2SCR543D
NPN 4.0A 50V Middle Power Transistor
lOutline
lFeatures
1) Suitable for Middle Power Driver
2) Complementary PNP Types : 2SAR543D
3) Low VCE(sat)
VCE(sat)=0.35V(Max.)
(IC/IB=2A/100mA)
4) Lead Free/RoHS Compliant.
lInner circuit
lApplications
Motor driver , LED driver
Power supply
lPackaging specifications
lAbsolute maximum ratings (Ta = 25°C)
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
DC
Pulsed
Junction temperature
Range of storage temperature
*1 Pw=10ms , single pulse
*2 Mounted on a substrate
*3 Tc=25°C
Parameter
Value
CPT3
VCEO
50V
IC
4.0A
Basic
ordering
unit (pcs)
Marking
2SCR543D
CPT3
6595
TL
330
16
2,500
CR543
Part No.
Package
Package
size
(mm)
Taping
code
Reel size
(mm)
Tape width
(mm)
Parameter
Symbol
Values
Unit
VCBO
50
V
VCEO
50
V
VEBO
6
V
Collector current
IC
4.0
A
ICP *1
8.0
A
Power dissipation
PD *2
1
W
PD *3
10
W
Tj
150
°C
Tstg
-55 to +150
°C
2SCR543D
(SC-63)
<SOT-428>
Base
Emitter
Collector
Collector
Base
Emitter
1/6
2013.05 - Rev.B
Not Recommended for
New Designs
hing time testé
hing time
use wxarrWAvssom
museum cunnaq
WAVEORM
0
Pw=50lu
DuwcchEsm
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
Data Sheet
2SCR543D
lElectrical characteristics(Ta = 25°C)
*1 Pulsed
*2 See switching time test circuit
lSwitching time test circuit
