Product Roadmap:
Flash Memory
Q3 2021
Cypress Semiconductor Corp.
An Infineon Technologies Company
(ifileon
1
NOR Flash Memory Family
(iflleon
2
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
NOR Flash Memory Family Decoder
S25 H S 512 T
Technology: J = 110-nm Floating Gate (FG) N = 110-nm MIRRORBIT™ (MB)
K = 90-nm FG P = 90-nm MB
L = 65-nm FG R, S = 65-nm MB
T = 45-nm MB
Density: 008 = 8Mb 064 = 64Mb 512 = 512Mb 04G = 4Gb
016 = 16Mb 128 = 128Mb 01G = 1Gb
032 = 32Mb 256 = 256Mb 02G = 2Gb
Voltage: D = 2.5 V L = 3.0 V S = 1.8 V
Family: A = Standard ADP (Address-Data Parallel)
C = Burst Mode ADP (Address-Data Parallel)
F = Serial
G = Page Mode
H = High-Performance Serial
J = Simultaneous Read/Write ADP (Address-Data Parallel)
K = HYPERBUS™
P = Page Mode Simultaneous Read/Write ADP (Address-Data Parallel)
V = Burst Mode Simultaneous Read/Write ADM (Address-Data Multiplexed)
X = Burst Mode Simultaneous Read/Write AADM (Address-Address-Data Multiplexed)
Series: 25 = SPI 26 = HYPERBUS™ 28 = Octal
35 = SPI with Security 36 = HYPERBUS™ with Security 38 = Octal with Security
29 = Parallel 70 = Stacked Die 79 = Dual Quad SPI
Prefix: S
’7 Inhneon (
3
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
NOR Flash Memory Product Portfolio: New Products
Family Interface Sector Series Volt Densities Lead Tech 202112022 2023 2024 2025
SEMPER™
Flash
QSPI
Hybrid
S25HS-T
S25HL-T 1.8 V
3.0 V 128Mb−4Gb 512Mb 45-nm MB
HYPERBUS S26HS-T
S26HL-T 1.8 V
3.0 V 128Mb−4Gb 512Mb 45-nm MB
Octal S28HS-T
S28HL-T 1.8 V
3.0 V 128Mb−4Gb 512Mb 45-nm MB
SEMPER™
Secure Flash
QSPI
Hybrid
S35HS-T
S35HL-T 1.8 V
3.0 V 128Mb−1Gb 256Mb 45-nm MB
HYPERBUS S36HS-T
S36HL-T 1.8 V
3.0 V 128Mb−1Gb 256Mb 45-nm MB
Octal S38HS-T
S38HL-T 1.8 V
3.0 V 128Mb−1Gb 256Mb 45-nm MB
Quad SPI QSPI
Hybrid S25FS-S 1.8 V 64Mb−1Gb - 65-nm MB
S25FL-S 3.0 V 128Mb−1Gb - 65-nm MB
Uniform
4KB S25FL-L 3.0 V 64−256Mb - 65-nm FG
Specialty Low
Power QSPI Uniform
512B SFM3204A 0.85–
2.75 V 32Mb - 40-nm
eFG2
Dual Quad SPI QSPI Hybrid S79FS-S
S79FL-S 1.8 V
3.0 V 256Mb−1Gb - 65-nm MB
HYPERFLASH™ HYPERBUS Hybrid S26KS-S
S26KL-S 1.8 V
3.0 V 128−512Mb - 65-nm MB
Parallel Parallel Hybrid S29GL-T 3.0 V 512Mb−2Gb - 45-nm MB
Production EOL
Samples
Concept
1Calendar Year 2Embedded FG
’7 Inhneon (
4
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
x8 Serial NOR Flash Memory Roadmap
Product Family Density (Prod)
[EOL]
202162022 2023 2024 2025
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
S28HS
-T1(1.8 V)
S28HL
-T1(3.0 V)
SEMPER™ Flash
with Octal Interface
45
-nm MB2
4Gb
3(TBD)
2Gb
3, 4
1Gb
512Mb
256Mb
(Q222)
128Mb
(TBD)
S26HS
-T1(1.8 V)
S26HL
-T1(3.0 V)
SEMPER Flash with
HYPERBUS™
Interface
45
-nm MB2
4Gb
3(TBD)
2Gb
3(Q421)
1Gb
512Mb
256Mb
(Q322)
128Mb
(TBD)
S26KS
-S (1.8 V)
S26KL
-S (3.0 V)
HYPERFLASH™
65
-nm MB2
512Mb
256Mb
128Mb
S79FS
-S (1.8 V)
Dual Quad SPI
65
-nm MB2
1Gb
5
512Mb
5(TBD)
256Mb
5(TBD)
S79FL
-S (3.0 V)
Dual Quad SPI
65
-nm MB2
1Gb
5
512Mb
5
256Mb
5
1JEDEC xSPI Compliant
2Hybrid Sector
3Stacked Die
41.8 V only in production
5 S79 Series (stacked die)
6Calendar Year
Products supported by
Longevity Program unless noted
Samples
Production
EOL - LTB
Concept
EOL - LTS
Infineon
5
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
x8 Serial NOR Flash Memory Portfolio
Dual Quad SPI
S79FL-S1, 2
65-nm MB, 3.0 V
HYPERFLASH™
S26KL-S1
65-nm MB, 3.0 V
SEMPER™ Flash3
S26HL-T1
45-nm MB, 3.0 V
SEMPER Flash4
S28HL-T1
45-nm MB, 3.0 V
Dual Quad SPI
S79FS-S1, 2
65-nm MB, 1.8 V
HYPERFLASH™
S26KS-S1
65-nm MB, 1.8 V
SEMPER Flash3
S26HS-T1
45-nm MB, 1.8 V
SEMPER Flash4
S28HS-T1
45-nm MB, 1.8 V
64–128Mb ≥256Mb
Product Family Number
SDR Clock/DDR Clock
* Temperature Range
All parts supported by
Longevity Program
unless noted
S26KS256S
-/166 MHz
* I, A, V, B, M
S26KS512S
-/166 MHz
* I, A, V, B, M
S26KS128S
-/166 MHz
* I, A, V, B, M
S79FS512S
133 MHz/80 MHz
* I, A, V, B
S79FS256S
133 MHz/80 MHz
* I, A, V, B
S79FS01GS
133 MHz/102 MHz
* I, A, V, B
S79FL512S
133 MHz/80 MHz
* I, A, V, B
S79FL256S
133 MHz/80 MHz
* I, A, V, B
S79FL01GS
133 MHz/80 MHz
* I, A, V, B
S26KL256S
-/100 MHz
* I, A, V, B, M
S26KL512S
-/100 MHz
* I, A, V, B, M
S26KL128S
-/100 MHz
* I, A, V, B, M
S26HS02GT5, 6
-/166 MHz
* I6, A6, V6, B, M6
S26HS512T
-/200 MHz
* I, A, V, B, M
S26HS01GT
-/200 MHz
* I, A, V, B, M6
S26HS04GT5, 6
-/166 MHz
* I, A, V, B, M
S28HS02GT5
166 MHz/166 MHz
* I 6, A 6, V 6, B, M
S28HS512T
200 MHz/200 MHz
* I, A, V, B, M
S28HS01GT6
200 MHz/200 MHz
* I, A, V, B, M
S28HS04GT5, 6
166 MHz/166 MHz
* I, A, V, B, M
S26HL02GT5, 6
-/133 MHz
* I6, A6, V6, B, M6
S26HL512T
-/166 MHz
* I, A, V, B, M
S26HL01GT
-/166 MHz
* I, A, V, B, M
S26HL04GT5, 6
-/133 MHz
* I, A, V, B, M
S28HL02GT5, 6
133 MHz/133 MHz
* I, A, V, B, M
S28HL512T
166 MHz/166 MHz
* I, A, V, B, M
S28HL01GT
166 MHz/166 MHz
* I, A, V, B, M
S28HL04GT5, 6
133 MHz/133 MHz
* I, A, V, B, M
* I = Industrial: -40C to +85C
A = Automotive, AEC-Q100 Grade 3: -40C to +85C
V = Industrial-plus: -40C to +105C
B = Automotive, AEC-Q100 Grade 2: -40C to +105C
M = Automotive, AEC-Q100 Grade 1: -40C to +125C
1 Hybrid Sector
2 S79 series (stacked die)
3HYPERBUS™ Interface (xSPI Profile 2.0)
S26HS256T6
-/200 MHz
* I, A, V, B, M
S28HS256T6
200 MHz/200 MHz
* I, A, V, B, M
S26HL256T6
-/166 MHz
* I, A, V, B, M
S28HL256T6
166 MHz/166 MHz
* I, A, V, B, M
S26HS128T
-/200 MHz
* I, A, V, B, M
S28HS128T
200 MHz/200 MHz
* I, A, V, B, M
S26HL128T
-/166 MHz
* I, A, V, B, M
S28HL128T
166 MHz/166 MHz
* I, A, V, B, M
4Octal Interface (xSPI Profile 1.0)
5 Stacked die
6Contact Sales
Sampling ProductionConcept Development
QQYYQQYY
QQYY
Status
Availability
EOL (Last-Time-Ship)
Q421Q421
Q322Q322 Q222Q222 Q421
Q421 Q421
Q421
®
6
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
x4 Serial NOR Flash Memory Roadmap
Product Family Density (Prod)
[EOL]
202182022 2023 2024 2025
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
S25HS-T (1.8 V)
S25HL-T (3.0 V)
SEMPER™ Flash with
QSPI Interface
45-nm MB2
4Gb4(TBD)
2Gb4
1Gb
512Mb
256Mb (TBD)
128Mb (TBD)
S25FS-S (1.8 V)
S25FL-S3(3.0V)
QSPI
65-nm MB2
1Gb5
512Mb
256Mb
128Mb6
64Mb7
S25FL-L (3.0 V)
QSPI
65-nm FG1
256Mb
128Mb
64Mb
SFM3204A (0.85-2.75 V)
QSPI
40-nm eFG1, 9 32Mb
Products supported by
Longevity Program unless noted
Samples
Production
EOL - LTB
Concept
EOL - LTS
1 Uniform Sector
2 Hybrid Sector
3 VIO 1.8 V to 3.0 V
4 Stacked die
5 S70 Series (stacked die)
6 S25FL127S & S25FL128S
7 FS-S only
8Calendar Year
9Embedded FG
(ifileon .................. .................. __________________ .................. __________________ ..................
7
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
x4 Serial NOR Flash Memory Portfolio
QSPI
S25FL-L1
65-nm FG, 3.0 V
QSPI
S25FL-S2
65-nm MB, 3.0 V
SEMPER™ Flash3
S25HL-T2
45-nm MB, 3.0 V
QSPI
S25FS-S2
65-nm MB, 1.8 V
SEMPER Flash3
S25HS-T2
45-nm MB, 1.8 V
Specialty LP
SFM3204A1
40-nm eFG8,
0.85-2.75 V
S25FS256S
133 MHz/80 MHz
* I, A, V, B, M
S25FS512S
133 MHz/80 MHz
* I, A, V, B, M
S70FS01GS5
133 MHz/80 MHz
* I, A, V, B, M
S25FS128S
133 MHz/80 MHz
* I, A, V, B, M
S25FS064S
133 MHz/80 MHz
* I, A, V, B, N, M
S25FL256S
133 MHz/80 MHz
* I, A, V, B, M
S25FL512S
133 MHz/80 MHz
* I, A, V, B, M
S70FL01GS5
133 MHz/80 MHz
* I, A, V, B, M
S25FL128S
133 MHz/80 MHz
* I, A, V, B, M
S25FL127S
108 MHz/--
* I, A, V, B
S25HS512T
166 MHz/102 MHz
* I, A, V, B, M
S25HS01GT
166 MHz/102 MHz
* I, A, V, B, M
S25HL512T
166 MHz/102 MHz
* I, A, V, B, M
S25HL01GT
166 MHz/102 MHz
* I, A, V, B, M
Product Family Number
SDR Clock/DDR Clock
* Temperature Range
1Uniform Sector
2Hybrid Sector
3With QSPI
4Stacked die
S25HS02GT4, 6
133 MHz/102 MHz
* I, A, V, B, M
S25HL02GT4, 6
166 MHz/102 MHz
* I, A, V, B, M
All parts supported by
Longevity Program
unless noted
S25HS04GT4, 6
133 MHz/66 MHz
* I, A, V, B, M
S25HL04GT4, 6
133 MHz/66 MHz
* I, A, V, B, M
* C = Commercial: 0C to +70C
I = Industrial: -40C to +85C
A = Automotive, AEC-Q100 Grade 3: -40C to +85C
S25FL256L
133 MHz/66 MHz
* I, A, V, B, M
S25FL128L
133 MHz/66 MHz
* I, A, V, B, M
S25FL064L
108 MHz/54 MHz
* I, A, V, B, M
S25HS256T
166 MHz/102 MHz
* I, A, V, B, M
S25HL256T
166 MHz/102 MHz
* I, A, V, B, M
S25HS128T
166 MHz/102 MHz
* I, A, V, B, M
S25HL128T
166 MHz/102 MHz
* I, A, V, B, M
32–128Mb ≥256Mb
Sampling ProductionConcept Development
QQYYQQYY
QQYY
Status
Availability
EOL (Last-Time-Ship)
SFM3204A
10 MHz/--
* C7
V = Industrial-plus: -40C to +105C
B = Automotive, AEC-Q100 Grade 2: -40C to +105C
M = Automotive, AEC-Q100 Grade 1: -40C to +125C
5S70 series (stacked die)
6Contact Sales
70C to +55C
8Embedded FG
(ifileon
8
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
SEMPER™ Secure Serial NOR Flash Memory Roadmap
Product Family Density (Prod)
[EOL]
202132022 2023 2024 2025
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
S35HS
-T (1.8 V)
S35HL
-T (3.0 V)
SEMPER™ Secure
Flash with QSPI
Interface
45
-nm MB2
1Gb
(TBD)
512Mb
(Q423)
256Mb
(Q122)
128Mb
(Q223)
S36HS
-T1(1.8 V)
S36HL
-T1(3.0 V)
SEMPER™ Secure
Flash with
HYPERBUS™
Interface
45
-nm MB2
1Gb
(TBD)
512Mb
(Q124)
256Mb
(Q322)
128Mb
(Q323)
S38HS
-T1(1.8 V)
S38HL
-T1(3.0 V)
SEMPER™ Secure
Flash with Octal
Interface
45
-nm MB2
1Gb
(TBD)
512Mb
(Q423)
256Mb
(Q222)
128Mb
(Q223)
1JEDEC xSPI Compliant
2Hybrid Sector
3Calendar Year
Products supported by
Longevity Program unless noted
Samples
Production
EOL - LTB
Concept
EOL - LTS
(ifileon ____________________________________________________________________________________________________________ """"""" 1 m1 m1 m1 m1 1 :- """" 1:- """" 1? """" 1:- """" 1:- """" ‘F """" ‘ -------- E g a -
9
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
SEMPER™ Secure Serial NOR Flash Memory Portfolio
Density (Name)
SDR Clock/DDR Clock
* Temperature Range
SEMPER™ Secure Flash1
S35HL-T2
45-nm MB, 3.0 V
SEMPER Secure Flash3
S36HL-T2
45-nm MB, 3.0 V
SEMPER Secure Flash4
S38HL-T2
45-nm MB, 3.0 V
SEMPER Secure Flash1
S35HS-T2
45-nm MB, 1.8 V
SEMPER Secure Flash3
S36HS-T2
45-nm MB, 1.8 V
SEMPER Secure Flash4
S38HS-T2
45-nm MB, 1.8 V
* I = Industrial: -40C to +85C
A = Automotive, AEC-Q100 Grade 3: -40C to +85C
V = Industrial-plus: -40C to +105C
B = Automotive, AEC-Q100 Grade 2: -40C to +105C
M = Automotive, AEC-Q100 Grade 1: -40C to +125C
All parts supported by
Longevity Program
unless noted
1 With QSPI
2 Hybrid Sector
3 HYPERBUS™ Interface (xSPI Profile 2.0)
4Octal Interface (xSPI Profile 1.0)
S35HL256T
166 MHz/102 MHz
* I, A, V, B, M
S35HL128T
166 MHz/102 MHz
* I, A, V, B, M
Q122 S36HL256T
-/166 MHz
* I, A, V, B, M
S36HL128T
-/166 MHz
* I, A, V, B, M
Q322 S38HL256T
166 MHz/166 MHz
* I, A, V, B, M
S38HL128T
166 MHz/166 MHz
* I, A, V, B, M
Q222 S35HS256T
166 MHz/102 MHz
* I, A, V, B, M
S35HS128T
166 MHz/102 MHz
* I, A, V, B, M
Q122 S36HS256T
-/200 MHz
* I, A, V, B, M
S36HS128T
-/200 MHz
* I, A, V, B, M
Q322 S38HS256T
200 MHz/200 MHz
* I, A, V, B, M
S38HS128T
200 MHz/200 MHz
* I, A, V, B, M
Q222
S35HL512T
166 MHz/102 MHz
* I, A, V, B, M
S36HL512T
-/166 MHz
* I, A, V, B, M
S38HL512T
166 MHz/166 MHz
* I, A, V, B, M
S35HS512T
166 MHz/102 MHz
* I, A, V, B, M
S36HS512T
-/200 MHz
* I, A, V, B, M
S38HS512T
200 MHz/200 MHz
* I, A, V, B, M
Product Family Number
SDR Clock/DDR Clock
* Temperature Range
Q422 Q223 Q123 Q323 Q422 Q223 Q422 Q223 Q123 Q323 Q422 Q223
64–128Mb ≥256Mb
Sampling ProductionConcept Development
QQYYQQYY
QQYY
Status
Availability
EOL (Last-Time-Ship)
S35HL01GT
166 MHz/102 MHz
* I, A, V, B, M
S36HL01GT
-/133 MHz
* I, A, V, B, M
S38HL01GT
133 MHz/133 MHz
* I, A, V, B, M
S35HS01GT
133 MHz/102 MHz
* I, A, V, B, M
S36HS01GT
-/166 MHz
* I, A, V, B, M
S38HS01GT
166 MHz/166 MHz
* I, A, V, B, M
Q223 Q423 Q323 Q124 Q223 Q423 Q223 Q423 Q323 Q124 Q223 Q423
infineon
10
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Parallel NOR Flash Memory Roadmap
Product Family Density (Prod)
[EOL]
202142022 2023 2024 2025
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
S29GL
-T1(3.0 V)
45
-nm MB
2Gb
3
1Gb
512Mb
S29GL
-S1(3.0 V)
65
-nm MB
2Gb
3
1Gb
512Mb
256Mb
128Mb
64Mb
S29GL
-P1(3.0 V)
90
-nm MB
256Mb
128Mb
S29GL
-N1(3.0 V)
110
-nm MB
64Mb
[Q422]
32Mb
[Q422]
S29PL
-J1, 2 (3.0 V)
110
-nm FG
128Mb
64Mb
32Mb
S29JL
-J2(3.0 V)
110
-nm FG
64Mb
32Mb
S29AL
-J (3.0 V)
110
-nm FG
16Mb
8Mb
S29AS
-J (1.8 V)
110
-nm FG
16Mb
1Supports Page Mode
2Supports simultaneous read/write operation
3 S70 series (stacked die)
4Calendar Year
Products supported by
Longevity Program unless noted
Samples
Production
EOL - LTB
Concept
EOL - LTS
(ifileon
11
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Parallel NOR Flash Memory Portfolio
S29AS-J
110-nm FG, 1.8 V S29AL-J
110-nm FG, 3.0 V S29JL-J1
110-nm FG, 3.0 V S29PL-J1, 2
110-nm FG, 3.0 V S29GL-N2
110-nm MB, 3.0 V S29GL-P2
90-nm MB, 3.0 V S29GL-S2
65-nm MB, 3.0 V S29GL-T2
45-nm MB, 3.0 V
S29GL032N
90 ns/25 ns
* I, A
S29GL064N
90 ns/25 ns
* I, A
S29GL256P
90 ns/25 ns
* I
S29GL128P
90 ns/25 ns
* I
S29GL256S
90 ns/15 ns
* I, A, V, B
S29GL512S
100 ns/15 ns
* I, A, V, B
S29GL01GS
100 ns/15 ns
* I, A, V, B
S29GL128S
90 ns/15 ns
* I, A, V, B
≤32Mb
S70GL02GS3
110 ns/20 ns
* I, A, V, B
S29GL064S
70 ns/15 ns
* I, A, B
S29PL128J
60 ns/20 ns
* I, A
S29PL032J
55 ns/20 ns
* I, A
S29PL064J
55 ns/20 ns
* I, A
S29AL016J
55 ns/--
* I, A, N, M
S29AL008J
55 ns/--
* I, A, N, M
S29AS016J
70 ns/--
* I, A
S29JL032J
60 ns/--
* I, A
S29JL064J
55 ns/--
* I, A
S29GL512T
100 ns/15 ns
* I, A, V, B, N
S29GL01GT
100 ns/15 ns
* I, A, V, B, N
S70GL02GT3
110 ns/20 ns
* I, A, V, B, N
Product Family Number
Initial/Page Access
* Temperature Range
*I = Industrial: -40C to +85C
V = Industrial-plus: -40C to +105C
N = Extended: -40C to +125C
1Supports simultaneous read/write operation
2Supports Page Mode
3 S70 series (stacked die)
All parts supported by
Longevity Program
unless noted
64–128Mb ≥256Mb
Sampling ProductionConcept Development
QQYYQQYY
QQYY
Status
Availability
EOL (Last-Time-Ship)
A = Automotive, AEC-Q100 Grade 3: -40C to +85C
B = Automotive, AEC-Q100 Grade 2: -40C to +105C
M = Automotive, AEC-Q100 Grade 1: -40C to +125C
Q422
Q422
(ifileon
12
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Burst NOR Flash Memory Roadmap
Product Family Density (Prod)
[EOL]
202132022 2023 2024 2025
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
S29VS-R2(1.8 V)
65-nm MB 64Mb [Q321]
S29CD-J1(2.5 V)
110-nm FG 32Mb [Q422]
S29CD-J1(2.5 V)
110-nm FG 16Mb
S29CL-J1(3.3 V)
110-nm FG 32Mb [Q421]
S29CL-J1(3.3 V)
110-nm FG 16Mb [Q422]
1 Address Data Parallel (ADP) Burst
2 Address Data Multiplex (ADM) Burst
3Calendar Year
Products supported by
Longevity Program unless noted
Samples
Production
EOL - LTB
Concept
EOL - LTS
(ifileon
13
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Burst NOR Flash Memory Portfolio
S29CL-J1
110-nm FG, 3.3 V S29CD-J1
110-nm FG, 2.5 V S29VS-R2
65-nm MB, 1.8 V
*W = Wireless: -25C to +85C
I = Industrial: -40C to +85C
A = Automotive, AEC-Q100 Grade 3: -40C to +85C
N = Extended: -40C to +125C
M = Automotive, AEC-Q100 Grade 1: -40C to +125C
T = Automotive, AEC-Q100 Grade 0: -40C to +150C
1 Address Data Parallel (ADP) Burst
2 Address Data Multiplex (ADM) Burst
Product Family Number
Initial Access/SDR Clock
* Temp Range
S29VS064R
80 ns/108 MHz
* W, I
All parts supported by
Longevity Program
unless noted
S29CD032J
54 ns/75 MHz
* I, A, N, M, H, T
S29CD016J
54 ns/66 MHz
* I, A, N, M, H, T
S29CL032J
54 ns/75 MHz
* I, A, N, M, H, T
S29CL016J
54 ns/66 MHz
* I, A, N, M, H, T
Q321
≤32Mb 64–128Mb ≥256Mb
Sampling ProductionConcept Development
QQYYQQYY
QQYY
Status
Availability
EOL (Last-Time-Ship)
Q421
Q422
Q422
E— Infineon 0/ :—
14
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
KGD/KGW NOR Flash Memory Portfolio1
HYPERFLASH™
3.0 V HYPERFLASH™
1.8 V Quad SPI
3.0 V Quad SPI
1.8 V Parallel
3.0 V
S26KS256S
-/166 MHz
* I, V
S26KS512S
-/166 MHz
* I, V
S26KL256S
-/100 MHz
* I, V
S26KL512S
-/100 MHz
* I, V
All parts supported by
Longevity Program
unless noted
S25FS256L
133 MHz/66 MHz
* I, V
S25FL128L
133 MHz/66 MHz
* I, V
S25FL064L
108 MHz/54 MHz
* I, V
Product Family Number
SDR Clock/DDR Clock
* Temperature Range
S25FS256S
80 MHz /-
* I, V
S25FS128S
133 MHz/80 MHz
* I, V
S25FS064S
133 MHz/80 MHz
* I, V, N
S29GL256S
90 ns/15 ns
* I, V
S29GL512S
100 ns/15 ns
* I, V
S29GL01GS
100 ns/15 ns
* I, V
S29GL128S
90 ns/15 ns
* I, V
Product Family Number
Initial/Page Access
* Temperature Range
S29AL016J
55 ns/-
* I, V, N
S29AL008J
55 ns/-
* I, V, N
S25FL512S
133 MHz/80 MHz
* I, V
S26KS128S
-/166 MHz
* I, V
S26KL128S
-/100 MHz
* I, V
1Contact Sales for KGD datasheets
≤32Mb 64–128Mb ≥256Mb
Sampling ProductionConcept Development
QQYYQQYY
QQYY
Status
Availability
EOL (Last-Time-Ship)
*C= Commercial: 0C to +70C
I = Industrial: -40C to +85C
V = Industrial-plus: -40C to +105C
N =Extended: -40C to +125C
All temperature grades are TJ
(ifileon
15
Flash and RAM Memory
Multi-chip Package (MCP)
3/, (Inflneon §7GHS§1_2TC l—E
16
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Flash and RAM Memory MCP Decoder
S76 H S 512 T C
RAM Density: A = 16Mb B = 32Mb C = 64Mb D = 128Mb E = 256Mb
Flash Technology: P = 90-nm MB R, S = 65-nm MB T = 45-nm MB
Flash Density: 032 = 32Mb 128 = 128Mb 512 = 512Mb
064 = 64Mb 256 = 256Mb 01G = 1Gb
Voltage: L = 3.0 V S = 1.8 V
Family: G = Page Mode
H = High-Performance Serial
K = HYPERFLASH™
V = Burst Mode Simultaneous Read/Write Address-Data Multiplexed (ADM)
W = Burst Mode Simultaneous Read/Write Address-Data Parallel (ADP)
X = Burst Mode Simultaneous Read/Write Address-Address-Data Multiplexed (AADM)
Series: 71, 98 = NOR Flash + pSRAM
72 = NOR Flash + DRAM
76 = HYPERBUS™ Interface (xSPI Profile 2.0) NOR Flash + HYPERRAM™
78 = Octal Interface (xSPI Profile 1.0) NOR Flash + HYPERRAM™
Prefix: S
(ifileon
17
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Serial Flash and RAM Memory MCP Roadmap
Product Family
Flash/RAM Flash/RAM
Density (Prod)
[EOL]
202142022 2023 2024 2025
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
S78HS
-T (1.8 V)1
45
-nm SEMPER™
Flash/HYPERRAM
1Gb/128Mb
(TBD)
1Gb/64Mb
(TBD)
512Mb/128Mb
(TBD)
512Mb/64Mb
(Q421)
S76HS
-T (1.8 V)2
45
-nm SEMPER
Flash/HYPERRAM
1Gb/128Mb
(TBD)
1Gb/64Mb
(Q122)
512Mb/128Mb
(TBD)
512Mb/64Mb
(TBD)
S71KS
-S (1.8 V)3
65
-nm
HYPERFLASH/
HYPERRAM
512Mb/64Mb
256Mb/64Mb
(TBD)
128Mb/64Mb
(TBD)
S78HL
-T (3.0 V)1
45
-nm SEMPER
Flash/HYPERRAM
1Gb/128Mb
(TBD)
1Gb/64Mb
(Q222)
512Mb/128Mb
(TBD)
512Mb/64Mb
(TBD)
S76HL
-T (3.0 V)2
45
-nm SEMPER
Flash/HYPERRAM
1Gb/128Mb
(TBD)
1Gb/64Mb
(TBD)
512Mb/128Mb
(TBD)
512Mb/64Mb
(Q421)
S71KL
-S (3.0 V)3
65
-nm
HYPERFLASH/
HYPERRAM
512Mb/64Mb
256Mb/64Mb
128Mb/64Mb
(TBD)
1 Octal Interface (xSPI Profile 1.0)
2 HYPERBUS™ Interface (xSPI Profile 2.0)
3HYPERBUS™ Interface
4Calendar Year
Products supported by
Longevity Program unless noted
Samples
Production
EOL - LTB
Concept
EOL - LTS
(ifileon
18
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Serial Flash and RAM Memory MCP Portfolio
S71KL-S
65-nm MB,
3.0 V
S76HL-T
45-nm MB,
3.0 V
S78HL-T
45-nm MB,
3.0 V
S71KS-S
65-nm MB,
1.8 V
S76HS-T
45-nm MB,
1.8 V
S78HS-T
45-nm MB,
1.8 V
* I = Industrial: -40C to +85C
A = Automotive, AEC-Q100 Grade 3: -40C to +85C
V = Industrial-plus: -40C to +105C
B = Automotive, AEC-Q100 Grade 2: -40C to +105C
1 HYPERFLASH™
2 HYPERBUS™ Interface (xSPI Profile 2.0)
3 Octal Interface (xSPI Profile 1.0)
4 HYPERRAM™
All parts supported
by Longevity
Program unless
noted
S71KS512SC1
64Mb4/ 166MHz
* I, A, V, B
S71KS128SC1
64Mb4/ 166MHz
* I, A, V, B
S71KS256SC1
64Mb4/ 166MHz
* I, A, V, B
S71KL512SC1
64Mb4/ 100MHz
* I, A, V, B
S71KL128SC1
64Mb4/ 100MHz
* I, A, V, B
S71KL256SC1
64Mb4/ 100MHz
* I, A, V, B
S76HS512TC2
64Mb4/ 200MHz
* I, A, V, B
S76HS01GTC2
64Mb4/ 200MHz
* I, A, V, B
S78HS512TC3
64Mb4/ 200MHz
* I, A, V, B
S78HS01GTC3
64Mb4/ 200MHz
* I, A, V, B
S76HL512TC2
64Mb4/ 166MHz
* I, A, V, B
S76HL01GTC2
64Mb4/ 166MHz
* I, A, V, B
S78HL512TC3
64Mb4/ 166MHz
* I, A, V, B
S78HL01GTC3
64Mb4/ 166MHz
* I, A, V, B
S76HS512TD2
128Mb4/ 166MHz
* I, A, V, B
S78HS512TD3
128Mb4/ 166MHz
* I, A, V, B
S76HL512TD2
128Mb4/ 133MHz
* I, A, V, B
S78HL512TD3
128Mb4/ 133MHz
* I, A, V, B
S76HS01GTD2
128Mb4/ 166MHz
* I, A, V, B
S78HS01GTD3
128Mb4/ 166MHz
* I, A, V, B
S76HL01GTD2
128Mb4/ 133MHz
* I, A, V, B
S78HL01GTD3
128Mb4/ 133MHz
* I, A, V, B
Q321 Q421
Q122 Q222
Q321 Q421
Q421 Q122
64–128Mb ≥256Mb
Sampling ProductionConcept Development
QQYYQQYY
QQYY
Status
Availability
EOL (Last-Time-Ship)
Product Family Number
RAM Density / DDR Clock
* Temperature Range
(ifileon
19
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Parallel Flash and RAM Memory MCP Roadmap
Product Family
Flash/RAM Flash/RAM
Density (Prod)
[EOL]
202112022 2023 2024 2025
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
S72XS
-R (1.8 V)
65
-nm MB/DRAM
256Mb/256Mb
[Q321]
S71VS
-R (1.8 V)
65
-nm MB/pSRAM
256Mb/128Mb
[Q321]
256Mb/64Mb
[Q321]
128Mb/64Mb
[Q321]
128Mb/32Mb
[Q321]
S71WS
-P (1.8 V)
90
-nm MB/pSRAM
256Mb/64Mb
Products supported by
Longevity Program unless noted
Samples
Production
EOL - LTB
Concept
EOL - LTS
1 Calendar Year
(ifileon —- —- —- —- —- —- ________ |:||:||:| -- -
20
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Parallel Flash and RAM Memory MCP Portfolio
S71WS-P1
90-nm MB,
1.8 V
S71VS-R2
65-nm MB,
1.8 V
S72XS-R3
65-nm MB,
1.8 V
*W = Wireless: -25C to +85C
I = Industrial: -40C to +85C
1 Address Data Parallel (ADP) Burst
2 Address Data Multiplex (ADM) Burst
3 Address High, Address Low, Data Multiplex (AADM) Burst
4 Parallel, Page Mode
S71VS256RC
64Mb
* W
S71WS256PC
64Mb
* W
S71VS128RB
32Mb
* W
S71VS128RC
64Mb
* W
Product Family Number
RAM Density
* Temperature Range
S71VS256RD
128Mb
* W
S72XS256RE
256Mb5
* I
All parts supported
by Longevity
Program unless
noted
S72XS256RE
256Mb6
* W, I
5 DRAM Version 2
6 DRAM Version 1
Q321
Q321
Q321
Q321
Q321
Q321
64–128Mb ≥256Mb
Sampling ProductionConcept Development
QQYYQQYY
QQYY
Status
Availability
EOL (Last-Time-Ship)
(ifileon
21
Package Offerings
infineon
22
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
x8 1.8V Serial Memory Packages
Family
Interface
Series
Device
SOIC-16
300 mil BGA24
8 x 8 mm/5 x 5 Ball BGA24
8 x 6 mm/5 x 5 Ball KGD
SEMPER™
Flash
Octal
HS
-T1
S28HS256T
CF CF
S28HS512T
✓CF
S28HS01GT
✓CF
S28HS02GT
✓
S28HS04GT
CF
HYPERBUS
HS
-T2
S26HS256T
CF CF
S26HS512T
✓CF
S26HS01GT
✓CF
S26HS02GT
CF
S26HS04GT
CF
HYPERFLASH™
KS
-S3
S26KS128S
✓CF
S26KS256S
✓CF
S26KS512S
✓CF
Quad SPI
QSPI
FS
-S
Dual Quad
S79FS256S
CF CF
S79FS512S
CF CF
S79FS01GS
✓
CF = Contact Factory
UD = Under Development
1 Octal Interface (xSPI Profile 1.0)
2 HYPERBUS™ Interface (xSPI Profile 2.0)
3 HYPERBUS™ Interface
infineon
23
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
x8 3.0V Serial Memory Packages
Family
Interface
Series
Device
SOIC-16
300 mil BGA24
8 x 8 mm/5 x 5 Ball BGA24
8 x 6 mm/5 x 5 Ball KGD
SEMPER™
Flash
Octal
HL
-T1
S28HL256T
CF CF
S28HL512T
✓CF
S28HL01GT
✓CF
S28HL02GT
CF
S28HL04GT
CF
HYPERBUS
HL
-T2
S26HL256T
CF CF
S26HL512T
✓CF
S26HL01GT
✓CF
S26HL02GT
CF
S26HL04GT
CF
HYPERFLASH™
KL
-S3
S26KL128S
✓CF
S26KL256S
✓CF
S26KL512S
✓CF
Quad SPI
QSPI
FL
-S
Dual Quad
S79FL256S
✓
S79FL512S
✓
S79FL01GS
✓
CF = Contact Factory
UD = Under Development
1 Octal Interface (xSPI Profile 1.0)
2 HYPERBUS™ Interface (xSPI Profile 2.0)
3 HYPERBUS™ Interface
(ifileon
24
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
x4 Serial NOR Flash Memory Packages
Family
Interface
Series
Density
Device
SOIC-8
208 mil SOIC-16
300 mil WSON
4 x 4 mm
WSON
6 x 5 mm
WSON
8 x 6 mm
BGA24
8 x 8 mm
5 x 5 Ball
BGA24
8 x 6 mm
5 x 5 Ball
BGA24
8 x 6 mm
4 x 6 Ball
KGD WLCSP
SEMPER™
Flash
QSPI
HS
-T
256Mb
S25HS256T
CF CF CF CF
512Mb
S25HS512T
✓ ✓ ✓ CF
1Gb
S25HS01GT
✓ ✓ CF
2Gb
S25HS02GT
✓
4Gb
S25HS04GT
CF
HL
-T
256Mb
S25HL256T
CF CF CF CF
512Mb
S25HL512T
✓ ✓ ✓ CF
1Gb
S25HL01GT
✓ ✓ CF
2Gb
S25HL02GT
✓
4Gb
S25HL04GT
CF
Quad SPI
FS
-S
64Mb
S25FS064S
✓ ✓ ✓ ✓
128Mb
S25FS128S
✓CF ✓ ✓ ✓ ✓ CF
256Mb
S25FS256S
✓ ✓ ✓ ✓ ✓
512Mb
S25FS512S
✓ ✓ ✓ ✓ CF
1Gb
S70FS01GS
✓ ✓
FL
-S
128Mb
S25FL127S
✓ ✓ ✓ ✓ ✓
128Mb
S25FL128S
✓ ✓ ✓ ✓
256Mb
S25FL256S
✓ ✓ ✓ ✓
512Mb
S25FL512S
✓ ✓ ✓ ✓
1Gb
S70FL01GS
✓ ✓
FL
-L
64Mb
S25FL064L
✓ ✓ ✓ ✓ ✓ ✓ CF
128Mb
S25FL128L
✓ ✓ ✓ ✓ ✓ CF
256Mb
S25FL256L
✓ ✓ ✓ ✓ CF
CF = Contact Factory
UD = Under Development
(ifileon ---------- — —
25
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
SEMPER™ Secure Serial NOR Flash Memory Packages
Family
Interface
Series
Density
Device
SOIC-16
300 mil WSON
8 x 6 mm
BGA24
8 x 8 mm
5 x 5 Ball
BGA24
8 x 6 mm
5 x 5 Ball KGD
SEMPER™
Secure Flash
QSPI
HS
-T
128Mb
S35HS128T
CF CF CF CF
256Mb
S35HS256T
✓UD ✓CF
512Mb
S35HS512T
CF CF
1Gb
S35HS01GT
CF
HL
-T
128Mb
S35HL128T
CF CF CF CF
256Mb
S35HL256T
✓UD ✓CF
512Mb
S35HL512T
CF CF
1Gb
S35HL01GT
CF
HYPERBUS
HS
-T
128Mb
S36HS128T
CF CF
256Mb
S36HS256T
✓CF
512Mb
S36HS512T
CF CF
1Gb
S36HS01GT
CF
HL
-T
128Mb
S36HL128T
CF CF
256Mb
S36HL256T
✓CF
512Mb
S36HL512T
CF CF
1Gb
S36HL01GT
CF
Octal
HS
-T
128Mb
S38HS128T
CF CF
256Mb
S38HS256T
✓CF
512Mb
S38HS512T
CF CF
1Gb
S38HS01GT
CF
HL
-T
128Mb
S38HL128T
CF CF
256Mb
S38HL256T
✓CF
512Mb
S38HL512T
CF CF
1Gb
S38HL01GT
CF
CF = Contact Factory
UD = Under Development
(ifileon
26
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Parallel NOR Flash Memory Packages
Family
Density
Device
48-Ball
FBGA
(0.8
-
mm pitch)
48-Ball
FBGA
(0.5
-
mm pitch)
56-Ball
BGA
(0.8
-
mm pitch)
64-Ball
BGA
(0.8
-
mm pitch)
64-Ball
Fortified BGA
(1.0
-
mm pitch)
48-Pin
TSOP 56-Pin
TSOP KGD
GL
-T
512Mb
S29GL512T
✓ ✓ ✓
1Gb
S29GL01GT
✓ ✓ ✓
2Gb
S70GL02GT
✓
GL
-S
64Mb
S29GL064S
✓ ✓ ✓ ✓
128Mb
S29GL128S
✓ ✓ ✓ ✓
256Mb
S29GL256S
✓ ✓ ✓ ✓
512Mb
S29GL512S
✓ ✓ ✓ ✓
1Gb
S29GL01GS
✓ ✓ ✓
2Gb
S70GL02GS
✓
GL
-P
128Mb
S29GL128P
✓ ✓ ✓
256Mb
S29GL256P
✓ ✓ ✓
GL
-N
32Mb
S29GL032N
EOL EOL EOL EOL EOL
64Mb
S29GL064N
EOL EOL EOL EOL EOL
PL
-J
32Mb
S29PL032J
✓ ✓
64Mb
S29PL064J
✓ ✓
128Mb
S29PL127J
✓ ✓ ✓
JL
-J
32Mb
S29JL032J
✓ ✓
64Mb
S29JL064J
✓ ✓ ✓
AL
-J
8Mb
S29AL008J
✓ ✓ ✓
16Mb
S29AL016J
✓ ✓ ✓ ✓
AS
-J
16Mb
S29AS016J
✓ ✓ ✓ ✓
(ifileon ------==-
27
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Burst NOR Flash Memory Packages
Family
Device
44-Ball
FBGA
(0.5-mm pitch)
64-Ball
BGA
(0.5-mm pitch)
84-Ball
Fortified BGA
(0.8-mm pitch)
80-Ball
FBGA
(1.0-mm pitch)
80-Pin
PQFP KGD
VS
-R
S29VS064R
EOL
CD
-J
S29CD016J
✓ ✓ ✓
S29CD032J
EOL EOL
CL
-J
S29CL016J
EOL EOL
S29CL032J
EOL EOL
(ifileon ---------
28
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
Flash and RAM Memory MCP Packages
Family
Flash
Density RAM
Density
BGA24
8 x 6 mm
5 x 5 Ball
BGA24
8 x 8 mm
5 x 5 Ball
56-Ball
Very Thin FBGA
(0.5-mm pitch)
56-Ball
FBGA
(0.8-mm pitch)
84-Ball
FBGA
(0.8-mm pitch)
133-Ball
FBGA
(0.5-mm pitch)
S76HS-T
S76HL-T
512Mb 64Mb CF
512Mb 128Mb CF
1Gb 64Mb CF
1Gb 128Mb CF
S78HS-T
S78HL-T
512Mb 64Mb UD
512Mb 128Mb CF
1Gb 64Mb CF
1Gb 128Mb CF
S71KS
-S
128Mb 64Mb ✓
256Mb 64Mb ✓
512Mb 64Mb ✓
S71KL
-S
128Mb 64Mb ✓
256Mb 64Mb ✓
512Mb 64Mb ✓
S72XS
-R 256Mb 256Mb EOL
S71VS
-R
256Mb 128Mb EOL
256Mb 64Mb EOL
128Mb 64Mb EOL
128Mb 32Mb EOL
S71WS
-P 256Mb 64Mb ✓
CF = Contact Factory
UD = Under Development
(ifileon
29
SEMPER™ Solution Development Kit (SDK)
(iflleon
30
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
SEMPER™ SDK – portfolio
S-SDK Package
202112022
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
all S-SDK packages receive regular updates for bugfixes and new features, for more details please contact SEMPER-sdk@infineon.com
BASE 2, 3, 4
(Flash Device Driver)
SAFE 2, 4
(Flash and Fusa Drivers)
SECURE 4
(Flash, Fusa and Secure Drivers)
1Calendar Year
2SEMPER
3SEMPER Nano
4SEMPER Secure sampling
release
(ifileon ,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,
31
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
SEMPER™ SDK – platform enablement
S-SDK Platform 202112022
Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4
Virtual S-SDK 2
ModusToolbox 4, 5
(PSoC, QSPI)
ARM Mbed 4, 5, 6
(PSoC, QSPI)
AURIX™Developer Studio3, 6
(iLLD, Queued-SPI)
Raspberry Pi 3
(Linux, SPI, spidev)
NVIDIA Jetson Nano 3, 6
(Linux, SPI, spidev)
Traveo™II
(xSPI)
AURIX TC4x
(xSPI)
Other Platforms 6
1Calendar Year
2Secure Driver only, Linux, C-Model
3SW Crypto Library (wolfSSL’s wolfCrypt)
4SW Crypto Library (ARM Mbed TLS)
5SW Crypto Library (ARM Mbed Crypto)
6Please contact SEMPER-sdk@infineon.com
please contact SEMPER-sdk@infineon.com
sampling
request
release
plan
(ifileon fi
32
Copyright © Infineon Technologies AG 2021. All rights reserved.restricted2021-07-01
SEMPER™ SDK – starter kits and Flash modules
Density (Name)
SDR Clock/DDR Clock
* Temperature Range
SEMPER Secure
Starter Kits SEMPER
Starter Kits SEMPER Family
Flash Memory Modules
For more starter kit options contact SEMPER-sdk@infineon.com or see:
https://www.cypress.com/microcontrollers-mcus-kits
https://www.infineon.com/cms/en/product/microcontroller/32-bit-tricore-microcontroller/#boards
1 QSPI Interface
2 Onboard flash
3Available from MikroElektronika
PMOD
Quad SPI
24-ball BGA 6x8mm
PMOD
Octal / HYPERBUS SPI
24-ball BGA 6x8mm
S35HL256T
AURIX™, PMOD
TC275 Lite Kit
Q122
Sampling ProductionConcept Development
QQYYQQYY
Status
Availability
S35HL256T2
AURIX
TC375 Lite Kit
Q122
S35HL256T1,2
PSoC 64, Symmetric
CY8CPROTO-064B0S1-SSS
Q122
S35HL256T1,2
PSoC 64, Asymmetric
CY8CPROTO-064B0S1-SSA
Q122
PMOD
Quad SPI
WLCSP
Click board™
SEMPER FLASH CLICK 1, 3
S25HS512T
Click board
SEMPER FLASH 2 CLICK 1, 3
S25HL512T
S25HL512T1,2
PSoC 64
CY8CPROTO-064B0S3
S25HL512T
AURIX, Click
TC275 Lite Kit
S25HL512T
AURIX, Click
TC375 Lite Kit
S25HL512T1,2
PSoC 64
CY8CPROTO-064S1-SB
(ifiineon Part ofyour life. Part of tomorrow.
33
001-97268 AC
