/CX (SCL)

WRX (R/WX)

D15 to D0

D17 to D16

RESX

CSX

R/WX

D15 to D0

RDX (E)

E

D/CX

GND

VDDI

P68

VDDI

ST7735R

V0.2 163 2009-08-05

13.3.7 6800-Series MCU Interface for 9-bit data bus (P68=1, IM2, IM1, IM0=”110”)

68 Serial MPU 9-Bit Bus

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

D/CX (SCL)

WRX (R/WX)

D7 to D0

D17 to D9

RESX

CSX

R/WX

D8 to D0

RDX (E)

E

D/CX

GND

VDDI GND

P68

VDDI

13.3.8 6800-Series MCU Interface for 18-bit data bus (P68=1, IM2, IM1, IM0=”111”)

68 Serial MPU 18-Bit Bus

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

D/CX (SCL)

WRX (R/WX)

D17 to D0

VDDI GND

RESX

CSX

R/WX

D17 to D0

RDX (E)

E

D/CX

P68

VDDI

13.3.9 3-Line serial MCU Interface (IM2, IM1, IM0=”000”, SPI4W=0)

3-Pin Serial Mode

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

RDX,WRX

D/CX (SCL)

SDA(D0)

D17 to D1

GND

RESX

CSX

SCL

SDA

GND

13.3.10 4-Line serial MCU Interface (IM2, IM1, IM0=”000”, SPI4W=1)

4-Pin Serial Mode

MPU

ST7735R

SPI4W

IM2

IM1

IM0

RESX

CSX

RDX

D/CX (SCL)

SDA(D0)

D17 to D1

VDDI

GND

RESX

CSX

SCL

SDA

WRX(D/CX)

D/CX

GND

ST7735R

V0.2 164 2009-08-05

14 Revision History

ST7735R Specification Revision History

Version Date Description

V0.1 2009/07/10

First issue.

V0.2 2009/08/05

Modify VGH, VGL PAD location (P7)

Add TESEL pin description. (P16)

Modify command DFh (P147)

Modify AVDD range 4.5~5.1 (P152)

ST7735R Preliminary Datasheet by Adafruit Industries LLC
