SBAU280–November 2016

ADS7049-Q1EVM-PDK

Microsoft, Windows are registered trademarks of Microsoft Corporation.

LabVIEW is a trademark of National Instruments.

All other trademarks are the property of their respective owners.

User's Guide

SBAU280–November 2016

ADS7049-Q1EVM-PDK

This user's guide describes the characteristics, operation, and use of the ADS7049-Q1 evaluation module

(EVM) performance demonstration kit (PDK). This kit is an evaluation platform for the ADS7049-Q1, which

is a 12-bit, 2-MSPS, single-ended analog input, successive approximation register (SAR) analog-to-digital

converter (ADC) that features an easy-to-use SPI serial interface. The EVM-PDK eases the evaluation of

the ADS7049-Q1 device with hardware, software, and computer connectivity through the universal serial

bus (USB) interface. This user's guide includes complete circuit descriptions, schematic diagrams, and a

bill of materials.

The following related documents are available through the Texas Instruments web site at www.ti.com.

Related Documentation

Device Literature Number

ADS7049-Q1 SBAS763

OPA365-Q1 SBOS512

TPS791-Q1 SGLS160

SN74AVC4T245-Q1 SCES792

l TEXAS INSTRUMENTS

www.ti.com

2SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

Contents

1 Overview ...................................................................................................................... 4

1.1 ADS7049-Q1EVM-PDK Features ................................................................................ 4

1.2 ADS7049-Q1EVM Features ....................................................................................... 4

2 Analog Interface.............................................................................................................. 5

2.1 Connectors for Single-Ended Analog Input ..................................................................... 5

2.2 ADC Single-Ended Input Signal Driver .......................................................................... 5

3 Digital Interfaces ............................................................................................................. 6

3.1 SPI Interface for ADC Digital IO .................................................................................. 6

4 Power Supplies .............................................................................................................. 7

5 ADS7049-Q1EVM-PDK Initial Setup ...................................................................................... 8

5.1 Default Jumper Settings ........................................................................................... 8

5.2 EVM Graphical User Interface (GUI) Software Installation.................................................... 8

6 ADS7049-Q1EVM-PDK Operation....................................................................................... 12

6.1 EVM GUI Global Settings for ADC Control .................................................................... 14

6.2 Time Domain Display Tool ....................................................................................... 15

6.3 Spectral Analysis Tool ............................................................................................ 16

6.4 Histogram Tool .................................................................................................... 17

6.5 Offset Calibration.................................................................................................. 17

7 Bill of Materials, PCB Layout, and Schematics......................................................................... 19

7.1 Bill of Materials .................................................................................................... 19

7.2 PCB Layout ........................................................................................................ 21

7.3 Schematics......................................................................................................... 25

List of Figures

1 ADS7049-Q1EVM Analog Input Path..................................................................................... 5

2 ADS7049-Q1EVM-PDK Jumper Locations............................................................................... 8

3 ADS7049-Q1 Software Installation Prompts ............................................................................. 9

4 Device Driver Installation Wizard Prompts.............................................................................. 10

5 LabVIEW Run-Time Engine Installation................................................................................. 11

6 ADS7049-Q1EVM-PDK Installation Final Step......................................................................... 11

7 EVM-PDK Hardware Setup and LED Indicators ....................................................................... 12

8 Launch the EVM GUI Software........................................................................................... 13

9 EVM GUI Global Input Parameters ...................................................................................... 14

10 Time Domain Display Tool Options...................................................................................... 15

11 Spectral Analysis Tool..................................................................................................... 16

12 Histogram Analysis Tool .................................................................................................. 17

13 ADS7049-Q1 Calibration .................................................................................................. 18

14 ADS7049-Q1EVM PCB Layer 1: Top Layer............................................................................ 21

15 ADS7049-Q1EVM PCB Layer 2: GND Plane .......................................................................... 22

16 ADS7049-Q1EVM PCB Layer 3: Power Planes ....................................................................... 23

17 ADS7049-Q1EVM PCB Layer 4: Bottom Layer........................................................................ 24

18 Schematic Diagram (Page 1) of the ADS7049-Q1EVM PCB ........................................................ 25

19 Schematic Diagram (Page 2) of the ADS7049-Q1EVM PCB ........................................................ 26

List of Tables

1 Analog Input Connector Description ...................................................................................... 5

2 TPS79101 Voltage Settings for AVDD and OPA+ Supplies ........................................................... 7

3 AVDD Voltage Selection Settings ......................................................................................... 7

4 Default Jumper Configurations............................................................................................. 8

5 External Source Requirements for Evaluation of the ADS7049-Q1 ................................................. 16

l TEXAS INSTRUMENTS

www.ti.com

SBAU280–November 2016

ADS7049-Q1EVM-PDK

6 ADS7049-Q1EVM Bill of Materials ...................................................................................... 19

l TEXAS INSTRUMENTS

Overview

www.ti.com

4SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

1 Overview

The ADS7049-Q1EVM-PDK is a platform for evaluating the performance of the ADS7049-Q1 SAR ADC,

which is a single-ended analog input, 12-bit, 2-MSPS device. The evaluation kit includes the ADS7049-

Q1EVM board and the Precision Host Interface (PHI) controller board that enables the accompanying

computer software to communicate with the ADC over USB for data capture and analysis.

The ADS7049-Q1EVM board includes the ADS7049-Q1 SAR ADC, all the peripheral analog circuits, and

components required to extract optimum performance from the ADC.

The PHI board primarily serves three functions:

• Provides a communication interface from the EVM to the computer through a USB port

• Provides the digital input and output signals necessary to communicate with the ADS7049-Q1

• Supplies power to all active circuitry on the ADS7049-Q1EVM board

Along with the ADS7049-Q1EVM and PHI controller board, this evaluation kit includes an A-to-micro-B

USB cable to connect to a computer.

1.1 ADS7049-Q1EVM-PDK Features

The ADS7049-Q1EVM-PDK includes the following features:

• Hardware and software required for diagnostic testing as well as accurate performance evaluation of

the ADS7049-Q1 ADC

• USB powered—no external power supply is required

• The PHI controller that provides a convenient communication interface to the ADS7049-Q1 ADC over

USB 2.0 (or higher) for power delivery as well as digital input and output

• Easy-to-use evaluation software for Microsoft®Windows®7, Windows 8, 64-bit operating systems

1.2 ADS7049-Q1EVM Features

The ADS7049-Q1EVM includes the following features:

• Onboard low-noise and low distortion ADC input drivers optimized to meet ADC performance

• Onboard ultralow noise low-dropout (LDO) regulators to generate supplies for the operation amplifier

and voltage reference.

‘5‘ TEXAS INSTRUMENTS 0PM

AVDD

OPA_VDD

OPA365-Q1

AINP

GND

VDD

Device

Input Driver Device: 12 Bit , 2 MSPS,

Single-Ended Input

GND

25.5 

1.5 nF

VSOURCE

±25.5 

25.5 

AINM

www.ti.com

Analog Interface

SBAU280–November 2016

ADS7049-Q1EVM-PDK

2 Analog Interface

The ADS7049-Q1 is an low-power, extremely small size ADC that supports single-ended analog inputs.

The ADS7049-Q1EVM uses an OPA365-Q1 amplifier to drive the inputs of the ADC. The ADS7049-

Q1EVM is designed for easy interface to analog sources. This section covers driver details including

jumper configuration for analog input signal source.

2.1 Connectors for Single-Ended Analog Input

The ADS7049-Q1EVM is designed for easy interfacing to an external analog single-ended source via a

subminiature version A (SMA) connector or 100-mil headers. J2 is the SMA connector that allows analog

source connectivity through coaxial cables. Alternatively, 100-mil jumper cables or mini-grabbers can be

used to connect analog sources to the J6:1 pin.

Table 1. Analog Input Connector Description

Pin Number Signal Description

J2 INP Positive single-ended input provided at the SMA

J6:1 INP Alternate location to provide the positive single-ended input

2.2 ADC Single-Ended Input Signal Driver

SAR ADC inputs terminate in switched-capacitor networks that create large instantaneous current loads

when the switches are closed that effectively make the ADC inputs dynamically low impedance. The

single-ended input of the ADS7049-Q1 are therefore driven by an OPA365-Q1 used in an non-inverting,

unity-gain configuration to maintain ADC performance with maximum loading at full device throughput of 2

MSPS.

2.2.1 Input Signal Path

Figure 1 shows the signal path for positive single-ended input applied to ADS7049-Q1EVM. An OPA365-

Q1 is used in buffer configuration drives single-ended input of ADS7049-Q1. An RC filter value of 25.5 Ω

and 1.5 nF are selected to achieve SINAD greater than 70 dB and THD less than – 80 dB for 2 kHz sine

wave input at full throughput of 2 MSPS.

Figure 1. ADS7049-Q1EVM Analog Input Path

l TEXAS INSTRUMENTS

Digital Interfaces

www.ti.com

6SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

3 Digital Interfaces

As noted in Section 1, the EVM interfaces with the PHI that, in turn, communicates with the computer over

USB. There are two devices on the EVM with which the PHI communicates: the ADS7049-Q1 ADC (over

SPI or multiSPI) and the EEPROM (over I2C). The EEPROM comes pre-programmed with the information

required to configure and initialize the ADS7049-Q1EVM-PDK platform. Once the hardware is initialized,

the EEPROM is no longer used.

3.1 SPI Interface for ADC Digital IO

The ADS7049-Q1EVM-PDK supports the interface and calibration modes as detailed in the ADS7049-Q1

datasheet (SBAS763). The PHI is capable of operating at a 3.3 V logic level and is directly connected to

the digital I/O lines of the ADC.

The buffer U6 is included in the design to ensure that, if required, the SDO can be driven to a host

controller over long cables with minimal distortion. For the normal operating condition with the PHI directly

plugged in on connector J1, the U6 buffer is not required and has been bypassed in the factory

configuration of the ADS7049-Q1EVM-PDK.

l TEXAS INSTRUMENTS

www.ti.com

Power Supplies

SBAU280–November 2016

ADS7049-Q1EVM-PDK

4 Power Supplies

The ADS7049-Q1 supports a wide range of operation on its analog supplies. The AVDD can operate from

2.35 V to 3.6 V. The DVDD operates from 1.65 V to 3.6 V, independent of the AVDD supply. The analog

portion of the ADS7049-Q1EVM-PDK operates from a 5.5 V supply, that in turn generates an AVDD

supply and an OPA+ supply using low-noise TPS79101 LDOs. The AVDD supply is nominally set to 3.3 V

at the factory, but this voltage may be changed to any value within the valid range, by modifying the value

of R12 as per Table 2. Similarly, the OPA+ supply is nominally set to 4.83 V at the factory, but this voltage

maybe changed by modifying the value of R15 as per Table 2. In case any intermediate values need to be

set, the detailed formula to arrive at these values are available in the TPS79101 (SGLS160) datasheet.

Table 2. TPS79101 Voltage Settings for AVDD and OPA+ Supplies

Output Voltage R12/R15 R13/R16 C7/C11

1.8 V 14.2 kΩ30.1 kΩ33 pF

2.0 V 19.1 kΩ30.1 kΩ27 pF

2.5 V 31.6 kΩ30.1 kΩ22 pF

3.0 V 43.7 kΩ30.1 kΩ15 pF

3.3 V 51.1 kΩ30.1 kΩ15 pF

3.6 V 59.0 kΩ30.1 kΩ15 pF

4.83 V 88.7 kΩ30.1 kΩ15 pF

Alternatively, AVDD may be set by connecting an external power source through J3. Table 3 describes the

modifications required for on-board or external AVDD supply.

Table 3. AVDD Voltage Selection Settings

AVDD Source Position Setting

Onboard regulated AVDD

(set to 3.3 V) J3 Closed

External AVDD J3 Open

R11 Disassembled

CAUTION

The external AVDD supply applied to external connector J3 must not exceed

3.6 V as this may damage the device. The external AVDD supply must be in

the range of 2.35 V to 3.6 V for proper operation of the ADS7049-Q1EVM.

The digital portion of the ADS7049-Q1 ADC operates from a 3.3 V supply from the PHI.

i TEXAS INSTRUMENTS For avaluallon anly: not ms approved lur resale. n3 CHI: 1 24 TF1 ‘22: "'r‘ m. H2 .- _ a” _ ' H6 I TEXAS : :2 INSTRUMENT; W 1—2 11 $5 ~ E a I— I I: J nl_IR:I]U |: _:Ic1 “,3 n5 rm ' n55 EFM

ADS7049-Q1EVM-PDK Initial Setup

www.ti.com

8SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

5 ADS7049-Q1EVM-PDK Initial Setup

This section explains the initial hardware and software setup procedure that must be completed for the

proper operation of the ADS7049-Q1EVM-PDK.

5.1 Default Jumper Settings

The silk screen plot shown in Figure 2 details the jumper locations for ADS7049-Q1EVM-PDK.

Figure 2. ADS7049-Q1EVM-PDK Jumper Locations

Table 4 explains the functionality of each of these jumpers and their default configurations. No shunts are

required on any location at the EVM for normal operation. Remove any shunts that may be present at

locations J3 through J6.

Table 4. Default Jumper Configurations

Reference Designator Default Configuration Description

J3 Open Location to feed external AVDD supply to the ADS7049-Q1EVM-PDK

J4 Open Unassembled by default

J5 Open Location for external trigger signal (3.3-V logic)

J6 Open Alternate location for analog input to the ADS7049-Q1EVM-PDK

5.2 EVM Graphical User Interface (GUI) Software Installation

Download the latest version of the EVM GUI installer from the Tools and Software folder of the ADS7049-

Q1 and run the GUI installer to install the EVM GUI software on the user’s computer.

CAUTION

Manually disable any antivirus software running on the computer before

downloading the EVM GUI installer onto the local hard disk. Otherwise,

depending on the antivirus settings, an error message may appear or the

installer.exe file may be deleted.

I TEXAS INSTRUMENTS wan-tumuvmmmmm NATIONAL lusmuuacu 306mm: ucEnaE WEEKS" mmunou mm: M: m cmr Kim mu man) u: what Arm was we nstnumou pnocsss mmm . . xunm-ym-é “W“W‘Mm" , lam-(whim KEEE Immmmhmrhmnvwmmmnmdm MWHMM-OHKW m .m mum-mm u.- lbI-nhmll Imerb-ucmlﬂmﬂumllummm. mmuuguryunmv Anny-um n .IWVHIM ma mvmuwaugmwhlm non-awn ‘I m 1—mlxxmn “°""‘““"“"‘“‘" 14.1,..an m (M mo'w

www.ti.com

ADS7049-Q1EVM-PDK Initial Setup

SBAU280–November 2016

ADS7049-Q1EVM-PDK

Accept the license agreements and follow the on-screen instructions to complete the installation.

Figure 3. ADS7049-Q1 Software Installation Prompts

As a part of the ADS7049-Q1EVM GUI installation, a prompt with a Device Driver Installation will appear

on the screen. Click Next to proceed.

TEXAS INSTRUMENTS Welcome lo me me omer mllam llllnnil can-plenum Ihe name nmey lnshllalmn W-ni Mmmmmmimmmmman [wmmmmm.._ M.,.._Mn.“mmm~ Ywmmwmmmmwimﬂ Iva-m mun-mum pic-mum»: mum: am. va-uu—nmm Rumm— Yum-16d“

ADS7049-Q1EVM-PDK Initial Setup

www.ti.com

10 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

Figure 4. Device Driver Installation Wizard Prompts

NOTE: A notice may appear on the screen stating that Widows cannot verify the publisher of this

driver software. Select Install this driver software anyway.

l TEXAS INSTRUMENTS a; ‘ ﬂLabVIEw 2012 1 ‘mr “nwmmunu. D....,m...._...._m._ “mm“..mwmw“ Nmmw-c-nwwmmmuhmmxw ounc ,uﬁwwym» Jam...” \uvaLNu .m,‘ w w m mm a.»— Ira-Imam m mm usnmn mm“: mans: museum" mum-4 mm was s Acormua gems mmum m m wag-mm n: mmuwu mam ChﬁinlVlle ms mum '1 mm M sonwmi mmcm m mums mane an: m: "Gunman mm M Wumwvi W“) was Kiwmwvmml‘zwzmﬂnmsumn rmmwmwo Mnmvumslmiwmunkmwu wwwmsw mum's cuummm mm w mm M usmumou Puma uormslm m use I»: wrwmz an aim M ”mu-as m. m yum-Isovnscimo‘ n: WE mm mm-mmmnm moms euc m mammmma M m: my man m4 m mums KmquNrsmmiNr-inmmm . V»-~~7mnu-«m—v.kn-mnu|mMV-ﬂmmtn l-nikla-‘J—I mmmak-um “M El 5... Whnmmmlmszuq Vﬁnd snap mm.“ “mm”, AWQI mm an ymvcumvmu. g 0.... ”5mm” L 2“.QO

www.ti.com

ADS7049-Q1EVM-PDK Initial Setup

SBAU280–November 2016

ADS7049-Q1EVM-PDK

The ADS7049-Q1EVM-PDK requires LabVIEW™ Run-Time Engine and may prompt for the installation of

this software, if not already installed.

Figure 5. LabVIEW Run-Time Engine Installation

After these installations, check the Create Desktop Shortcut as shown in Figure 6.

Figure 6. ADS7049-Q1EVM-PDK Installation Final Step

l TEXAS INSTRUMENTS

ADS7049-Q1EVM-PDK Operation

www.ti.com

12 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

6 ADS7049-Q1EVM-PDK Operation

The following instructions are a step-by-step guide to connecting the ADS7049-Q1EVM-PDK to the

computer and evaluating the performance of the ADS7049-Q1:

1. Connect the ADS7049-Q1EVM to the PHI. Install the two screws as indicated in Figure 7.

2. Use the provided USB cable to connect the PHI to the computer.

• LED D5 on the PHI lights up, indicating that the PHI is powered up.

• LEDs D1 and D2 on the PHI start blinking to indicate that the PHI is booted up and communicating

with the PC.

Figure 7. EVM-PDK Hardware Setup and LED Indicators

3. Launch the ADS7049-Q1EVM GUI software from the installed path as shown in Figure 8 or using the

desktop shortcut created during installation.

0.9.0:: . 1.51.1531an . Shilzwlh v "(Klaus * Fm I 051000 I mm mm“ Nam: I Conﬁymw ﬁla I ﬁsvuch-u I Mm “MEN-0y Emma: @mw—lem‘ﬁg L] mm mm. E Am-QLWMjULM-rﬂdjml L} page MADE/0001mm , 051mg Map_m9q1ml L1 mm a um um modmad 11/9/2015 500 PM 11/9/2015 590 PM 11/9/2015 500 PM 11/9/2015 500 PM 11/9/2015 500 PM 11/9/2015 3:59 PM 11/9/2015 335 PM 11/9/2015 355 PM 11/9/2015 3 A9 0M 11/9/2015 30; PM 11/9/2015 3w PM 11/9/2015 500 PM 11/9/2015 500 PM Typé me «5111. H: man Me 15155. We may 5/. loldu Applltatmn XML Canllgmalm M m: HVML Dow/MM m 5.1: XML 052mm on 50: 15502155.. 11,213 KB 1 KB 1 KB 19 KB 2 KB 10 KB 9 110 0,301 KB

www.ti.com

ADS7049-Q1EVM-PDK Operation

SBAU280–November 2016

ADS7049-Q1EVM-PDK

Figure 8. Launch the EVM GUI Software

l TEXAS INSTRUMENTS m mum:ms1wa1£w E Crmnmwﬂmman gamma Time Domain Display ”5mm mm WWW mmummm. iEmmm anllode scIKrm-Iatﬂ‘m mgu Ann-unl- am A mm mm Walls) Tame! mauve 2m: 2m Ii—nwxv—a "mom: n Venn)" 1 2n

ADS7049-Q1EVM-PDK Operation

www.ti.com

14 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

6.1 EVM GUI Global Settings for ADC Control

Figure 9 identifies the input parameters of the GUI (as well as their default values) through which the

various functions of the ADS7049-Q1 can be exercised. These settings are global because they persist

across the GUI tools listed in the top left pane (or from one page to another).

Figure 9. EVM GUI Global Input Parameters

The user can select SCLK Frequency and Sampling Rate on this pane. The GUI allows the user to enter

the targeted values for these two parameters and the GUI computes the best values that can be achieved,

considering the timing constraints of the device.

The user can specify a target SCLK frequency (in Hz) and the GUI tries to match this frequency as closely

as possible by changing the PHI PLL settings and the achievable frequency may differ from the target

value entered. Similarly, the sampling rate of the ADC can be adjusted by modifying the Target Sampling

Rate argument (also in Hz). The achievable ADC sampling rate can differ from the target value, depending

on the applied SCLK frequency and the closest match achievable is displayed. This pane, therefore,

allows the user to try various settings available on the ADS7049-Q1 in an iterative fashion until the user

converges to the best settings for the corresponding test scenario.

Located above these controls, is an External Trigger Mode checkbox. When selected this configures the

PHI to monitor the signal connected on J5:1 for a low to 3.3 V transition and captures the requested

number of samples after this level transition is detected. This is useful in cases when the external analog

input is generated or ready for measurement only after an external trigger event.

I TEXAS INSTRUMENTS <> swan! mm o Hmmm Mums o matcalmm mm man... D Ell-mi magnum: sun flan-mm mm Mam. unH 32W my mum! rug-u mmw. WNW Time Domain Display mennu:ms1wm£w Vsmleil ﬁlouxielanue E all)!

www.ti.com

ADS7049-Q1EVM-PDK Operation

SBAU280–November 2016

ADS7049-Q1EVM-PDK

6.2 Time Domain Display Tool

The time domain display tool allows visualization of the ADC response to a given input signal. This tool is

useful for both studying the behavior and debugging any gross problems with the ADC or drive circuits.

The user can trigger a capture of the data of the selected number of samples from the ADS7049-Q1, as

per the current interface mode settings using the Capture button as indicated in Figure 10. The sample

indices are on the x-axis and there are two y-axes showing the corresponding output codes as well as the

equivalent analog voltages based on the specified reference voltage. Switching pages to any of the

Analysis tools described in the subsequent sections, triggers calculations to be performed on the same set

of data.

Figure 10. Time Domain Display Tool Options

I TEXAS INSTRUMENTS mum-1%” memam:ms1mmzw FM"— 0 nmmmmsum 0 WWW,” Spectral Analysis <> wumumm unwamuﬁ Dmn‘m/DC' H m mmmnum H mm Ynmullm: gm mammary raga Ann-um WW ”madam 5....- Walls] mm mm» 2mm 2mm mum 5W5 sums) mm, sgm mans) “mukm 55535 E \ mm \ mm \ ‘0493103 run \—1 ms mm 5mm mm 4201 \ mm mm \ \ mm rm. mm mm mm mun m ”M “Hi-"WI: n Cindi-mm ummmsxnusu nummmuw mm mm a El ram-sun EH ‘zomwk‘ ‘wms ‘ ‘ mu ‘ iﬁiiiéﬁi Veulmﬂl) ﬂ mslmmm

ADS7049-Q1EVM-PDK Operation

www.ti.com

16 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

6.3 Spectral Analysis Tool

The spectral analysis tool is intended to evaluate the dynamic performance (SNR, THD, SFDR, SINAD,

and ENOB) of the ADS7049-Q1 SAR ADC through single-tone sinusoidal signal FFT analysis using the 7-

term Blackman-Harris window setting. Alternatively, the window setting of None can be used to search for

noise spurs over frequency in dc inputs.

For dynamic performance evaluation, the external single-ended source must have better specifications

than the ADC itself to ensure that the measured system performance is not limited by the performance of

the signal source. Therefore, the external reference source must meet the source requirements mentioned

in Table 5.

Table 5. External Source Requirements for Evaluation of the ADS7049-Q1

Specification Description Specification Value

Signal frequency 2 kHz

External source type Single ended

External source common-mode 1.65 V

Maximum SNR 80 dB

Maximum THD –100 dB

Figure 11. Spectral Analysis Tool

I TEXAS INSTRUMENTS mmwm 2w mum:wsma1£w lZ Cmmmum. mu 0 nunmmumy e um . <> om mmn mmaumm. ﬁ 9mm WWI-mm murmcmu fame! Mamie mHRm my may mm.“ "199‘ IE- Histogram Analysis m=_ mm «m m. sow»

www.ti.com

ADS7049-Q1EVM-PDK Operation

SBAU280–November 2016

ADS7049-Q1EVM-PDK

6.4 Histogram Tool

Noise degrades ADC resolution and the histogram tool can be used to estimate effective resolution, which

is an indicator of the number of bits of ADC resolution losses resulting from noise generated by the

various sources connected to the ADC when measuring a dc signal. The cumulative effect of noise

coupling to the ADC output from sources such as the input drive circuits, the reference drive circuit, the

ADC power supply, and the ADC itself is reflected in the standard deviation of the ADC output code

histogram that is obtained by performing multiple conversions of a dc input applied to a given channel.

The histogram corresponding to a dc input is displayed on clicking the Capture button, as shown in

Figure 12:

Figure 12. Histogram Analysis Tool

6.5 Offset Calibration

The ADS7049-Q1 device has the ability to calibrate its internal offset. The offset calibration can be

initiated by the user either on power-up or during normal operation. During offset calibration, the analog

input pins (AINP and AINM) are disconnected from the sampling stage and connected to an internal

reference. The result of the offset calibration is stored in an internal register. For subsequent conversions,

the device adjusts the conversion results provided on the SDO output with the value stored in this internal

The ADS7049-Q1 GUI implements offset calibration as described in the Offset Calibration During Normal

Operation section of ADS7049-Q1 datasheet (SBAS763). Figure 13 depicts the Offset Calibration page of

the GUI.

I TEXAS INSTRUMENTS mom-smug: Pas-s sv- rum-cm : mam-mm mm In mm" o n... Dwmm mm <> and": Wm: 0 ms mm 515 dam lulu-(mum vaua rm» an scum-mm m;- mm. WIT 5mm! w» Amman: El Id: Offset Calibration mowmmnm xsmenl mm E HEM mug-am H. mm mm M15 mi; M25 24“ m mks zodssmkazoksmh M15 2n‘u 2nd: mks 2.9895 2050 cm“ HEM may!!!" ﬁ mm am” imam mm» m mu: m mu m 31435 m n: m ms nu mu: m ms nu mu m mun-mm: my“ um 3mm manna OMszmm ‘Hﬁm E mum 114571 In; 3 m numbing.“ mm a”. cum-smut: mm m 3 ‘ Mama _¢mmm

ADS7049-Q1EVM-PDK Operation

www.ti.com

18 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

Figure 13. ADS7049-Q1 Calibration

The Offset Calibration test is best conducted with a DC input at the Analog Input Terminal of the

ADS7049-Q1EVM-PDK. Simply click the Calibrate button. The GUI first performs a histogram test for the

device described in Section 6.4 and populates the first of the two graphs. The pre-calibrated Mean code is

inserted in the indicator. Next, the calibration frame is sent to the ADS7049-Q1 device that enables the

internal offset calibration logic. The GUI performs the histogram test for a second time and the second

graph is populated and Post Calibrated Mean value computed. Finally, the difference between the first and

second computed mean is populated in the Calculated Offset Correction indicator.

The computed offset for all subsequent attempts to calibrate the device will always yield a result within the

limits specified in the datasheet. This indicates that after the calibration is performed for the first time, the

offset is actually being applied on all subsequent conversions. This computed offset will remain fixed,

unless the device is reset or there is a significant change in operating temperature or analog supply

voltage.

l TEXAS INSTRUMENTS

www.ti.com

Bill of Materials, PCB Layout, and Schematics

SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

7 Bill of Materials, PCB Layout, and Schematics

This section contains the ADS7049-Q1EVM bill of materials,PCB layout, and the EVM schematics.

7.1 Bill of Materials

Table 6 lists the ADS7049-Q1EVM BOM.

Table 6. ADS7049-Q1EVM Bill of Materials

Manufacturer Part Number Qty Reference Designators Manufacturer Description

PA043 1 !PCB Any Printed Circuit Board

PA007A 1 !PCB2 Any PHI-EVM-CONTROLLER

1891 4 @H1, @H2, @H3, @H4 Keystone 3/16 Hex Female Standoff

RM3X4MM 2701 2 @H5, @H6 APM HEXSEAL Machine Screw Pan PHILLIPS M3

GRM155R71C104KA88D 3 C1, C2, C3 Murata CAP, CERM, 0.1 µF, 16 V, +/- 10%, X7R, 0402

08051C153KAT2A 2 C4, C5 AVX CAP, CERM, 0.015 µF, 100 V, +/- 10%, X7R, 0805

GRM1885C1H150JA01D 2 C7, C11 Murata CAP, CERM, 15 pF, 50 V, +/- 5%, C0G/NP0, 0603

C3216X7R1V106K160AC 2 C8, C12 TDK CAP, CERM, 10 µF, 35 V, +/- 10%, X7R, 1206_190

C1608X7R1C105K 2 C9, C13 TDK CAP, CERM, 1 µF, 16 V, +/- 10%, X7R, 0603

GCM155R71H103KA55D 2 C10, C14 Murata CAP, CERM, 0.01 µF, 50 V, +/- 10%, C0G/NP0, 0402

CGA4J1X7S1C106K125AC 3 C16, C17, C18 TDK CAP, CERM, 10 µF, 16 V, +/- 10%, X7S, AEC-Q200 Grade 1, 0805

GCM155R71C104KA55D 1 C19 Murata CAP, CERM, 0.1 µF, 16 V, +/- 10%, X7R, 0402

PMSSS 440 0025 PH 4 H1, H2, H3, H4 B&F Fastener Supply MACHINE SCREW PAN PHILLIPS 4-40

9774050360R 2 H5, H6 Wurth Elektronik ROUND STANDOFF M3 STEEL 5MM

QTH-030-01-L-D-A 1 J1 Samtec Header(Shrouded), 19.7mil, 30x2, Gold, SMT

5-1814832-1 1 J2 TE Connectivity SMA Straight PCB Socket Die Cast, 50 Ohm, TH

TSM-102-01-L-SV 4 J3, J4, J5, J6 Samtec Header, 100mil, 2x1, Gold with Tin Tail, SMT

THT-14-423-10 1 LBL1 Brady Thermal Transfer Printable Labels, 0.650" W x 0.200" H - 10,000 per roll

CRCW040249R9FKED 3 R2, R5, R7 Vishay-Dale RES, 49.9, 1%, 0.063 W, 0402

CRCW040225R5FKED 3 R3, R4, R10 Vishay-Dale RES, 25.5, 1%, 0.063 W, 0402

CRCW06031M00JNEA 1 R8 Vishay-Dale RES, 1.0 M, 5%, 0.1 W, 0603

RC0603FR-0710RL 1 R11 Yageo America RES, 10.0, 1%, 0.1 W, 0603

CRCW040251K1FKED 1 R12 Vishay-Dale RES, 51.1 k, 1%, 0.063 W, 0402

CRCW040230K1FKED 2 R13, R16 Vishay-Dale RES, 30.1 k, 1%, 0.063 W, 0402

CRCW04020000Z0ED 5 R14, R28, R29, R30, R31 Vishay-Dale RES, 0, 5%, 0.063 W, 0402

CRCW040288K7FKED 1 R15 Vishay-Dale RES, 88.7 k, 1%, 0.063 W, 0402

CRCW040210K0FKED 2 R17, R18 Vishay-Dale RES, 10.0k ohm, 1%, 0.063W, 0402

ERJ-2GE0R00X 4 R21, R22, R23, R24 Panasonic RES, 0, 5%, 0.063 W, 0402

CRCW040220R0FKED 1 R25 Vishay-Dale RES, 20.0, 1%, 0.063 W, 0402

5015 1 TP1 Keystone Test Point, Miniature, SMT

l TEXAS INSTRUMENTS

Bill of Materials, PCB Layout, and Schematics

www.ti.com

20 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

Table 6. ADS7049-Q1EVM Bill of Materials (continued)

Manufacturer Part Number Qty Reference Designators Manufacturer Description

5002 3 TP2, TP3, TP4 Keystone Test Point, Miniature, White, TH

ADS7049IDCUR 1 U1 Texas Instruments Ultra-Low Power, Ultra-Small Size, 12-Bit, 1-MSPS, SAR ADC, DCU0008A

OPA365AQDBVRQ1 1 U2 Texas Instruments Automotive Catalog, 50 MHz, Low-Noise, Single-Supply Rail-to-Rail Operational Amplifier, 2.2 to 5.5 V, -40 to 125

degC, 5-pin SOT23 (DBV0005A), Green (RoHS & no Sb/Br)

TPS79101DBVRQ1 2 U3, U4 Texas Instruments Single Output High PSRR LDO, 100 mA, Adjustable 1.2 to 5.5 V Output, 2.7 to 5.5 V Input, 6-pin SOT-23 (DBV), -40

to 125 degC, Green (RoHS & no Sb/Br)

BR24G32FVT-3AGE2 1 U5 Rohm I2C BUS EEPROM (2-Wire), TSSOP-B8

GCM155R71H103KA55D 0 C6, C15 Murata CAP, CERM, 0.01 µF, 50 V, +/- 10%, C0G/NP0, 0402

GRM1555C1H470FA01D 0 C20 Murata CAP, CERM, 47 pF, 50 V, +/- 1%, C0G/NP0, 0402

SP4020-01FTG 0 D1 Littelfuse Diode, TVS, Uni, 3.3 V, 21.8 Vc, SOD-323

N/A 0 FID1, FID2, FID3 N/A Fiducial mark. There is nothing to buy or mount.

CRCW04020000Z0ED 0 R1, R6, R27 Vishay-Dale RES, 0, 5%, 0.063 W, 0402

CRCW040210K0FKED 0 R9, R19, R20, R26 Vishay-Dale RES, 10.0k ohm, 1%, 0.063W, 0402

74AVC4T245QRGYRQ1 0 U6 Texas Instruments 4-Bit Dual-supply Bus Transceiver with Configurable Voltage Translation and 3-State Outputs, RGY0016A

Ola OIm._________________________no _==_=_h_h_w==r __=m_ Oman» mer JHMMHW if weirmmo 3LT _ Wmmaf 3,, $0... fugum alrruw ILu: ! a“ O o o O a O

www.ti.com

Bill of Materials, PCB Layout, and Schematics

SBAU280–November 2016

ADS7049-Q1EVM-PDK

7.2 PCB Layout

Figure 14 through Figure 17 illustrate the EVM PCB layout.

Figure 14. ADS7049-Q1EVM PCB Layer 1: Top Layer

l TEXAS INSTRUMENTS

Bill of Materials, PCB Layout, and Schematics

www.ti.com

22 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

Figure 15. ADS7049-Q1EVM PCB Layer 2: GND Plane

l TEXAS INSTRUMENTS

www.ti.com

Bill of Materials, PCB Layout, and Schematics

SBAU280–November 2016

ADS7049-Q1EVM-PDK

Figure 16. ADS7049-Q1EVM PCB Layer 3: Power Planes

l TEXAS INSTRUMENTS O O 0 0 ° 0 o o 0 ° 0 O O o O O 0 O O O 0 ° ° 0 o o O o a o oo °o°°o°1 0° 00 ° ‘K°—/ O O 0 o 00 O O 000 0 00 O O D 0 O O 0 00

Bill of Materials, PCB Layout, and Schematics

www.ti.com

24 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

Figure 17. ADS7049-Q1EVM PCB Layer 4: Bottom Layer

I TEXAS INSTRUMENTS “”j \ T , l T;

EVM_DVDDEVM_REG_5V5 EVM_ID_PWR

EVM_ID_SDA

EVM_ID_SCL

10.0k

R17

VSS

4SDA 5

SCL 6

WP 7

VCC 8

BR24G32FVT-3AGE2

11 11

13 13

15 15

17 17

19 19

21 21

23 23

25 25

27 27

29 29

31 31

33 33

35 35

37 37

39 39

41 41

43 43

45 45

47 47

49 49

51 51

53 53

55 55

57 57

59 59

GND

MP1

GND

MP2 GND MP3

GND MP4

QTH-030-01-L-D-A

EVM_DVDD

EVM_ID_SDA

EVM_ID_SCL

EVM_PRSNT_N

EVM_REG_5V5

EVM_ID_PWR

BYPASS 4

FB 5

OUT 6

GND

TPS79101DBVRQ1

1µF

GND

EVM_REG_5V5

15pF

51.1k

R12

30.1k

R13

10µF

BYPASS 4

FB 5

OUT 6

GND

TPS79101DBVRQ1

1µF

C13

GND

15pF

C11

30.1k

R16

10µF

C12

88.7k

R15

0R14

10.0R11

49.9R5

0.015µF

1.0M

OPA+

0R1DNP

0.1µF

OPA+

GND

49.9R2

25.5R3

GND

0.015µF

25.5R4

25.5

R10

AIN+

GND

CS_DUT

49.9R7

SCLK_DUT

EVM_DVDD

AVDD

GND

0.1µF

EVM_DVDD AVDD

GND GND

OPA-

CS 4

SDO 3

SCLK 2

DVDD 1

GND

AVDD 7

AINP

AINM

ADS7049IDCUR

R23

R24

R22CS_H

DNP

GND

GND GND GND

GND

10.0k

R18

EVM_ID_PWREVM_ID_PWR

GND

R27

DNP

AVDD

GND

AVDD

GND

R21

OPA365AQDBVRQ1

10µF

C16

0.1µF

C19

VCCA 1

1DIR 2

2DIR 3

1A1 4

1A2 5

2A1 6

2A2 7

GND

2B2

10 2B1

1B2

12 1B1

2OE

1OE

VCCB

GND/FLOAT

74AVC4T245QRGYRQ1

DNP

10µF

C17

10µF

C18

SDO_DUT

AIN-

SDO_H

SCLK_H

RET_CLK_H

SCLK_HSCLK_DUT

EVM_DVDD

SDO_HSDO_DUT

CS_HCS_DUT

SCLK_DUT RET_CLK

EVM_DVDD

10.0k

R19

DNP

0.01µF

C10

0.01µF

C14

0.01µF

DNP

EVM_DVDD

0.01µF

C15

DNP

EVM_DVDD

10.0k

DNP

GND

GND GND

10.0k

R20

DNP

10.0kR26 DNP

R31

R28

R29

R30

SCLK_DUT

CS_DUT

SDO_DUT

SCLK_DUT

CS_H

SCLK_H

RET_CLK

20.0

R25

GND

RET_CLK_H

47pF

C20

DNP

SDO_H

RET_CLK

EVM_DVDD

GND

EXT_TRIG

TP2TP3 TP4

TP1

3.3 V

SP4020-01FTG

DNP

GND

www.ti.com

Bill of Materials, PCB Layout, and Schematics

SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

7.3 Schematics

Figure 18 and Figure 19 illustrate the EVM schematics.

Figure 18. Schematic Diagram (Page 1) of the ADS7049-Q1EVM PCB

l TEXAS INSTRUMENTS @mm @W @W @mm @W @W‘ Copyngm @ 2016. Texas Instruments Inwrpuramd

LOGO

PCB

Texas Instruments

PA043

PCB Number:

PCB Rev:

Label Assembly Note

ZZ1

This Assembly Note is for PCB labels only

PCB Label

LBL1

Size: 0.65" x 0.20 "

Assembly Note

ZZ2

These assemblies are ESD sensitive, ESD precautions shall be observed.

Assembly Note

ZZ3

These assemblies must be clean and free from flux a nd all contaminants. Use of no clean flux is not ac ceptable.

Assembly Note

ZZ4

These assemblies must comply with workmanship stand ards IPC-A-610 Class 2, unless otherwise specified.

Variant/Label Table

Variant Label Text

001 ADS7049-Q1EVM-PDK

LOGO

PCB

Pb-Free Symbol

LOGO

PCB

FCC disclaimer

@H5

RM3X4MM 2701

@H6

RM3X4MM 2701

@H1

1891

@H2

1891

@H3

1891

@H4

1891

PMSSS 440 0025 PH

9774050360R

FID1

DNP

FID2

DNP

FID3

DNP

PCB: PA007A

PHI-EVM-CONTROLLER EDGE # 6591636 Kitting item

Bill of Materials, PCB Layout, and Schematics

www.ti.com

26 SBAU280–November 2016

Submit Documentation Feedback

ADS7049-Q1EVM-PDK

Figure 19. Schematic Diagram (Page 2) of the ADS7049-Q1EVM PCB

STANDARD TERMS AND CONDITIONS FOR EVALUATION MODULES

1. Delivery: TI delivers TI evaluation boards, kits, or modules, including demonstration software, components, and/or documentation

which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms

and conditions set forth herein. Acceptance of the EVM is expressly subject to the following terms and conditions.

1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility

evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not

finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For

clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions

set forth herein but rather shall be subject to the applicable terms and conditions that accompany such Software

1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,

or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production

system.

2Limited Warranty and Related Remedies/Disclaimers:

2.1 These terms and conditions do not apply to Software. The warranty, if any, for Software is covered in the applicable Software

License Agreement.

2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM

to User. Notwithstanding the foregoing, TI shall not be liable for any defects that are caused by neglect, misuse or mistreatment

by an entity other than TI, including improper installation or testing, or for any EVMs that have been altered or modified in any

way by an entity other than TI. Moreover, TI shall not be liable for any defects that result from User's design, specifications or

instructions for such EVMs. Testing and other quality control techniques are used to the extent TI deems necessary or as

mandated by government requirements. TI does not test all parameters of each EVM.

2.3 If any EVM fails to conform to the warranty set forth above, TI's sole liability shall be at its option to repair or replace such EVM,

or credit User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the

warranty period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to

repair or replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall

be warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day

warranty period.

3Regulatory Notices:

3.1 United States

3.1.1 Notice applicable to EVMs not FCC-Approved:

This kit is designed to allow product developers to evaluate electronic components, circuitry, or software associated with the kit

to determine whether to incorporate such items in a finished product and software developers to write software applications for

use with the end product. This kit is not a finished product and when assembled may not be resold or otherwise marketed unless

all required FCC equipment authorizations are first obtained. Operation is subject to the condition that this product not cause

harmful interference to licensed radio stations and that this product accept harmful interference. Unless the assembled kit is

designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must operate under the authority of

an FCC license holder or must secure an experimental authorization under part 5 of this chapter.

3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:

CAUTION

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to

operate the equipment.

FCC Interference Statement for Class A EVM devices

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

SPACER

FCC Interference Statement for Class B EVM devices

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

3.2 Canada

3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210

Concerning EVMs Including Radio Transmitters:

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may

cause undesired operation of the device.

Concernant les EVMs avec appareils radio:

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation

est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit

accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Concerning EVMs Including Detachable Antennas:

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)

gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type

and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for

successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types

listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.

Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited

for use with this device.

Concernant les EVMs avec antennes détachables

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et

d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage

radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope

rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le

présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le

manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne

non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de

l'émetteur

3.3 Japan

3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に

輸入される評価用キット、ボードについては、次のところをご覧ください。

http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page

3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified

by TI as conforming to Technical Regulations of Radio Law of Japan.

If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required by Radio Law of

Japan to follow the instructions below with respect to EVMs:

1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal

Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for

Enforcement of Radio Law of Japan,

2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to

EVMs, or

3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan

with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note

that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.

SPACER

【無線電波を送信する製品の開発キットをお使いになる際の注意事項】開発キットの中には技術基準適合証明を受けて

いないものがあります。技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの

措置を取っていただく必要がありますのでご注意ください。

1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用

いただく。

2. 実験局の免許を取得後ご使用いただく。

3. 技術基準適合証明を取得後ご使用いただく。

なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。

上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。日本テキサス・イ

ンスツルメンツ株式会社

東京都新宿区西新宿６丁目２４番１号

西新宿三井ビル

3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page

電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/

/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page

SPACER

4EVM Use Restrictions and Warnings:

4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT

LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.

4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling

or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information

related to, for example, temperatures and voltages.

4.3 Safety-Related Warnings and Restrictions:

4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user

guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and

customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input

and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or

property damage. If there are questions concerning performance ratings and specifications, User should contact a TI

field representative prior to connecting interface electronics including input power and intended loads. Any loads applied

outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible

permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any

load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.

During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit

components may have elevated case temperatures. These components include but are not limited to linear regulators,

switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the

information in the associated documentation. When working with the EVM, please be aware that the EVM may become

very warm.

4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the

dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.

User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,

affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic

and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely

limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and

liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or

designees.

4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,

state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all

responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and

liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local

requirements.

5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate

as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as

accurate, complete, reliable, current, or error-free.

SPACER

6. Disclaimers:

6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY WRITTEN DESIGN MATERIALS PROVIDED WITH THE EVM (AND THE

DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL FAULTS." TI DISCLAIMS ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT NOT LIMITED TO ANY IMPLIED

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY

THIRD PARTY PATENTS, COPYRIGHTS, TRADE SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.

6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS AND

CONDITIONS SHALL BE CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY

OTHER INDUSTRIAL OR INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD

PARTY, TO USE THE EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY

INVENTION, DISCOVERY OR IMPROVEMENT MADE, CONCEIVED OR ACQUIRED PRIOR TO OR AFTER DELIVERY OF

THE EVM.

7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS

LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,

EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY

HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS AND CONDITIONS. THIS OBLIGATION

SHALL APPLY WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY

OTHER LEGAL THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.

8. Limitations on Damages and Liability:

8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,

INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE

TERMS ANDCONDITIONS OR THE USE OF THE EVMS PROVIDED HEREUNDER, REGARDLESS OF WHETHER TI HAS

BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED

TO, COST OF REMOVAL OR REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS

OR SERVICES, RETESTING, OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS,

LOSS OF SAVINGS, LOSS OF USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL

BE BROUGHT AGAINST TI MORE THAN ONE YEAR AFTER THE RELATED CAUSE OF ACTION HAS OCCURRED.

8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY WARRANTY OR OTHER OBLIGATION

ARISING OUT OF OR IN CONNECTION WITH THESE TERMS AND CONDITIONS, OR ANY USE OF ANY TI EVM

PROVIDED HEREUNDER, EXCEED THE TOTAL AMOUNT PAID TO TI FOR THE PARTICULAR UNITS SOLD UNDER

THESE TERMS AND CONDITIONS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE CLAIMED. THE EXISTENCE

OF MORE THAN ONE CLAIM AGAINST THE PARTICULAR UNITS SOLD TO USER UNDER THESE TERMS AND

CONDITIONS SHALL NOT ENLARGE OR EXTEND THIS LIMIT.

9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)

will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in

a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable

order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),

excluding any postage or packaging costs.

10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,

without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to

these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.

Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief

in any United States or foreign court.

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

spacer

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other

changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest

issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and

complete. All semiconductor products (also referred to herein as “components”) are sold subject to TI’s terms and conditions of sale

supplied at the time of order acknowledgment.

TI warrants performance of its components to the specifications applicable at the time of sale, in accordance with the warranty in TI’s terms

and conditions of sale of semiconductor products. Testing and other quality control techniques are used to the extent TI deems necessary

to support this warranty. Except where mandated by applicable law, testing of all parameters of each component is not necessarily

performed.

TI assumes no liability for applications assistance or the design of Buyers’ products. Buyers are responsible for their products and

applications using TI components. To minimize the risks associated with Buyers’ products and applications, Buyers should provide

adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or

other intellectual property right relating to any combination, machine, or process in which TI components or services are used. Information

published by TI regarding third-party products or services does not constitute a license to use such products or services or a warranty or

endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the

third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of significant portions of TI information in TI data books or data sheets is permissible only if reproduction is without alteration

and is accompanied by all associated warranties, conditions, limitations, and notices. TI is not responsible or liable for such altered

documentation. Information of third parties may be subject to additional restrictions.

Resale of TI components or services with statements different from or beyond the parameters stated by TI for that component or service

voids all express and any implied warranties for the associated TI component or service and is an unfair and deceptive business practice.

TI is not responsible or liable for any such statements.

Buyer acknowledges and agrees that it is solely responsible for compliance with all legal, regulatory and safety-related requirements

concerning its products, and any use of TI components in its applications, notwithstanding any applications-related information or support

that may be provided by TI. Buyer represents and agrees that it has all the necessary expertise to create and implement safeguards which

anticipate dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cause

harm and take appropriate remedial actions. Buyer will fully indemnify TI and its representatives against any damages arising out of the use

of any TI components in safety-critical applications.

In some cases, TI components may be promoted specifically to facilitate safety-related applications. With such components, TI’s goal is to

help enable customers to design and create their own end-product solutions that meet applicable functional safety standards and

requirements. Nonetheless, such components are subject to these terms.

No TI components are authorized for use in FDA Class III (or similar life-critical medical equipment) unless authorized officers of the parties

have executed a special agreement specifically governing such use.

Only those TI components which TI has specifically designated as military grade or “enhanced plastic” are designed and intended for use in

military/aerospace applications or environments. Buyer acknowledges and agrees that any military or aerospace use of TI components

which have not been so designated is solely at the Buyer's risk, and that Buyer is solely responsible for compliance with all legal and

regulatory requirements in connection with such use.

TI has specifically designated certain components as meeting ISO/TS16949 requirements, mainly for automotive use. In any case of use of

non-designated products, TI will not be responsible for any failure to meet ISO/TS16949.

Products Applications

Audio www.ti.com/audio Automotive and Transportation www.ti.com/automotive

Amplifiers amplifier.ti.com Communications and Telecom www.ti.com/communications

Data Converters dataconverter.ti.com Computers and Peripherals www.ti.com/computers

DLP® Products www.dlp.com Consumer Electronics www.ti.com/consumer-apps

DSP dsp.ti.com Energy and Lighting www.ti.com/energy

Clocks and Timers www.ti.com/clocks Industrial www.ti.com/industrial

Interface interface.ti.com Medical www.ti.com/medical

Logic logic.ti.com Security www.ti.com/security

Power Mgmt power.ti.com Space, Avionics and Defense www.ti.com/space-avionics-defense

Microcontrollers microcontroller.ti.com Video and Imaging www.ti.com/video

RFID www.ti-rfid.com

OMAP Applications Processors www.ti.com/omap TI E2E Community e2e.ti.com

Wireless Connectivity www.ti.com/wirelessconnectivity

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

Products related to this Datasheet

EVAL BOARD FOR ADS7049-Q1

ADS7049-Q1EVM-PDK
